Manufacturer
Sony
Model Number
KD65X75CH
Description
65-inch Class 4k Hdr Led Tv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
(POWER CBA) GL95-STATIC CONVERTER (TV) (UC2) |
|
|
)MAIN CBA) COMPL_SVC_BKR_UC (UC2) |
|
|
BEZEL (2L NCS) A (UC2) |
|
|
BRACKET SIDE (NCS) (UC2) |
|
|
CONNECTOR ASSY 30P (UC2) |
|
|
CONNECTOR ASSY 5P (UC2) (PANEL PART) |
|
|
CUSHION,SUPPORT S-PWB (M PTT) (UC2) (PANEL PART) |
|
|
DIFFUSER PLATE (2L) (UC2) (PANEL PART) |
|
|
FLEXIBLE FLAT CABLE 20P (UC2) |
|
|
FLEXIBLE FLAT CABLE 51P (UC2) |
|
|
FLEXIBLE FLAT CABLE 60P (BM11) (UC2) (PANEL PART) |
|
|
FLEXIBLE FLAT CABLE 60P (UC2) |
|
|
GASKET (5.3X5 (5)), SOFT (UC2) (PANEL PART) |
|
|
GASKET, TCON CN (NCS) (UC2) (PANEL PART) |
|
|
HARNESS ASSY (UC2) |
|
|
HKR-L_CITIZEN MOUNT (UC2) |
|
|
LABEL, UNDER TERMINAL (CPN) (UC2) |
|
|
LIQUID CRYSTAL ELEMENT(C650D02 (UC2) |
|
|
MICROLENS ON PRISM (2L) (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS B (2L GBR) A (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS L (2L GBR) A (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS R (2L GBR) A (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS T (2L GBR) A (UC2) (PANEL PART) |
|
|
MOUNTED PWB E-T-CON (65) (UC2) |
|
|
MOUNTED PWB LS BAR (2L L BAR) (UC2) (PANEL PART) |
|
|
MOUNTED PWB LS BAR (2L R BAR) (UC2) (PANEL PART) |
|
|
MOUNTED PWB LS BAR (GBR 2L L) (UC2) |
|
|
MOUNTED PWB LS BAR (GBR 2L R) (UC2) |
|
|
P-MOD (YSAS065CNS01)(SERVICE) (UC2) |
|
|
POLARIZER F/CF (313050BZ000003) (UC2) (PANEL PART) |
|
|
POLARIZER R/TFT (313050BY000003) (UC2) (PANEL PART) |
|
|
REAR COVER (2L NCS) A (UC2) |
|
|
REFERENCE GUIDE (UC2) |
|
|
REFLECTIVE SHEET (L) (UC2) (PANEL PART) |
|
|
SCREW, +PSW M3X6 (UC2) (PANEL PART) |
|
|
SETUP GUIDE (UC2) |
|
|
SHEET, THERMAL (CCB) (UC2) (PANEL PART) |
|
|
SHEET, THERMAL(BKR) (UC2) |
|
|
SOURCE DRIVER IC MT BOARD (33021000000199) (UC2) (PANEL PART) |
|
|
STAND, NECK (2L RBY) A (UC2) |
|
|
TAPE (3M 1350FB-1)15MMX66M BLK (UC2) (PANEL PART) |
|
|
WLAN/BT MODULE(11AC)/DHUK-SY22 (UC2) |
