Manufacturer

Sony

Model Number

PMW100

Description

Xdcam Hd422 Handheld Camcorder

Interactive Exploded View

Parts List

Part Number	Description
7-600-000-48	ADHESIVE AGENT(SC608LVZ2)180ML
X-2585-288-1	ASSY BRACKET LENS(R)
A-1881-999-A	ASSY IO-252
X-2584-461-3	AU COVER SUB ASSEMBLY
X-2584-461-5	AU COVER SUB ASSY
X-2584-461-4	AU COVER SUB ASSY
3-704-293-01	BAG (STANDARD), PROTECTION
A-1881-601-C	BATTERY CASE SUB ASSY
4-427-934-02	BATTERY LID
1-482-012-11	BEADS, FERRITE
4-275-256-02	BELT, GRIP
4-428-129-03	BEZEL, LCD
J-6325-110-A	BIT FOR TORQUE DRIVER (M1.4)
J-6325-380-A	BIT FOR TORQUE DRIVER (M2)
1-480-457-41	BLOCK, AU VOLUME
X-2584-460-1	BRACKET (A) ASSY, SWITCH
4-427-965-01	BRACKET (L), LENS
4-427-936-02	BRACKET AU
4-428-366-01	BRACKET BNC
4-428-366-02	BRACKET BNC
4-427-937-02	BRACKET HDMI
4-427-938-01	BRACKET USB
4-428-156-02	BRACKET, MICROPHONE
4-428-155-02	BRACKET, MICROPHONE (FRONT)
4-410-288-01	BUTTON, REC
3-288-567-21	CABINET (B), PANEL HINGE
3-288-566-22	CABINET (T), PANEL HINGE
X-2584-439-2	CABINET ASSY, HANDLE (REAR)
X-2584-440-2	CABINET ASSY, MICROPHONE
4-428-130-03	CABINET LCD
A-2042-726-A	CABLE (3) ASSY, ISP CONVERSION
1-837-302-11	CABLE ASSEMBLY, COAXIAL
1-846-056-21	CABLE, FLEXIBLE FLAT (10 CORE)
X-2584-487-1	CAP ASSY
1-112-777-11	CAP, CERAMIC 0.01MF X7R 1005
1-114-569-11	CAP, CERAMIC 0.01MF X7R 1608
1-114-570-11	CAP, CERAMIC 0.068MF X7R 1608
1-100-916-11	CAP, CERAMIC 0.1MF X7R 1005
1-118-361-11	CAP, CERAMIC 0.1MF X7R 1608
1-114-325-11	CAP, CERAMIC 0.1MF X7R 1608
1-116-857-91	CAP, CERAMIC 0.22MF B (2012)
1-118-290-11	CAP, CERAMIC 1000PF B (1608)
1-114-419-21	CAP, CERAMIC 10MF B (2012)
1-112-815-91	CAP, CERAMIC 10MF C (1608)
1-100-909-11	CAP, CERAMIC 10MF X6S 2012
1-116-737-11	CAP, CERAMIC 1MF X5R 1005
1-114-130-11	CAP, CERAMIC 1MF X6S 1005
1-112-717-91	CAP, CERAMIC 1UF B (1005)
1-114-813-11	CAP, CERAMIC 1UF X7R 1608
1-100-436-91	CAP, CERAMIC 33000PF B (1608)
1-112-300-91	CAP, CERAMIC 4.7MF B (2012)
1-114-331-11	CAP, CERAMIC 4.7MF X7R 2012
1-112-776-11	CAP, CERAMIC 4700PF X7R 1005
1-114-798-11	CAP, CERAMIC 560PF X7R 1005
1-100-415-11	CAP, CHIP CERAMIC 0.47MF(1005)
1-100-703-91	CAP, CHIP CERAMIC 10MF B(3225)
1-114-831-91	CAP, CHIP CERAMIC 1MFX7R(3216)
1-114-726-11	CAP, CHIP CERAMIC 27MF B 3216
1-128-991-21	CAP, ELECT 10MF (5.3X5.5)
4-130-262-01	CAP, FRONT
2-635-118-01	CAP, LENS
1-112-066-11	CAP,CERAMIC 10UF X7R 3216
1-112-064-11	CAP,CERAMIC 2.2UF X7R 2012
1-107-819-11	CAP,CERAMIC 22000PF/16V(1005)
1-100-567-81	CAP,CHIP CERAMIC 0.01MF B 1005
1-164-880-81	CAP,CHIP CERAMIC 180PF CH 1005
1-125-777-11	CAPACITOR CERAMIC 0.1MF/10V
1-112-298-91	CAPACITOR CERAMIC 1MF B (1608)
1-100-591-91	CAPACITOR CERAMIC 1MF B2012
1-114-728-91	CAPACITOR CERAMIC 22MF B 3216
1-112-746-11	CAPACITOR CERAMIC 4.7MF B 1608
1-100-880-91	CAPACITOR CERAMIC100MF C(3225)
1-100-881-91	CAPACITOR CERAMIC47MF C(3216)
1-114-582-11	CAPACITOR, CERAMIC 0.1MF B1005
1-112-863-91	CAPACITOR, CERAMIC 0.22MF B
1-165-989-11	CAPACITOR, CERAMIC 10MF (2012)
1-165-884-91	CAPACITOR, CERAMIC 2.2MF(1608)
1-100-597-91	CAPACITOR, CHIP 0.1MF B 1608
1-100-672-11	CAPACITOR, CHIP CERAMIC 10MF
1-100-670-11	CAPACITOR, CHIP CERAMIC 4.7MF
1-112-015-91	CAPACITOR, CHIP CERAMIC 47MF B
1-116-100-11	CAPACITOR, ELECT 220MF 105
1-112-918-11	CAPACITOR, NIOBIUM ELECT 100MF
1-114-548-11	CAPACITOR, NIOBIUM ELECT 22UF
1-114-817-11	CAPACITOR,CER 2.2UF X7R 50V
1-114-870-11	CAPACITOR,CER4.7MF X6S 16V
1-127-715-11	CAPACITOR,CERAMIC 0.22MF B1608
1-112-021-91	CAPACITOR,CERAMIC 2.2MFF(1608)
1-164-882-11	CAPACITOR,CERAMIC 220PF/16V CH
1-100-611-91	CAPACITOR,CERAMIC 22MF C(2012)
1-164-858-11	CAPACITOR,CERAMIC 22PF/50V
1-164-934-11	CAPACITOR,CERAMIC 330PF/50V B
1-117-743-11	CAPACITOR,CERAMIC 5.0PF CH1005
1-112-692-11	CAPACITOR,CERAMIC1000PF CH1005
1-119-923-11	CAPACITOR,CHIP CERAMIC 0.047MF
1-164-937-11	CAPACITOR,CHIP CERAMIC 1000PF
1-164-874-11	CAPACITOR,CHIP CERAMIC 100PF
1-164-850-11	CAPACITOR,CHIP CERAMIC 10PF/50
1-164-852-11	CAPACITOR,CHIP CERAMIC 12PF/50
1-164-854-11	CAPACITOR,CHIP CERAMIC 15PF/50
1-164-939-11	CAPACITOR,CHIP CERAMIC 2200PF
1-164-935-11	CAPACITOR,CHIP CERAMIC 470PF
1-164-866-11	CAPACITOR,CHIP CERAMIC 47PF/50
1-164-848-11	CAPACITOR,CHIP CERAMIC 8PF/50V
1-114-214-81	CAPACITOR,CHIP CERAMIC470PF
1-124-779-00	CAPACITOR,ELECT 10MF/16V
1-126-405-11	CAPACITOR,ELECT 10MF/50V(CHIP
1-127-772-11	CAPACTOR C,CERAMIC 33000PF B
X-2584-438-4	CASE ASSY, HANDLE (UPPER)
4-428-045-01	CASE, EVF FRONT
4-428-044-02	CASE, EVF REAR
4-428-154-01	CASE, MICROPHON
4-425-718-07	CD-ROM (INSTRUCTION MANUAL)
4-425-718-06	CD-ROM (INSTRUCTION MANUAL)
4-425-718-05	CD-ROM (INSTRUCTION MANUAL)
4-425-718-02	CD-ROM (INSTRUCTION MANUAL)
4-425-718-08	CD-ROM (INSTRUCTION MANUAL)
1-114-329-11	CERAMIC CHIP 0.47 UF 10% 50V
1-114-335-11	CERAMIC CHIP 22UF 10% 16V
1-100-581-81	CHIP CERAMIC0.0047MF B1005
1-535-757-11	CHIP, CHECKER (CONNECTOR)
1-535-877-22	CHIP,CHECKER (TEST POINT)
1-576-122-21	CIRCUIT PROTECTOR 0.4A(IC LINK
1-482-017-11	CLAMP, FERRITE
4-430-771-02	CN GUARD
4-430-771-01	CN GUARD
1-428-965-11	COIL, CHOKE (SMD)
1-456-046-21	COIL, CHOKE (SMD) 10UH (10X10)
1-457-144-21	COIL, CHOKE (SMD) 4.7UH(10X10)
1-457-372-21	COIL, CHOKE 1UH
1-460-358-11	COIL, CHOKE 2.2UH (4018)
1-416-436-11	COIL, CHOKE 68UH
1-456-799-11	COIL, COMMON MODE CHOKE
1-813-308-11	COMMON MODE FILTER (SMD)
4-427-939-02	CONDUCTIVE TAPE(EC)
1-218-990-81	CONDUCTOR, CHIP (1005)
1-216-864-91	CONDUCTOR, CHIP(1608)
1-764-243-11	CONNECTOR (COAXIAL)
9-910-999-34	CONNECTOR (MULTIPLE)
1-818-513-11	CONNECTOR (SQUARE TYPE)(USB)5P
1-784-254-11	CONNECTOR 10P
1-817-820-11	CONNECTOR, BOARD TO BOARD 30P
1-766-380-11	CONNECTOR, COAXIAL (BNC TIPE)
1-820-806-21	CONNECTOR, COAXIAL(RECEPTACLE)
1-821-530-12	CONNECTOR, EX CARD (HOST)
1-821-531-14	CONNECTOR, EX CARD(GUIDE UNIT)
1-821-531-15	CONNECTOR, EX CARD(GUIDE UNIT)
1-822-883-61	CONNECTOR, FFC/FPC (ZIF) 22P
1-573-915-71	CONNECTOR, FFC/FPC (ZIF) 6P
1-815-597-31	CONNECTOR, FFC/FPC (ZIF) AN 6P
1-844-939-11	CONNECTOR, FFC/FPC (ZIF) ST 10
1-779-327-51	CONNECTOR, FFC/FPC 6P
1-778-645-31	CONNECTOR, FFC/FPC(ZIF) AN 10P
1-785-840-31	CONNECTOR, FFC/FPC(ZIF) AN 15P
1-774-260-31	CONNECTOR, FFC/FPC(ZIF) AN 20P
1-778-646-31	CONNECTOR, FFC/FPC(ZIF) ST 10P
1-822-910-11	CONNECTOR, FPC (LIF(NON-ZIF))
1-820-857-81	CONNECTOR, FPC (ZIF) 51P
1-842-522-21	CONNECTOR, FPC (ZIF) 61P
1-843-070-61	CONNECTOR, FPC(LIF (NON-ZIF))
1-794-099-14	CONNECTOR, ROUND TYPE
1-794-276-21	CONNECTOR, SQUARE TYPE 4P
1-780-152-11	CONTACT, ON-BOARD
1-784-240-11	CONVERTER, COAXIAL CONNECTOR
1-757-562-11	CORD SET, POWER
1-831-553-11	CORD, CONNECTION (AV MULTIPLE)
1-848-676-42	CORD, CONNECTION (USB 5P)
1-482-034-11	CORE, FERRITE
X-2584-442-2	COVER ASSY, HINGE (FRONT)
X-2584-432-2	COVER ASSY, ZOOM SEESAW
4-427-940-01	COVER USER TAP
4-428-985-01	COVER, AU VOLUME
4-428-050-02	COVER, EVF
4-428-048-01	COVER, EVF DIAL
4-428-161-01	COVER, HP JACK
4-428-160-03	COVER, XLR
4-428-161-02	COVER,HP JACK
3-284-075-02	COVER,MICROPHONE HOLDER RUBBER
4-427-941-01	CUSHION CONNECTOR(MAIN)
4-428-128-01	CUSHION, PANEL
6-503-185-01	DI DSR520,H3SONYF
6-503-474-01	DI SML-J13RWT96
8-719-820-41	DIODE 1SS302
8-719-024-71	DIODE 1SS362-TE85L
8-719-056-48	DIODE 1SS388(TPL3)
8-719-083-15	DIODE 1SS389(TPH3)
8-719-069-28	DIODE 1SS400TE61
8-719-085-26	DIODE CL-165HR/SYG-D-T
8-719-084-43	DIODE CL-196HR-CD-T
8-719-989-00	DIODE DA221
8-719-989-03	DIODE DAN222-TL
8-719-065-59	DIODE MBR0530T1
6-500-750-01	DIODE NSAD500H-T1-AT
8-719-072-43	DIODE RB050L-40TE25
6-500-864-01	DIODE RB050LA-40TR
6-501-361-01	DIODE RB051LA-40TR
6-501-123-01	DIODE RB160M-60TR
8-719-989-08	DIODE RB717F
8-719-083-61	DIODE UDZSTE-1711B
6-500-694-01	DIODE UDZSTE-172.4B
6-500-695-01	DIODE UDZSTE-172.7B
8-719-083-60	DIODE UDZSTE-174.7B
1-400-826-21	EMI FERRITE (SMD) (1005)
1-400-382-21	EMI FERRITE (SMD) (1608)
X-2584-450-3	ESCUTCHEON ASSY, SXS
1-802-245-11	ESD SUPPRESSOR
4-459-383-01	EYE CUP (LARGE)
4-428-049-02	EYE CUP, EVF
1-500-921-11	FERRITE CORE
1-416-976-11	FERRITE, EMI (SMD)
1-414-445-11	FERRITE, EMI (SMD)
1-400-580-21	FERRITE, EMI (SMD)
1-400-462-21	FERRITE, EMI (SMD) (1005)
1-400-461-21	FERRITE, EMI (SMD) (1005)
1-469-100-21	FERRITE, EMI (SMD) (1608)
1-414-864-11	FERRITE, EMI (SMD) (1608)
1-469-324-21	FERRITE, EMI (SMD) (2012)
7-600-015-27	FILM,EPOXY (SUPER #10)10MMX55M
1-856-421-11	FILTER BLOCK, OPTICAL
1-781-494-11	FILTER, EMI
1-239-898-22	FILTER, EMI (SMD)
1-239-896-22	FILTER, EMI (SMD)
1-239-895-12	FILTER, EMI (SMD)
1-234-939-21	FILTER, EMI REMOVAL (SMD)
X-2188-609-1	FIXED (759) ASSEMBLY
3-278-317-02	FPC GUIDE
4-428-150-03	FR-CABINET, HANDLE
4-428-150-02	FR-CABINET,HANDLE
4-428-262-11	FRONT FRAME
4-428-262-02	FRONT FRAME
X-2584-449-1	FRONT PANEL SUB ASSY
1-576-329-11	FUSE CHIP 10A/125V (6125)
4-428-811-01	GASKET (C), MAIN
4-428-812-01	GASKET (D), MAIN
4-428-813-01	GASKET (E), MAIN
4-433-494-01	GASKET (F), MAIN
4-433-494-02	GASKET (F), MAIN
4-427-942-01	GASKET MAIN A
4-427-942-02	GASKET MAIN A
4-427-943-01	GASKET MAIN B
4-435-865-02	GASKET(G), MAIN
4-435-865-01	GASKET(G),MAIN
4-435-866-01	GASKET(H), MAIN
4-435-867-01	GASKET(J), MAIN
J-6394-080-A	GRAY SCALE CHART (16:9)
4-428-158-02	GRILLE, MICROPHONE
2-178-566-01	GRILLE, SPEAKER
4-428-157-01	GRIP
4-486-736-01	GUARD (S), CN
4-428-167-34	HANDLE
4-428-167-12	HANDLE
4-428-167-33	HANDLE
4-428-167-35	HANDLE
A-1885-649-A	HANDLE ASSEMBLY //C
A-1885-649-B	HANDLE ASSY //C
A-1885-649-C	HANDLE ASSY //C
1-968-348-12	HARNESS (DR-HN)
1-968-340-11	HARNESS(DCP-BI283)
1-968-343-11	HARNESS(DCP-KSW)
1-968-346-11	HARNESS(DPR-EC/SWC)
1-968-341-11	HARNESS(LCD-KSW)
4-427-944-01	HEAT SPREADER DCP
J-6326-120-A	HEXAGON BIT(FOR TORQUE DRIVER)
X-2342-571-1	HINGE (TYPE 07KAI) ASSEMBLY, PANEL
X-2515-729-3	HINGE ASSEMBLY
X-2515-729-2	HINGE ASSEMBLY
X-2342-570-5	HOLDER (93000) ASSEMBLY,MICROPHONE
4-427-947-01	HOLDER EC HARNESS B
4-428-046-01	HOLDER, EVF
4-428-046-02	HOLDER, EVF
4-428-047-01	HOLDER, EVF PC BOARD
4-428-047-02	HOLDER, EVF PC BOARD
4-119-279-01	HOLDER, FLEXIBLE
1-756-991-21	HOLDER, LITHIUM BATTERY (CR203
3-678-684-00	HOLDER,CABLE
X-2187-866-1	HOOD ASSEMBLY
4-164-063-01	HOOD, SQUARE
8-759-561-46	IC AD8014ART-REEL7
6-707-997-01	IC ADV7320KSTZ
6-714-316-01	IC ADV7541BCBZ-P-1R
6-718-169-01	IC AK5358BET2-E2
6-708-882-01	IC BH18MA3WHFV-TR
6-706-640-01	IC BH25FB1WG-TR
6-808-503-01	IC BU24130GU-E2
6-712-342-01	IC CDCVF2310PWR
8-753-276-37	IC CXD3195AGG-T6
6-714-628-02	IC EPM3032ATC44-RE271-V11
6-714-561-01	IC FMS4A16LCH-60AER
6-714-589-01	IC FMS8B16LBH-60AER
6-715-475-01	IC FW32207T100-DT
8-749-016-83	IC GP1S092HCPIF
6-711-915-01	IC LM73CIMK-0
6-712-902-01	IC LMH1980MM
6-706-220-01	IC LTC3411EMS#TR
6-713-169-01	IC LTC3412AEFE#TR
6-716-459-01	IC M24256-BWMN6TP
6-701-652-01	IC MAX4374TEUB+TG069
6-703-223-01	IC MAX668EUB+T
6-711-947-01	IC MM1431CURE
6-708-371-01	IC MP1580HS-LF-Z
6-708-889-01	IC MP2105DJ-LF-Z
6-717-739-01	IC MT47H128M16RT-25E
6-710-533-01	IC NJM2878F4-28(TE2)
8-759-338-95	IC NJM2903V (TE2)
8-759-278-58	IC NJM4558V (TE2)
8-759-710-28	IC NJM4565M-A
6-703-858-01	IC NJU7042F(TE1)
6-714-067-01	IC PCA9555DB-T
6-703-976-01	IC R1114Q181D-TR-FA
6-703-977-01	IC R1114Q331D-TR-FA
6-716-760-01	IC R2J30503LG
6-704-643-01	IC R3112N221A-TR-FA
6-702-955-01	IC R3112N251A-TR-FE
6-701-946-01	IC R3112N271A-TR-FE
6-702-879-01	IC R3112N281A-TR-FA
6-600-681-01	IC RS-770N
6-702-948-01	IC SN74AUC1G08DCKR
6-703-848-01	IC SN74CB3T3306DCUR
6-707-843-01	IC TC74LCX125FT(EKJ)
6-711-467-01	IC TC74LCX138FK(EL,K)
6-711-485-01	IC TC74VCX125FK(EL)
6-711-488-01	IC TC74VCX157FK(EL)
6-711-497-01	IC TC74VCX541FK(EL)
6-707-872-01	IC TC74VHC221AFT(EKJ)
6-710-710-01	IC TC7PA19AFE(T5RSOYF
6-701-917-01	IC TC7PA34FU(TE85R)
6-710-861-01	IC TC7SET34FU(T5RSONF
6-706-484-01	IC TC7SH04FU(T5RSOYJF)
6-706-487-01	IC TC7SH08FU(T5RSOYJF)
6-710-786-01	IC TC7SH125FU(T5RSOYF
6-709-861-01	IC TC7SH126FU
6-706-488-01	IC TC7SH14FU(T5RSOYJF)
6-706-489-01	IC TC7SH32FU(T5RSOYJF)
6-712-373-01	IC TC7SH34FU
6-715-036-01	IC TC7SZ04FU,RSONYJ
6-715-039-01	IC TC7SZ08FU,RSONYJ
6-715-041-01	IC TC7SZ125FU,RSOYJ
6-715-042-01	IC TC7SZ126FU,RSOYJ
6-700-217-01	IC TC7SZ14FU(TE85R)
6-715-031-01	IC TC7SZ14FU,RSONYJ
8-759-675-54	IC TC7W53FK-TE85R
8-759-680-48	IC TC7WH157FK(TE85R)
8-759-655-22	IC TC7WH34FK(TE85R)
6-704-099-01	IC TC7WZ08FK(TE85R)
6-700-831-01	IC TC7WZ74FK(TE85R)
6-709-646-01	IC TLC2933AIPWR
8-759-462-09	IC TLV431AIDBVR
6-711-654-01	IC TPS5420DRG4
6-712-939-01	IC TPS715A01DRBR
8-759-111-56	IC UPC4572G2
9-910-999-UU	INDIVIDUAL CARTON
1-412-979-21	INDUCTOR (SMALL TYPE)
1-412-987-31	INDUCTOR (SMALL TYPE) 4.70UH
1-414-398-11	INDUCTOR (SMD) 10UH
1-414-406-11	INDUCTOR (SMD) 220UH
1-400-135-11	INDUCTOR 1UH
1-400-870-21	INDUCTOR 2.2UH
1-469-845-11	INDUCTOR 4.7UH
1-414-400-11	INDUCTOR, 22UH
1-469-549-21	INDUCTOR, CHIP 1.0UH (LB2016)
1-469-555-21	INDUCTOR, CHIP 10UH (LB2016)
1-481-581-21	INDUCTOR, CHIP 2.2UH
1-469-551-21	INDUCTOR, CHIP 2.2UH (LB2016)
1-481-585-21	INDUCTOR, CHIP 4.7UH
1-469-553-21	INDUCTOR, CHIP 4.7UH (LB2016)
1-469-559-21	INDUCTOR, CHIP 47UH (LB2016)
1-412-983-31	INDUCTOR, SMALL TYPE 2.2UH
1-414-772-11	INDUCTOR,MICRO(CHIP TYPE) 2012
1-794-525-12	JACK, MIC
1-793-459-11	JACK,DC(POLARITY UNIFIED TYPE)
J-6082-563-C	JIG FOR FLANGE BACK ADJUSTMENT
X-2584-437-1	KNOB ASSY, ZOOM SELECTION
3-870-012-02	LABEL (HD1500), XDCAM
A-1885-650-C	LCD ASSEMBLY //C
A-1885-650-B	LCD ASSY //C
1-811-647-12	LCD MODULE
8-719-063-83	LED SML-510MWT86
4-164-060-01	LENS (MAIN), W
A-1889-914-A	LENS ASSY(RP) (WITH MOUNT)
4-428-318-02	LEVER, SXS LOCK
X-2584-458-5	LID ASSEMBLY, SXS
X-2584-458-6	LID ASSEMBLY, SXS
X-2584-458-7	LID ASSY, SXS
X-2584-458-4	LID ASSY, SXS
1-858-774-12	LOUDSPEAKER (2.0 CM)
A-1990-817-A	M.C.B, (RP), DU-659
A-1900-750-A	M.C.B, DCP-62 COMPL-NC
A-1935-968-A	M.C.B, RE-315 COMPL-NC
9-910-999-40	M.C.B. DCP-55 COMPLE-NC
A-1869-400-B	M.C.B. DPR-339 COMPLE-NC
A-1869-162-A	M.C.B. RE-298 COMPLE-NC
A-1965-085-A	M.C.B. RE-298(C) (COMPL-NC)
A-1935-967-A	M.C.B. RE-314 COMPL-NC
1-471-514-11	MAGNET (LM-FH30)
4-427-948-11	MAIN FRAME
9-910-999-SM	MANUAL, INSTRUCTION
4-425-716-02	MANUAL, INSTRUCTION
4-425-716-04	MANUAL, INSTRUCTION
4-425-716-05	MANUAL, INSTRUCTION
4-425-716-06	MANUAL, INSTRUCTION
4-425-716-07	MANUAL, INSTRUCTION
4-425-716-12	MANUAL, INSTRUCTION
4-425-716-13	MANUAL, INSTRUCTION
4-425-716-14	MANUAL, INSTRUCTION
NSI	MANUAL, INSTRUCTION
4-425-716-16	MANUAL, INSTRUCTION
4-425-716-17	MANUAL, INSTRUCTION
1-542-862-11	MICROPHONE UNIT
A-1864-808-B	MOUNTED C.BOARD, AU-342
A-1864-826-A	MOUNTED C.BOARD, AXM-46
A-1864-810-A	MOUNTED C.BOARD, DC-160
A-1864-832-A	MOUNTED C.BOARD, DET-54
A-1919-945-A	MOUNTED C.BOARD, DPR-339
A-1923-807-A	MOUNTED C.BOARD, DPR-339 COMPL
A-1864-838-A	MOUNTED C.BOARD, DR-669
A-1864-809-A	MOUNTED C.BOARD, EC-73
A-1864-825-A	MOUNTED C.BOARD, FP-175
A-1864-828-A	MOUNTED C.BOARD, HN-384
A-1864-834-A	MOUNTED C.BOARD, HN-385
A-1864-824-A	MOUNTED C.BOARD, HN-386
A-1864-817-A	MOUNTED C.BOARD, HN-387
A-1864-818-A	MOUNTED C.BOARD, HN-388
A-1864-819-A	MOUNTED C.BOARD, HN-389
A-1864-833-A	MOUNTED C.BOARD, HN-390
A-1864-829-A	MOUNTED C.BOARD, IF-1182
A-1870-880-A	MOUNTED C.BOARD, IFC-15
A-1864-821-A	MOUNTED C.BOARD, IO-252
A-1864-830-B	MOUNTED C.BOARD, KSW-60
A-1866-574-A	MOUNTED C.BOARD, LE-383
A-1864-816-A	MOUNTED C.BOARD, PSW-97
A-1864-827-B	MOUNTED C.BOARD, RM-235
A-1864-835-A	MOUNTED C.BOARD, SE-1107
A-1864-831-A	MOUNTED C.BOARD, SW-1540
A-1864-836-A	MOUNTED C.BOARD, SW-1541
A-1864-837-A	MOUNTED C.BOARD, SW-1545
A-1864-822-A	MOUNTED C.BOARD, SWC-53
3-061-234-02	NUT (M6X0.5)
3-061-234-01	NUT (M6X0.5)
1-813-285-12	OSCILLATOR, CRYSTAL
1-813-264-11	OSCILLATOR, CRYSTAL
1-795-983-11	OSCILLATOR, CRYSTAL
1-795-671-12	OSCILLATOR, CRYSTAL
1-795-670-12	OSCILLATOR, CRYSTAL
1-813-942-11	OSCILLATOR, CRYSTAL 27MHZ
1-814-063-11	OSCILLATOR, CRYSTAL 54MHZ
X-2584-441-5	PANEL ASSEMBLY, CONTROL
X-2187-983-1	PANEL ASSEMBLY, F
X-2584-441-6	PANEL ASSY, CONTROL
X-2584-441-7	PANEL ASSY, CONTROL
X-2584-456-6	PANEL SUB ASSEMBLY, INSIDE
X-2584-456-5	PANEL SUB ASSY, INSIDE
X-2584-456-7	PANEL SUB ASSY, INSIDE
X-2584-456-9	PANEL SUB ASSY, INSIDE
X-2584-430-4	PANEL SUB ASSY, OUTSIDE
4-427-935-03	PANEL, BOTTOM
4-427-911-01	PANEL, OUTSIDE FRONT
J-6029-140-B	PATTERN BOX
3-669-481-08	PIN (DIA.1X8), PARALLEL
1-816-463-11	PIN, CONNECTOR (PC BOARD)
1-764-250-11	PIN, CONNECTOR (PC BOARD) 4P
1-774-297-21	PIN, CONNECTOR (PC BOARD) 7P
1-764-080-21	PIN, CONNECTOR (PC BOARD) 8P
1-794-375-11	PIN, CONNECTOR 2P
1-794-376-11	PIN, CONNECTOR 4P
1-817-054-21	PIN, CONNECTOR 6P
1-750-005-11	PIN,CONNECTOR 4P
4-428-165-01	PLATE LCD GROUND
4-428-300-02	PLATE, AU HOLD
4-428-367-01	PLATE, BNC GND
4-428-367-02	PLATE, BNC GND
4-429-227-01	PLATE, LCD SHIELD
4-429-228-01	PLATE, PANEL GROUND
4-427-949-02	RADIATION SHEET A
4-427-950-02	RADIATION SHEET B
4-427-951-02	RADIATION SHEET C
4-427-952-02	RADIATION SHEET D
4-427-953-02	RADIATION SHEET E
4-427-954-02	RADIATION SHEET F
4-427-956-02	RADIATION SHEET H
4-427-955-02	RADIATION_SHEET_G
X-2584-455-4	REAR PANEL ASSY
1-479-570-14	REMOTE COMMANDER (RM-F300)
1-208-889-11	RES, CHIP 1.2K (1005)
1-220-874-11	RES, CHIP 15 (1005)
1-208-691-11	RES, CHIP 2.2K (1005)
1-208-871-81	RES, CHIP 220 (1005)
1-208-874-11	RES, CHIP 300 (1005)
1-208-876-81	RES, CHIP 360 (1005)
1-250-471-11	RES, METAL FILM CHIP 100(1005)
1-250-519-11	RES, METAL FILM CHIP 10K(1005)
1-250-475-11	RES, METAL FILM CHIP 150(1005)
1-250-523-11	RES, METAL FILM CHIP 15K(1005)
1-250-527-11	RES, METAL FILM CHIP 22K(1005)
1-250-531-11	RES, METAL FILM CHIP 33K(1005)
1-250-487-11	RES, METAL FILM CHIP 470(1005)
1-250-535-11	RES, METAL FILM CHIP 47K(1005)
1-234-381-21	RES, NETWORK 100KX4 (1005)
1-234-378-21	RES, NETWORK 10KX4 (1005)
1-234-370-11	RES, NETWORK 22X4 (1005)
1-234-377-21	RES, NETWORK 4.7KX4 (1005)
1-234-371-11	RES, NETWORK 47X4 (1005)
1-250-495-11	RES,METAL FILM CHIP 1.0K(1005)
1-250-543-11	RES,METAL FILM CHIP 100K(1005)
1-250-547-11	RES,METAL FILM CHIP 150K(1005)
1-250-503-11	RES,METAL FILM CHIP 2.2K(1005)
1-250-551-11	RES,METAL FILM CHIP 220K(1005)
1-250-507-11	RES,METAL FILM CHIP 3.3K(1005)
1-250-511-11	RES,METAL FILM CHIP 4.7K(1005)
1-250-559-11	RES,METAL FILM CHIP 470K(1005)
1-250-515-11	RES,METAL FILM CHIP 6.8K(1005)
1-208-687-11	RESISTOR CHIP 1.5K 1/16W (1005
1-208-635-11	RESISTOR CHIP 10 1/16W (1005)
1-208-661-11	RESISTOR CHIP 120 1/16W (1005)
1-208-709-11	RESISTOR CHIP 12K 1/16W (1005)
1-208-663-11	RESISTOR CHIP 150 1/16W (1005)
1-208-711-11	RESISTOR CHIP 15K 1/16W (1005)
1-208-712-11	RESISTOR CHIP 16K 1/16W (1005)
1-208-941-11	RESISTOR CHIP 180K
1-208-683-11	RESISTOR CHIP 1K 1/16W (1005)
1-208-643-11	RESISTOR CHIP 22 1/16W (1005)
1-208-943-11	RESISTOR CHIP 220K
1-218-982-11	RESISTOR CHIP 270K 1/16W(1005)
1-218-970-11	RESISTOR CHIP 27K 1/16W (1005)
1-208-695-11	RESISTOR CHIP 3.3K 1/16W(1005)
1-208-697-11	RESISTOR CHIP 3.9K 1/16W(1005)
1-208-647-11	RESISTOR CHIP 33 1/16W (1005)
1-208-671-11	RESISTOR CHIP 330 1/16W (1005)
1-208-947-11	RESISTOR CHIP 330K 1/16W(1005)
1-208-649-11	RESISTOR CHIP 39 1/16W (1005)
1-218-948-11	RESISTOR CHIP 390 1/16W (1005)
1-208-721-11	RESISTOR CHIP 39K 1/16W (1005)
1-208-698-11	RESISTOR CHIP 4.4H 1/16W(1005)
1-208-675-11	RESISTOR CHIP 470 1/16W (1005)
1-218-985-11	RESISTOR CHIP 470K 1/16W(1005)
1-208-652-11	RESISTOR CHIP 51 1/16W (1005)
1-208-677-11	RESISTOR CHIP 560 1/16W (1005)
1-220-168-11	RESISTOR CHIP 62
1-208-883-81	RESISTOR CHIP 680 (1005)
1-208-955-11	RESISTOR CHIP 680K
1-220-169-11	RESISTOR CHIP 75 1/16W (1005)
1-219-611-21	RESISTOR, CHIP 0.047 1W
1-219-706-11	RESISTOR, CHIP 0.10/1W
1-208-893-11	RESISTOR, CHIP 1.8K (1005)
1-208-935-11	RESISTOR, CHIP 100K (1005)
1-208-707-11	RESISTOR, CHIP 10K (1005)
1-218-965-11	RESISTOR, CHIP 10K 1/16W
1-208-939-11	RESISTOR, CHIP 150K (1005)
1-218-847-11	RESISTOR, CHIP 1K 1/10W (1608)
1-218-959-11	RESISTOR, CHIP 3.3K
1-218-947-11	RESISTOR, CHIP 330 1/16W
1-208-923-11	RESISTOR, CHIP 33K (1005)
1-218-961-11	RESISTOR, CHIP 4.7K 1/16W
1-208-927-11	RESISTOR, CHIP 47K 1/16W(1005)
1-220-179-11	RESISTOR, CHIP 510 1/16W(1005)
1-208-930-11	RESISTOR, CHIP 62K (1005)
1-208-859-81	RESISTOR, CHIP 68 (1005)
1-208-931-11	RESISTOR, CHIP 68K (1005)
1-234-383-11	RESISTOR, NETWORK 470KX4(1005)
1-234-380-21	RESISTOR, NETWORK 47K (1005X4)
1-240-247-11	RESISTOR, SQUARE TYPE CHIP 0.1
1-211-899-11	RESISTOR,CHIP 0.22 1/4W (3225)
1-218-823-11	RESISTOR,CHIP 100 1/10W (1608)
1-218-941-81	RESISTOR,CHIP 100 1/16W (1005)
1-218-871-11	RESISTOR,CHIP 10K 1/10W (1608)
1-218-989-11	RESISTOR,CHIP 1M 1/16W (1005)
1-208-894-11	RESISTOR,CHIP 2.0K 1/16W(1005)
1-218-957-11	RESISTOR,CHIP 2.2K 1/16W(1005)
1-218-958-11	RESISTOR,CHIP 2.7K 1/16W(1005)
1-216-801-11	RESISTOR,CHIP 22 1/10W (1608)
1-218-879-11	RESISTOR,CHIP 22K 1/10W (1608)
1-208-715-81	RESISTOR,CHIP 22K 1/16W (1005)
1-208-873-11	RESISTOR,CHIP 270 1/16W (1005)
1-208-699-11	RESISTOR,CHIP 4.7K 1/16W(1005)
1-211-985-11	RESISTOR,CHIP 47 1/10W (1608)
1-208-855-81	RESISTOR,CHIP 47 1/16W (1005)
1-218-864-11	RESISTOR,CHIP 5.1K 1/10W(1608)
1-218-938-11	RESISTOR,CHIP 56 1/16W (1005)
1-218-867-11	RESISTOR,CHIP 6.8K 1/10W(1608)
1-208-703-11	RESISTOR,CHIP 6.8K 1/16W(1005)
1-211-990-11	RESISTOR,CHIP 75 1/10W (1608)
1-208-909-11	RESISTOR,CHIP 8.2K 1/16W(1005)
1-208-910-11	RESISTOR,CHIP 9.1K (1005)
1-208-862-11	RESISTOR,CHIP 91 (1005)
1-220-803-81	RESISTOR,CHIP4.7 1/16W (1005)
7-624-198-21	RETAINER RING, TYPE C 10DIA
4-428-406-03	RETAINER, AU SHAFT
4-428-407-01	RETAINER, LID SHAFT
4-428-134-02	RETAINER, PANEL
4-428-134-01	RETAINER,PANEL
X-2584-901-2	RING ASSY, F
2-698-010-01	RUBBER (1190), SEAL
4-119-861-01	RUBBER (93000), HOLDER
3-284-080-01	RUBBER, MICROPHONE
4-474-981-01	SCREEN, LCD PROTECTION
4-428-166-01	SCREEN, SPEAKER
4-428-159-01	SCREEN, WIND
3-989-735-51	SCREW (M1.7X3), LOCK ACE, P2
3-968-729-53	SCREW (M2), LOCK ACE, P2
3-968-729-52	SCREW (M2), LOCK ACE, P2
3-056-233-21	SCREW (M2), LOCK ACE, P2
3-080-203-42	SCREW (M2), NEW TRUSTER, P2
3-056-233-22	SCREW (M2), NEW TRUSTER, P2
7-627-551-27	SCREW +P1.4X2.5(EP-FE/CU,NI,CR
7-685-135-19	SCREW +PTP2.6X10(EP-FE/ZNBK/CM
7-685-134-19	SCREW +PTP2.6X8(EP-FE/ZNBK/CM2
3-080-204-31	SCREW(1.7X6),TAPPING,P2
2-630-005-31	SCREW(ECO)NEW TRUSTER,P2
2-635-562-31	SCREW(M1.7)
2-599-475-31	SCREW(M1.7)
4-432-184-01	SCREW(M2),NEW TRUSTER,P2
2-630-005-01	SCREW(M2),NEW TRUSTER,P2
3-080-203-41	SCREW(M2X5),LOCK ACE,P2
3-080-206-51	SCREW, TAPPING, P2
3-080-206-21	SCREW, TAPPING, P2
3-080-204-11	SCREW, TAPPING, P2
7-627-556-58	SCREW,PRECISION +P2.6X5
A-1885-653-B	SEESAW ASSY, ZOOM //C
1-487-653-11	SENSOR, ANGULAR VELOCITY
9-968-937-01	SERVICE MANUAL
4-428-399-01	SHEET (IN), WATERPROOF
4-427-905-01	SHEET (ZOOM L), WATERPROOF
4-435-962-01	SHEET BI 6X6
4-435-696-01	SHEET BI 7X17
4-435-697-01	SHEET BI 7X20
4-428-756-01	SHEET BI CUPPER
4-431-622-01	SHEET BI RADI
4-432-461-01	SHEET RADIATION 20X20
4-432-462-01	SHEET RADIATION 30X30
4-432-463-01	SHEET RADIATION 40X40
4-576-583-01	SHEET, COVER
3-284-081-11	SHEET, RUBBER ADHESIVE
3-069-286-04	SHOE, ACCESSORY
3-288-538-11	SHOE, REAR (COLD)
3-278-903-02	SHOULDER BELT
1-400-833-21	SMD EMI FERRITE
A-1881-989-A	SONY PART
8-848-898-01	SONY PART
4-433-453-01	SPACER, BOTTOM
4-428-365-01	SPACER, V-OUT
4-428-162-01	SPEAKER HOLDER
4-428-408-01	SPRING, HELICAL TORSION COIL
3-288-615-03	SPRING, SHOE
1-968-347-11	SUB HARNESS (AU-IFC)
1-968-344-11	SUB HARNESS (EXT DC-RE299)
1-968-342-11	SUB HARNESS (LE-IFC)
1-968-345-11	SUB HARNESS (PSW-RE298)
1-968-339-11	SUB HARNESS (REVERSE-KSW)
4-435-386-01	SW CONDUCTIVITY SHEET
4-428-409-01	SW INSULATING SHEET A
4-428-410-01	SW INSULATING SHEET B
4-428-411-01	SW INSULATING SHEET C
1-480-298-11	SWITCH BLOCK, CONTROL(GZ92000)
1-489-348-12	SWITCH BLOCK, CONTROL(RS40000)
4-428-312-06	SWITCH, AU SLIDE
1-786-180-11	SWITCH, PUSH (1KEY)
1-771-025-41	SWITCH, ROTARY (ENCODER)
1-771-487-11	SWITCH, SLIDE
1-771-140-21	SWITCH, SLIDE
1-786-806-13	SWITCH, TACT (WITH LED)
1-786-157-31	SWITCH, TACTILE
1-571-787-31	SWITCH, TACTILE
1-570-985-21	SWITCH, TOGGLE
1-554-088-41	SWITCH,KEY BOARD
1-572-922-11	SWITCH,SLIDE (1-1-2)
1-692-605-11	SWITCH,SLIDE (1-1-3)
3-278-255-01	TAPE (BT)
3-878-657-01	TAPE 50
3-878-656-01	TAPE 60
4-432-464-01	TAPE ADHESION 40X40
4-433-495-01	TAPE, DCP CONDUCTIVE
4-433-496-01	TAPE, FP CONDUCTIVE
4-428-814-01	TAPE, HN CONDUCTIVE
4-435-868-02	TAPE, LCD CONDUCTIVE
4-435-868-01	TAPE, LCD CONDUCTIVE
1-780-112-21	TERMINAL, CONTACT
1-803-615-11	THERMISTOR, POSITIVE
1-771-845-11	THERMISTOR, POSITIVE
X-2584-469-1	TOP PANEL ASSY
J-6325-400-A	TORQUE DRIVER (3KG)
J-6252-510-A	TORQUE DRIVER 6KG-CM
6-552-430-01	TR DRC5114E0L
6-552-542-01	TR RRR030P03TL
6-552-077-01	TR RUE003N02TL
6-552-624-01	TR SI2301CDS-T1-GE3
6-552-642-01	TR SI2304DDS-T1-GE3
6-552-022-01	TR SI4436DY-T1-E3
6-552-801-01	TR SI7114DN-T1-GE3
8-729-105-08	TRANSISTOR 2SA1330-06
8-729-026-53	TRANSISTOR 2SA1576A-T106-QR
8-729-928-19	TRANSISTOR 2SA1774R
6-550-232-01	TRANSISTOR 2SA2029T2LQ/R
8-729-271-31	TRANSISTOR 2SC2713-G
8-729-202-38	TRANSISTOR 2SC3326N-A
8-729-117-73	TRANSISTOR 2SC4178-F14
6-550-545-01	TRANSISTOR 2SC4617FTLQ
6-550-632-01	TRANSISTOR 2SC4672-T100-Q
8-729-928-55	TRANSISTOR DTA123JE-TL
8-729-928-28	TRANSISTOR DTA144EE-TL
6-550-239-01	TRANSISTOR DTA144EMT2L
8-729-928-91	TRANSISTOR DTC114EE-TL
8-729-929-27	TRANSISTOR DTC114TE-TL
8-729-929-08	TRANSISTOR DTC123JE-TL
8-729-928-82	TRANSISTOR DTC144EE-TL
6-550-119-01	TRANSISTOR DTC144EMT2L
6-551-090-01	TRANSISTOR FET HAT1125H-EL-E
8-729-054-35	TRANSISTOR HAT2070R-EL
6-551-294-01	TRANSISTOR MCH6606-TL-E
6-550-981-01	TRANSISTOR RN1905(TE85R.F)
6-551-041-01	TRANSISTOR RN4904(T5RSONY,D,F)
4-428-375-01	USB COVER
1-803-974-11	VARISTOR, CHIP
1-803-742-11	VARISTOR, CHIP
1-801-925-11	VARISTOR, CHIP
1-813-828-21	VIBRATOR, CRYSTAL
1-813-826-21	VIBRATOR, CRYSTAL
1-813-345-21	VIBRATOR, CRYSTAL
1-813-052-21	VIBRATOR, CRYSTAL
1-813-049-21	VIBRATOR, CRYSTAL
1-781-913-22	VIBRATOR, CRYSTAL
7-688-001-02	WASHER (2)(EP-FE/ZNBK/CM2)
7-688-002-02	WASHER (2.6)(EP-FE/ZNBK/CM2)
4-428-368-01	WASHER, BNC COAXIAL FIXED
4-119-234-21	WASHER, TRIPOD
4-119-234-11	WASHER, TRIPOD
4-428-163-05	XLR SW KNOB
4-428-164-01	XLR SW RALL
