Model Image
Manufacturer

Sony

Model Number

STRDE505

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-249-408-11 1-249-408-11 180 OHM 5% 1/4W
1-249-409-11 1-249-409-11 220 OHM 5% 1/4W
1-501-374-72 1-501-374-72 ANTENNA, LOOP USE "SOX"
1-770-397-11 1-770-397-11 HOUSING, CONNECTOR(PC BOA
8-749-012-72 8-749-012-72 IC GP1U58X
6-700-943-01 6-700-943-01 IC UPC2581V
8-759-333-84 8-759-333-84 IC251
8-759-333-83 8-759-333-83 IC950
1-770-336-11 1-770-336-11 JACK, PIN 2P
1-573-028-11 1-573-028-11 JACK, PIN 4P
1-770-015-11 1-770-015-11 JACK, PIN 6P
3-810-996-31 3-810-996-31 MANUAL, INSTRUCTION
6-553-201-01 6-553-201-01 Q752
8-749-010-25 8-749-010-25 Q753
8-749-010-26 8-749-010-26 Q754
1-515-918-11 1-515-918-11 RY851; CANADIAN UNIT ONLY
1-755-018-11 1-755-018-11 RY901
1-569-312-11 1-569-312-11 SOCKET, CONNECTOR (L TYRE
1-568-741-11 1-568-741-11 SOCKET,CONNECTOR 23P
1-429-529-11 1-429-529-11 TRANSFORMER, POWER
1-773-250-11 1-773-250-11 WIRE (FLAT TYPE) (27 CORE
1-769-908-11 1-769-908-11 WIRE (FLAT TYPE) (9 CORE)
