Model Image
Manufacturer

Whirlpool

Model Number

3468XVA

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
1555258K 1555258K 3/8`` NUT & FERRULE
WP7101P485-60 WP7101P485-60 ANCHOR-TIP
74009884 74009884 BACK, MAIN
3601F208-45 3601F208-45 BAFFLE
3601F236-51 3601F236-51 BAFFLE
3601F307-45 3601F307-45 BAFFLE, BROIL
3601F353-45 3601F353-45 BAFFLE, DOOR
3601F229-45 3601F229-45 BAFFLE, OVEN BOTTOM
WP7740P058-60 WP7740P058-60 BEZEL- KNO
7401P037-60 7401P037-60 BLOCK TER
WP5504M003-19 WP5504M003-19 BOTTOM, OVEN ASSEMBLY.
4011F250-80 4011F250-80 BOX, BURNER
4011F462-80 4011F462-80 BOX, BURNER
4006D187-45 4006D187-45 BOX, VENT
WP3801F656-51 WP3801F656-51 BRACKET
74002080 74002080 BRACKET, CLOCK
74003960 74003960 BURNER, BAKE
3403D024-45 3403D024-45 BURNER, BROIL
WP3412D024-09 WP3412D024-09 BURNR-HEAD
WP9781049 WP9781049 CAMERA LENS-LIGHT
3818F052-80 3818F052-80 CHANNEL
3805F002-34 3805F002-34 CLAMP, WINDOW ASSEMBLY.
7112P003-60 7112P003-60 CLIP, DOOR LATCH HANDLE
7112P087-60 7112P087-60 CLIP, TOP LOCKING
12001613 12001613 CLOCK (BLK)
12400044 12400044 CORD, POWER
4005F421-45 4005F421-45 COVER IGN
4005F331-51 4005F331-51 COVER, MAIN BACK WIRE
4005F429-51 4005F429-51 COVER, VALVE
4005F448-45 4005F448-45 COVER, WIRE
8002P027-60 8002P027-60 DOOR LATCH ASSEMBLY.
3405F018-80 3405F018-80 DRAWER, STORAGE
74008337 74008337 DRAWER, STORAGE
WP7725P021-60 WP7725P021-60 DRIP BOWL KIT (ACCESSORY)
7744P076-60 7744P076-60 END CAP (LT)
WP7746P031-60 WP7746P031-60 END CAP (LT-BLK)
7726P050-60 7726P050-60 END CAP (LTBLK)
7744P075-60 7744P075-60 END CAP (RT)
7726P046-60 7726P046-60 END CAP (RT-BLK)
WP7746P030-60 WP7746P030-60 END CAP (RT-BLK)
WP74003430 WP74003430 END CAP, DOOR (BLK)
7744P055-60 7744P055-60 END CAP, OVEN DOOR (BLK)
4001F064-51 4001F064-51 EXTENSION
4022W007-19 4022W007-19 EXTENSION, FLUE BOX
7507P088-60 7507P088-60 FITTING, BROIL BURNER
12001074 12001074 FITTING, ORIFICE (R.R.)
W11665456 W11665456 FOOT-LEVEL
7201P050-60 7201P050-60 GASKET, BURNER
WPW10162384 WPW10162384 GASKT-DOOR
7902P321-60 7902P321-60 GLASS, DOOR (BLK)
74003431 74003431 GLASS, DOOR (OUTER-BLK)
74003320 74003320 GLASS, INNER
WP8016P015-60 WP8016P015-60 GLIDE-DRWR
WP7518P464-60 WP7518P464-60 GRATE-BRNR
W11400301 W11400301 GRATE-BRNR
8008P021-60 8008P021-60 GROMMET S
16000329 16000329 GUIDE, QUICK REF. - MAGIC CHEF
7701P103-60 7701P103-60 HANDLE, DOOR (BLK)
7701P088-60 7701P088-60 HANDLE, DOOR LATCH (BLK)
74003429 74003429 HANDLE- DO
5120D019-60 5120D019-60 HARNESS S
5170P204-60 5170P204-60 HARNESS S
5180D152-60 5180D152-60 HARNESS, CONTROL PANEL
5125A312-60 5125A312-60 HARNESS, LOOSE/BURNER BOX
12400043 12400043 HINGE
WP74011140 WP74011140 HINGE- OVE
4001F091-51 4001F091-51 HOUSING, CONTROL PANEL
74002162 74002162 HOUSING, CONTROL PANEL
12400035 12400035 IGNITER KIT
WP3413F018-19 WP3413F018-19 INSERT
7002P078-60 7002P078-60 INSULATION
74001842 74001842 INSULATION
74001084 74001084 INSULATION
74001159 74001159 INSULATION, BACK
4804F051-60 4804F051-60 INSULATION, DOOR
4804F028-60 4804F028-60 INSULATION, DOOR LATCH ASSEMBLY.
4804F014-60 4804F014-60 INSULATION, OVEN BOTTOM
4804F036-60 4804F036-60 INSULATION, WRAP
7003P063-60 7003P063-60 INSULATOR
WP7711P492-60 WP7711P492-60 KNOB- CLOC
WP74003781 WP74003781 KNOB- VALV
WP7407P182-60 WP7407P182-60 LAMP-ASM
74001069 74001069 LATCH DOO
7101P306-60 7101P306-60 LEG, LEVELING
8009P023-60 8009P023-60 LEVER, DOOR LATCH ASSEMBLY.
8009P029-60 8009P029-60 LEVER, DOOR LATCH ASSEMBLY.
WP8009P031-60 WP8009P031-60 LEVER-LOCK
8009 8009 LIGHT BULB
WP2402W271-19 WP2402W271-19 LINER-DOOR
2404F030-51 2404F030-51 LINING DR
2402W209-19 2402W209-19 LINING, DOOR
8113P066-60 8113P066-60 MANUAL, USE & CARE
74003059 74003059 MANUAL, USE & CARE
3801F267-45 3801F267-45 NLABRACKET, SWITCH
W10124350 W10124350 NOT REQUIRED PART OR SEE NOTE
7103P130-60 7103P130-60 NUT
WP3195558 WP3195558 NUT
WPW10131078 WPW10131078 NUT
7103P045-60 7103P045-60 NUT NYLON
1555-251 1555-251 NUT, LOXIT (3/8``)
7103P030-60 7103P030-60 NUT- WING
74001219 74001219 ORIFICE
7103P119-60 7103P119-60 PALNUT
74001651 74001651 PAN, BAKE BURNER
WP3401F075-19 WP3401F075-19 PAN, BROIL
7703P606-60 7703P606-60 PANEL, CONTROL (BLK)
2416F038-64 2416F038-64 PANEL, DRAWER (ALM)
74003522 74003522 PANEL, DRAWER (ALM)
74002177 74002177 PANEL, MANIFOLD (BLK)
7712P130-60 7712P130-60 PANEL, MANIFOLD (BLK)
2618F110-74 2618F110-74 PANEL, SIDE (ALM)
74003003 74003003 PEDESTAL
4020F001-80 4020F001-80 PEDESTAL
12001342 12001342 PEDESTAL S
7513P120-60 7513P120-60 PIPE MANIFOLD
3605F186-45 3605F186-45 PLATE, FITTING
WPW10282492 WPW10282492 RACK-OVEN
12001596 12001596 RANGE SPARK MODULE
74003125 74003125 RECEPTACLE, BULB
WP74006429 WP74006429 REGULATOR-
3804F245-51 3804F245-51 RETAINER, BOTTOM
74001844 74001844 RETAINER, GLASS
3804F103-51 3804F103-51 RETAINER, INSULATION (SIDE)
12001527 12001527 ROLLER, DRAWER
3406F028-51 3406F028-51 RUNNER, DRAWER
W10182835 W10182835 RUNNER, DRAWER (2)
7118P018-60 7118P018-60 SCREW
W11111008 W11111008 SCREW
7101P287-60 7101P287-60 SCREW
7101P343-60 7101P343-60 SCREW
WP3387230 WP3387230 SCREW
W10491986 W10491986 SCREW
7101P280-60 7101P280-60 SCREW
WP74004005 WP74004005 SCREW
WP74003976 WP74003976 SCREW
WP4159193 WP4159193 SCREW
W11233072 W11233072 SCREW
WP59002061 WP59002061 SCREW
WPY706189 WPY706189 SCREW
WP98008545 WP98008545 SCREW
WP7101P072-60 WP7101P072-60 SCREW
WP3351614 WP3351614 SCREW
WPW10068250 WPW10068250 SCREW
74008798 74008798 SCREW W/SHOULDER (NO.8)
7101P130-60 7101P130-60 SCREW, DOOR LATCH SWITCH
7118P015-60 7118P015-60 SCREW, HOUSING
7101P330-60 7101P330-60 SCREW, SWITCH
7208P002-60 7208P002-60 SEAL
WP854334 WP854334 SEAL-STRIP
12001655 12001655 SENSOR
3604F188-09 3604F188-09 SHIELD
3604F165-51 3604F165-51 SHIELD FL
3604F205-51 3604F205-51 SHIELD, DRAWER
8036P003-60 8036P003-60 SHIELD, SIGHT
3604F327-51 3604F327-51 SHIELD, WARMING DRAWER
8010P083-60 8010P083-60 SPACER
W10857933 W10857933 SPACER
8010P085-60 8010P085-60 SPACER RU
8010P088-60 8010P088-60 SPACER, MAIN TOP (RT)
8010P087-60 8010P087-60 SPACER- MA
3807F469-45 3807F469-45 SUPPORT
3807F480-45 3807F480-45 SUPPORT, BAKE BNR
74002312 74002312 SUPPORT, DRAWER
3807F431-45 3807F431-45 SUPPORT, MAIN TOP
3807F454-51 3807F454-51 SUPPORT, MAIN TOP (LT)
3807F453-51 3807F453-51 SUPPORT, MAIN TOP (RT)
3807F473-51 3807F473-51 SUPPORT, SPARK MODULE
3807F476-51 3807F476-51 SUPPORT, VALVE & REGULATOR
WP8004P026-60 WP8004P026-60 SUPPORT- D
7403P361-60 7403P361-60 SWITCH, DOOR DOOR LATCH
7403P363-60 7403P363-60 SWITCH, DOOR DOOR LATCH
WP7403P279-60 WP7403P279-60 SWITCH- IG
7403P067-60 7403P067-60 SWTCH-LITE
8270P095-60 8270P095-60 TAPE, DOUBLE SIDED
8270P093-60 8270P093-60 TAPE, END CAP
8270P090-60 8270P090-60 TAPE, FOIL (3`` WIDE)
2001W085-84 2001W085-84 TOP, MAIN (ALM)
74003432 74003432 TRIM, BOTTOM (BLK)
7744P105-60 7744P105-60 TRIM, BOTTOM (BLK)----NA
3608F042-09 3608F042-09 TRIM, VENT (BLK)
74006430 74006430 TUBING, BROIL BURNER (3/8``)
WP74006428 WP74006428 TUBING, REGULATOR/PIPE (3/8``)
WP74003924 WP74003924 VALVE, TOP BURNER
WP74006427 WP74006427 VALVE- OVE
7907P021-60 7907P021-60 WINDOW ASY.
5140D035-60 5140D035-60 WIRES, IGNITER
5125A354-60 5125A354-60 WIRES, LOOSE
15001191 15001191 WIRING INFORMATION
