Model Image
Manufacturer

Sony

Model Number

PXWX180

Description

Full Hd Xdcam Handheld Camcorder

Interactive Exploded View

Parts List

Part Number Description
1-492-994-23 1-492-994-23 AC ADAPTOR (60W) (ACDP-060S02)
1-492-994-24 1-492-994-24 AC ADAPTOR (60W) (ACDP-060S02)
1-492-994-22 1-492-994-22 AC ADAPTOR (60W) (ACDP-060S02)
1-492-511-31 1-492-511-31 AC ADAPTOR (60W) ACDP-060S01
1-492-994-32 1-492-994-32 AC ADAPTOR (60W) ACDP-060S01
1-400-704-21 1-400-704-21 ARR FERRITE CHIP
3-701-622-00 3-701-622-00 BAG, POLYETHYLENE (150X200)
4-540-555-01 4-540-555-01 BASE, FN
1-756-128-11 1-756-128-11 BATTERY, LITHIUM (SECONDARY)
1-009-118-11 1-009-118-11 BATTERY, LITHIUM (SECONDARY)
1-756-128-15 1-756-128-15 BATTERY, LITHIUM (SECONDARY)
1-500-919-21 1-500-919-21 BEAD, FERRITE
1-400-331-11 1-400-331-11 BEAD, FERRITE
1-400-632-21 1-400-632-21 BEAD, FERRITE (1005)
1-481-516-11 1-481-516-11 BEAD, FERRITE (1608)
2-178-804-03 2-178-804-03 BELT, GRIP
2-178-804-02 2-178-804-02 BELT, GRIP
A-2063-702-B A-2063-702-B BOARD, WM COMPLETE PC(RP)
4-165-327-01 4-165-327-01 BRACKET (FRONT), GRIP BELT
4-540-586-01 4-540-586-01 BRACKET (GP)
4-461-957-01 4-461-957-01 BRACKET (REAR)
4-165-331-01 4-165-331-01 BRACKET (REAR), GRIP BELT
4-540-585-01 4-540-585-01 BRACKET (UPPER)
4-165-279-01 4-165-279-01 BRACKET, XL
X-2596-805-1 X-2596-805-1 BUTTON, AUTO ASSEMBLY (SERVICE)
4-165-373-11 4-165-373-11 BUTTON, CONTROL
4-460-849-01 4-460-849-01 BUTTON, IRIS PUSH
4-540-614-01 4-540-614-01 BUTTON, WB
1-216-827-11 1-216-827-11 C-RES,U 3.3K-1/16W J
6-550-316-01 6-550-316-01 C-TR,2SB792A(RS)
A-2063-029-A A-2063-029-A CAB(G) ASSY 94100 (SERVICE)
A-2063-042-B A-2063-042-B CAB(R) ASSY 94100 (SERVICE)
X-2588-892-1 X-2588-892-1 CABINET (93600) ASSEMBLY, (UPPER)
X-2589-887-1 X-2589-887-1 CABINET (BM) ASSY
4-460-896-22 4-460-896-22 CABINET (C), P
4-460-896-21 4-460-896-21 CABINET (C), P
4-460-886-01 4-460-886-01 CABINET (FRONT), HANDLE
X-2590-147-1 X-2590-147-1 CABINET (G) (TOP) ASSY
X-2589-958-1 X-2589-958-1 CABINET (G) (TOP) ASSY
X-2589-897-2 X-2589-897-2 CABINET (L) ASSY
4-540-593-02 4-540-593-02 CABINET (MI)
4-540-593-01 4-540-593-01 CABINET (MI)
X-2589-890-1 X-2589-890-1 CABINET ASSY, JK
A-2066-043-A A-2066-043-A CABINET BLOCK ASSY (SERVICE)
X-2589-893-1 X-2589-893-1 CABINET(SIDE (941)) ASSY
4-460-850-01 4-460-850-01 CABINET, DUCT
4-540-596-02 4-540-596-02 CABINET, VF
1-848-676-32 1-848-676-32 CABLE, CONNECTION
1-848-676-31 1-848-676-31 CABLE, CONNECTION
1-846-004-11 1-846-004-11 CABLE, FLEXIBLE FLAT (FFC-1002
1-835-025-11 1-835-025-11 CABLE, FLEXIBLE FLAT (FFC-167)
1-836-006-11 1-836-006-11 CABLE, FLEXIBLE FLAT (FFC-172)
1-834-804-11 1-834-804-11 CABLE, FLEXIBLE FLAT (FFC-332)
1-834-810-11 1-834-810-11 CABLE, FLEXIBLE FLAT (FFC-339)
1-118-168-11 1-118-168-11 CAP CERAMIC 1UF X5R (0603)
1-118-459-11 1-118-459-11 CAP, CERAMIC 0.01MF X5R 1005
1-114-569-11 1-114-569-11 CAP, CERAMIC 0.01MF X7R 1608
1-118-033-11 1-118-033-11 CAP, CERAMIC 0.047MF X5R(0603)
1-118-388-11 1-118-388-11 CAP, CERAMIC 0.047MF X7R 1005
1-114-570-11 1-114-570-11 CAP, CERAMIC 0.068MF X7R 1608
1-118-035-11 1-118-035-11 CAP, CERAMIC 0.1MF X5R (1005)
1-118-458-11 1-118-458-11 CAP, CERAMIC 0.1MF X5R 0603
1-118-417-11 1-118-417-11 CAP, CERAMIC 0.1MF X5R 1005
1-114-367-11 1-114-367-11 CAP, CERAMIC 0.1MF X6S 1005
1-118-391-11 1-118-391-11 CAP, CERAMIC 0.1MF X7R 1005
1-118-361-11 1-118-361-11 CAP, CERAMIC 0.1MF X7R 1608
1-118-037-11 1-118-037-11 CAP, CERAMIC 0.22MF X5R (1608)
1-118-042-11 1-118-042-11 CAP, CERAMIC 0.22MF X5R (2012)
1-116-741-11 1-116-741-11 CAP, CERAMIC 0.47MF X5R 1005
1-118-403-11 1-118-403-11 CAP, CERAMIC 1000PF X7R 1005
1-116-704-11 1-116-704-11 CAP, CERAMIC 100MF X5R 3216
1-116-865-11 1-116-865-11 CAP, CERAMIC 10MF (3216)
1-118-047-11 1-118-047-11 CAP, CERAMIC 10MF X5R (2012)
1-116-715-11 1-116-715-11 CAP, CERAMIC 10MF X7R 3225
1-118-401-11 1-118-401-11 CAP, CERAMIC 1500PF 50V
1-118-039-11 1-118-039-11 CAP, CERAMIC 1MF X5R (1608)
1-118-462-11 1-118-462-11 CAP, CERAMIC 1MF X5R 1005
1-116-737-11 1-116-737-11 CAP, CERAMIC 1MF X5R 1005
1-116-734-11 1-116-734-11 CAP, CERAMIC 1MF X5R 1608
1-116-738-11 1-116-738-11 CAP, CERAMIC 1MF X6S 1005
1-116-735-11 1-116-735-11 CAP, CERAMIC 1MF X7R 1608
1-112-717-91 1-112-717-91 CAP, CERAMIC 1UF B (1005)
1-118-040-11 1-118-040-11 CAP, CERAMIC 2.2MF X5R (1608)
1-118-048-11 1-118-048-11 CAP, CERAMIC 2.2MF X5R (3216)
1-118-477-11 1-118-477-11 CAP, CERAMIC 2.2MF X5R 1005
1-116-732-11 1-116-732-11 CAP, CERAMIC 2.2MF X5R 1005
1-116-729-11 1-116-729-11 CAP, CERAMIC 2.2MF X5R 1608
1-118-399-11 1-118-399-11 CAP, CERAMIC 2200PF X7R 1005
1-118-412-11 1-118-412-11 CAP, CERAMIC 220PF X7R 1005
1-116-713-11 1-116-713-11 CAP, CERAMIC 22MF X5R 2012
1-116-711-11 1-116-711-11 CAP, CERAMIC 22MF X5R 3216
1-116-709-11 1-116-709-11 CAP, CERAMIC 22MF X5R 3225
1-116-714-11 1-116-714-11 CAP, CERAMIC 22MF X6S 2012
1-127-991-91 1-127-991-91 CAP, CERAMIC 2PF CK (0603)
1-118-397-11 1-118-397-11 CAP, CERAMIC 3300PF X7R 1005
1-118-410-11 1-118-410-11 CAP, CERAMIC 330PF X5R 1005
1-118-041-11 1-118-041-11 CAP, CERAMIC 4.7MF X5R (1608)
1-118-480-11 1-118-480-11 CAP, CERAMIC 4.7MF X5R 1608
1-116-724-11 1-116-724-11 CAP, CERAMIC 4.7MF X5R 1608
1-118-465-11 1-118-465-11 CAP, CERAMIC 4.7MF X5R 2012
1-118-395-11 1-118-395-11 CAP, CERAMIC 4700PF X7R 1005
1-116-707-11 1-116-707-11 CAP, CERAMIC 47MF X5R 3216
1-116-506-91 1-116-506-91 CAP, CERAMIC 47UF X5R (2012)
1-127-995-91 1-127-995-91 CAP, CERAMIC 5PF CH (0603)
1-116-350-21 1-116-350-21 CAP, CHIP CERAMIC 47UF B 2012
1-114-410-21 1-114-410-21 CAP, CHIP CERAMIC 680PF CH1005
1-118-390-11 1-118-390-11 CAP,CER 0.015MF X7R 1005 25V
1-118-389-11 1-118-389-11 CAP,CER 0.022MF X7R 1005 25V
1-118-387-11 1-118-387-11 CAP,CER 0.068MF X7R 1005 16V
1-118-407-11 1-118-407-11 CAP,CER 470PF X7R 1005 50V
1-118-269-11 1-118-269-11 CAP,CERAMIC4.7UFX5R(1106)
1-164-880-81 1-164-880-81 CAP,CHIP CERAMIC 180PF CH 1005
1-116-173-91 1-116-173-91 CAP,CHIP CERAMIC 2200PF CH1608
1-112-746-11 1-112-746-11 CAPACITOR CERAMIC 4.7MF B 1608
1-165-989-11 1-165-989-11 CAPACITOR, CERAMIC 10MF (2012)
1-112-197-91 1-112-197-91 CAPACITOR, CERAMIC 10PF CH
1-114-098-91 1-114-098-91 CAPACITOR, CERAMIC 2.2MF C
1-116-720-11 1-116-720-11 CAPACITOR,10MF X5R 1608 6.3V
1-128-607-11 1-128-607-11 CAPACITOR,CERAMIC 18PF CH(0603
1-164-856-11 1-164-856-11 CAPACITOR,CERAMIC 18PF/50V1005
1-164-882-11 1-164-882-11 CAPACITOR,CERAMIC 220PF/16V CH
1-128-608-11 1-128-608-11 CAPACITOR,CERAMIC 22PF (0603)
1-164-858-11 1-164-858-11 CAPACITOR,CERAMIC 22PF/50V
1-117-743-11 1-117-743-11 CAPACITOR,CERAMIC 5.0PF CH1005
1-127-998-11 1-127-998-11 CAPACITOR,CERAMIC 8PF CH(0603)
1-128-617-11 1-128-617-11 CAPACITOR,CERAMIC,100PF (0603)
1-128-615-11 1-128-615-11 CAPACITOR,CERAMIC,68PF (0603)
1-112-692-11 1-112-692-11 CAPACITOR,CERAMIC1000PF CH1005
1-116-717-11 1-116-717-11 CAPACITOR,CERAMIC10MF X5R 2012
1-100-743-91 1-100-743-91 CAPACITOR,CERAMIC2.2MF B(2012)
1-164-943-11 1-164-943-11 CAPACITOR,CHIP CERAMIC 0.01MF
1-164-874-11 1-164-874-11 CAPACITOR,CHIP CERAMIC 100PF
1-164-850-11 1-164-850-11 CAPACITOR,CHIP CERAMIC 10PF/50
1-164-852-11 1-164-852-11 CAPACITOR,CHIP CERAMIC 12PF/50
1-164-854-11 1-164-854-11 CAPACITOR,CHIP CERAMIC 15PF/50
1-164-866-11 1-164-866-11 CAPACITOR,CHIP CERAMIC 47PF/50
1-164-848-11 1-164-848-11 CAPACITOR,CHIP CERAMIC 8PF/50V
1-114-214-81 1-114-214-81 CAPACITOR,CHIP CERAMIC470PF
1-128-594-11 1-128-594-11 CAPACITOR,ELECT 1MF/50V(BP)
1-113-984-11 1-113-984-11 CAPACITOR,TANTALUM 1.5MF/35V
1-137-910-11 1-137-910-11 CAPACITOR,TANTALUM ELECT 10MF
1-100-539-91 1-100-539-91 CAPAPACITR, ELECT 47MF (3216)
4-547-808-01 4-547-808-01 CASE (SD), SHIELD
4-547-809-01 4-547-809-01 CASE (VF), SHIELD
1-114-950-91 1-114-950-91 CERAMIC CAP 4.7MF X5R 1005
4-540-526-01 4-540-526-01 CHASSIS, MAIN
4-540-526-02 4-540-526-02 CHASSIS, MAIN
1-802-251-21 1-802-251-21 CHIP VARISTOR
1-481-981-11 1-481-981-11 CHOKE COIL 4.7UH(ML 2520)
4-540-645-01 4-540-645-01 CLAMP (IM), HARNESS
2-892-095-01 2-892-095-01 CLAMP, CABLE
4-460-887-01 4-460-887-01 CLAMP, HARNESS
1-456-499-11 1-456-499-11 COIL, CHOKE (4.7UH)
1-457-612-11 1-457-612-11 COIL, CHOKE 0.78UH
1-457-049-21 1-457-049-21 COIL, CHOKE 10UH
1-460-370-11 1-460-370-11 COIL, CHOKE 10UH (4018)
1-457-854-11 1-457-854-11 COIL, CHOKE 2.2UH
1-460-369-11 1-460-369-11 COIL, CHOKE 33UH (4018)
1-460-355-11 1-460-355-11 COIL, CHOKE 4.7UH
1-419-939-21 1-419-939-21 COIL, CHOKE 4.7UH
1-460-359-11 1-460-359-11 COIL, CHOKE 4.7UH (4018)
X-2188-877-5 X-2188-877-5 COLD SHOE KIT
X-2188-877-4 X-2188-877-4 COLD SHOE KIT
1-487-540-14 1-487-540-14 COMMANDER, STANDARD
1-487-540-13 1-487-540-13 COMMANDER, STANDARD
1-457-374-21 1-457-374-21 COMMOM MODE CHOKE COIL
1-460-671-11 1-460-671-11 COMMON MODE CHOKE COIL
1-457-223-11 1-457-223-11 COMMON MODE CHOKE COIL
1-694-535-11 1-694-535-11 CONDCTOR, CHIP (0603)
1-218-990-81 1-218-990-81 CONDUCTOR, CHIP (1005)
1-216-295-00 1-216-295-00 CONDUCTOR, CHIP (2012)
1-216-296-91 1-216-296-91 CONDUCTOR, CHIP (3216)
1-216-864-91 1-216-864-91 CONDUCTOR, CHIP(1608)
1-234-400-21 1-234-400-21 CONDUCTOR, NETWORK (2010)
1-820-589-21 1-820-589-21 CONNECTOR, BOARD TO BOARD 100P
1-820-588-21 1-820-588-21 CONNECTOR, BOARD TO BOARD 100P
9-910-999-TF 9-910-999-TF CONNECTOR, CARD
1-793-324-21 1-793-324-21 CONNECTOR, COAXIAL (BNC TYPE)
1-844-078-11 1-844-078-11 CONNECTOR, COAXIAL (BOARD) 32P
1-821-760-21 1-821-760-21 CONNECTOR, COAXIAL(RECEPTACLE)
1-820-806-21 1-820-806-21 CONNECTOR, COAXIAL(RECEPTACLE)
1-821-530-12 1-821-530-12 CONNECTOR, EX CARD (HOST)
1-821-531-15 1-821-531-15 CONNECTOR, EX CARD(GUIDE UNIT)
1-843-623-11 1-843-623-11 CONNECTOR, FFC/FPC (LIF) 20P
1-793-331-51 1-793-331-51 CONNECTOR, FFC/FPC (LIF) 20P
1-843-711-11 1-843-711-11 CONNECTOR, FFC/FPC (LIF) 26P
1-820-821-51 1-820-821-51 CONNECTOR, FFC/FPC (LIF) 6P
1-820-821-31 1-820-821-31 CONNECTOR, FFC/FPC (LIF) 6P
1-779-329-51 1-779-329-51 CONNECTOR, FFC/FPC 10P
1-779-330-51 1-779-330-51 CONNECTOR, FFC/FPC 12P
1-779-332-51 1-779-332-51 CONNECTOR, FFC/FPC 16P
1-779-333-51 1-779-333-51 CONNECTOR, FFC/FPC 18P
1-779-335-51 1-779-335-51 CONNECTOR, FFC/FPC 22P
1-817-554-62 1-817-554-62 CONNECTOR, FFC/FPC 6P
1-816-655-61 1-816-655-61 CONNECTOR, FFC/FPC 8P
1-779-328-51 1-779-328-51 CONNECTOR, FFC/FPC 8P
1-815-039-61 1-815-039-61 CONNECTOR, FFC/FPC(ZIF) AN 10P
1-822-245-61 1-822-245-61 CONNECTOR, FPC (LIF(NON-ZIF))
1-819-973-61 1-819-973-61 CONNECTOR, FPC (LIF(NON-ZIF))
1-842-269-11 1-842-269-11 CONNECTOR, FPC (ZIF) 23P
1-818-679-71 1-818-679-71 CONNECTOR, FPC (ZIF) 23P
1-822-769-21 1-822-769-21 CONNECTOR, FPC (ZIF) 27P
1-817-829-81 1-817-829-81 CONNECTOR, FPC (ZIF) 27P
1-821-502-11 1-821-502-11 CONNECTOR, FPC (ZIF) 29P
1-822-893-11 1-822-893-11 CONNECTOR, FPC (ZIF) 33P
1-822-378-11 1-822-378-11 CONNECTOR, FPC (ZIF) 33P
1-821-500-21 1-821-500-21 CONNECTOR, FPC (ZIF) 45P
1-821-501-11 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
1-842-176-51 1-842-176-51 CONNECTOR, FPC (ZIF) 61P
1-842-604-11 1-842-604-11 CONNECTOR, FPC (ZIF) 61PIN
1-844-006-11 1-844-006-11 CONNECTOR, HDMI
1-821-724-21 1-821-724-21 CONNECTOR, SQUARE TYPE (USB)5P
1-780-729-12 1-780-729-12 CONTACT TERMINAL
1-780-638-22 1-780-638-22 CONTACT TERMINAL
1-846-425-53 1-846-425-53 CORD SET, POWER-SUPPLY
1-846-433-33 1-846-433-33 CORD SET, POWER-SUPPLY
1-836-735-11 1-836-735-11 CORD WITH CONNECTOR
1-848-676-11 1-848-676-11 CORD, CONNECTION (USB 5P)
4-476-763-01 4-476-763-01 COVER (40400), JACK
X-2589-891-1 X-2589-891-1 COVER (941) ASSY, HANDLE (REAR)
4-460-895-02 4-460-895-02 COVER (O), HINGE
4-460-894-02 4-460-894-02 COVER (U), HINGE
X-2589-959-1 X-2589-959-1 COVER ASSY, GRIP
4-540-578-01 4-540-578-01 COVER, AU JACK
4-540-575-01 4-540-575-01 COVER, BN JACK
4-540-579-01 4-540-579-01 COVER, DC JACK
4-437-471-01 4-437-471-01 COVER, EYEPIECE
4-540-550-01 4-540-550-01 COVER, FN
4-540-577-01 4-540-577-01 COVER, HD JACK
4-165-284-02 4-165-284-02 COVER, HP JACK
4-547-748-01 4-547-748-01 COVER, TRIPOD
4-165-282-41 4-165-282-41 COVER, XLR
4-165-285-02 4-165-285-02 COVER, XLR RUBBER
4-548-624-01 4-548-624-01 CUSHION (MI), SPACER
4-540-599-01 4-540-599-01 CUSHION, LCD
3-284-621-11 3-284-621-11 CUSHION, MICROPHONE HOLDER
4-119-285-01 4-119-285-01 CUSHION, SPEAKER
1-855-369-11 1-855-369-11 DC FAN
1-855-369-21 1-855-369-21 DC FAN (UC)
A-2060-183-B A-2060-183-B DEVICE (SERVICE), PRISM
A-2129-451-A A-2129-451-A DEVICE, LENS LSV-1740A
6-503-572-01 6-503-572-01 DI 1SS355VMTE-17
8-719-024-69 8-719-024-69 DI 1SS361(T5LS
6-503-737-01 6-503-737-01 DI CES520
6-503-738-01 6-503-738-01 DI CES521
6-502-978-01 6-502-978-01 DI DA2J10400L
6-503-126-01 6-503-126-01 DI DA2S10100K8
6-503-314-01 6-503-314-01 DI DA37103E0L
6-503-058-01 6-503-058-01 DI DB2J31700L
6-502-890-01 6-502-890-01 DI DZ2S05600K8
6-502-893-01 6-502-893-01 DI DZ2S06800K8
6-503-106-01 6-503-106-01 DI DZ2S100M0L
6-503-109-01 6-503-109-01 DI DZ2S12000K8
6-503-585-01 6-503-585-01 DI EDZVT2R5.6B
6-501-272-01 6-501-272-01 DI RB520CS-30FJT2R
6-503-579-01 6-503-579-01 DI RB521SM-30T2R
6-502-193-01 6-502-193-01 DI SML-D12V8WT86SN
6-502-294-01 6-502-294-01 DI SML-D13M8WT86S
8-719-820-41 8-719-820-41 DIODE 1SS302
8-719-024-71 8-719-024-71 DIODE 1SS362-TE85L
6-500-854-01 6-500-854-01 DIODE 1SS413
6-501-461-01 6-501-461-01 DIODE CMS05(T2RSONY2, Q)
8-719-989-03 8-719-989-03 DIODE DAN222-TL
6-501-123-01 6-501-123-01 DIODE RB160M-60TR
6-500-695-01 6-500-695-01 DIODE UDZSTE-172.7B
A-2060-309-A A-2060-309-A DISPLAY MODULE(MH1-WDJD)
A-1963-392-C A-1963-392-C DONGLE ASSEMBLY (WW)
4-540-534-01 4-540-534-01 DUCT, BM
4-540-638-01 4-540-638-01 DUCT, CABINET (R)
A-2032-324-B A-2032-324-B ECX331CA-1_SERVICE
4-416-347-01 4-416-347-01 EMBLEM (G)
1-889-950-11 1-889-950-11 ENCODER, MR (1740)
4-535-706-02 4-535-706-02 ESD GASKET
4-535-706-01 4-535-706-01 ESD GASKET
1-802-245-11 1-802-245-11 ESD SUPPRESSOR
X-2585-387-1 X-2585-387-1 EYE CUP (456) ASSEMBLY
X-2342-702-2 X-2342-702-2 EYE CUP (LARGE) ASSEMBLY
4-544-247-01 4-544-247-01 FAN, SHEET
1-481-377-21 1-481-377-21 FERRITE, EMI (SMD)
1-469-637-11 1-469-637-11 FERRITE, EMI (SMD)
1-400-580-21 1-400-580-21 FERRITE, EMI (SMD)
1-481-345-21 1-481-345-21 FERRITE, EMI (SMD)
1-816-644-51 1-816-644-51 FFC/FPC CONNECTOR (LIF) 12P
1-816-646-61 1-816-646-61 FFC/FPC CONNECTOR (LIF) 16P
1-816-647-61 1-816-647-61 FFC/FPC CONNECTOR (LIF) 18P
1-816-649-51 1-816-649-51 FFC/FPC CONNECTOR (LIF) 22P
1-816-650-51 1-816-650-51 FFC/FPC CONNECTOR (LIF) 24P
1-816-654-61 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
1-234-939-21 1-234-939-21 FILTER, EMI REMOVAL (SMD)
1-814-589-11 1-814-589-11 FILTER, SAW
1-848-580-11 1-848-580-11 FLEXIBLE FLAT CABLE (FFC-1064)
1-846-258-11 1-846-258-11 FLEXIBLE FLAT CABLE(FFC-1030)
A-2063-151-A A-2063-151-A FP-2, FLEXIBLE (PWB) BLOCK ASSY
1-893-014-11 1-893-014-11 FP-2226 FLEXIBLE PWB
1-893-016-11 1-893-016-11 FP-2228 FLEXIBLE PWB
1-893-017-11 1-893-017-11 FP-2229 FLEXIBLE PWB
1-893-018-11 1-893-018-11 FP-2230 FLEXIBLE PWB
1-893-018-12 1-893-018-12 FP-2230 FLEXIBLE PWB
1-893-019-11 1-893-019-11 FP-2231 FLEXIBLE PWB
1-893-020-11 1-893-020-11 FP-2232 FLEXIBLE PWB
1-893-185-11 1-893-185-11 FP-2238 FLEXIBLE PWB
1-893-186-11 1-893-186-11 FP-2239 FLEXIBLE PWB
1-893-187-11 1-893-187-11 FP-2240 FLEXIBLE PWB
1-893-188-11 1-893-188-11 FP-2241 FLEXIBLE PWB
1-893-189-11 1-893-189-11 FP-2242 FLEXIBLE PWB
1-893-191-11 1-893-191-11 FP-2244 FLEXIBLE PWB
1-893-197-11 1-893-197-11 FP-2250 FLEXIBLE PWB
1-893-198-11 1-893-198-11 FP-2251 FLEXIBLE PWB
1-893-199-11 1-893-199-11 FP-2252 FLEXIBLE PWB
1-893-201-11 1-893-201-11 FP-2254 FLEXIBLE PWB
1-893-202-11 1-893-202-11 FP-2255 FLEXIBLE PWB
1-893-830-11 1-893-830-11 FP-2281 FLEXIBLE PWB
A-2063-040-A A-2063-040-A FRAME ASSY (SERVICE), ME
4-540-576-01 4-540-576-01 FRAME, DC
4-540-662-01 4-540-662-01 FRAME, GC
4-540-574-01 4-540-574-01 FRAME, HD
4-540-527-01 4-540-527-01 FRAME, MAIN
4-461-959-01 4-461-959-01 FRAME, PD
4-165-326-01 4-165-326-01 FRAME, PS
4-594-851-01 4-594-851-01 FRONT SEAL SHEET (1740)
1-523-131-31 1-523-131-31 FUSE 2012
1-576-286-31 1-576-286-31 FUSE, MICRO
1-533-981-31 1-533-981-31 FUSE, MICRO
1-523-068-31 1-523-068-31 FUSE, MICRO
1-576-843-31 1-576-843-31 FUSE, MICRO (1608)
3-274-171-01 3-274-171-01 GASKET (A), VD
4-279-305-11 4-279-305-11 GASKET, DCP-TX REAR
4-279-310-11 4-279-310-11 GASKET, USB BOTTOM
X-2515-772-1 X-2515-772-1 GRILLE (94000) ASSEMBLY,MICROPHONE
4-165-303-01 4-165-303-01 GRILLE (REAR), MICROPHONE
2-178-566-01 2-178-566-01 GRILLE, SPEAKER
4-165-278-01 4-165-278-01 GRIP
3-288-562-02 3-288-562-02 GUARD (F), PANEL
3-288-563-02 3-288-563-02 GUARD (R), PANEL
4-460-898-01 4-460-898-01 GUARD, HARNESS
4-460-730-12 4-460-730-12 HANDLE
1-965-937-21 1-965-937-21 HARNESS (COAXIAL CABLE)
1-963-577-61 1-963-577-61 HARNESS (COAXIAL CABLE)
1-970-362-11 1-970-362-11 HARNESS (DD-1012)
1-966-067-11 1-966-067-11 HARNESS (DIVIDER 4 PIN)
1-970-416-11 1-970-416-11 HARNESS (HN-1014)
1-970-417-11 1-970-417-11 HARNESS (HN-1015)
1-970-418-11 1-970-418-11 HARNESS (HN-1016)
1-963-030-21 1-963-030-21 HARNESS (SW-116)
4-540-556-01 4-540-556-01 HEAT SINK (L), WA
4-540-551-01 4-540-551-01 HEAT SINK (S), WA
4-540-531-01 4-540-531-01 HEAT SINK, BM
4-540-530-01 4-540-530-01 HEAT SINK, DD
4-540-644-01 4-540-644-01 HEAT SINK, IM
4-540-643-01 4-540-643-01 HEAT SINK, LENS
4-540-568-01 4-540-568-01 HEAT SINK, ME
4-540-528-01 4-540-528-01 HEAT SINK, VC
4-290-431-01 4-290-431-01 HEAT SINK, VF
X-2592-325-2 X-2592-325-2 HINGE (40400) ASSEMBLY
4-540-554-01 4-540-554-01 HOLDER, FN
4-165-330-01 4-165-330-01 HOLDER, GRIP BELT
4-460-897-01 4-460-897-01 HOLDER, HT
4-540-642-01 4-540-642-01 HOLDER, ID
4-540-631-01 4-540-631-01 HOLDER, KP
2-178-550-01 2-178-550-01 HOLDER, SPEAKER
4-540-621-01 4-540-621-01 HOLDER, TG
4-165-286-01 4-165-286-01 HOLDER, XS BLOCK
X-2589-888-2 X-2589-888-2 HOOD (941) ASSEMBLY
X-2589-888-5 X-2589-888-5 HOOD (941) ASSY
6-722-276-01 6-722-276-01 IC 74VHCT04AFT
8-759-561-46 8-759-561-46 IC AD8014ART-REEL7
6-721-337-01 6-721-337-01 IC ADG5412BCPZ-REEL7
6-707-997-01 6-707-997-01 IC ADV7320KSTZ
6-721-731-01 6-721-731-01 IC ASM1061
6-718-005-01 6-718-005-01 IC BA4580RFVM-TR
6-716-783-01 6-716-783-01 IC BD11600NUX-E2
6-708-230-01 6-708-230-01 IC BD6876AGLV-E2
6-717-389-01 6-717-389-01 IC BD8330AGU-E2
6-716-945-01 6-716-945-01 IC BD8331GU-E2
6-808-503-01 6-808-503-01 IC BU24130GU-E2
6-712-342-01 6-712-342-01 IC CDCVF2310PWR
6-703-875-01 6-703-875-01 IC CDCVF2505PWR
8-753-404-05 8-753-404-05 IC CXD4236GG
6-715-114-01 6-715-114-01 IC CXD9950AK
6-707-415-01 6-707-415-01 IC DS90LT012ATMF
6-713-192-11 6-713-192-11 IC GS2978-CNTE3Z
6-716-964-01 6-716-964-01 IC K4B2G1646C-HCH9
6-711-915-01 6-711-915-01 IC LM73CIMK-0
6-712-902-01 6-712-902-01 IC LMH1980MM
6-716-910-01 6-716-910-01 IC LMH1983SQE/NOPB
6-717-747-01 6-717-747-01 IC LMP7711MK
6-705-481-01 6-705-481-01 IC LT1931ES5#TR
6-711-375-01 6-711-375-01 IC LT1964ES5-BYP#TR
6-720-893-01 6-720-893-01 IC M24256-BRMN6TP
6-721-847-01 6-721-847-01 IC MB9AF004BGL-G-105-ERE1
6-722-533-01 6-722-533-01 IC MB9AF004BGL-G-105-K1ERE1
6-714-054-01 6-714-054-01 IC MM1665XHBE
6-716-993-01 6-716-993-01 IC MM1836A33NRE
6-715-075-01 6-715-075-01 IC MM1965ATRE
6-714-504-01 6-714-504-01 IC MM3404A15URE
6-716-441-01 6-716-441-01 IC MM3404A31URE
6-717-025-01 6-717-025-01 IC MM3404Z11NRE
6-719-054-01 6-719-054-01 IC MM3411A18URE
6-719-351-01 6-719-351-01 IC MM3416A18URE
6-719-358-01 6-719-358-01 IC MM3416A25URE
6-719-695-01 6-719-695-01 IC MM3571A10URE
6-719-697-01 6-719-697-01 IC MM3571A12URE
6-717-013-01 6-717-013-01 IC MN864716
6-708-889-01 6-708-889-01 IC MP2105DJ-LF-Z
6-717-739-01 6-717-739-01 IC MT47H128M16RT-25E
8-759-581-11 8-759-581-11 IC NJM2125F(TE2)
6-710-823-01 6-710-823-01 IC NJM2737RB1(TE2)
6-707-702-01 6-707-702-01 IC NJM2746RB1(TE2)
8-759-338-95 8-759-338-95 IC NJM2903V (TE2)
8-759-337-40 8-759-337-40 IC NJM2904V(TE2)
6-707-333-01 6-707-333-01 IC NJM3230SE7
8-759-278-58 8-759-278-58 IC NJM4558V (TE2)
8-759-710-28 8-759-710-28 IC NJM4565M-A
8-759-572-28 8-759-572-28 IC NJU7016R
6-703-879-01 6-703-879-01 IC NJU7043RB1(TE2)
6-720-455-01 6-720-455-01 IC OZ8034
6-720-456-01 6-720-456-01 IC PI6C20800SIAEX
6-720-457-01 6-720-457-01 IC PI6C557-05LEX
6-715-659-01 6-715-659-01 IC PST8428UL
6-707-617-01 6-707-617-01 IC R1154H001C-FB
6-709-976-01 6-709-976-01 IC R1173D001B-TR-FA
6-712-135-01 6-712-135-01 IC R1173H001D-T1-F
6-718-498-01 6-718-498-01 IC R1203N071B
6-716-760-01 6-716-760-01 IC R2J30503LG
6-704-642-01 6-704-642-01 IC R3112N131A-TR-FA
6-704-643-01 6-704-643-01 IC R3112N221A-TR-FA
6-600-629-01 6-600-629-01 IC RS-470
6-708-478-01 6-708-478-01 IC RX-8025NB
6-712-050-01 6-712-050-01 IC SN65LVDS301ZQER
6-712-051-01 6-712-051-01 IC SN65LVDS302ZQER
6-710-243-01 6-710-243-01 IC SN74AVC1T45DCKR
6-709-220-01 6-709-220-01 IC SN74AVC2T45DCUR
6-703-848-01 6-703-848-01 IC SN74CB3T3306DCUR
6-705-569-01 6-705-569-01 IC TAR5S45U
8-759-082-61 8-759-082-61 IC TC4W53FU
8-759-523-02 8-759-523-02 IC TC74HC4053AFT(EL)
6-707-843-01 6-707-843-01 IC TC74LCX125FT(EKJ)
6-711-485-01 6-711-485-01 IC TC74VCX125FK(EL)
6-711-497-01 6-711-497-01 IC TC74VCX541FK(EL)
6-707-884-01 6-707-884-01 IC TC74VHCT04AFT(EKJ)
8-759-494-88 8-759-494-88 IC TC75S56F(TE85R)
6-701-917-01 6-701-917-01 IC TC7PA34FU(TE85R)
6-705-673-01 6-705-673-01 IC TC7PA53FU(TE85L.F)
6-722-637-01 6-722-637-01 IC TC7PZ34FU,RSNJ(CT
6-720-795-01 6-720-795-01 IC TC7SB3157CFU,RSF
6-706-484-01 6-706-484-01 IC TC7SH04FU(T5RSOYJF)
6-710-786-01 6-710-786-01 IC TC7SH125FU(T5RSOYF
6-706-489-01 6-706-489-01 IC TC7SH32FU(T5RSOYJF)
6-712-850-01 6-712-850-01 IC TC7SP3125TU (5RSO,F
6-715-036-01 6-715-036-01 IC TC7SZ04FU,RSONYJ
6-715-039-01 6-715-039-01 IC TC7SZ08FU,RSONYJ
6-718-936-01 6-718-936-01 IC TC7SZ125FE(T5RSY,F
6-715-041-01 6-715-041-01 IC TC7SZ125FU,RSOYJ
8-759-675-54 8-759-675-54 IC TC7W53FK-TE85R
8-759-598-43 8-759-598-43 IC TC7WH04FK(TE85R)
8-759-598-44 8-759-598-44 IC TC7WH08FK(TE85R)
6-722-607-01 6-722-607-01 IC TC7WH08FK,RSNJ(CT
8-759-831-52 8-759-831-52 IC TC7WH125FK(TE85R)
6-600-060-01 6-600-060-01 IC TC7WZ32FK(TE85R)
6-722-625-01 6-722-625-01 IC TC7WZ32FK,RSNJ(CT
6-703-238-01 6-703-238-01 IC TC7WZ34FK(TE85R)
6-722-626-01 6-722-626-01 IC TC7WZ34FK,RSNJ(CT
6-700-831-01 6-700-831-01 IC TC7WZ74FK(TE85R)
6-722-627-01 6-722-627-01 IC TC7WZ74FK,RSNJ(CT
6-715-164-01 6-715-164-01 IC TPS2553DBVR
6-716-852-01 6-716-852-01 IC TPS54425PWPR
6-721-574-01 6-721-574-01 IC TPS54531DDAR
6-720-977-01 6-720-977-01 IC TPS61093DSKR
6-714-421-01 6-714-421-01 IC UPD720101F1-EA8-E2-A
6-721-732-01 6-721-732-01 IC UPD720202K8-701-BAA-A
6-721-308-01 6-721-308-01 IC W25Q256FVEIG
6-721-598-01 6-721-598-01 IC XC7A100T-L2FGG484E
1-412-979-21 1-412-979-21 INDUCTOR (SMALL TYPE)
1-412-987-31 1-412-987-31 INDUCTOR (SMALL TYPE) 4.70UH
1-481-992-11 1-481-992-11 INDUCTOR 1UH (2520)
1-482-097-11 1-482-097-11 INDUCTOR 2.2UH (3225)
1-400-136-11 1-400-136-11 INDUCTOR 4.7UH (1608)
1-460-473-11 1-460-473-11 INDUCTOR 4.7UH (2520)
1-481-887-11 1-481-887-11 INDUCTOR 8.2NH (0603)
1-469-843-11 1-469-843-11 INDUCTOR, (SMD) 3.3UH
1-469-967-21 1-469-967-21 INDUCTOR, CHIP 10UH (2518)
1-469-555-21 1-469-555-21 INDUCTOR, CHIP 10UH (LB2016)
1-400-824-21 1-400-824-21 INDUCTOR, CHIP 2.2UH (2012)
1-414-844-21 1-414-844-21 INDUCTOR, CHIP 22NH (1005)
1-414-836-21 1-414-836-21 INDUCTOR, CHIP 4.7NH (1005)
1-469-553-21 1-469-553-21 INDUCTOR, CHIP 4.7UH (LB2016)
1-481-250-11 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
1-400-198-21 1-400-198-21 INDUCTOR, FERRITE BEAD (1005)
1-400-588-11 1-400-588-11 INDUCTOR, LAMINATE CHIP 10UH
1-469-580-21 1-469-580-21 INDUCTOR,FERRITE BEAD 120 1005
1-779-745-21 1-779-745-21 JACK, DC
1-794-525-12 1-794-525-12 JACK, MIC
1-793-995-21 1-793-995-21 JACK, SUPER SMALL TYPE (BLACK)
4-540-613-01 4-540-613-01 KNOB (CMR), MODE
X-2188-599-1 X-2188-599-1 KNOB ASSEMBLY, ZOOM SELECTION
1-845-063-11 1-845-063-11 LAN MODULE, WIRELESS FPS
X-2585-386-1 X-2585-386-1 LENS (456) ASSEMBLY, VF
A-1991-182-A A-1991-182-A LENS ASSEMBLY, 1 GROUP
4-540-619-01 4-540-619-01 LEVER (SP), CMR LINK
4-540-618-01 4-540-618-01 LEVER, CMR LINK
4-489-239-01 4-489-239-01 LEVER, ZOOM
4-540-651-01 4-540-651-01 LID (WU), DONGLE
1-471-514-11 1-471-514-11 MAGNET (LM-FH30)
4-542-447-63 4-542-447-63 MANUAL, INSTRUCTION
4-542-447-62 4-542-447-62 MANUAL, INSTRUCTION
4-542-447-53 4-542-447-53 MANUAL, INSTRUCTION
4-542-447-52 4-542-447-52 MANUAL, INSTRUCTION
4-542-447-43 4-542-447-43 MANUAL, INSTRUCTION
4-542-447-42 4-542-447-42 MANUAL, INSTRUCTION
4-542-447-33 4-542-447-33 MANUAL, INSTRUCTION
4-542-447-32 4-542-447-32 MANUAL, INSTRUCTION
4-542-447-23 4-542-447-23 MANUAL, INSTRUCTION
4-542-447-21 4-542-447-21 MANUAL, INSTRUCTION
4-542-447-13 4-542-447-13 MANUAL, INSTRUCTION
4-542-447-03 4-542-447-03 MANUAL, INSTRUCTION
4-542-447-01 4-542-447-01 MANUAL, INSTRUCTION
4-542-447-11 4-542-447-11 MANUAL, INSTRUCTION
4-568-396-12 4-568-396-12 MANUAL, INSTRUCTION(UUD VER2)
4-568-396-11 4-568-396-11 MANUAL, INSTRUCTION(UUD VER2)
4-568-396-02 4-568-396-02 MANUAL, INSTRUCTION(UUD VER2)
4-568-396-01 4-568-396-01 MANUAL, INSTRUCTION(UUD VER2)
4-581-336-11 4-581-336-11 MANUAL, INSTRUCTION(UUD VER3)
4-581-336-01 4-581-336-01 MANUAL, INSTRUCTION(UUD VER3)
4-684-465-01 4-684-465-01 MANUAL, INSTRUCTION(UUD VER3.1
4-693-389-11 4-693-389-11 MANUAL, INSTRUCTION(UUD VER4)
4-693-389-01 4-693-389-01 MANUAL, INSTRUCTION(UUD VER4)
4-697-525-01 4-697-525-01 MANUAL, INSTRUCTION(UUD VER4.1
A-2066-044-A A-2066-044-A MIC BLOCK ASSY E (SERVICE)
X-2590-361-3 X-2590-361-3 MIC HOLDER, ASSY(9383)
X-2590-361-1 X-2590-361-1 MIC HOLDER,ASSEMBLY(9383)
1-576-858-31 1-576-858-31 MICRO FUSE-LINKS
1-542-808-21 1-542-808-21 MICROPHONE
A-2064-031-A A-2064-031-A MICROPHONE BLOCK ASSY(SERVICE)
A-2058-766-A A-2058-766-A MOUNTED C.BOARD GY-1006
A-2058-779-A A-2058-779-A MOUNTED C.BOARD SD-1004
A-2058-759-A A-2058-759-A MOUNTED C.BOARD, AS-1002
A-2058-760-A A-2058-760-A MOUNTED C.BOARD, AU-1002
A-2063-076-A A-2063-076-A MOUNTED C.BOARD, CK-1010(S)
A-2058-762-A A-2058-762-A MOUNTED C.BOARD, DC-1004
A-2063-077-A A-2063-077-A MOUNTED C.BOARD, DD-1011(S)
A-2058-764-A A-2058-764-A MOUNTED C.BOARD, FC-1003
A-1971-415-A A-1971-415-A MOUNTED C.BOARD, FP2065
A-2058-846-A A-2058-846-A MOUNTED C.BOARD, FP2227
A-2058-847-A A-2058-847-A MOUNTED C.BOARD, FP2245
A-2058-845-A A-2058-845-A MOUNTED C.BOARD, FP2249
A-2059-595-A A-2059-595-A MOUNTED C.BOARD, GC-1004_U2
A-2059-048-A A-2059-048-A MOUNTED C.BOARD, GP-1019
A-2058-767-A A-2058-767-A MOUNTED C.BOARD, HG-1003
A-2058-768-A A-2058-768-A MOUNTED C.BOARD, HP-1007
A-2058-769-A A-2058-769-A MOUNTED C.BOARD, HT-1003
A-2058-770-A A-2058-770-A MOUNTED C.BOARD, JK-1010
A-2058-771-A A-2058-771-A MOUNTED C.BOARD, KN-1002
A-2058-772-A A-2058-772-A MOUNTED C.BOARD, KY-1010
A-2063-147-A A-2063-147-A MOUNTED C.BOARD, LD-1016(S)
A-2058-774-A A-2058-774-A MOUNTED C.BOARD, MA-1011
A-2063-074-A A-2063-074-A MOUNTED C.BOARD, MM-1006(S)
A-2063-152-A A-2063-152-A MOUNTED C.BOARD, ND-1001(S)
A-2058-758-A A-2058-758-A MOUNTED C.BOARD, OP-1002
A-2058-776-A A-2058-776-A MOUNTED C.BOARD, PD-1042
A-2063-075-A A-2063-075-A MOUNTED C.BOARD, PI-1003(S)
A-2058-929-A A-2058-929-A MOUNTED C.BOARD, RT-1004
A-2058-778-A A-2058-778-A MOUNTED C.BOARD, SC-1002
A-2058-780-A A-2058-780-A MOUNTED C.BOARD, SE-1007
A-2058-781-A A-2058-781-A MOUNTED C.BOARD, SV-1001
A-2063-150-A A-2063-150-A MOUNTED C.BOARD, TC-1001(S)
A-2058-783-A A-2058-783-A MOUNTED C.BOARD, TG-1002
A-2058-784-A A-2058-784-A MOUNTED C.BOARD, UP-1001
A-2063-073-A A-2063-073-A MOUNTED C.BOARD, VC-1030(S)
A-2058-786-A A-2058-786-A MOUNTED C.BOARD, VF-1012
A-2058-925-A A-2058-925-A MOUNTED C.BOARD, WC-1002
A-2058-927-A A-2058-927-A MOUNTED C.BOARD, WL-1001
A-2059-597-A A-2059-597-A MOUNTED C.BOARD, WU-1001_U2
A-2058-787-A A-2058-787-A MOUNTED C.BOARD, XL-1004
A-1902-812-A A-1902-812-A MOUNTED C.BOARD,FP-2005
A-2040-499-A A-2040-499-A NFC BLOCK ASSEMBLY
3-061-234-02 3-061-234-02 NUT (M6X0.5)
3-061-234-01 3-061-234-01 NUT (M6X0.5)
1-814-615-11 1-814-615-11 OSCILLATOR, CRYSTAL
1-813-857-21 1-813-857-21 OSCILLATOR, CRYSTAL
1-813-067-61 1-813-067-61 OSCILLATOR, CRYSTAL
1-795-994-11 1-795-994-11 OSCILLATOR, CRYSTAL
A-2116-011-A A-2116-011-A P CAB C ASSY (SERVICE)
A-2066-640-A A-2066-640-A P CAB M ASSY (SERVICE )
X-2589-961-1 X-2589-961-1 PANEL ASSY, CONTROL
A-2058-699-A A-2058-699-A PANEL BLOCK ASSY, BT
1-774-731-21 1-774-731-21 PIN, CONNECTOR (PC BOARD) 5P
1-774-297-21 1-774-297-21 PIN, CONNECTOR (PC BOARD) 7P
1-817-872-11 1-817-872-11 PIN, CONNECTOR 12P
1-794-997-11 1-794-997-11 PIN, CONNECTOR 20P
1-794-375-11 1-794-375-11 PIN, CONNECTOR 2P
1-778-506-21 1-778-506-21 PIN, CONNECTOR 2P
1-794-376-11 1-794-376-11 PIN, CONNECTOR 4P
1-817-054-21 1-817-054-21 PIN, CONNECTOR 6P
4-446-382-01 4-446-382-01 PIN, LOCK
1-580-056-21 1-580-056-21 PIN,CONNECTOR 3P
3-703-358-06 3-703-358-06 PIN,PARALLEL (2X14) (STEEL)
X-2589-892-1 X-2589-892-1 PLATE (941) ASSY, FIXED
4-540-648-01 4-540-648-01 PLATE, (L) ELECTROSTATIC
1-887-583-11 1-887-583-11 PWB, FP-2124 FLEXIBLE
1-814-363-11 1-814-363-11 QUARTZ CRYSTAL UNIT
1-814-543-11 1-814-543-11 QUARTZ CRYSTAL UNITS 11.2896MH
1-814-367-11 1-814-367-11 QUARTZ CRYSTAL UNITS 30MHZ
1-208-889-11 1-208-889-11 RES, CHIP 1.2K (1005)
1-208-691-11 1-208-691-11 RES, CHIP 2.2K (1005)
1-208-918-11 1-208-918-11 RES, CHIP 20K (1005)
1-208-871-81 1-208-871-81 RES, CHIP 220 (1005)
1-218-981-91 1-218-981-91 RES, CHIP 220K
1-220-883-81 1-220-883-81 RES, CHIP 36 (1005)
1-245-567-81 1-245-567-81 RES, CHIP 49.9 (1005)
1-208-906-81 1-208-906-81 RES, CHIP 6.2K(1005)
1-208-957-11 1-208-957-11 RES, CHIP 820K (1005)
1-250-471-11 1-250-471-11 RES, METAL FILM CHIP 100(1005)
1-250-519-11 1-250-519-11 RES, METAL FILM CHIP 10K(1005)
1-250-521-11 1-250-521-11 RES, METAL FILM CHIP 12K(1005)
1-250-475-11 1-250-475-11 RES, METAL FILM CHIP 150(1005)
1-250-523-11 1-250-523-11 RES, METAL FILM CHIP 15K(1005)
1-250-477-11 1-250-477-11 RES, METAL FILM CHIP 180(1005)
1-250-567-11 1-250-567-11 RES, METAL FILM CHIP 1M (1005)
1-250-527-11 1-250-527-11 RES, METAL FILM CHIP 22K(1005)
1-250-480-11 1-250-480-11 RES, METAL FILM CHIP 240(1005)
1-250-528-11 1-250-528-11 RES, METAL FILM CHIP 24K 1/16W
1-250-529-11 1-250-529-11 RES, METAL FILM CHIP 27K(1005)
1-250-531-11 1-250-531-11 RES, METAL FILM CHIP 33K(1005)
1-250-461-11 1-250-461-11 RES, METAL FILM CHIP 39 (1005)
1-250-463-11 1-250-463-11 RES, METAL FILM CHIP 47 (1005)
1-250-487-11 1-250-487-11 RES, METAL FILM CHIP 470(1005)
1-250-535-11 1-250-535-11 RES, METAL FILM CHIP 47K(1005)
1-250-464-11 1-250-464-11 RES, METAL FILM CHIP 51 (1005)
1-250-467-11 1-250-467-11 RES, METAL FILM CHIP 68 (1005)
1-250-491-11 1-250-491-11 RES, METAL FILM CHIP 680(1005)
1-250-539-11 1-250-539-11 RES, METAL FILM CHIP 68K(1005)
1-250-468-11 1-250-468-11 RES, METAL FILM CHIP 75 (1005)
1-250-493-11 1-250-493-11 RES, METAL FILM CHIP 820(1005)
1-234-381-21 1-234-381-21 RES, NETWORK 100KX4 (1005)
1-234-378-21 1-234-378-21 RES, NETWORK 10KX4 (1005)
1-234-369-21 1-234-369-21 RES, NETWORK 10X4 (1005)
1-234-375-21 1-234-375-21 RES, NETWORK 1KX4 (1005)
1-234-373-21 1-234-373-21 RES, NETWORK 220X4 (1005)
1-234-370-11 1-234-370-11 RES, NETWORK 22X4 (1005)
1-234-377-21 1-234-377-21 RES, NETWORK 4.7KX4 (1005)
1-234-371-11 1-234-371-11 RES, NETWORK 47X4 (1005)
1-250-495-11 1-250-495-11 RES,METAL FILM CHIP 1.0K(1005)
1-250-499-11 1-250-499-11 RES,METAL FILM CHIP 1.5K(1005)
1-250-543-11 1-250-543-11 RES,METAL FILM CHIP 100K(1005)
1-250-503-11 1-250-503-11 RES,METAL FILM CHIP 2.2K(1005)
1-250-505-11 1-250-505-11 RES,METAL FILM CHIP 2.7K(1005)
1-250-551-11 1-250-551-11 RES,METAL FILM CHIP 220K(1005)
1-250-506-11 1-250-506-11 RES,METAL FILM CHIP 3.0K(1005)
1-250-507-11 1-250-507-11 RES,METAL FILM CHIP 3.3K(1005)
1-250-509-11 1-250-509-11 RES,METAL FILM CHIP 3.9K(1005)
1-250-511-11 1-250-511-11 RES,METAL FILM CHIP 4.7K(1005)
1-250-513-11 1-250-513-11 RES,METAL FILM CHIP 5.6K(1005)
1-250-515-11 1-250-515-11 RES,METAL FILM CHIP 6.8K(1005)
1-250-517-11 1-250-517-11 RES,METAL FILM CHIP 8.2K(1005)
1-208-687-11 1-208-687-11 RESISTOR CHIP 1.5K 1/16W (1005
1-208-635-11 1-208-635-11 RESISTOR CHIP 10 1/16W (1005)
1-208-709-11 1-208-709-11 RESISTOR CHIP 12K 1/16W (1005)
1-208-663-11 1-208-663-11 RESISTOR CHIP 150 1/16W (1005)
1-208-711-11 1-208-711-11 RESISTOR CHIP 15K 1/16W (1005)
1-208-869-11 1-208-869-11 RESISTOR CHIP 180 (1005)
1-218-980-11 1-218-980-11 RESISTOR CHIP 180K 1/16W(1005)
1-208-713-11 1-208-713-11 RESISTOR CHIP 18K 1/16W (1005)
1-208-683-11 1-208-683-11 RESISTOR CHIP 1K 1/16W (1005)
1-208-942-11 1-208-942-11 RESISTOR CHIP 200K
1-208-643-11 1-208-643-11 RESISTOR CHIP 22 1/16W (1005)
1-208-943-11 1-208-943-11 RESISTOR CHIP 220K
1-218-982-11 1-218-982-11 RESISTOR CHIP 270K 1/16W(1005)
1-218-970-11 1-218-970-11 RESISTOR CHIP 27K 1/16W (1005)
1-208-695-11 1-208-695-11 RESISTOR CHIP 3.3K 1/16W(1005)
1-202-974-11 1-202-974-11 RESISTOR CHIP 3.3M 1/16W(1005)
1-208-697-11 1-208-697-11 RESISTOR CHIP 3.9K 1/16W(1005)
1-208-647-11 1-208-647-11 RESISTOR CHIP 33 1/16W (1005)
1-208-671-11 1-208-671-11 RESISTOR CHIP 330 1/16W (1005)
1-208-947-11 1-208-947-11 RESISTOR CHIP 330K 1/16W(1005)
1-208-719-11 1-208-719-11 RESISTOR CHIP 33K 1/16W (1005)
1-208-649-11 1-208-649-11 RESISTOR CHIP 39 1/16W (1005)
1-208-721-11 1-208-721-11 RESISTOR CHIP 39K 1/16W (1005)
1-208-674-11 1-208-674-11 RESISTOR CHIP 430 1/16W (1005)
1-208-675-11 1-208-675-11 RESISTOR CHIP 470 1/16W (1005)
1-218-985-11 1-218-985-11 RESISTOR CHIP 470K 1/16W(1005)
1-208-677-11 1-208-677-11 RESISTOR CHIP 560 1/16W (1005)
1-218-974-11 1-218-974-11 RESISTOR CHIP 56K 1/16W (1005)
1-208-883-81 1-208-883-81 RESISTOR CHIP 680 (1005)
1-208-955-11 1-208-955-11 RESISTOR CHIP 680K
1-220-169-11 1-220-169-11 RESISTOR CHIP 75 1/16W (1005)
1-208-933-11 1-208-933-11 RESISTOR CHIP 82K
1-234-384-21 1-234-384-21 RESISTOR NETWORK 1M(1005X4)
1-242-967-11 1-242-967-11 RESISTOR, CHIP 1.0 (1005)
1-218-954-11 1-218-954-11 RESISTOR, CHIP 1.2K 1/16W
1-218-955-11 1-218-955-11 RESISTOR, CHIP 1.5K
1-208-688-11 1-208-688-11 RESISTOR, CHIP 1.6K1/16W 1005
1-218-956-11 1-218-956-11 RESISTOR, CHIP 1.8K
1-208-893-11 1-208-893-11 RESISTOR, CHIP 1.8K (1005)
1-216-001-00 1-216-001-00 RESISTOR, CHIP 10 1/10W(2012)
1-208-935-11 1-208-935-11 RESISTOR, CHIP 100K (1005)
1-208-707-11 1-208-707-11 RESISTOR, CHIP 10K (1005)
1-218-965-11 1-218-965-11 RESISTOR, CHIP 10K 1/16W
1-208-939-11 1-208-939-11 RESISTOR, CHIP 150K (1005)
1-218-953-11 1-218-953-11 RESISTOR, CHIP 1K 1/16W
1-218-933-81 1-218-933-81 RESISTOR, CHIP 22 1/16W
1-218-959-11 1-218-959-11 RESISTOR, CHIP 3.3K
1-218-960-11 1-218-960-11 RESISTOR, CHIP 3.9K 1/16W
1-218-947-11 1-218-947-11 RESISTOR, CHIP 330 1/16W
1-208-923-11 1-208-923-11 RESISTOR, CHIP 33K (1005)
1-218-961-11 1-218-961-11 RESISTOR, CHIP 4.7K 1/16W
1-218-937-11 1-218-937-11 RESISTOR, CHIP 47
1-208-927-11 1-208-927-11 RESISTOR, CHIP 47K 1/16W(1005)
1-208-905-11 1-208-905-11 RESISTOR, CHIP 5.6K (1005)
1-240-582-11 1-240-582-11 RESISTOR, CHIP 6.8 (1005)
1-220-300-11 1-220-300-11 RESISTOR, CHIP 6.8K (4532)
1-218-939-11 1-218-939-11 RESISTOR, CHIP 68 1/16W (1005)
1-218-951-11 1-218-951-11 RESISTOR, CHIP 680 1/16
1-208-931-11 1-208-931-11 RESISTOR, CHIP 68K (1005)
1-208-934-11 1-208-934-11 RESISTOR, CHIP 91K (1005)
1-250-553-11 1-250-553-11 RESISTOR, METAL FILM CHIP 270K
1-250-488-11 1-250-488-11 RESISTOR, METAL FILM CHIP 510
1-234-380-21 1-234-380-21 RESISTOR, NETWORK 47K (1005X4)
1-208-890-11 1-208-890-11 RESISTOR,CHIP 1.3K (1005)
1-218-941-81 1-218-941-81 RESISTOR,CHIP 100 1/16W (1005)
1-219-606-11 1-219-606-11 RESISTOR,CHIP 100K 1/16W(1005)
1-216-833-91 1-216-833-91 RESISTOR,CHIP 10K 1/10W (1608)
1-218-942-11 1-218-942-11 RESISTOR,CHIP 120,1/16W
1-218-978-11 1-218-978-11 RESISTOR,CHIP 120K 1/16W(1005)
1-218-967-11 1-218-967-11 RESISTOR,CHIP 15K 1/16W (1005)
1-218-989-11 1-218-989-11 RESISTOR,CHIP 1M 1/16W (1005)
1-218-957-11 1-218-957-11 RESISTOR,CHIP 2.2K 1/16W(1005)
1-218-958-11 1-218-958-11 RESISTOR,CHIP 2.7K 1/16W(1005)
1-218-945-11 1-218-945-11 RESISTOR,CHIP 220 1/16W(1005)
1-218-969-11 1-218-969-11 RESISTOR,CHIP 22K 1/16W (1005)
1-208-715-81 1-208-715-81 RESISTOR,CHIP 22K 1/16W (1005)
1-216-837-11 1-216-837-11 RESISTOR,CHIP 22K 1/16W 1608
1-208-873-11 1-208-873-11 RESISTOR,CHIP 270 1/16W (1005)
1-218-971-11 1-218-971-11 RESISTOR,CHIP 33K 1/16W (1005)
1-216-793-11 1-216-793-11 RESISTOR,CHIP 4.7 1/10W 1608
1-208-699-11 1-208-699-11 RESISTOR,CHIP 4.7K 1/16W(1005)
1-211-985-11 1-211-985-11 RESISTOR,CHIP 47 1/10W (1608)
1-208-855-81 1-208-855-81 RESISTOR,CHIP 47 1/16W (1005)
1-218-949-11 1-218-949-11 RESISTOR,CHIP 470 1/16W
1-218-962-11 1-218-962-11 RESISTOR,CHIP 5.6K 1/16W(1005)
1-218-938-11 1-218-938-11 RESISTOR,CHIP 56 1/16W (1005)
1-218-963-11 1-218-963-11 RESISTOR,CHIP 6.8K 1/16W
1-208-703-11 1-208-703-11 RESISTOR,CHIP 6.8K 1/16W(1005)
1-208-909-11 1-208-909-11 RESISTOR,CHIP 8.2K 1/16W(1005)
1-208-861-81 1-208-861-81 RESISTOR,CHIP 82 (1005)
1-208-910-11 1-208-910-11 RESISTOR,CHIP 9.1K (1005)
1-233-411-11 1-233-411-11 RESISTOR,CHIP NETWORK 220/3216
1-220-803-81 1-220-803-81 RESISTOR,CHIP4.7 1/16W (1005)
1-250-500-11 1-250-500-11 RESISTOR,METAL FILM CHIP 1.6K
1-250-483-11 1-250-483-11 RESISTOR,METAL FILM CHIP 330
J-7121-620-A J-7121-620-A RESOLUTION CHECK CHART (PXW)(1
4-540-637-01 4-540-637-01 RETAINER, AS PC BOARD
4-540-636-01 4-540-636-01 RETAINER, FC PC BOARD
3-288-526-01 3-288-526-01 RETAINER, SPEAKER
4-165-332-01 4-165-332-01 RETAINER, VF FLEXIBLE
A-1991-209-A A-1991-209-A RING BLOCK ASSY, MANUAL
4-489-240-01 4-489-240-01 RING, FRONT
3-288-474-01 3-288-474-01 RUBBER, PANEL RETAINER
4-165-304-01 4-165-304-01 SCREEN (REAR), WINDOW
3-254-029-11 3-254-029-11 SCREW
2-342-356-01 2-342-356-01 SCREW (M2 (ECO ,EG))
3-968-729-53 3-968-729-53 SCREW (M2), LOCK ACE, P2
7-627-552-48 7-627-552-48 SCREW +P1.7X4(EP-FE/ZNBK/CM2)
2-655-582-01 2-655-582-01 SCREW 0+P2 M2 NEWTRU-STAR
3-080-204-31 3-080-204-31 SCREW(1.7X6),TAPPING,P2
2-630-005-31 2-630-005-31 SCREW(ECO)NEW TRUSTER,P2
2-635-562-31 2-635-562-31 SCREW(M1.7)
3-080-204-21 3-080-204-21 SCREW(M1.7X5), TAPPING, P2
2-891-494-11 2-891-494-11 SCREW(M2),NEW TRUSTER,P2
2-630-005-41 2-630-005-41 SCREW(M2),NEW TRUSTER,P2
2-640-315-02 2-640-315-02 SCREW(M2X5),SMALL (STEEL)
3-080-203-51 3-080-203-51 SCREW(M2X6),LOCK ACE,P2
3-080-206-21 3-080-206-21 SCREW, TAPPING, P2
3-080-206-11 3-080-206-11 SCREW, TAPPING, P2
7-627-556-58 7-627-556-58 SCREW,PRECISION +P2.6X5
1-489-167-11 1-489-167-11 SENSOR MAGNETIC
1-489-147-11 1-489-147-11 SENSOR, INFRARED
A-2066-639-B A-2066-639-B SERVICE, LCD BLOCK ASSY
4-119-356-01 4-119-356-01 SHEET (1122), LENS RADIATION
4-119-238-01 4-119-238-01 SHEET (1212), VC RADIATION
4-119-362-01 4-119-362-01 SHEET (2828), LENS RADIATION
4-489-010-01 4-489-010-01 SHEET (ANT), ADHESIVE
4-532-959-01 4-532-959-01 SHEET (B), VC RADIATION
4-265-596-01 4-265-596-01 SHEET (BL)
4-475-841-11 4-475-841-11 SHEET (HN)
4-476-923-01 4-476-923-01 SHEET (HP)
4-136-717-21 4-136-717-21 SHEET (K)
3-089-986-01 3-089-986-01 SHEET (L), LIGHT INTERCEPTION
4-540-598-01 4-540-598-01 SHEET (LCD), ADHESIVE
4-412-294-01 4-412-294-01 SHEET (R), RADIATION
4-548-628-01 4-548-628-01 SHEET (TX), RADIATION
4-264-292-01 4-264-292-01 SHEET (VC), RADIATION
4-475-840-01 4-475-840-01 SHEET (VF)
4-437-473-01 4-437-473-01 SHEET (VF), RADIATION
4-540-639-01 4-540-639-01 SHEET METAL (F), ELECTROSTATIC
4-540-640-01 4-540-640-01 SHEET METAL (R), ELECTROSTATIC
4-540-634-01 4-540-634-01 SHEET METAL, KP ELECTROSTATIC
4-165-302-01 4-165-302-01 SHEET METAL, MICROPHONE
4-446-655-01 4-446-655-01 SHEET VF
4-488-840-01 4-488-840-01 SHEET, CM RADIATION
4-488-840-11 4-488-840-11 SHEET, CM RADIATION
4-540-548-01 4-540-548-01 SHEET, MAIN RADIATION
4-457-518-01 4-457-518-01 SHEET, MM FLEXIBLE
4-438-734-03 4-438-734-03 SHOE CAP (875)
1-843-477-21 1-843-477-21 SHOE CONNECTOR (21P)
4-438-404-01 4-438-404-01 SHOE COVER
3-069-286-04 3-069-286-04 SHOE, ACCESSORY
3-288-538-11 3-288-538-11 SHOE, REAR (COLD)
3-278-903-02 3-278-903-02 SHOULDER BELT
1-400-833-21 1-400-833-21 SMD EMI FERRITE
X-2589-958-2 X-2589-958-2 SONY PART
1-838-955-22 1-838-955-22 SONY PART
4-549-004-01 4-549-004-01 SPACER (LE)
1-858-706-21 1-858-706-21 SPEAKER (1.8CM)
1-858-706-11 1-858-706-11 SPEAKER (1.8CM)
3-288-615-03 3-288-615-03 SPRING, SHOE
1-970-448-11 1-970-448-11 SUB HARNESS (WA_POWER3)
1-970-448-12 1-970-448-12 SUB HARNESS (WA_POWER3)
1-492-881-11 1-492-881-11 SWITCH BLOCK CONTROL (AU94100)
1-492-897-11 1-492-897-11 SWITCH BLOCK CONTROL (ID94100)
1-492-880-11 1-492-880-11 SWITCH BLOCK CONTROL (PZ94100)
1-492-896-11 1-492-896-11 SWITCH BLOCK CONTROL (XS94100)
1-480-298-11 1-480-298-11 SWITCH BLOCK, CONTROL(GZ92000)
1-492-342-11 1-492-342-11 SWITCH BLOCK, CONTROL(KP40400)
1-487-447-12 1-487-447-12 SWITCH BLOCK, CONTROL(PS94000)
1-786-180-11 1-786-180-11 SWITCH, PUSH (1KEY)
1-771-731-11 1-771-731-11 SWITCH, SLIDE
1-771-487-11 1-771-487-11 SWITCH, SLIDE
1-771-449-11 1-771-449-11 SWITCH, SLIDE
1-786-806-13 1-786-806-13 SWITCH, TACT (WITH LED)
1-798-119-11 1-798-119-11 SWITCH, TACTILE
1-786-914-51 1-786-914-51 SWITCH, TACTILE
4-274-987-01 4-274-987-01 TAPE (AS 1/2) (C)
4-548-623-01 4-548-623-01 TAPE (HS13-005 (9X21))
4-548-622-01 4-548-622-01 TAPE (HS16-010 (10X40))
4-300-115-01 4-300-115-01 TAPPING (1.7) (CH)
4-558-645-01 4-558-645-01 TEMPERATURE CAUTION LABEL(UC)
1-780-986-11 1-780-986-11 TERMINAL BOARD, BATTERY
1-804-949-11 1-804-949-11 THERMISTOR, NTC (SMD)
1-805-726-11 1-805-726-11 THERMISTOR, POSITIVE
1-803-615-11 1-803-615-11 THERMISTOR, POSITIVE
X-2515-764-1 X-2515-764-1 TILT ASSEMBLY, VF
6-552-150-01 6-552-150-01 TR 2SD2702TL
6-552-353-01 6-552-353-01 TR DRC3143T0L
6-552-354-01 6-552-354-01 TR DRC3144E0L
6-553-023-01 6-553-023-01 TR FK3303010L
6-552-029-01 6-552-029-01 TR MCH3377-S-TL-E
6-552-542-01 6-552-542-01 TR RRR030P03TL
6-552-975-01 6-552-975-01 TR RW1A030APT2CR
6-552-874-01 6-552-874-01 TR RW1C025ZPT2CR
6-552-624-01 6-552-624-01 TR SI2301CDS-T1-GE3
6-552-642-01 6-552-642-01 TR SI2304DDS-T1-GE3
6-552-845-01 6-552-845-01 TR SSM3K121TU,LSOYF
6-552-621-01 6-552-621-01 TR SSM3K37MFV,L3SOF
6-552-830-01 6-552-830-01 TR SSM6N15AFE
8-729-928-19 8-729-928-19 TRANSISTOR 2SA1774R
6-551-623-01 6-551-623-01 TRANSISTOR 2SA2154MFV(TL3SONY)
8-729-013-37 8-729-013-37 TRANSISTOR 2SC4213-AB-TE85L
6-550-545-01 6-550-545-01 TRANSISTOR 2SC4617FTLQ
6-551-622-01 6-551-622-01 TRANSISTOR 2SC6026MFV(TL3SONY)
8-729-220-93 8-729-220-93 TRANSISTOR 2SK209-G
8-729-928-55 8-729-928-55 TRANSISTOR DTA123JE-TL
8-729-929-27 8-729-929-27 TRANSISTOR DTC114TE-TL
8-729-929-08 8-729-929-08 TRANSISTOR DTC123JE-TL
8-729-928-82 8-729-928-82 TRANSISTOR DTC144EE-TL
8-729-053-52 8-729-053-52 TRANSISTOR HN1C01FE-Y/GR(TPLR3
6-551-346-01 6-551-346-01 TRANSISTOR LSK3541FS8T
6-551-630-01 6-551-630-01 TRANSISTOR RN1102MFV(TL3SONY)
6-551-631-01 6-551-631-01 TRANSISTOR RN1104MFV(TL3SONY)
8-729-053-58 8-729-053-58 TRANSISTOR RN1904FE(TPL3)
6-551-624-01 6-551-624-01 TRANSISTOR RN2102MFV(TL3SONY)
6-551-625-01 6-551-625-01 TRANSISTOR RN2104MFV(TL3SONY)
8-729-055-01 8-729-055-01 TRANSISTOR RN4984FE(TPLR3)
6-550-750-01 6-550-750-01 TRANSISTOR SSM3K15FS-TE85L
8-729-427-74 8-729-427-74 TRANSISTOR XP4601-TXE
3-694-181-11 3-694-181-11 TYPE1,AROCK PRECISION +P2.6X5
1-842-675-13 1-842-675-13 USB CONNECTOR
1-842-535-11 1-842-535-11 USB3.0 CONNECTOR
1-805-774-21 1-805-774-21 VARISTOR, CHIP
1-802-090-21 1-802-090-21 VARISTOR, CHIP
A-2063-043-A A-2063-043-A VC OUTER SUB ASSY (SERVICE)
1-795-602-11 1-795-602-11 VIBRATOR, CRYSTAL
1-781-525-11 1-781-525-11 VIBRATOR, CRYSTAL
4-544-590-02 4-544-590-02 WASHER (HP), POLYETHYLENE
4-528-373-71 4-528-373-71 WASHER, ADJUSTMENT
4-528-373-61 4-528-373-61 WASHER, ADJUSTMENT
4-528-373-51 4-528-373-51 WASHER, ADJUSTMENT
4-528-373-41 4-528-373-41 WASHER, ADJUSTMENT
4-528-373-31 4-528-373-31 WASHER, ADJUSTMENT
4-528-373-21 4-528-373-21 WASHER, ADJUSTMENT
4-528-373-11 4-528-373-11 WASHER, ADJUSTMENT
4-528-373-01 4-528-373-01 WASHER, ADJUSTMENT
4-489-241-91 4-489-241-91 WASHER, ADJUSTMENT
4-489-241-81 4-489-241-81 WASHER, ADJUSTMENT
4-489-241-71 4-489-241-71 WASHER, ADJUSTMENT
4-489-241-61 4-489-241-61 WASHER, ADJUSTMENT
4-489-241-51 4-489-241-51 WASHER, ADJUSTMENT
4-489-241-41 4-489-241-41 WASHER, ADJUSTMENT
4-489-241-31 4-489-241-31 WASHER, ADJUSTMENT
4-489-241-21 4-489-241-21 WASHER, ADJUSTMENT
4-489-241-11 4-489-241-11 WASHER, ADJUSTMENT
4-489-241-01 4-489-241-01 WASHER, ADJUSTMENT
4-119-234-11 4-119-234-11 WASHER, TRIPOD
4-437-475-01 4-437-475-01 WINDOW, EYE SENSOR
3-076-631-01 3-076-631-01 WOVEN(T0.25)FABRIC NON 210X297
1-820-791-11 1-820-791-11 XLR CONNECTOR (RECEPTACLE) 3P
Main Menu x
