Manufacturer
Sony
Model Number
SVL24125CXW
Description
Vaio L Series 24 Desktop.
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ADAPTERAC(AC19V54)(Q)(S) |
|
|
ANTENNA WLAN ASSY 260-23265 |
|
|
ANTENNA WLAN QTIW1-EQL0202A |
|
|
BATTERY LI 3V 210MAH (CR2032) |
|
|
BATTERY LI3V220MAH(CR2032) |
|
|
CABLE ASSY IW1 CAMERA-MB(6P/6P |
|
|
CABLE ASSY IW1 CIR US(3P/3P/1A |
|
|
CABLE ASSY IW1 CONTROLLER GND( |
|
|
CABLE ASSY IW1 DC-MB(1P/6P/1A) |
|
|
CABLE ASSY IW1 DMIC-MB(4P/6P/2 |
|
|
CABLE ASSY IW1 DRIVER-MB(10P/1 |
|
|
CABLE ASSY IW1 DRIVER-PANEL(6P |
|
|
CABLE ASSY IW1 FRONT LED(12/12 |
|
|
CABLE ASSY IW1 FUN BUTTON(12/1 |
|
|
CABLE ASSY IW1 GARUDA TV(8/8P/ |
|
|
CABLE ASSY IW1 HDMI-GARUDA(31/ |
|
|
CABLE ASSY IW1 HDMI-MB (40P/30 |
|
|
CABLE ASSY IW1 LVDS-GARUDA(30/ |
|
|
CABLE ASSY IW1 ODD(7/6P4/7P1 |
|
|
CABLE ASSY IW1 POWER BUTTON(6/ |
|
|
CABLE ASSY IW1 RCA(8P/8P/1A)30 |
|
|
CABLE ASSY IW1 RJ45-MB(8P/8P/1 |
|
|
CABLE ASSY IW1 TOUCH SCREEN(5/ |
|
|
CABLE ASSY IW1 TV-T(1P/1P30V |
|
|
CABLE ASSY IW1 USB(4P/4P/1A)30 |
|
|
CABLE ASSY IWI HDD(7+15P/7+15P |
|
|
CABLE FFC IW1 GARUDA-MB(93MM1 |
|
|
CABLE FFC IW1 GARUDA-QTV(140MM |
|
|
CAMERA MODULE (CN1318-P88B) 2D |
|
|
CARD WLAN/BT COMBO(Q)(S) |
|
|
CONDUCTIVE TAPE RF SIDE IW1 |
|
|
CONDUCTIVE TAPE RF UP IW1 |
|
|
CONDUCTIVE TAPE SHIELDING (JXI |
|
|
GARUDA VTV-2TU |
|
|
HDD 2TBWD20EARX-55PASB0(B)(S) |
|
|
HDD SPRING IW1(FDIW1001REV3A) |
|
|
IC AW8063801032301SR0MZ(B)(S) |
|
|
IC EBJ40UG8BBU0-GN-F(B)(S) |
|
|
IC M471B5273DH0-CK0(B)(S) |
|
|
IC NT4GC64B8HG0NS-DI(B)(S) |
|
|
INSULATOR TAPE CABLE IW1(FCIW1 |
|
|
IW1 CIR BRKT ASSY |
|
|
IW1 REAR COVER SUB BK(RHEA GAR |
|
|
IW1 THERMAL ASSY 45W UMA CMR |
|
|
IW1 VESA BRKT ASSY BLACK |
|
|
IW1 VESA BRKT ASSY WHITE |
|
|
IW3 2D CENTER CHASSIS BK TS+ |
|
|
IW3 2D CENTER CHASSIS WH TS+ |
|
|
IW3 2D GLASS ASSY BK TS+ |
|
|
IW3 CONTROLLER HOLDER ASSY |
|
|
LABEL, (3 X 2) UPC |
|
|
LCD UNIT(B)(S) |
|
|
MYLAR TV BRKT IW1(FCIW1008REV |
|
|
ODD (SOP/SMQL/127/7800)(B)(S) |
|
|
ODD BRKT BACK IW1(FBIW1019REV |
|
|
PANEL SPACER SPONGE H WO/T (GB |
|
|
PANEL SPACER SPONGE V WO/T (GB |
|
|
RAM COVER IW1(FBIW1012REV3A) |
|
|
RAM(4GB)DDR3 NT4GC64C8HG0NS-DI |
|
|
RECOVERY DISK |
|
|
SCREW 6#-32UNC8.4-I(ZN)IRON |
|
|
SCREW M2.0*2-I(NI)(NYLOK)IRON |
|
|
SCREW M2.03.0-I(BKAG)(NYLOK) |
|
|
SCREW M25-I(BNI)(IRON) |
|
|
SCREW M3.05.0-I(NI)(NYLOK) |
|
|
SCREW M311-I(BNI)(NYLOK)IRON |
|
|
SCREW T2*4-I(NI)IRON |
|
|
SCREW T2.05.0-I(NI)IRON |
|
|
SCREW T3.06.0-I(BNI)IRON |
|
|
SCREW T3.07.0-I(BNI)IRON |
|
|
SCREW T3.08.0-B(NI)IRON |
|
|
SPONGE FRONT LED IW1(GBIW1033 |
|
|
SYRINGE 7783D S39 |
|
|
THERMAL PAD PCH IW1(JXIW1006R |
|
|
THERMAL PAD POWER IW1(JXIW1007 |
|
|
VAIO RAW BOARD |
