Model Image
Manufacturer

Sony

Model Number

KDL48R550C

Description

48-inch 1080p Hd 60hz Led Smart Tv

Interactive Exploded View

Parts List

Part Number Description
4-573-962-01 4-573-962-01 48-INCH CF POLARIZER FILM
4-573-963-01 4-573-963-01 48-INCH TFT POLARIZER FILM
1-492-995-12 1-492-995-12 AC ADAPTOR (85W)
A-2071-689-A A-2071-689-A ACCESSORY ASSY LA1 SE2N
A-2071-578-A A-2071-578-A ACCESSORY ASSY UC2 SE2N
4-558-330-01 4-558-330-01 BAG, SCREW ASSY (OWL)
4-566-646-01 4-566-646-01 BEZEL (48 SGL) A
4-565-416-11 4-565-416-11 BRACKET, SIDE (OWL)
4-565-427-01 4-565-427-01 BRACKET, UNDER (OWL)
1-458-751-21 1-458-751-21 CARD, WIRELESS LAN
A-2066-952-C A-2066-952-C COMPL SVC BA_SE2N_ (Main CBA)UC_48F #
1-910-805-35 1-910-805-35 CONNECTOR ASSY 10P
1-846-090-32 1-846-090-32 CORD SET, POWER-SUPPLY
4-548-776-01 4-548-776-01 CUSHION, S-PCB
1-895-825-11 1-895-825-11 DRIVER X COF DATA
1-848-844-12 1-848-844-12 FLEXIBLE FLAT CABLE 51P
1-848-840-12 1-848-840-12 FLEXIBLE FLAT CABLE 5P
1-910-805-31 1-910-805-31 HARNESS ASSY
A-2066-599-A A-2066-599-A HKK(MOUNT)
4-549-627-01 4-549-627-01 LABEL, UNDER TERMINAL
4-566-498-02 4-566-498-02 LIGHT, GUIDE (OWL)
1-812-117-11 1-812-117-11 LIQUID CRYSTAL ELEMENT(S48N02)
1-859-101-11 1-859-101-11 LOUDSPEAKER
4-562-287-31 4-562-287-31 MANUAL, INSTRUCTION
4-562-279-11 4-562-279-11 MANUAL, INSTRUCTION
A-2071-680-A A-2071-680-A PACKING COMMON 48 UC2 SE2N
4-546-313-01 4-546-313-01 PANEL REAR COVER (48 SGL)
4-566-496-01 4-566-496-01 PANEL, ORNAMENTAL (OWL)
4-566-597-01 4-566-597-01 REAR COVER (48SGL) A
4-559-107-01 4-559-107-01 REAR COVER KDL-48R550C
1-492-980-11 1-492-980-11 REMOTE COMMANDER (RMT-TX102U)
2-990-421-41 2-990-421-41 SCREW (+PSW) (M3X6)
4-472-518-01 4-472-518-01 SCREW, +PSW M3X6
4-167-019-22 4-167-019-22 SCREW, +PSW M3X8
2-580-602-01 2-580-602-01 SCREW, +PSW M4X12
4-564-765-01 4-564-765-01 SHEET,THERMAL(5595)
1-492-517-12 1-492-517-12 SWITCH UNIT
7-600-031-96 7-600-031-96 TAPE (3M 1350FB-1)15MMX66M BLK
4-569-140-11 4-569-140-11 TAPE, HS
3-876-036-71 3-876-036-71 UNI-LABEL, BLANK
