Model Image
Manufacturer

Sony

Model Number

KDL60W610B

Description

60-inch Led Hdtv

Interactive Exploded View

Parts List

Part Number Description
1-848-330-11 1-848-330-11 (LVDS) FLEXIBLE FLAT CABLE 51P
4-299-531-01 4-299-531-01 AC COVER
AM4PTB2D AM4PTB2D BATTERY "AAA"
A-2037-764-A A-2037-764-A BAXL BOARD COMPLETE
4-530-895-03 4-530-895-03 BEZEL
4-528-972-03 4-528-972-03 BRACKET, SIDE
4-528-973-01 4-528-973-01 BRACKET, UNDER
4-437-710-21 4-437-710-21 BRACKET, VESA
X-2589-601-1 X-2589-601-1 CARTON ASSY (PLU 60)
4-262-708-03 4-262-708-03 CLAMPER, CABLE
1-910-804-73 1-910-804-73 CONNECTOR ASSEMBLY 30P
1-910-804-75 1-910-804-75 CONNECTOR ASSEMBLY 4P
4-529-163-01 4-529-163-01 COVER, OP LEFT
4-529-164-01 4-529-164-01 COVER, OP RIGHT
4-531-206-11 4-531-206-11 CUSHION LOWER (2L PLU)
4-534-601-11 4-534-601-11 CUSHIONUPP L(2L PLU)
4-534-602-11 4-534-602-11 CUSHIONUPP R(2L PLU)
1-474-586-11 1-474-586-11 GL2 BOARD, COMPLETE
1-910-804-74 1-910-804-74 HARNESS ASSEMBLY
4-484-999-51 4-484-999-51 LABEL , UNDER TERMINAL
4-537-410-11 4-537-410-11 MANUAL, INSTRUCTION (ENGLISH VERSION)
4-591-311-11 4-591-311-11 MANUAL, INSTRUCTIONS (UC2)
4-476-156-11 4-476-156-11 PANEL, ORNAMENTAL
1-839-679-11 1-839-679-11 POWER SUPPLY CORD
1-492-767-21 1-492-767-21 REMOTE COMMANDER (RM-YD103)
2-580-639-01 2-580-639-01 SCREW +BVTP2 4X12
2-990-421-41 2-990-421-41 SCREW, (+PSW) (M3X6)
4-449-743-01 4-449-743-01 SCREW- STAND TO LCD TV M5X16
4-529-156-01 4-529-156-01 SHEET, INSULATION
4-440-057-01 4-440-057-01 SHEET, THERMAL
4-488-201-01 4-488-201-01 SPACER (T)
1-858-963-11 1-858-963-11 SPEAKER BOX (LEFT)
1-858-963-21 1-858-963-21 SPEAKER BOX (RIGHT)
4-531-504-01 4-531-504-01 STAND BASE
4-529-162-01 4-529-162-01 STAND BRACKET
4-530-894-02 4-530-894-02 STAND SUPPORT
3-674-673-22 3-674-673-22 STOPPER (A)
4-443-737-02 4-443-737-02 SUPPORT BELT KIT
1-798-510-11 1-798-510-11 SWITCH UNIT
4-531-208-11 4-531-208-11 TRAY (2L PLU)
1-458-865-11 1-458-865-11 WIRELESS LAN CARD
1-458-918-11 1-458-918-11 WLAN MODULE (UC2)
