Model Image
Manufacturer

Whirlpool

Model Number

AFD2535FES

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
12002500 12002500 ADAPTER, SIDE (RT)
WP627843 WP627843 ARM-EJECTR
WP67004028 WP67004028 ARM-SHUT
WP2182124 WP2182124 ARM-STRIPR
67006434 67006434 AXLE, ROLLER
WP67003795 WP67003795 BAR- TEMP
12457108 12457108 BASEPAN
67004987 67004987 BASKET, FRZ. (UPR)
WPW10503184 WPW10503184 BASKET-FZR
WPW10289497 WPW10289497 BIN CONTROL LEVER
WPW10451506 WPW10451506 BIN CONTROL LEVER
WPW10371193 WPW10371193 BIN CONTROL LEVER
W10156818 W10156818 BLADE, FAN
WP2169142 WP2169142 BLADE-FAN
WP12777701 WP12777701 BLOCK- FIL
WP67003405 WP67003405 BLOCK- PIV
WP12642303WD WP12642303WD BRACE- CRI
WP2256087 WP2256087 BRACKET
WPW10280613 WPW10280613 BRACKET
WPW10280608 WPW10280608 BRACKET
WP67005633 WP67005633 BRACKET
WP67004953 WP67004953 BRACKET
12456801V 12456801V BRACKET, FOOT
12906303WD 12906303WD BRACKET, FOOT CABINET
WP12812502WD WP12812502WD BRACKET- D
WP12812501WD WP12812501WD BRACKET- D
WP67002731 WP67002731 BUSHING- D
WP67002721 WP67002721 BUSHING- D
WP2315522 WP2315522 CLIP
W11673433 W11673433 CLIP
WPM0104106 WPM0104106 CLIP
67007052 67007052 CLIP, CAPACITOR
M0104102 M0104102 CLIP, CORD
67001067 67001067 CLIP, DRAIN TUBE
10547002 10547002 CLIP, DRIER
10623002 10623002 CLIP, EVAPORATOR
67002816 67002816 CLIP, WATERLINE
WPM0114003 WPM0114003 CLIP- SPEE
WP12627302 WP12627302 CLIP- TOE
WP67003639 WP67003639 CLOSER
W10160407 W10160407 COMPRESSOR KIT (CONTAINS ITEMS 12, 17, 27, & 29)
WP67006131 WP67006131 CONDENSER
WP10423131 WP10423131 CONTAINER
WPW10196393 WPW10196393 CONTROL
W11519867 W11519867 COVER
W10720642 W10720642 COVER
W10827015 W10827015 COVER
W11284721 W11284721 COVER
67003485 67003485 COVER, CORNER (BLK)
67003905 67003905 COVER, FZ LIGHT
W10177767 W10177767 COVER, LEFT HINGE (BLACK)
67006101 67006101 COVER, MC BACK
12684202B 12684202B COVER, TOP HINGE (RT-BLK)
12726003 12726003 COVER, WATER LINE
67004098 67004098 COVER, WATER VALVE
WP12568001 WP12568001 COVER- FIL
WP67003924 WP67003924 COVER- FZ
WP12806701 WP12806701 COVER-BOX
W11727809 W11727809 COVER-EVAP
WP628356 WP628356 CUP-FILL
12225601 12225601 DAM, LEFT RETURN
67001084 67001084 DAM, RIGHT RETURN
WP67002759 WP67002759 DIVIDER
67006644 67006644 DIVIDER, BASKET
67004127 67004127 DIVIDER, BASKET (UPPER)
13024203SQ 13024203SQ DOOR ASSEMBLY., FRZ. FOAM (STNLS)
13024004SQ 13024004SQ DOOR ASSEMBLY.,LT REF FOAM (STNLS)
13024003SQ 13024003SQ DOOR ASSEMBLY.,RT REF FOAM (STNLS)
WP12744905 WP12744905 DOOR COMP
WP12566606ED WP12566606ED DOOR HINGE
W10918164 W10918164 DOOR HINGE
WP12566607ED WP12566607ED DOOR HINGE
WP12722803B WP12722803B DRAWER SLIDE RAIL
WP67003531 WP67003531 DRAWER- PA
WPB2150504 WPB2150504 DRIER
W10874836 W10874836 ENDCAP
WPW10128551 WPW10128551 EVAPORATOR MOTOR
WP67006010 WP67006010 EXTR- GLAS
W11177593 W11177593 FEET-LVLNG
67003796 67003796 FIBER, ACOUSTIC
EDR4RXD1 EDR4RXD1 FILTER
WP2300868 WP2300868 FITTING
WP67003854 WP67003854 FRAME- CRI
WPW10289690 WPW10289690 FRONT COVER
12002756 12002756 FROST KIT, S X S DOMESTIC
W10815413 W10815413 FUNNEL
W10856123 W10856123 GASKET
W11451451 W11451451 GASKET
W11368721 W11368721 GASKET ASSEMBLY
W10436252 W10436252 GASKET, DOOR (BLACK)
B5759649 B5759649 GASKET, MC BACK
67002329 67002329 GASKET, PANTRY
WPB8381501 WPB8381501 GASKET- DR
12002497 12002497 GEAR (INCLDS. BOTH)
WP67002761 WP67002761 GLASS, PANTRY
WP67006704 WP67006704 GLASS- CRI
WPW10235370 WPW10235370 GLIDE
WPW10175909 WPW10175909 GRILLE
WPW10534153 WPW10534153 GRILLE-FRT
W10450024 W10450024 GRIPPER, BUCKET (GALLON)
W10450022 W10450022 GRIPPER, BUCKET (MEDIUM)
67003493 67003493 GROMMET, COMPRESSOR
67005680 67005680 GROMMET, CONDENSER
12732802 12732802 GROMMET, FAN MOTOR (TAN)
WP61004743 WP61004743 GROMMET- B
WPW10136873 WPW10136873 HANDLE
10508506 10508506 HANDLE, BASKET/SHELF
67003931 67003931 HARNESS, EVAP HEATER
67006094 67006094 HARNESS, FZ MODULE
67004955 67004955 HARNESS, MC
WP67002493 WP67002493 HEATER- DE
WP67006524 WP67006524 HOUSING
W11702858 W11702858 HOUSING
12656202 12656202 HOUSING, CONTROL
12806601 12806601 HOUSING, LIGHT
WP2195914 WP2195914 HOUSING-IM
D7824706Q D7824706Q ICE MAKER ASSEMBLY.
8003RP 8003RP ICEMAKER INSTALL KIT
WP67006531 WP67006531 INLET VALVE
67003900 67003900 INSERT, DAMPER COVER
WPA3223101 WPA3223101 INSERT- PL
WP13012402 WP13012402 INSULATION
12002041 12002041 KIT, EVAP REPLACEMENT
12002023 12002023 KIT, WATER TANK
W11498983 W11498983 KNOB
67001073 67001073 LADDER, CENTER
67002489 67002489 LADDER, L/R SIDE
10436404 10436404 LID, UTILITY
W11679940 W11679940 LIGHT BULB
67007094 67007094 MANUAL, USE & CARE
67003906 67003906 MODULE, FZ CONTROL
67004078 67004078 MODULE, LIGHT
67004005 67004005 MODULE, REF CONTROL
W11613295 W11613295 MOTOR-COND
Y12528501 Y12528501 NAMEPLATE (AMANA PLUS)
M0286708 M0286708 NUT, SPEED
W10317181 W10317181 OVERLAY
WP67005915 WP67005915 PAN, CRISPER
WP12579803 WP12579803 PAN- DRAIN
WP67001255 WP67001255 PAN-ICE
WP67006642 WP67006642 PIN
WP67006113 WP67006113 PLATE
WP67001668 WP67001668 PLATE- FIL
WPA3076901 WPA3076901 PLUG, BUTTON
WP12664501 WP12664501 PLUG, BYPASS
67004838 67004838 PLUG, VENT (BLK)
A4539607 A4539607 POP RIVET
WP67006506 WP67006506 POWER CORD
WPW10326469 WPW10326469 RAIL-CENTR
WPM1205302 WPM1205302 RIVET
WP10450603 WP10450603 ROLLER
WP67005149 WP67005149 ROLLER
WP12580304 WP12580304 ROLLER BRACKET ASSEMBLY
WP67006415 WP67006415 SCREW
WP67006380 WP67006380 SCREW
W11233072 W11233072 SCREW
WP8281196 WP8281196 SCREW
WP489349 WP489349 SCREW
W10709795 W10709795 SCREW
WP681249 WP681249 SCREW
WP3387230 WP3387230 SCREW
67006608 67006608 SCREW
WP489474 WP489474 SCREW
WP33001882 WP33001882 SCREW
W10709798 W10709798 SCREW
71003131 71003131 SCREW
W10709797 W10709797 SCREW
WP400021-1 WP400021-1 SCREW
WP67004954 WP67004954 SCREW
12992301 12992301 SCREW
WP98165 WP98165 SCREW
WP489128 WP489128 SCREW
12846902 12846902 SCREW (2)
12991101 12991101 SCREW, HANDLE (BLACK)
67006425 67006425 SCREW, SM
67006564 67006564 SCREW, SM/HEX
WPM0500703 WPM0500703 SEAL- O RI
WP854334 WP854334 SEAL-STRIP
W11028221 W11028221 SHAFT
16023133 16023133 SHEET, TECH DATA
WP67004637 WP67004637 SHELF, GLIDE OUT
12579702 12579702 SHIM, TOP HINGE
67001090 67001090 SHROUD, CONDENSER FAN
67002777 67002777 SHROUD, EVAP FAN
WP67005864 WP67005864 SLIDE
WP67006607 WP67006607 SLIDE
WP67003793 WP67003793 SLIDE- TEM
W11447232 W11447232 SOCKET
W10613606 W10613606 START-DEV
W11708403 W11708403 STOP-DOOR
WP12227305WD WP12227305WD SUPPORT
WP12603701 WP12603701 SUPPORT- C
16025629 16025629 SVC MAN, BTM MT
12831101 12831101 SWEEP-WATER VALVE
W11396033 W11396033 SWITCH
W11384469 W11384469 SWITCH
WP12575501 WP12575501 SWITCH- LI
16026954 16026954 TECH SHT, BTM MT
12002355 12002355 THERMISTOR KIT
WP67003426 WP67003426 THERMOSTAT
WP67001719 WP67001719 TRACK
67004102 67004102 TRACK, WATERLINE
10436506 10436506 TRAY, EGG
WP67001279 WP67001279 TRAY- DAIR
W11547653 W11547653 TRAY-DRIP
WPW10231344 WPW10231344 TRIM-SHELF
67001656 67001656 TRIVET, BOTTLE
WP12866903 WP12866903 TUBE
WPB5705307 WPB5705307 TUBE
67001066 67001066 TUBE, DRAIN
W11176463 W11176463 WATER TUBE
WP12868601 WP12868601 WIRE HARNESS
WPD7813010 WPD7813010 WIRE HARNESS
15003922 15003922 WIRING INFORMATION
