Model Image
Manufacturer

Sony

Model Number

KV24FS100

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-249-441-11 1-249-441-11 1/4W 100K , RESISTOR
1-249-429-11 1-249-429-11 1/6W 1.0K CAR RES
1-249-417-11 1-249-417-11 1/6W 1.0K CAR RES
1-164-315-11 1-164-315-11 C351
1-117-813-11 1-117-813-11 C511 0.75F 5% 250V
1-130-777-00 1-130-777-00 C643
8-719-108-12 8-719-108-12 D234 D235 D236
6-501-299-01 6-501-299-01 D505
8-719-510-53 8-719-510-53 D605
8-719-302-43 8-719-302-43 D611 DIODE EL1Z-V1
8-719-979-63 8-719-979-63 D618
8-719-063-70 8-719-063-70 D631
1-453-310-11 1-453-310-11 FBT ASSEMBLY NX-4521//X4
6-705-810-01 6-705-810-01 IC
6-704-607-01 6-704-607-01 IC002
8-759-701-01 8-759-701-01 IC3
8-759-700-44 8-759-700-44 IC565 NJM2902M-TE2
8-749-017-76 8-749-017-76 IC604
8-759-450-47 8-759-450-47 IC608
8-759-445-59 8-759-445-59 IC633 BA033T
1-451-552-11 1-451-552-11 NECK ASSEMB
8-749-010-64 8-749-010-64 PHOTO COUPLER PC123F
8-729-422-33 8-729-422-33 Q006
8-729-053-36 8-729-053-36 Q600, 601
8-729-200-90 8-729-200-90 Q604
8-729-922-37 8-729-922-37 Q608
1-216-853-11 1-216-853-11 R352
1-215-919-11 1-215-919-11 R503
1-215-885-00 1-215-885-00 R515
1-205-998-11 1-205-998-11 R601
1-202-961-11 1-202-961-11 R602
1-215-481-00 1-215-481-00 R627 R629 R630
1-260-131-11 1-260-131-11 R628 R612
1-260-289-51 1-260-289-51 R640
1-249-393-11 1-249-393-11 R658,R659
1-477-119-22 1-477-119-22 REMOTE CONTROL , SILVER/GRAY (RM-Y173)
1-243-979-11 1-243-979-11 RES, OXIDE METAL FILM 0.1
1-249-377-11 1-249-377-11 RESISTOR 824
1-762-816-11 1-762-816-11 S007, S008
1-692-431-21 1-692-431-21 SWITCH
1-810-974-21 1-810-974-21 VDR600
