Model Image
Manufacturer

Sony

Model Number

XR85X95K

Description

4k Hdr Mini Led Tv With Smart Google Tv

Interactive Exploded View

Parts List

Part Number Description
A-5041-950-A A-5041-950-A 22LD768A2 COMPL (UCM) (PANEL PART)
1-843-998-31 1-843-998-31 AC INLET (UCM)
1-843-998-12 1-843-998-12 AC INLET (UCM)
4-462-871-03 4-462-871-03 BAG, SCREW A (CCT) (UCM)
5-033-254-02 5-033-254-02 BEZEL BTM (4L MKY) A (UCM) (PANEL PART)
5-036-017-21 5-036-017-21 BRACKET SIDE(SGT) (UCM)
5-036-018-21 5-036-018-21 BRACKET SIDE(SGT) (UCM)
4-726-396-13 4-726-396-13 BRACKET UNDER (BM2A) (UCM)
4-724-146-14 4-724-146-14 BRACKET UNDER(BM2A (UCM)
5-009-258-21 5-009-258-21 BRACKET, WIFI(BNN) (UCM)
5-023-339-01 5-023-339-01 BRACKET,VESA(GMN) (UCM)
1-002-004-12 1-002-004-12 C18 AC INLET (UCM)
1-014-905-11 1-014-905-11 CONNECTOR ASSY 10P (SP) (UCM)
1-014-904-11 1-014-904-11 CONNECTOR ASSY 28P (UCM)
5-035-718-01 5-035-718-01 COVER TML H (3L MKY) A (UCM)
5-035-717-01 5-035-717-01 COVER TML V (3L MKY) A (UCM)
5-032-670-01 5-032-670-01 COVER,BTM(MKY) (UCM)
5-032-671-01 5-032-671-01 COVER,TOP(MKY) (UCM)
4-531-003-01 4-531-003-01 CUSHION 3525A (UCM)
4-745-335-01 4-745-335-01 FLAT CLAMP(FFC) (UCM)
1-014-854-11 1-014-854-11 FLEXIBLE FLAT CABLE 20P/25P (UCM)
1-014-842-11 1-014-842-11 FLEXIBLE FLAT CABLE 20P/25P (UCM)
1-014-855-11 1-014-855-11 FLEXIBLE FLAT CABLE 30P (UCM)
1-014-844-11 1-014-844-11 FLEXIBLE FLAT CABLE 30P (UCM)
1-014-845-11 1-014-845-11 FLEXIBLE FLAT CABLE 41P (UCM)
1-014-846-11 1-014-846-11 FLEXIBLE FLAT CABLE 51P (UCM)
5-032-673-01 5-032-673-01 GUIDE,LIGHT ILM(MKY) (UCM)
5-032-675-01 5-032-675-01 GUIDE,LIGHT LED(MKY) (UCM)
5-032-674-01 5-032-674-01 GUIDE,LIGHT OPT(MKY) (UCM)
5-032-676-01 5-032-676-01 GUIDE,LIGHT RGB(MKY) (UCM)
A-5042-262-A A-5042-262-A HR3_WW_RA_YI_OS MOUNT (UCM)
5-036-145-01 5-036-145-01 LABEL, SIDE TERMINAL (BM5S22) (UCM)
5-036-141-01 5-036-141-01 LABEL, UNDER TERMINAL (BM5S22) (UCM)
1-013-275-11 1-013-275-11 LOUDSPEAKER, FY22 TW16-19MM (UCM)
A-5044-976-A A-5044-976-A MAIN CBA_BM5S22B_FM_UCMX COMPL (UCM)
1-013-504-11 1-013-504-11 MOUNTED PWB E-T-CON (85) (UCM) (PANEL PART)
5-032-672-01 5-032-672-01 OP,INNER(MKY) (UCM)
A-5042-998-A A-5042-998-A P-MOD(YDCS085MDU02) (UCM)
1-013-592-11 1-013-592-11 POWER CBA_G29 - STATIC CONVERTER(TV) (UCM)
1-836-883-12 1-836-883-12 POWER-SUPPLY CORD (UCM)
1-912-810-11 1-912-810-11 POWER-SUPPLY CORD SET(UC) (UCM)
5-033-689-01 5-033-689-01 REAR COVER (4L MKY) A (UCM)
5-038-398-11 5-038-398-11 REFERENCE GUIDE (UCM)
1-013-691-22 1-013-691-22 REMOTE COMMANDER (RMF-TX800U) (UCM)
4-579-926-01 4-579-926-01 SCREW M3X3.0 STEP (UCM)
4-731-435-01 4-731-435-01 SCREW, +F M3X4.8 (UCM) (PANEL PART)
4-472-518-11 4-472-518-11 SCREW, +PSW M3X6 (UCM)
2-580-592-01 2-580-592-01 SCREW, +PSW M3X8 (UCM)
2-580-600-01 2-580-600-01 SCREW, +PSW M4X8 (UCM)
4-726-549-01 4-726-549-01 SCREW, M3X3 (UCM) (PANEL PART)
4-268-126-02 4-268-126-02 SCREW, ORNAMENTAL M6X12 (UCM)
5-038-399-11 5-038-399-11 SETUP GUIDE (UCM)
5-023-557-01 5-023-557-01 SHEET THERMAL(BM5S21 DDR) (UCM)
5-011-960-01 5-011-960-01 SHEET THERMAL(LMN TCON) (UCM)
4-699-975-02 4-699-975-02 SHEET, THERMAL (5567H) (UCM)
5-035-897-01 5-035-897-01 SHT, INSULATION (4L MKY) (UCM)
5-032-677-01 5-032-677-01 SILICON,MIC(MKY) (UCM)
2-650-770-31 2-650-770-31 SLIDE, CLAMP (UCM)
1-013-634-11 1-013-634-11 SP-BOX ASSY, FY22 D33-SLIT(L) (UCM)
1-013-634-21 1-013-634-21 SP-BOX ASSY, FY22 D33-SLIT(R) (UCM)
4-587-424-22 4-587-424-22 SPACER(17)+C (UCM)
5-035-720-01 5-035-720-01 STAND COVER CL (3L MKY) A (UCM)
5-035-721-01 5-035-721-01 STAND COVER CR (3L MKY) A (UCM)
5-035-719-01 5-035-719-01 STAND COVER LR (3L MKY) A (UCM)
5-034-696-01 5-034-696-01 STAND L (4L MKY) A (UCM)
5-034-697-01 5-034-697-01 STAND R (4L MKY) A (UCM)
5-037-659-01 5-037-659-01 TAPE LL REAR BTM (MKY) (UCM) (PANEL PART)
5-041-912-11 5-041-912-11 TAPE, FFC (LS) (UCM) (PANEL PART)
1-005-419-32 1-005-419-32 WLAN/BT MODULE (11AC) (UCM)
1-005-419-13 1-005-419-13 WLAN/BT MODULE(11AC) (UCM)
