Manufacturer
Sony
Model Number
SVF15414CXB
Description
Vaio Fit 15e Laptop
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ADHESIVE ACID BEZEL HK9 |
|
|
ANTENNA 81.EKH15.G25 (NFC) |
|
|
ANTENNA WLAN ASSY EQL0202A |
|
|
BATTERY LI3V220MAH(CR2032) |
|
|
CABLE ASSY HK9 ADAPTER |
|
|
CABLE ASSY HK9 CAMERA(4P)30V |
|
|
CABLE HKB LCD (40P)30V GLE |
|
|
CABLE HKB LCD (40P)30V XYE |
|
|
CAMERA MODULE 12P2BF147 |
|
|
CAMERA MODULE BN9P18NTK-500 |
|
|
CONDUCTIVE TAPE RAM L HK9 |
|
|
FFC HK8 USB(170MM,24P)30V |
|
|
FFC HK9 MB-TP(190MM,6P,R1A) |
|
|
FFC HK9 PSB(97.5MM,10P)30V |
|
|
FFC HKB MB-NFC(215MM,11P)30V |
|
|
GASKET TP HKD |
|
|
GASKET TP TOP HKD |
|
|
HDD (750GB,MQ01ABD075)(B)(S) |
|
|
HDD(D750GB,HTS541075A9)(B)(S) |
|
|
HK8 HDD BRACKET ASSY |
|
|
HK8 HDD BRACKET TOP ASSY |
|
|
HK8 ODD BEZEL ASSY RECY |
|
|
HK8 TOUCH PAD ASSY (B) |
|
|
HK9 HDD COVER ASSY |
|
|
HK9 HOLDER PSB BRKT ASSY |
|
|
HK9 HOUSING BEZEL ASSY |
|
|
HK9 HOUSING LCD ASSY(B,NJ) |
|
|
HK9LCD-HOUSING_BLK(S) |
|
|
HK9_PSW/B (S-DMIC) ASSY (S) |
|
|
HKA MEMORY COVER ASSY |
|
|
HKA_USB/B ASSY (S) |
|
|
HKB THER MDU ASSY 25W UMA(CHM) |
|
|
HKBMB_A10_21_UMA(S) |
|
|
HKD H-BTM ASSY W/O SP(NOISE) |
|
|
HKD SUPPORT CLICKPAD ASSY |
|
|
HKDPALM_BK_US_BL_NFC(S) |
|
|
INSULATOR MYLAR DDR HK8 |
|
|
KAPTON UL CIRCUIT HKB |
|
|
LCD UNIT (B)(S) |
|
|
LOCK 2680 RJ5 |
|
|
PORON AL FOIL DOWN NT HK9 |
|
|
PORON AL FOIL UP NT HK9 |
|
|
PORON NT LCD HK9 |
|
|
PORON NT LCD R HK9 |
|
|
Q SPECIAL APPEAR M1.6X3(NI)(NY |
|
|
Q SPECIAL APPEAR M2X1_7 BZN NY |
|
|
Q SPECIAL APPEAR M2X3(BK)(NYL) |
|
|
Q SPECIAL APPEAR M2X3.5BNI NYL |
|
|
Q SPECIAL APPEAR M2X5.5(NI)(NY |
|
|
Q SPECIAL APPEAR M2X7(NI)(NYL) |
|
|
RDVD - RECOVERY DISK |
|
|
RUBBER STOPPER DMIC HK8 SI |
|
|
SCREW M2*2-I(BNI)IRON |
|
|
SCREW M2*3-I(BNI)(NYLOK)IRON |
|
|
SCREW M2*3I(BNI)(NYLOK)IRON |
|
|
SCREW M2*4 -I(NI-3C)NYLOK)IRON |
|
|
SCREW M2*8-I(NI)(NYLOCK)IRON |
|
|
SCREW M3*3.5 I(NI-3C)IRON |
|
|
SPK MDU ASSY VAN L/R NJ(NOISE) |
|
|
SPK MODULE ASSY VAN WOOFER_NJP |
|
|
TAPE ADHESIVE ACID BASE HK9 |
|
|
THERMAL GREASE X-23-7762- |
|
|
VGP-BPS35A(U)(S) |
