Model Image
Manufacturer

Sony

Model Number

KDL46HX850

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-858-711-11 1-858-711-11 SPEAKER BOX ASSY (60MM)
1-910-105-89 1-910-105-89 (LVDS FFC) 3A-G 46 FLEXIBLE FLAT CABLE 51P
1-910-105-64 1-910-105-64 3A-G 46 CONNECTOR ASSEMBLY 28P
1-910-105-65 1-910-105-65 3A-G 46 HARNESS ASSEMBLY
KDL46HX850 46" 2012 SONY TV JIG KDL46HX850
4-299-528-01 4-299-528-01 AC COVER
1-754-820-11 1-754-820-11 ANTENNA
1-754-811-11 1-754-811-11 ANTENNA
4-413-952-01 4-413-952-01 ARM COVER (USES 2)
4-421-111-01 4-421-111-01 BAG SCREW A (G)
A-1875-753-C A-1875-753-C BAPS BOARD
AM4PTB2D AM4PTB2D BATTERY "AAA"
4-299-507-01 4-299-507-01 BRACKET, SIDE (METAL)
4-299-508-01 4-299-508-01 BRACKET, UNDER (METAL)
4-298-305-01 4-298-305-01 CLIP (M)
1-839-679-11 1-839-679-11 CORD, POWER (WITH CONNECTOR)
4-408-119-01 4-408-119-01 CUSHION (PWB G)
4-426-130-01 4-426-130-01 CUSHION, SR (L)
4-426-131-01 4-426-131-01 CUSHION, SR (M)
4-298-303-02 4-298-303-02 FRAME (46), SEL
1-489-986-11 1-489-986-11 FUNCTION SWITCH PCB
1-474-386-11 1-474-386-11 G6 BOARD
A-1865-308-A A-1865-308-A HEM3 BOARD - 3D IR EMITTER BOARD
A-1865-279-A A-1865-279-A HL BOARD - IR BOARD PCB
4-427-915-01 4-427-915-01 LABEL ENERGY GUIDE (3AG)
4-427-910-01 4-427-910-01 LABEL MX ENERGY GUIDE (3AG)
4-400-439-01 4-400-439-01 LABEL, REAR TERMINAL
4-400-428-01 4-400-428-01 LABEL, SIDE TERMINAL
4-400-433-01 4-400-433-01 LABEL, UNDER TERMINAL
A-1869-393-A A-1869-393-A LCD DISPLAY (P-MOD)(FQLR460LT01) - FQLR460LT01)
4-400-645-01 4-400-645-01 REAR COVER A (46 G)
3-299-071-05 3-299-071-05 SAFETY AND REGULATORY BOOKLET
2-990-421-41 2-990-421-41 SCREW (+PSW) (M3X6)
4-256-393-01 4-256-393-01 SCREW, +PSW M3X6 W12
4-400-043-01 4-400-043-01 SCREW, JOINT
4-268-126-02 4-268-126-02 SCREW, ORNAMENTAL M6X12
4-408-435-11 4-408-435-11 SHEET (METAL) SIDE
4-408-577-11 4-408-577-11 SHEET (METAL) UNDER
4-298-212-01 4-298-212-01 SHEET, ANT (G)
4-297-992-01 4-297-992-01 SHEET, INSULATION (G6 46)
4-300-810-01 4-300-810-01 SHEET, THERMAL (ATREYU)
4-298-004-01 4-298-004-01 SPACER (B)
1-858-712-11 1-858-712-11 SPEAKER BOX ASSY (15X90MM)
4-400-785-01 4-400-785-01 STAND BASE
4-400-775-01 4-400-775-01 STAND HEAD
4-400-778-02 4-400-778-02 STAND NECK T. S (46ML)
2-580-608-01 2-580-608-01 STAND SCREW +PSW M5X16 (EACH, USES 6)
4-419-690-01 4-419-690-01 SUPPORT BELT KIT
1-458-353-33 1-458-353-33 WIRELESS LAN CARD
