Model Image
Manufacturer

Whirlpool

Model Number

34JN3TKXWON

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
3801F047-34 3801F047-34 *NLA*BRACKETCONTROL PANEL (R)
5415A015-60 5415A015-60 + NAT. GAS CONVERSION KIT
2620W018-90 2620W018-90 + PANEL, BKGD LOWER
1555258K 1555258K 3/8`` NUT & FERRULE
4396923 4396923 ACCESSORY PARTS, BROILER PAN AND GRID
WP7101P485-60 WP7101P485-60 ANCHOR-TIP
4002F145-45 4002F145-45 BACK, BROIL SECTION
4002F144-80 4002F144-80 BACK, MAIN
4002F094-80 4002F094-80 BACK, MAIN
4002F165-80 4002F165-80 BACK, MAIN
4002F119-45 4002F119-45 BACK,BROILER SECTION
3601F181-45 3601F181-45 BAFFLE
3601F116-45 3601F116-45 BAFFLE
3601W184-15 3601W184-15 BAFFLE
3601W125-19 3601W125-19 BAFFLE OVEN FRONT
3601W184-19 3601W184-19 BAFFLE, BAKE
3601W130-45 3601W130-45 BAFFLE, BAKE & BROIL
3601F112-51 3601F112-51 BAFFLE, FLUE BOX
3601F107-51 3601F107-51 BAFFLE, FLUE BOX TOP
3601W125-15 3601W125-15 BAFFLE, OVN FRONT
3601F106-51 3601F106-51 BAFFLE, SIDE PANEL
7401P018-60 7401P018-60 BLOCK
7401P015-60 7401P015-60 BLOCK, TERMINAL
7116P003-60 7116P003-60 BOLT
4011F200-80 4011F200-80 BOTTOM BURNER BOX
4011F157-80 4011F157-80 BOTTOM, BURNER BOX
4011F178-80 4011F178-80 BOTTOM, BURNER BOX
2205F020-15 2205F020-15 BOTTOM, OVEN
2205F020-21 2205F020-21 BOTTOM, OVEN
4006W026-15 4006W026-15 BOX, FLUE
3802F076-51 3802F076-51 BRACE, INNER SIDE
3801F021-45 3801F021-45 BRACKET
3801F093-51 3801F093-51 BRACKET
3801F198-51 3801F198-51 BRACKET
WP3801F656-51 WP3801F656-51 BRACKET
3801F024-51 3801F024-51 BRACKET
3801F118-45 3801F118-45 BRACKET C
3801F096-45 3801F096-45 BRACKET, H.L. SWIT
3801F205-45 3801F205-45 BRACKET, MODULE SUPPORT
3801F191-45 3801F191-45 BRACKET, REGULATOR MTG
3801F049-34 3801F049-34 BRACKET,CONTROL PANEL (L)
3801F179-45 3801F179-45 BRACKET. BURNER LIGHTER NLA
8003P009-60 8003P009-60 BUMPER DO
8003P002-60 8003P002-60 BUMPER DOOR (ROUND)
8003P010-60 8003P010-60 BUMPER, MAIN TOP
7505P101-60 7505P101-60 BURNER
3403A016-45 3403A016-45 BURNER ASSEMBLY BROIL
3403A015-45 3403A015-45 BURNER OVEN
7505P100-60 7505P100-60 BURNER, BAKE & BROIL
3403D028-45 3403D028-45 BURNER, BROIL
3403D027-45 3403D027-45 BURNER, OVEN
7505P187-60 7505P187-60 BURNER, TOP
7505A155-60 7505A155-60 BURNER, TOP COMPLETE
8007P003-60 8007P003-60 BUSHING S
7711P335-60 7711P335-60 BUTTON SE
7711P452-60 7711P452-60 BUTTON, CLOCK SET
7711P449-60 7711P449-60 BUTTON, CONTROL SET
7730P005-60 7730P005-60 CAMERA LENS, CLOCK
7504P005-60 7504P005-60 CAP, BURNER
8002P021-60 8002P021-60 CATCH, DOOR LOCK
3818F032-80 3818F032-80 CHANNEL - AIR DUCT
3818F025-45 3818F025-45 CHANNEL, AIR
3818F027-45 3818F027-45 CHANNEL, SWITCH
7112P072-60 7112P072-60 CLIP
7112P034-60 7112P034-60 CLIP DOOR
7112P003-60 7112P003-60 CLIP, DOOR LATCH HANDLE
7112P019-60 7112P019-60 CLIP, HINGE PIN
7112P051-60 7112P051-60 CLIP, RETAINER
7112P030-60 7112P030-60 CLIP, TOP RETAINER
7112P045-60 7112P045-60 CLIP, WIRE
WP25-7220 WP25-7220 CLIP- CABI
7601P163-60 7601P163-60 CLOCK
7601P101-60 7601P101-60 CLOCK
7601P181-60 7601P181-60 CLOCK, ELECTRONIC
7601P155-60 7601P155-60 CNTRLELEC
12400044 12400044 CORD, POWER
4005F396-80 4005F396-80 COVER MODULE
4005F194-80 4005F194-80 COVER, BACKGUARD
4005F369-80 4005F369-80 COVER, BKGD WIRE
4005F155-80 4005F155-80 COVER, BOTTOM BKDG WIRE
4005F137-80 4005F137-80 COVER, CATCH ASSEMBLY.
4005F174-80 4005F174-80 COVER, MODULE
4005F258-51 4005F258-51 COVER, OVEN VALVE
4005F139-51 4005F139-51 COVER, SWITCH
WP2411F013-71 WP2411F013-71 DOOR HANDLE
3405F008-80 3405F008-80 DRAWER, SERVICE
7427P002-60 7427P002-60 FAN ASSEMBLY
7507P028-60 7507P028-60 FITTING, BROIL BURNER
7706P177-60 7706P177-60 FRAME WIN
7706P243-60 7706P243-60 FRAME, DOOR
4012F013-80 4012F013-80 FRONT, BURNER BOX
2201F061-23 2201F061-23 FRONT, OVEN UPPER
7201P013-60 7201P013-60 GASKET
7201P037-60 7201P037-60 GASKET BU
7201P018-60 7201P018-60 GASKET WI
7201P014-60 7201P014-60 GASKET, HOUSING
7201P015-60 7201P015-60 GASKET, LAMP RETAINER
7201P036-60 7201P036-60 GASKET- OV
7910P129-60 7910P129-60 GLASS BACKGUARD
7910P042-60 7910P042-60 GLASS, BACKGUARD
7902P276-60 7902P276-60 GLASS, DOOR
WP7902P097-60 WP7902P097-60 GLASS, INNER
7902P057-60 7902P057-60 GLASS, LAMP GUARD
7902P287-60 7902P287-60 GLASS, WINDOW INNER
7902P340-60 7902P340-60 GLASS, WINDOW INNER
7902P101-60 7902P101-60 GLASS, WINDOW OUTER
8016P004-60 8016P004-60 GLIDE DRA
8016P009-60 8016P009-60 GLIDE, DRAWER
8016P005-60 8016P005-60 GLIDE, FRONT
W11400301 W11400301 GRATE-BRNR
7701P047-60 7701P047-60 HANDLE, DOOR
7701P068-60 7701P068-60 HANDLE, DOOR LATCH (BLK)
5170P007-60 5170P007-60 HARNESS OVEN SENSOR
5170P100-60 5170P100-60 HARNESS, OVEN SENSOR
3418A029-34 3418A029-34 HINGE
3418A030-34 3418A030-34 HINGE ASSEMBLY. (RT)
4001F060-45 4001F060-45 HOUSING, BAKE BURNER
4001F036-45 4001F036-45 HOUSING, BAKE BURNER
4001F020-23 4001F020-23 HOUSING, LAMP
12400035 12400035 IGNITER KIT
7432P053-60 7432P053-60 IGNITER, BURNER
WP3413F018-19 WP3413F018-19 INSERT
7728P012-60 7728P012-60 INSERT, OVEN DOOR HANDLE
12001100 12001100 KIT, TUBING W/LOXIT (3/8``)
7733P059-60 7733P059-60 KNOB
7711P172-60 7711P172-60 KNOB CLOC
7733P053-60 7733P053-60 KNOB, VALVE
7733P038-60 7733P038-60 KNOB, VALVE
7733P099-60 7733P099-60 KNOB, VALVE (BLK)
W11238392 W11238392 KNOB- CLOC
WP7711P492-60 WP7711P492-60 KNOB- CLOC
Y7101P25460 Y7101P25460 LEG, LEVELING
8009P010-60 8009P010-60 LEVER, DOOR LOCK
8009P019-60 8009P019-60 LEVER, DOOR LOCK
8009 8009 LIGHT BULB
2402W173-19 2402W173-19 LINING
2402W128-15 2402W128-15 LINING
2402W173-15 2402W173-15 LINING
4009W074-80 4009W074-80 LINING, ASSEMBLY INNER SIDE
4009W058-80 4009W058-80 LINING, INNER SIDE
7807P004-60 7807P004-60 LINK SWIT
7807P012-60 7807P012-60 LINK, DOOR LOCK
5415A016-60 5415A016-60 LP CONVERSION KIT
3413F002-23 3413F002-23 M*INSERT PAN
7513P093-60 7513P093-60 MANIFOLD PIPE
3802F050-45 3802F050-45 MBRACE, INNER SIDE NLA
3411F006-34 3411F006-34 MIXER AIR OVEN BURNER
3411F006-35 3411F006-35 MIXER, AIR
7431P016-60 7431P016-60 MODULE, SPARK
3801F115-51 3801F115-51 NLABRACKET, DRAWER
7101P031-60 7101P031-60 NLAFSCREW
2410F016-51 2410F016-51 NLAPAD, INNER
W10124350 W10124350 NOT REQUIRED PART OR SEE NOTE
WP3195558 WP3195558 NUT
WP7103P003-60 WP7103P003-60 NUT
7103P053-60 7103P053-60 NUT PUSH
1555222 1555222 NUT, LOXIT (3/16``)
1555-251 1555-251 NUT, LOXIT (3/8``)
WP7103P114-60 WP7103P114-60 NUT- SNAP
7103P030-60 7103P030-60 NUT- WING
7509P034-60 7509P034-60 ORIFICE, SEALED BURNER-NAT
12400020 12400020 OVEN BOTTOM ASSEMBLY KIT
7430P007-60 7430P007-60 OVEN SENSOR
7201P052-60 7201P052-60 PAD
2410A037-15 2410A037-15 PAD, OVEN DOOR
WP3401F075-19 WP3401F075-19 PAN, BROIL
2618F073-71 2618F073-71 PANEL
2601W199-81 2601W199-81 PANEL
2601W328-81 2601W328-81 PANEL, CONTROL (WHITE)
2614F008-80 2614F008-80 PANEL, LOWER FRONT
2618F052-71 2618F052-71 PANEL, SIDE (WHT)
2416F018-71 2416F018-71 PANEL, STORAGE DWR WHITE
7113P002-60 7113P002-60 PIN- HINGE
7513P104-60 7513P104-60 PIPE, MANIFOLD
3605F019-45 3605F019-45 PLATE, FITTING
7801P031-60 7801P031-60 RACK, OVEN
12001596 12001596 RANGE SPARK MODULE
7408P002-60 7408P002-60 RECEPTACLE, LAMP
7510P040-60 7510P040-60 REGULATOR
7510P028-60 7510P028-60 REGULATOR, PRESSURE
7510P048-60 7510P048-60 REGULATOR, PRESSURE
7428P006-60 7428P006-60 RELAY, BOARD ASSEMBLY.
3804F051-80 3804F051-80 RETAINER
3804F010-50 3804F010-50 RETAINER
3804F022-45 3804F022-45 RETAINER
3804F012-45 3804F012-45 RETAINER, LAMP GUARD
2014F001-00 2014F001-00 RING, BLACK
7107P017-60 7107P017-60 RIVET
3406F020-80 3406F020-80 RUNNER, INNER
3406F026-80 3406F026-80 RUNNER, INNER
3406F027-51 3406F027-51 RUNNER, OUTER
3406F025-51 3406F025-51 RUNNER,OUTER
7101P008-60 7101P008-60 SCREW
7101P256-60 7101P256-60 SCREW
WP7101P126-60 WP7101P126-60 SCREW
WP4159193 WP4159193 SCREW
WP59002061 WP59002061 SCREW
74009538 74009538 SCREW
WPW10068250 WPW10068250 SCREW
7101P123-60 7101P123-60 SCREW
W10491986 W10491986 SCREW
7101P043-60 7101P043-60 SCREW CON
7101P013-60 7101P013-60 SCREW, SPECIAL
7101P101-60 7101P101-60 SCREW, THERMOSTAT
7208P002-60 7208P002-60 SEAL
WP854334 WP854334 SEAL-STRIP
12001655 12001655 SENSOR
3604F016-51 3604F016-51 SHIELD
3604F132-51 3604F132-51 SHIELD, HEAT
3604F083-45 3604F083-45 SHIELD, SVC DRAWER
3604F046-80 3604F046-80 SHIELD, WIRE
7214P003-60 7214P003-60 SLEEVE
7214P004-60 7214P004-60 SLEEVE, HEAT SHRINK
7214P005-60 7214P005-60 SLEEVE, WIRE PROTECT
8010P045-60 8010P045-60 SPACER GL
8010P048-60 8010P048-60 SPACER, MAIN TOP
WP8010P069-60 WP8010P069-60 SPACER- HI
WP7803P058-60 WP7803P058-60 SPRING- OV
3420A033-34 3420A033-34 STOP OVEN
3807F349-51 3807F349-51 SUPPORT
3807F348-51 3807F348-51 SUPPORT
3807F408-45 3807F408-45 SUPPORT, CATCH ASSEMBLY.
3807F195-45 3807F195-45 SUPPORT, CATCH ASSEMBLY.
3807F193-45 3807F193-45 SUPPORT, LOCK SWITCH
3807W207-45 3807W207-45 SUPPORT, OV BOT BAR ASSEMBLY
3807F205-45 3807F205-45 SUPPORT, OVEN REAR
8004P020-60 8004P020-60 SUPPORT, RELAY BOARD
3807F219-51 3807F219-51 SUPPORT, THERM DISC
3807F329-45 3807F329-45 SUPPORT, VALVE
7403P258-60 7403P258-60 SWITCH
7403P188-60 7403P188-60 SWITCH
7403P077-60 7403P077-60 SWITCH
7403P099-60 7403P099-60 SWITCH OV
7403P087-60 7403P087-60 SWITCH, H.L. FAN
7403P187-60 7403P187-60 SWITCH, HI LIMIT
7403P067-60 7403P067-60 SWITCH, ROCKER (BLK)
7403P004-60 7403P004-60 SWITCH, THERM LOCK
12500019 12500019 SWITCH, TOP BURNER
7403P282-60 7403P282-60 SWITCH, TOP IGNITOR
WP7403P190-60 WP7403P190-60 SWITCH- BU
WP7403P287-60 WP7403P287-60 SWITCH- IG
4870F005-60 4870F005-60 TAPE 295
2001F063-91 2001F063-91 TOP, MAIN SNOW WHITE
7712A052-60 7712A052-60 TRIM ASSEMBLY
7740P010-60 7740P010-60 TRIM, BEZEL
7740P016-60 7740P016-60 TRIM, BEZEL
7726P031-60 7726P031-60 TRIM, BKGD END (LT)
7726P032-60 7726P032-60 TRIM, BKGD END (RT)
7715P016-60 7715P016-60 TRIM, BKGD TOP
7720P088-60 7720P088-60 TRIM, GLASS RET
7742P009-60 7742P009-60 TRIM, RETAINER GLASS
7506P101-60 7506P101-60 TUBE MANIFOLD FEED
8026P006-60 8026P006-60 TUBE, AIR
7506P076-60 7506P076-60 TUBE, FRONT BURNER
7506P077-60 7506P077-60 TUBE, REAR BURNER
7506P075-60 7506P075-60 TUBE, REGULATOR----NA
7502P229-60 7502P229-60 VALVE
7501P034-60 7501P034-60 VALVE, BROIL & BAKE
7501P095-60 7501P095-60 VALVE, BROIL & BAKE - NAT
7502P220-60 7502P220-60 VALVE, TOP BURNER
7502P100-60 7502P100-60 VALVE, TOP BURNER
5170P067-60 5170P067-60 WIRE HARNESS, CLOCK
5110P824-60 5110P824-60 WIRE, IGNITER FRONT
5110P825-60 5110P825-60 WIRE, IGNITER REAR
