Sony

Model Number

STRDE915

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-501-659-42 1-501-659-42 ANTENNA (FM)
1-501-374-72 1-501-374-72 ANTENNA, LOOP USE "SOX"
1-777-172-12 1-777-172-12 CABLE, CONTROL , CONNECTION
1-828-145-21 1-828-145-21 CORD CONNECTION
4-931-031-11 4-931-031-11 COVER, TOP
8-719-921-20 8-719-921-20 D601,D504,D604,D501
8-719-109-54 8-719-109-54 D602,D603,D503,D502
6-700-943-01 6-700-943-01 IC 501
8-759-446-40 8-759-446-40 IC3412
1-770-966-11 1-770-966-11 PIN, CONNECTOR(V TYPE) 6P
8-729-422-57 8-729-422-57 Q503
8-729-119-76 8-729-119-76 Q504,Q604
8-749-010-25 8-749-010-25 Q506 Q606 MN2488-OPY-M
8-729-140-82 8-729-140-82 Q508 Q608 Q549
8-749-010-26 8-749-010-26 Q557
8-729-231-13 8-729-231-13 Q614 ON AMP BOARD
8-729-029-67 8-729-029-67 Q701
6-553-201-01 6-553-201-01 Q705; 2SC3623A-LK
1-249-408-11 1-249-408-11 R525,R625
1-240-855-11 1-240-855-11 R527
1-249-417-11 1-249-417-11 R540
1-249-414-11 1-249-414-11 R623 1/4W 560
1-249-419-11 1-249-419-11 R628 R528
1-215-890-11 1-215-890-11 R644 ON AMP BOARD
1-227-395-11 1-227-395-11 RV401; VOLUME CONTROL
1-515-920-11 1-515-920-11 RY701
1-569-309-11 1-569-309-11 SOCKET, CONNECTOR (L TYRE
1-431-284-11 1-431-284-11 TRANSFORMER, POWER
1-767-434-21 1-767-434-21 VIBRATOR, CRYSTAL
1-773-057-11 1-773-057-11 WIRE (FLAT TYPE) (17 CORE
1-773-324-11 1-773-324-11 WIRE (FLAT TYPE) (31 CORE
