Model Image
Manufacturer

Sony

Model Number

VO2860

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-586-196-13 1-586-196-13 9RL-4 P.C. BOARD
7-682-547-04 7-682-547-04 B 3X6
X-3654-012-0 X-3654-012-0 BASE ASSY E-HEAD
3-654-181-00 3-654-181-00 BELT,HUM PROOF
3-654-001-00 3-654-001-00 BOTTOM PLATE
X-3642-137-3 X-3642-137-3 BRACKET ASSY
3-642-360-03 3-642-360-03 BRACKET COUNTER
3-654-050-00 3-654-050-00 BRACKET EC BOARD
3-654-040-00 3-654-040-00 BRACKET, METER
1-102-738-00 1-102-738-00 CAP CER 200PF 50V
1-109-690-41 1-109-690-41 CAP MICA 510PF 500W
1-104-987-11 1-104-987-11 CAP MYL 50V
1-131-348-00 1-131-348-00 CAP TANT 35V 1.5MF
X-3654-013-0 X-3654-013-0 CHASSIS ASSY REV
A-6730-153-A A-6730-153-A CHASSIS ASSY, REAR
X-3654-025-0 X-3654-025-0 CHASSIS L SWITCH
3-654-110-01 3-654-110-01 CHASSIS,LEFT FRONT
1-508-840-00 1-508-840-00 CONN HOUSING 9P
1-508-945-00 1-508-945-00 CONNECTOR 7P P
1-557-377-11 1-557-377-11 CORD,W/F,END 3P POWER(AEP
1-415-129-00 1-415-129-00 DELAY LINE (48X39.5X7MM)
8-719-109-89 8-719-109-89 DIODE RD5.6E(B2)
1-126-943-11 1-126-943-11 ELECT 3.3UF 50V
1-126-924-11 1-126-924-11 ELECT 330UF 10V
3-646-065-00 3-646-065-00 HOLDER
A-6730-154-A A-6730-154-A HOLDER RIGHT
8-759-901-07 8-759-901-07 IC SN74107N
8-759-708-05 8-759-708-05 IC UA78L05A-CL
A-6731-047-B A-6731-047-B L-SW ASSY
3-703-044-26 3-703-044-26 LABEL,FUSE CAUTION
X-3642-036-3 X-3642-036-3 LEVER ASSY SK SPRING
3-642-478-02 3-642-478-02 LEVER R TENSION
A-6711-101-A A-6711-101-A MCB,DM-7
A-6715-090-A A-6715-090-A MCB,DS-6
A-6715-090-C A-6715-090-C MCB,DS-6
A-6711-123-B A-6711-123-B MCB,HF-3
A-6715-066-A A-6715-066-A MCB,MA-7
A-6715-091-A A-6715-091-A MCB,PS-1
A-6711-214-A A-6711-214-A MCB,YE-2
A-6723-065-A A-6723-065-A MTD CIR BD
A-6711-100-A A-6711-100-A MTD CIR BD RE
A-6717-068-A A-6717-068-A MTD CIR BD SY-8 BD
A-6711-102-A A-6711-102-A MTD CIR IE-2 BD
3-654-184-00 3-654-184-00 ORNAM PANEL CONNECT
A-6730-151-A A-6730-151-A PANEL ASSY ,LEFT SIDE
1-586-190-12 1-586-190-12 PCB T1-3
1-586-747-00 1-586-747-00 PCB,SW-18
3-663-312-00 3-663-312-00 PLATE,COVER
1-588-557-00 1-588-557-00 PRINTED CIR BRD GH-1
3-654-055-11 3-654-055-11 PULLEY CAPSTAN
3-654-055-21 3-654-055-21 PULLEY CAPSTAN
3-654-055-31 3-654-055-31 PULLEY CAPSTAN
3-654-055-41 3-654-055-41 PULLEY CAPSTAN
3-654-055-51 3-654-055-51 PULLEY CAPSTAN
3-654-055-61 3-654-055-61 PULLEY CAPSTAN
3-654-055-71 3-654-055-71 PULLEY CAPSTAN
3-654-055-81 3-654-055-81 PULLEY CAPSTAN
3-654-055-91 3-654-055-91 PULLEY CAPSTAN
1-586-195-00 1-586-195-00 PWB DC-4
1-586-191-00 1-586-191-00 PWB FR-5
1-586-189-00 1-586-189-00 PWB IS-4
1-586-198-00 1-586-198-00 PWB JN-2
1-586-186-00 1-586-186-00 PWB PC-2
1-586-187-00 1-586-187-00 PWB RS-2
X-3654-004-0 X-3654-004-0 REAR PLATE ASSY
1-508-839-00 1-508-839-00 RECPT. M 9 PIN
1-515-198-00 1-515-198-00 RELAY DN2-DH-12
3-654-084-00 3-654-084-00 REV TEN REG STOPPER
7-682-649-09 7-682-649-09 SCREW 3X10
3-642-805-00 3-642-805-00 SCREW ADJ
7-682-663-09 7-682-663-09 SCREW, () PS 4 X 12
7-682-664-09 7-682-664-09 SCREW, () PS 4 X 14
7-682-665-09 7-682-665-09 SCREW, () PS 4 X 16
7-682-950-09 7-682-950-09 SCREW, ()PSW 3 X 12
7-682-550-04 7-682-550-04 SCREW, B3X12
7-682-554-04 7-682-554-04 SCREW,B 3 X 25
7-682-548-09 7-682-548-09 SCREW,TOT B 3 X 8
A-6703-023-A A-6703-023-A SIDE PLATE ASSY R
8-759-901-32 8-759-901-32 SN74LS132N,IC
8-759-900-14 8-759-900-14 SN74LS14N,IC
8-759-901-93 8-759-901-93 SN74LS193N IC
8-759-910-74 8-759-910-74 SN74S74N,IC
3-650-523-00 3-650-523-00 SPRING COMPRESSION
3-642-780-00 3-642-780-00 SPRING COMPRESSION
X-3654-028-2 X-3654-028-2 STAY,FRONT
3-654-019-01 3-654-019-01 SUPPORTER
1-552-746-00 1-552-746-00 SWITCH SLIDE
1-131-347-00 1-131-347-00 TANTAL 1UF 35V
1-131-349-00 1-131-349-00 TANTAL 2.2UF 10V
1-131-352-00 1-131-352-00 TANTAL 6.8UF 35V
7-682-554-09 7-682-554-09 TOTSU, B 3.0X25.0 BLK
