Model Image
Manufacturer

Sony

Model Number

RCDW500C

Description

Cd/cdr Recorder/player

Interactive Exploded View

Parts List

Part Number Description
3-703-244-00 3-703-244-00 2 BUSHING (2104), CORD- STRAI
4-211-237-01 4-211-237-01 508 BELT (MODE) ONE OF FOUR IN CD MECH
4-237-181-01 4-237-181-01 605 TRAY- LOADING TRAY FOR CD
4-999-537-01 4-999-537-01 613 BELT (LOADING) ONE OF FOUR IN CD MECH
1-113-920-11 1-113-920-11 C921 CERAMIC 0.0022UF 20.00%
4-231-686-11 4-231-686-11 CASE (409538) BLACK
1-776-263-12 1-776-263-12 CORD CONNECTION
6-803-746-01 6-803-746-01 IC HD6433064BA02FV
6-806-863-01 6-806-863-01 IC M30624MWP-068FP
1-518-898-11 1-518-898-11 INDICATOR TUBE, FLUORESCE
2-166-060-01 2-166-060-01 INSULATOR (MAIN)
4-238-396-01 4-238-396-01 KNOB (AMS)
A-4732-812-A A-4732-812-A LED MOUNTED PC BOARD
A-4732-814-A A-4732-814-A MOUNTED C.BOARD,DISPLAY
A-4732-835-A A-4732-835-A MOUNTED C.BOARD,MAIN
1-683-869-21 1-683-869-21 POWER BOARD
4-231-973-01 4-231-973-01 POWER BUTTON
1-683-867-21 1-683-867-21 PWB, CD-SW
1-683-868-21 1-683-868-21 PWB, HP
1-218-847-11 1-218-847-11 R114 RESISTOR, CHIP 1.0K
1-211-977-11 1-211-977-11 R218 RESISTOR,CHIP 22
1-439-732-11 1-439-732-11 T900 POWER TRANSFORMER
4-211-212-53 4-211-212-53 TRAY (SUB)
1-782-881-11 1-782-881-11 WIRE (FLAT TYPE) (25 CORE
