Manufacturer
Sony
Model Number
SVT14124CXS
Description
Vaio T Series 14 Ultrabook
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
AC ADAPTOR (VGP-AC19V43)(W)(S) |
|
|
ASSY 60 KB BRKT Z40UL |
|
|
ASSY 60 ODD BEZELZ40UL |
|
|
ASSY 60-DIMM DOOR-Z40UL |
|
|
ASSY 60-HDD_BRKT-Z40UL |
|
|
ASSY 60-HDD_DOOR-Z40UL |
|
|
ASSY 60-LCASE-Z40UL |
|
|
ASSY HINGE Z41UL LH |
|
|
ASSY LCD PANEL 60 Z41UL |
|
|
ASSY TOUCHPAD |
|
|
ASSY TPK KIT(B)(S) |
|
|
ASSY TPK+LCD PANEL(B)(S) |
|
|
ASSY Z40UL UCASE + KB (US) |
|
|
ASSY Z40UL UMA TH AURAS+DELTA |
|
|
ASSY Z40UL UMA THM AURAS+ADDA |
|
|
ASSY_KB_BRKT_MYLAR_TENYIEH_Z40 |
|
|
ASSY_KB_BRKT_MYLAR_Z40UL |
|
|
ASSY_KB_BRKT_MYLAR_Z40UL |
|
|
ASSY_KB_BRKT_MYLAR_Z40UL |
|
|
BTY RTC CR2025_60MM DBV 2PIN |
|
|
BTY RTC CR2025_60MM JHT 2PIN |
|
|
C.A. DC-IN CABLE SINGATRON |
|
|
C.A. LVDS CABLE Z41UL HONG LIN |
|
|
C.A.LVDS CABLE Z41UL |
|
|
CAMERA 1.3M_HD LITEON |
|
|
CARD WLAN/BT COMBO(W)(S) |
|
|
COMPL MBX Z41UL 3227U-4G |
|
|
FFC_CARDREADER_BOARD-PTWO |
|
|
FFC_CARDREADER_BOARD-Z40UL |
|
|
FFC_FUN_BOARD-Z40UL |
|
|
FFC_FUN_BOARD-Z40UL-PTWO |
|
|
FFC_LED_BOARD-Z40UL |
|
|
FFC_LED_BOARD-Z40UL-PTWO |
|
|
FFC_TP_BOARD-Z40UL-PTWO |
|
|
FFC_USB_BOARD-Z40UL |
|
|
FFC_USB_BOARD-Z40UL-PTWO |
|
|
HDD (500GBMQ01ABD050)(B)(S) |
|
|
HDD (D500GB,ST500LT012)(B)(S) |
|
|
HDD_CABLE-Z40UL |
|
|
HDD_CABLE-Z40UL-HL |
|
|
IC AXM13S2 24GM-B(B)(S) |
|
|
LABEL, (3 X 2) UPC |
|
|
LCD UNIT(B)(S) |
|
|
ODD (HDS/SMQL/9.5/GU70)(B)(S) |
|
|
RDVD RECOVERY DISC MODEL SVT14124CXS |
|
|
SCREW (M2XL4) |
|
|
SCREW M1.4*L2 #0 D5 T:0.4/B |
|
|
SCREW M1.7*L1.7, #0, D3.5 |
|
|
SCRW IMS M2X2 NI NYLOK |
|
|
SCRW M1.6XL1.5 T0.3 D3.5 GL(LC |
|
|
SCRW M2X7,#1 T=0.8 D=4/BLACK/S |
|
|
SCRW M2XL2 T0.35 D7 GL |
|
|
SCRW M2XL3 HEAD T=0.3 BZN(BEZE |
|
|
SCRW M3*L3.5 #1 NON NYLOK |
|
|
SCRW NYLOK M2*L2.5 |
|
|
SPEAKER Z40UL FG |
|
|
SPEAKER Z40UL FG |
|
|
SPEAKER Z40UL YG |
|
|
SPEAKER Z40UL YG |
|
|
THERMAL GREASE Z1(S) |
|
|
VGP-BPS33(U)(W)(S) |
|
|
Z40UL ANT 60# ASSY ACON |
|
|
Z40UL ANT 60# ASSY WHAYU |
|
|
Z40UL CARD BOARD S2401-1(D) |
|
|
Z40UL FUN BOARD S2403-1(D) |
|
|
Z40UL I/O BOARD S2400-1(D) |
|
|
Z40UL LED BOARD S2402-1(D) |
