Model Image
Manufacturer

Whirlpool

Model Number

A4TXNWFWW01

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
9790408 9790408 AIR-TOWER
606755 606755 BAG
WP2196003 WP2196003 BARRIER
WPW10225581 WPW10225581 BIMETL-DEF
WP2169142 WP2169142 BLADE-FAN
2217944 2217944 BRACKET
WPW10180172 WPW10180172 BRACKET
WP2197405 WP2197405 BRACKET
WP2151652 WP2151652 BUTTON-PLG
WP2212648 WP2212648 BUTTON-PLG
WP941839 WP941839 BUTTON-PLG
N_P N_P CABINET (NOT A SERVICEABLE PART)
WP487996 WP487996 CAP-TUBE
WPW10662129 WPW10662129 CAPACITOR
4387478 4387478 CAPACITOR (SERVICE)
WP4317852 WP4317852 CEMENT, ALUMILASTIC (1 1/4 OZ.)
549193 549193 CLAMP, POWER CORD
W10812038 W10812038 CLIP
4386951 4386951 CLIP
W10233960 W10233960 COMPRESSOR
WPW10219348 WPW10219348 CONDENSER
2215213 2215213 CONTRL-BOX
2261978 2261978 COVER
WP2202819W WP2202819W COVER
WP2183061 WP2183061 COVER
WP2217784 WP2217784 COVER
W11595196 W11595196 COVER
2264669 2264669 COVER, EVAPORATOR
WP2164186 WP2164186 CRISPER PAN
2262195 2262195 DEFLECTOR
WP2221992 WP2221992 DIFFUSER
L2316022W L2316022W DOOR ASSEMBLY WH
L2316021W L2316021W DOOR ASSEMBLY WH
WP2261963 WP2261963 DOOR HINGE
WP2166037 WP2166037 DOOR HINGE
W11129820 W11129820 DOOR TRIM
WP2266727 WP2266727 DOOR TRIM
WP2266738 WP2266738 DOOR TRIM
WP2207942 WP2207942 DOOR-COMP
W10843121 W10843121 DRIER-TUBE
WP2195916K WP2195916K ENDCAP
WP2156003 WP2156003 ENDCAP
W10251626 W10251626 ENERGY GUIDE
WP2263919 WP2263919 EVAPORATOR
W11196330 W11196330 EVAPORATOR MOTOR
W10859322 W10859322 FILLER
WP2196157 WP2196157 FITTING
WP1106508 WP1106508 GASKET
WP2319265T WP2319265T GASKET ASSEMBLY
WP2319263T WP2319263T GASKET ASSEMBLY
WP2210047 WP2210047 GLASS SHELF
WP542638 WP542638 GREASE
WP2264462 WP2264462 GROMMET
WP2163786 WP2163786 GROMMET
WP2221946W WP2221946W HANDLE
WP2202098 WP2202098 HANDLE
W10290501 W10290501 HARNS-WIRE
W10151655 W10151655 HARNS-WIRE
WP2263749 WP2263749 HEATER
WP2325482 WP2325482 HINGE
WP2325483 WP2325483 HINGE-PIN
WP2316186 WP2316186 HOOD&FOIL
W11700559 W11700559 ICEMAKER
876029 876029 INSULATION
876370 876370 INSULATION
WP2202885 WP2202885 KNOB-THERM
W11034434 W11034434 LENS-LIGHT
8009 8009 LIGHT BULB
2325418 2325418 NAMEPLATE
285002 285002 NUT
4392900 4392900 PAINT
511873 511873 PAINT
799344 799344 PAINT
24364001 24364001 PIN, COTTER
WP2189000 WP2189000 PLUG-HNDLE
W10249638 W10249638 RETAINER
939962 939962 RIVET
WP2264756 WP2264756 RIVET
WPW10142530 WPW10142530 ROLLER-CAB
WPW10475495 WPW10475495 ROLLER-CAB
WPW10133299 WPW10133299 SCREW
WP489497 WP489497 SCREW
WP488729 WP488729 SCREW
WP8281206 WP8281206 SCREW
WP489357 WP489357 SCREW
WP488921 WP488921 SCREW
WP489174 WP489174 SCREW
WP489399 WP489399 SCREW
WP489474 WP489474 SCREW
WP489478 WP489478 SCREW
WP489442 WP489442 SCREW
WP487353 WP487353 SCREW
WP965173 WP965173 SCREW
8533892 8533892 SCREW
WP505587 WP505587 SEALER
WP503695 WP503695 SEALER
212643 212643 SEALER-GUM
W10212088 W10212088 SERVICE AND WIRING SHEET
WP2192515 WP2192515 SHELF-WIRE
WPW10401596 WPW10401596 SHELF-WIRE
2319224 2319224 SHIELD
WP2201567 WP2201567 SHIM
2166043 2166043 SHIM, HINGE CENTER (WHITE)
2258452 2258452 SPACER
2176844 2176844 SPACER
W10892065 W10892065 START-DEV
WPW10222451 WPW10222451 SUPPORT
8201619 8201619 SUPPORT-EV
W11384469 W11384469 SWITCH
W11238399 W11238399 TAPE
833938 833938 TERMINAL
WPW10567140 WPW10567140 THERMOSTAT
WP2183003 WP2183003 THIMBLE
WPW10339879 WPW10339879 TIE-WIRE
W10822278 W10822278 TIMER-DEF
WP1117510 WP1117510 TORX SCREW WRENCH, TORX KEY
WP2176668 WP2176668 TRAY-EVAP
W10212090 W10212090 TUBE
2320728 2320728 TUBE
4392899 4392899 TUCHUP
72017 72017 TUCHUP
72032 72032 TUCHUP
W10214129 W10214129 USE AND CARE GUIDE
978026 978026 VALVE
978027 978027 VALVE
978029 978029 VALVE
978030 978030 VALVE
876764 876764 VALVE
WP978025 WP978025 VALVE
978028 978028 VALVE, ACCESS
WP487802 WP487802 WASHER
2176927 2176927 WIRE ASSEMBLY (CONTROL BOX)
