Manufacturer
VIZIO
Model Number
VP50HDTV10A
Description
50" Vizio Tv Jig Vp50hdtv10a
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ACCESSARY BOX (330W*230D*50H) |
|
|
ACETATE CLOTH TAPE 20*45MM |
|
|
ACETATE CLOTH TAPE 27*75MM |
|
|
AV CABLE RCA(Y/W/R) 1800MM BLK (VINC) |
|
|
B/C LBL VIZIO VP50 HDTV10A |
|
|
BASE COVER (PD-50LM)(ABS, 877C) |
|
|
BATTERY ZN-CARBON 1.5V AA |
|
|
BROCHURE VIZIO SERIES |
|
|
CARTON BOTTOM-TRAY BLANK(VP50 HDTV10A) |
|
|
CARTON JOINT (TM-32V) |
|
|
CARTON VIZIO VP50 HDTV10A |
|
|
CONDUCTIVE FABRIC TAPE (40W*1162.6L)MM |
|
|
CONDUCTIVE FABRIC TAPE (40W*678.6L)MM |
|
|
CONTROL BOARD 6871QCH083A- FOR S/N PHLADAH |
|
|
CORNER-SUPPORT (PD-50LM)(SECC T=2MM) |
|
|
CUSHION BOTTOM-L(VP50 HDTV10A) |
|
|
CUSHION BOTTOM-R(VP50 HDTV10A) |
|
|
CUSHION TOP-L(VP50 HDTV10A) |
|
|
CUSHION TOP-R(VP50 HDTV10A) |
|
|
DECORATION PLATE VIZIO VP42 HDTV |
|
|
EDGE SADDLE DS-10 |
|
|
EDGE SADDLE DS-12 (NYLON) |
|
|
EPE BAG (1500W*1300L*1.2T)(PD-50LM) |
|
|
FILAMENT TAPE (TIBON 25WIDE) |
|
|
FILTER BRACKET RIGHT(PD-50LM)(SECC T=0.8MM) |
|
|
FILTER BRACKET TOP (PD-50LM)(SGCC T=0.8MM) |
|
|
FILTER CLIP (SPTE = 0.3MM)(PD-50LM) |
|
|
FOOT(PORON) (20L*15W*1H) |
|
|
GASKET BLOCK (12L*10W*1.5HMM) HOLE 6 F |
|
|
GASKET BLOCK (17W*21H*120L)MM |
|
|
GASKET BLOCK (20*3*12MM) (850GT) |
|
|
GASKET BLOCK (610L*8W*2H) |
|
|
HEAT SINK (PD-42S) |
|
|
HEATPATH (25X14MM) |
|
|
I/O BRACKET (PD-50LM)(SECC T=1.0MM) |
|
|
MAC SCREW-MB M4.0*10.0L,BLK_NI, NYLOK |
|
|
MAC. SCREW-MB M3.0*6.0L,BLK-NI |
|
|
MAC. SCREW-MB M4.0*10.0L, BLK-NI |
|
|
MAC. SCREW-MB M4.0*8.0L, BLK-NI |
|
|
MAC. SCREW-MF M3.0*8.0L,BLK-NI |
|
|
MAC. SCREW-MHSW #4-40*8.0L,NI |
|
|
MAC. SCREW-MPGW M4.0*8.0L,NI |
|
|
MAC. SCREW-SFW, M8.0*20.0L,BLK |
|
|
MAC.SCREW-MI M3.0*5.0L,NI |
|
|
MAC.SCREW-MPSWF M3.0*6.0L NI |
|
|
MAIN BD ASS'Y VP50 HDTV10A(LGE PDP50X4P) |
|
|
MAIN FRAME LEFT (PD-50LM)(SECC T=2.0MM) |
|
|
MAIN FRAME RIGHT (PD-50LM)(SECC T=2.0MM) |
|
|
MANUAL VIZIO VP50 HDTV10A |
|
|
NON-WOVEN FABRICS (100L*7W*0.5H) |
|
|
NON-WOVEN FABRICS (200L*7W*0.5H) |
|
|
PANEL CUSHION-H (LENGTH = 1130MM)(PD-50LM) |
|
|
PANEL CUSHION-V (LENGTH = 650MM)(PD-50LM) |
|
|
PCB SUPPORT (PD-50LT) |
|
|
PDP DISPLAY BD ASS'Y PD-50LT |
|
|
PDP IR BD ASS'Y PD-50LT |
|
|
PE BAG (120.0*170.0*0.04T)(NO.#6) |
|
|
PE BAG (180W*290L*0.04T)(PE-LD)(ACC.-1) |
|
|
PE BAG 320*230*0.04T |
|
|
POLISHING CLOTH VIZIO P42 HDTV10A |
|
|
POWER CORD 110V UL/CSA 1800MM BLK N.M. (VINC) |
|
|
QUICK SETUP GUIDE VIZIO VP50 HDTV10A |
|
|
QUICK SETUP GUIDE VIZIO VP50 HDTV10A |
|
|
REAR COVER (PD-50LM)(SGCC T=1MM, BLACK) |
|
|
REAR PLATE_L VIZIO P50 HDTV10A |
|
|
REAR PLATE_R VIZIO P50 HDTV10A |
|
|
REGISTER CARD VIZIO SERIES |
|
|
SAFETY STRAP ASS'Y (VINC) |
|
|
SERIAL NO.LBL BYD:SIGN |
|
|
SHINING PLATE (185.0*24.5*0.6T) |
|
|
SHINING PLATE VP42/VP50(185.0*24.5*0.4T) |
|
|
SOFTWARE MTK HDCP KEY W/MASK CODE (TAIWAN) |
|
|
SPEAKER 8OHM 10W BOX 1045MM CORE*1 P302GRG |
|
|
SPEAKER 8OHM 10W BOX 840MM CORE*1 P302GLG |
|
|
SPEAKER DECORATION (VP42 HDTV)(PMMA) |
|
|
SPRING PLATE(VP50) |
| 3850-0012-0301 | STAND COMPLETE W/ SCREWS |
|
|
TAP. SCREW-TB #3.0*6.0L,NI |
|
|
TAP. SCREW-TF #M3.0*8.0L, NI |
|
|
TAP. SCREW-TP #4.0*10.0L, BLK-NI |
|
|
TAP. SCREW-TRF #3.0*8.0L,NI |
|
|
TECHNOLOGY LOGO LBL VIZIO GV46L HDTV |
|
|
VIDEO BOX BD ASS'Y PD-50LT |
|
|
WARRANTY & REPAIR SHEET VIZIO(ORANGE PAPER) |
|
|
WARRANTY & REPAIR SHEET VIZIO(ORANGE PAPER) |
|
|
WH 5102110-PH7P+PH4P 995/883MM SHIELDING CORE*3 |
|
|
WH FI-W31S / FI-W31S 20276 230MM CORE*2 |
|
|
WH IDC40P-IDC40P 2651#28 100MM |
|
|
WH PH4P-EI4P 1007#24 390MM CORE |
|
|
WH PH5P+PH12P/EI7P+EI12P 1007#24 500/345MM+CORE |
|
|
WH XH5P-EI9P 1007#24 300MM CORE |
|
|
WIRE CLIP(TDY8-1A) |
|
|
WIRE SADDLE (CH-01B) |
|
|
Y-SUS BOARD EBR36223601- FOR S/N PHLADAH |
