Model Image
Manufacturer

Sony

Model Number

WDAE550J

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
4-630-524-01 4-630-524-01 BRUSH, REMOVE ELECTRIC
8-719-801-48 8-719-801-48 DIODE 1SS193
1-698-635-11 1-698-635-11 FAN, DC
8-759-985-50 8-759-985-50 IC 74AC240SJ
8-759-985-60 8-759-985-60 IC 74AC273SJ
8-759-339-79 8-759-339-79 IC A1010B-LJ550MA-A
8-759-353-30 8-759-353-30 IC A1020B-R3MEMCNT-10
8-759-187-92 8-759-187-92 IC HM514900ATT-8
8-759-378-13 8-759-378-13 IC IDT79R3041J-16J
6-700-556-01 6-700-556-01 IC M48T18-100MH1TR
1-767-156-11 1-767-156-11 IC M4T28-BR12SH1
8-759-244-83 8-759-244-83 IC TC74AC573F
8-759-287-56 8-759-287-56 IC UPD4701AGT
1-698-592-11 1-698-592-11 MOTOR, DC (GEARED)
1-698-017-21 1-698-017-21 MOTOR, DC 450W
A-8053-745-A A-8053-745-A MOUNTED C. BOARD, DR-W2
A-8053-740-A A-8053-740-A MOUNTED C. BOARD, HN-W1
A-8053-742-A A-8053-742-A MOUNTED C. BOARD, HN-W2
A-8053-743-A A-8053-743-A MOUNTED C. BOARD, HN-W3
A-8053-739-A A-8053-739-A MOUNTED C. BOARD, HN-W4
A-8053-747-A A-8053-747-A MOUNTED C. BOARD, IF-W3
A-8053-746-A A-8053-746-A MOUNTED C. BOARD, PS-W1
A-8053-748-A A-8053-748-A MOUNTED C.BOARD,IF-W4
8-749-011-20 8-749-011-20 PHOTO RELAY AQZ105
4-630-332-01 4-630-332-01 PLATE, TOP (FRONT)
1-515-696-11 1-515-696-11 RELAY,POWER
A-8043-642-A A-8043-642-A ROLLER ASSY (R), HOOK
1-540-254-11 1-540-254-11 SOCKET, IC (PLCC)
1-692-780-21 1-692-780-21 SWITCH, SLIDE 8P
1-251-068-11 1-251-068-11 TERMINATER, ACTIVE SCSI
4-624-944-21 4-624-944-21 WINDOW, PW SWITCH
