Manufacturer
Whirlpool
Model Number
ACQ214XM0
Description
Room Air Conditioner
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
19 X 12 X 14`` |
|
|
ACCESS VALVE (3/4``) |
|
|
ADHESIVE |
|
|
ADHESIVE,INSULATION (2OZ TUBE) |
|
|
ANGLE, TOP MOUNTING |
|
|
ANGLE-SIDE |
|
|
BAG, ACCESSORY |
|
|
BASE |
|
|
BLADE, FAN (CONDENSER) |
|
|
BOARD-FILL |
|
|
BOLT, 1/4 X 3/4 (6) |
|
|
BOX-CONTRL |
|
|
BRACKET, FAN MOTOR |
|
|
BRACKET, WINDOW LOCK |
|
|
CABINET |
|
|
CAPACITOR |
|
|
CAPSL-OIL |
|
|
CARTRIDGE |
|
|
CLAMP (2) |
|
|
CLIP, ANTICIPATOR |
|
|
CLIP- MOTO |
|
|
COMPRESSOR |
|
|
CONDENSER |
|
|
CORD, RETAINER (WINTER COVER) |
|
|
CORDPOWER |
|
|
COVER, CONTROL BOX |
|
|
COVER, TERMINAL |
|
|
COVER, WINTER (22``X15``X3 TO 18``) |
|
|
COVER, WINTER (27``X19``X6 TO 27``) |
|
|
COVER, WINTER (28 X 19 X 31``) |
|
|
CUP, CONDENSATE |
|
|
DAMPENER |
|
|
DISTRIBUTR |
|
|
DIVIDING WALL |
|
|
DOOR, FILTER |
|
|
DOOR-EXHST |
|
|
ENERGY GUIDE |
|
|
EPOXY, TUBE (ALUMINUM REPAIR) |
|
|
EVAPORATOR |
|
|
FILTER |
|
|
FRAMEFRNT |
|
|
FRONT |
|
|
GASKET, TERMINAL COVER |
|
|
GROMMET |
|
|
HANDLE, BASE |
|
|
HARNS-WIRE |
|
|
HOUSING, AIR |
|
|
LINK-LOUVR |
|
|
LITERATURE PARTS (USE & CARE GUIDE) |
|
|
LITERATURE PARTS (WIRING DIAGRAM) |
|
|
LOCKNUT (3) |
|
|
LOCKWASHER (6) |
|
|
LOUVER-VT |
|
|
MISCELLANEOUS, SEALER |
|
|
MOTOR-FAN |
|
|
NUT |
|
|
NUT |
|
|
NUT, 1/4-20 (6) |
|
|
NUT-MTG |
|
|
PAN, DRAIN |
|
|
PANEL, CONTROL |
|
|
PUTTY, SOUND DAMPENER |
|
|
REFRIGERANT CHARGE 30.00 OZ. |
|
|
REMOTE CONTROL |
|
|
RETURN BEND REPLACEMENTKIT (3/8 INCH TUBE) |
|
|
RETURN BEND REPLACEMENTKIT (5/16 INCH TUBE) |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW (SIDE ANGLE TO FILLER BOARD) |
|
|
SCREW (WINDOW LOCK BRACKET) |
|
|
SCREW, NO.8-18 X 3/8``, HWHTCS |
|
|
SEAL |
|
|
SEAL, MEETING RAIL |
|
|
SEAL, RESTRICTOR TUBE |
|
|
SEAL, SHROUD |
|
|
SEAL, SUCTION TUBE |
|
|
SEAL-STRIP |
|
|
SEAL-STRIP |
|
|
SEAL-STRIP |
|
|
SEALER, PERMAGUM (4 - 12`` STRIPS) |
|
|
SHROUD ASSEMBLY, EVAPORATOR |
|
|
SHROUD, CONDENSER |
|
|
SPACER |
|
|
STRAINER, TUBE |
|
|
SUPPORT |
|
|
SUPPORT |
|
|
SUPPORT, RETAINER (2) |
|
|
TAPE |
|
|
TAPE, NO DRIP 30` |
|
|
TIE-WIRE |
|
|
TOP PARTS NOT ILLUSTRATED AND OPTIONAL PARTS (NOT INCLUDED) (VALVE, ACCESS (5/16``)) |
|
|
TOP, CONDENSER |
|
|
TUBE, CONNECT |
|
|
TUBE, DISCHARGE |
|
|
TUBE, FLOW DIVIDER |
|
|
TUBE, OUTLET (INCLUDES 4) |
|
|
TUBE, RESTRICTOR (4) |
|
|
TUBE, SUCTION |
|
|
TUBE-CRSVR |
|
|
TUBE-MNFLD |
|
|
VALVE, ACCESS ((3/8``) TUBE) |
|
|
VALVE, ACCESS (1/2`` TUBE O.D.) |
|
|
VALVE, ACCESS (1/4``) |
|
|
VALVE, ACCESS (5/8) |
|
|
VALVE,ACCESS (3/16) |
|
|
WASHER |
|
|
WASHER |
|
|
WASHER |
|
|
WASHER |
|
|
WHEEL, BLOWER (EVAPORATOR) |
|
|
WIRE |
|
|
WIRE |
|
|
WIRE (14 GA. 150 C BLACK) |
|
|
WIRE (16 GA. 80 C BLUE) |
|
|
WIRE ASYB |
|
|
WIRE, 25`` ROLL (BLACK 12 GA.) |
|
|
WIRE, 25`` ROLL (WHITE 12 GA.) |
|
|
WIRE, 25`` ROLL (WHITE 14 GA.) |
|
|
WIRE, GROUND |
