Model Image
Manufacturer

Sony

Model Number

PCGTR3AP3U

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
X-4625-889-5 X-4625-889-5 ASSY (PALMREST)
1-162-964-61 1-162-964-61 CAP, CHIP CERAMIC 1000PF
1-456-314-11 1-456-314-11 COIL, CHOKE 0.56UH
1-419-939-21 1-419-939-21 COIL, CHOKE 4.7UH
1-815-830-21 1-815-830-21 CONNECTOR, FPC (ZIF) 14P
1-400-200-21 1-400-200-21 FERRITE, EMI (SMD)
6-704-293-01 6-704-293-01 IC AN12944A-VB
6-804-023-01 6-804-023-01 IC ICS950812CGLF
6-700-262-01 6-700-262-01 IC NJM2870F45(TE2)
8-759-649-47 8-759-649-47 IC SN74AHC1G14DCKR
1-414-957-21 1-414-957-21 INDUCTOR 3.9NH (1608)
4-682-150-21 4-682-150-21 LABEL ID
4-682-150-01 4-682-150-01 LABEL ID
1-439-983-11 1-439-983-11 MAGNETIC MODULE
4-681-839-01 4-681-839-01 QUICK START,2970 LA
1-208-944-81 1-208-944-81 RES, CHIP 240K (
1-216-793-81 1-216-793-81 RES, CHIP 4.7 (
1-234-800-21 1-234-800-21 RES, CHIP NETWORK 56X8 (
1-245-534-11 1-245-534-11 RES, METAL PLATE CHIP 0.0
1-220-749-21 1-220-749-21 RES, SQUARE TYPE CHIP 0.0
1-208-869-11 1-208-869-11 RESISTOR CHIP 180 (1005)
1-216-198-91 1-216-198-91 RESISTOR, CHIP 1.0K 1/8W
1-239-671-81 1-239-671-81 RESISTOR, NETWORK 56
1-786-510-11 1-786-510-11 SWITCH, REED
4-673-367-02 4-673-367-02 THERMAL SHEET(CPU)
1-804-668-21 1-804-668-21 THERMISTOR, POSITIVE
6-550-636-01 6-550-636-01 TRANSISTOR HN1C05FE-B(TPL
6-550-615-01 6-550-615-01 TRANSISTOR SI4925BDY-T1
6-550-064-01 6-550-064-01 TRANSISTOR SI5404DC-T1
1-795-958-21 1-795-958-21 VIBRATOR, CRYSTAL
1-795-916-21 1-795-916-21 VIBRATOR, CRYSTAL
