Manufacturer
Sony
Model Number
MDX100
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BRACKET (IC) |
|
|
BRACKET (REAR) |
|
|
BUTTON (EJECT) |
|
|
BUTTON (MD) |
|
|
BUTTON (OFF) |
|
|
BUTTON (V/A) |
|
|
CAP, ELECT 220MF |
|
|
CAP, ELECT 47MF |
|
|
CAPACITOR,CHIP FILM .0039 |
|
|
CAPACITOR,ELECT 22MF 10V |
|
|
CAPACITOR,ELECT 470MF 10V |
|
|
CAPACITOR,ELECT 47MF |
|
|
CAPACITOR,POLYESTER FILM |
|
|
CHASSIS ASSY |
|
|
COIL, CHIP CHOKE 10UH |
|
|
COLLAR |
|
|
CUSHION (FAN) |
|
|
DIODE MA8039-L-TX |
|
|
DIODE MA8110-M |
|
|
DIODE MA8160 |
|
|
FILTER (COVER) |
|
|
HEAT SINK |
|
|
HEAT SINK (D) |
|
|
HOLDER (LCD) |
|
|
IC M62008FP-T1 |
|
|
IC MSM6665-04GS-K |
|
|
LAMP, PILOT |
|
|
LED CL-155Y/PG-D-T-YL |
|
|
MOTOR, FAN |
|
|
NETWORK, RESISTOR(CHIP TY |
|
|
PANEL ASSY, BACK |
|
|
PANEL, SUB |
|
|
PLATE (LCD), LIGHT GUIDE |
|
|
PLATE (MOTOR), SHIELD |
|
|
PLUG,CONNECTOR |
|
|
RES, CHIP 2.2 |
|
|
RES, CHIP 470 |
|
|
RESISTOR,CHIP 1.3K 1/16W( |
|
|
RESISTOR,NETWORK (CHIP)22 |
|
|
RETAINER FOR FLEXIBLE BOA |
|
|
SCREW (2X13.5), ? |
|
|
SHEET (REFLECTOR) |
|
|
SOUNDER, VOLTAGE |
|
|
SPACER (KEY) |
|
|
SPACER (KEY) |
|
|
SPACER (LCD) |
|
|
SPRING (FITTING) |
|
|
THERMISTOR NTH5G39B223K01 |
|
|
THERMISTOR NTH5G40B333K01 |
|
|
TRANSISTOR 2SB1386-T100-R |
