Manufacturer
VIZIO
Model Number
VXW20LHDTV10A
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ACCESSORY BOX (VIZIO L37 HDTV) |
|
|
ACETATE CLOTH TAPE 20*20MM |
|
|
ACETATE CLOTH TAPE 20*45MM |
|
|
ACETATE CLOTH TAPE 27*75MM |
|
|
ACETATE CLOTH TAPE 60*45MM |
|
|
BASE CAB(VX20L)(ABS 94-HB,GARY)(877C) ASS'Y |
|
|
BASE FOOT ( F 18.0*1.5T,SILCON RUBBER,BLK) |
|
|
BATTERY ZN-CARBON 1.5V AA(R6KG) TOSHIBA LF |
|
|
BATTERY ZN-CARBON 1.5V AA(R6P/2S) MITSUBISHI |
|
|
BLUE TAPE (18*50MM)(KLV-20SP2) |
|
|
BROCHURE VIZIO SERIES |
|
|
CARTON VIZIO VXW20L HDTV10A |
|
|
CHASSIS (SECC T=0.8) (VX20L HDTV) |
|
|
CR SPONGE 17*8MM*3.0T (VX20L HDTV) |
|
|
CR SPONGE 182*8MM*0.5T (VX20L HDTV) |
|
|
CR SPONGE 20*20MM*5.0T (VX20L HDTV) |
|
|
CR SPONGE 25*8MM*0.5T (VX20L HDTV) |
|
|
CR SPONGE 267.8*5*0.5MM(VX20L HDTV20A) |
|
|
CR SPONGE 442*5*0.5MM(VX20L HDTV20A) |
|
|
CR SPONGE 50*42MM*0.5T (VX20L HDTV) |
|
|
CR SPONGE F 12* F 6MM*0.5T (VX20L HDTV) |
|
|
CR SPONGE F 14*0.5MM(VX20L HDTV20A) |
|
|
DISPLAY BD ASS'Y (VX20L HDTV) |
|
|
EPE BAG 650*500MM*0.5T (VX20L HDTV) |
|
|
EPS FOAM-L(VX20L HDTV) |
|
|
EPS FOAM-R(VX20L HDTV) |
|
|
FILAMENT TAPE (TIBON 25WIDE) |
|
|
FRONT BEZEL(VXW20L)(ABS 94-HB/SD-0150,P432C) ASS'Y |
|
|
GLUE SUPER X 8008(CLEAR,135ML) |
|
|
HANDLE-B FOR CARTON (L1-150T) |
|
|
HEAT SINK (30*18*5.0T) |
|
|
HINGE ASSY' (VX20L HDTV) |
|
|
INSULATOR MYLAR (VX20L HDTV) |
|
|
INSULATOR(D16*D10*T1.2)(TRANSPARENT) |
|
|
IR BD ASS'Y (VXW20L) |
|
|
LCD EARPHONE BD ASS'Y (VX20L HDTV) |
|
|
LCD MODULE 20'' TFT T200XW02 V0 (AUS) |
|
|
MAC SCREW-MI M4.0*6.0L ,NI,NYLOK |
|
|
MAC. SCREW-MHSW #4-40*8.0L,NI |
|
|
MAC. SCREW-MI M3.0*4.0L, BLK-NI |
|
|
MAC. SCREW-MI M3.0*8.0L,BLK-NI |
|
|
MAC. SCREW-MPGW M4.0*8.0L,NI |
|
|
MAC.SCREW MI M4*10.0L,NI NYLOK |
|
|
MAC.SCREW-MI M3.0*5.0L,NI |
|
|
MAC.SCREW-MPSWF M3.0*8.0L NI |
|
|
MAIN BD ASS'Y (VXW20L HDTV10A-AUO)(HDCP) |
|
|
MANUAL VIZIO VXW20L HDTV10A |
|
|
NUT 3/8 -32(W12.5*2.0T,NI)(FOR TUNER) |
|
|
PE BAG (180W*290L*0.04T)(PE-LD)(ACC.-1) |
|
|
PE BAG 320*230*0.06T |
|
|
POLISHING CLOTH VIZIO P42 HDTV10A |
|
|
POWER CORD 110V UL/CSA 1800MM BLK N.M. (VINC) |
|
|
POWER/INVERTER ASS'Y BD 0635D0264 LF |
|
|
QSG VIZIO VXW20L HDTV10A |
|
|
REAR COVER(VX20L)(ABS 94-HB,WHITE) ASS'Y |
|
|
REAR PLATE VIZIO VX20L HDTV20A |
|
|
REGISTER CARD VIZIO SERIES |
|
|
SERIAL NO.LBL BYD:SIGN |
|
|
SHIELDING (SECC T=1.0) (VX20L HDTV20A) |
|
|
SPACER SUPPORT(LBS-8)(VX20L HDTV) |
|
|
SPEAKER 3W 8OHM +WIRE 110/430MM L-F |
|
|
SPEAKER CUSHION (VX20L HDTV) |
|
|
TAP. SCREW-TB #3.0*10.0L,NI |
|
|
TAP. SCREW-TP #3.0X10.0L, NI |
|
|
TAP. SCREW-TP #4.0*16.0L,NI |
|
|
TAP. SCREW-TRF #3.0*10.0L,NI |
|
|
TECHNOLOGY LOGO LBL VIZIO VX20L/32/37 HDTV |
|
|
WARRANTY & REPAIR SHEET VIZIO(ORANGE PAPER) |
|
|
WH A1251-6/3P+A2001-4 1061#28 130MM |
|
|
WH A1251H02-10P/A1251H02-10P 1571#28 350MM |
|
|
WH A2001H02-13P-A2001H02-13P 1007#24 300MM |
|
|
WH A2001H02-7P-A2001H02-7P 1571#28 690MM |
|
|
WH P240430/FI-X30HL 300MM |
