Model Image
Manufacturer

Sony

Model Number

KVGENE

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-408-401-00 1-408-401-00 2.2UH,(LF-8S) MICRO INDUC
8-729-301-32 8-729-301-32 2SC1413A,TRANSISTOR
8-729-178-63 8-729-178-63 2SC1674 TRANSISTOR
8-729-306-92 8-729-306-92 2SD669D,TRANSISTOR
1-107-929-11 1-107-929-11 63V 10MF ELECT CAPACITOR
1-417-170-11 1-417-170-11 ANTENNA SELECTOR
1-141-181-11 1-141-181-11 CAPACITOR,TRIMER
1-408-969-21 1-408-969-21 COIL
1-506-371-00 1-506-371-00 CONNECTOR 2P
1-555-110-00 1-555-110-00 CORD CABLE PIN-PLUG
X-4330-305-2 X-4330-305-2 CRT BRACKET
8-750-822-00 8-750-822-00 CX-082F IC
8-750-000-35 8-750-000-35 CX-753 IC
8-719-312-71 8-719-312-71 DIODE
8-719-109-75 8-719-109-75 DIODE
8-719-109-54 8-719-109-54 DIODE
8-719-200-02 8-719-200-02 DIODE
8-719-118-33 8-719-118-33 DIODE
8-719-110-31 8-719-110-31 DIODE EQB01-12
8-719-104-10 8-719-104-10 DIODE IS2198
8-719-064-30 8-719-064-30 DIODE IT264M-30
8-719-949-46 8-719-949-46 DIODE IT6-4
8-719-200-50 8-719-200-50 DIODE SK1W52
8-719-911-55 8-719-911-55 DIODE U05G
8-719-931-08 8-719-931-08 DIODE,EQBO1-08
8-719-160-26 8-719-160-26 EQB01-06,DIODE
8-719-300-33 8-719-300-33 ERC24-06S,DIODE
8-719-928-08 8-719-928-08 ERD28-04,DIODE
3-703-730-12 3-703-730-12 IBM BAG
8-759-940-42 8-759-940-42 IC
1-421-225-00 1-421-225-00 LINE FILTER COIL
4-048-133-01 4-048-133-01 MAGNET, PERMALLOY CHIP (B
1-408-971-21 1-408-971-21 MICRO 12H
1-408-964-21 1-408-964-21 MICRO 3.30H
1-408-987-21 1-408-987-21 MICRO 330H
1-408-981-21 1-408-981-21 MICRO INDUCTOR
1-408-604-31 1-408-604-31 MICRO INDUCTOR 12UH (LF-8
1-408-424-00 1-408-424-00 MICRO INDUCTOR LF-8S
1-410-469-41 1-410-469-41 MICRO INDUCTOR,LF-8S
1-408-403-00 1-408-403-00 MICRO INDUCTOR,LF-8S
1-408-605-31 1-408-605-31 MICRO INDUCTORLF-85
1-506-348-99 1-506-348-99 PLUG 3P
1-237-523-21 1-237-523-21 RESISTOR CARBON 470K
1-237-515-21 1-237-515-21 RESISTOR, ADJUSTABLE
T-9980-226-1 T-9980-226-1 RM-703
3-662-365-01 3-662-365-01 SHAFT, DOOR
8-729-382-62 8-729-382-62 TRANSISTOR 2SC1826
8-729-238-32 8-729-238-32 TRANSISTOR 2SD667
8-719-900-95 8-719-900-95 V09G,DIODE
