Model Image
Manufacturer

Encompass

Model Number

KDL55HX729

Description

55" Class (54.6" Diag) Led Hx729-series I

Interactive Exploded View

Parts List

Part Number Description
14797 14797 40"-70" LED CD PL STAND
A-1825-544-A A-1825-544-A BATL BOARD, COMPLETE
AM4PTB2D AM4PTB2D BATTERY "AAA"
4-266-743-01 4-266-743-01 BEZEL (55 VEG)
1-910-802-00 1-910-802-00 CONNECTOR ASSY 6P
1-857-944-11 1-857-944-11 CONVERTER MT BOARD
4-281-014-01 4-281-014-01 DOUBLE SIDED TAPE (PANEL 10)
1-838-816-11 1-838-816-11 FLEXIBLE FLAT CABLE Y3 55S
1-474-303-11 1-474-303-11 G6 BOARD COMPLETE
1-474-305-11 1-474-305-11 G7 BOARD COMPLETE
1-895-031-11 1-895-031-11 GATE DRIVER IC MT BOARD
1-910-802-23 1-910-802-23 HARNESS ASSY
4-188-302-11 4-188-302-11 HEXAGON WRENCH
A-1806-495-A A-1806-495-A HMS3_B MOUNT
4-291-833-11 4-291-833-11 LABEL
4-265-028-01 4-265-028-01 LABEL (BATV REAR)
4-259-186-02 4-259-186-02 NECK (L9)
1-838-797-11 1-838-797-11 POWER-SUPPLY CORD (WITH CON
A-1836-750-B A-1836-750-B PYL SERVICE(Y3-55)
4-268-007-32 4-268-007-32 REAR COVER (55 CAS )A
4-268-007-31 4-268-007-31 REAR COVER (55 CAS) A
1-489-473-11 1-489-473-11 REMOTE CONTROL RMYD061
3-299-071-05 3-299-071-05 SAFETY AND REGULATORY BOOKLET
2-580-608-01 2-580-608-01 SCREW +PSW M5X16 SCREW WITH
4-268-443-01 4-268-443-01 SHEET INSULATION (G4)
4-268-445-01 4-268-445-01 SHEET INSULATION (G7)
1-895-038-12 1-895-038-12 SOURCE DRIVER IC MT BOARD
4-269-895-01 4-269-895-01 STAND BASE A (L1)
4-269-894-02 4-269-894-02 STAND BASE A(L1)
4-269-895-02 4-269-895-02 STAND BASE A(LL1)
1-489-443-11 1-489-443-11 SWITCH UNIT
4-259-541-02 4-259-541-02 USER SCREW ST
1-458-355-11 1-458-355-11 WIRELESS LAN CARD
