Manufacturer
Sony
Model Number
SVL24112FXB
Description
Vaio 24 L Series Desktop
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ADAPTERAC(AC19V54)(Q)(S) |
|
|
ADAPTERAC(AC19V54)(Q)(S) |
|
|
ANTENNA WLAN ASSY 260-23265 |
|
|
ANTENNA WLAN QTIW1-EQL0202A |
|
|
BATTERY LI3V225MAH(CR-2032L/ |
|
|
CABLE ASSY IW1 CONTROLLER GND( |
|
|
CABLE ASSY IW1 DC-MB(1P/6P/1A) |
|
|
CABLE ASSY IW1 DMIC-MB(4P/6P/2 |
|
|
CABLE ASSY IW1 FRONT LED(12/12 |
|
|
CABLE ASSY IW1 FUN BUTTON(12/1 |
|
|
CABLE ASSY IW1 GARUDA TV(8/8P/ |
|
|
CABLE ASSY IW1 HDMI-GARUDA(31/ |
|
|
CABLE ASSY IW1 ODD(7/6P4/7P1 |
|
|
CABLE ASSY IW1 POWER BUTTON(6/ |
|
|
CABLE ASSY IW1 RCA(8P/8P/1A)30 |
|
|
CABLE ASSY IW1 RJ45-MB(8P/8P/1 |
|
|
CABLE ASSY IWI HDD(7+15P/7+15P |
|
|
GARUDA VTV-2TU |
|
|
HDD (1TBST31000524AS)(B)(S) |
|
|
HDD (1TBST31000528AS)(B)(S) |
|
|
HDD (1TBST31000528AS)(B)(S) |
|
|
HDD SPRING IW1(FDIW1001REV3A) |
|
|
IC AW8063801032301SR0MZ(B)(S) |
|
|
IC EBJ40UG8BBU0-GN-F(B)(S) |
|
|
IC HMT325S6CFR8C-PBN0(B)(S) |
|
|
IC M471B5273DH0-CK0(B)(S) |
|
|
IC M471B5773DH0-CK0(B)(S) |
|
|
IC NT4GC64B8HG0NS-DI(B)(S) |
|
|
INSULATOR TAPE TOUCH IW1(FCIW1 |
|
|
IW1 2D GLASS-ASSY BK TS+ |
|
|
IW1 CENTER CHASSIS 2D SUB ASSY |
|
|
IW1 MMB BOARD(8NS-IW100D-Q11H) |
|
|
IW1 MMB BOARD(CRW-QT-IW1-C1)-S |
|
|
IW1 REAR COVER SUB BK(RHEA GAR |
|
|
IW1 THERMAL ASSY 45W UMA CMR |
|
|
IW1 VESA BRKT ASSY BLACK |
|
|
LABEL, (3 X 2) UPC |
|
|
LCD UNIT(B)(S) |
|
|
LIGHT BAR MODULE LTB-D02819 |
|
|
ODD (SOP/SMQL/127/7800)(B)(S) |
|
|
ODD BRKT BACK IW1(FBIW1019REV |
|
|
PANEL SPACER SPONGE H IW1(GBIW |
|
|
PANEL SPACER SPONGE V IW1(GBIW |
|
|
RAM COVER IW1(FBIW1012REV3A) |
|
|
RDVD - RECOVERY DISK |
|
|
SCREW 6#-32UNC8.4-I(ZN)IRON |
|
|
SCREW M2.03.0-I(BKAG)(NYLOK) |
|
|
SCREW M25-I(BNI)(IRON) |
|
|
SCREW M3.05.0-I(NI)(NYLOK) |
|
|
SCREW T3.07.0-I(BNI)IRON |
|
|
SCREW T3.08.0-B(NI)IRON |
|
|
SYRINGE 7783D S39 |
|
|
THERMAL PAD POWER IW1(JXIW1007 |
|
|
VAIO RAW BOARD |
