Model Image
Manufacturer

Whirlpool

Model Number

ATF1836ARQ

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
61005173 61005173 ARM, SENSOR
WP627843 WP627843 ARM-EJECTR
WP2182124 WP2182124 ARM-STRIPR
WP627985 WP627985 BIMETL-DEF
63002045 63002045 BLADE, EVAPORATOR FAN
63001018 63001018 BLADE- CON
63001252 63001252 BOLT
63001251 63001251 BOLT
WP2256087 WP2256087 BRACKET
63001020 63001020 BRACKET F
63001063 63001063 BRACKET, EVAPORATOR FAN
63001023 63001023 BRACKET, VALVE
63001058 63001058 BUSHING E
63001075 63001075 CAP BUSHI
63001414 63001414 CAP CENTE
63001022 63001022 CAP DRAIN
63001114 63001114 CAP HINGE
63001078 63001078 CAP HINGE
63001005 63001005 CAPACITOR
876595 876595 CAPACITOR
W10833902 W10833902 CLAMP
WP2315522 WP2315522 CLIP
63001019 63001019 CLIP FAN
63001053 63001053 CLIP FUSE
63001346 63001346 CLIP POWE
M0104102 M0104102 CLIP, CORD
63001813 63001813 CLIP, FAN BLADE
63001014 63001014 CLIP, RELAY COVER
61005175 61005175 CLIP, SENSOR ARM
63001050 63001050 CLIP- DEFR
63001351 63001351 CLIP- KICK
WPM0114003 WPM0114003 CLIP- SPEE
W10309989 W10309989 COMPRESSOR
63001245 63001245 CONDENSER
63001358 63001358 CONTROL ASSEMBLY., TEMPERATURE
63001420 63001420 CORD, POWER
63001499 63001499 COVER AIR
63001447 63001447 COVER EVA
63001449 63001449 COVER LIG
63001348 63001348 COVER MAC
63001013 63001013 COVER REL
63001407 63001407 COVER UPP
63001507 63001507 COVER, FAN
61005374 61005374 COVER, ICE MAKER
WP628356 WP628356 CUP-FILL
63001471 63001471 DAMPER/INSULATION ASSEMBLY.
63001513 63001513 DOOR ASSEMBLY. REF.(BSQ)!!
63001509 63001509 DOOR ASSEMBLY., FREEZER (BSQ)
63001397 63001397 DOOR, DAIRY
WPW10143759 WPW10143759 DRIER-UV
63001477 63001477 DUCT ASM
61005174 61005174 EXTENSION
63001518 63001518 FRAME SHE
63001523 63001523 FRAME SHE
63001052 63001052 FUSE
63001374 63001374 GLASS, CRISPER SHELF
95099-1 95099-1 GREASE, SILICONE
WP63001006 WP63001006 GROMMET, COMPRESSOR
63001074 63001074 GROMMET, FAN MOTOR
WP61005940 WP61005940 GROMMET, FILL TUBE
63001017 63001017 GROMMET- B
63001387 63001387 HEATER, DEFROST
W10851465 W10851465 HINGE- CEN
63001408 63001408 HINGE- UPP
63001128 63001128 HINGE-LOWE
63001473 63001473 HOUSING C
D7824706Q D7824706Q ICE MAKER ASSEMBLY.
WP61005273 WP61005273 INLET VALVE
63001478 63001478 INSULATION
63001350 63001350 KICKPLATE
12002519 12002519 KIT, EVAPORATOR
63001497 63001497 KNOB FREE
63001355 63001355 KNOB- TEMP
63001439 63001439 LABEL, ENERGY GUIDE
63001025 63001025 LEG, LEVELING
63001472 63001472 LEVER DAM
W11679940 W11679940 LIGHT BULB
3013913000 3013913000 MANUAL, USE & CARE
63001057 63001057 MOTOR, EVAPORATOR FAN
63001021 63001021 MOTOR- CON
63001415 63001415 NAMEPLATE
WP245183 WP245183 NUT
63001004 63001004 OVERLOAD
63001347 63001347 PAN DRAIN
63001377 63001377 PAN, CRISPER
63001373 63001373 PAN, DELI
WP61001886 WP61001886 PAN, ICE
63001002 63001002 PIN WHEEL
63001089 63001089 PIN- LOWER
63001357 63001357 PLATE BUL
63001519 63001519 RAIL DELI
63001520 63001520 RAIL DELI
63001498 63001498 RAIL SHEL
63001517 63001517 RAIL SHEL
63001380 63001380 RAIL, CRISPER SUPPORT
63001356 63001356 RECEPTACLE
63001448 63001448 RECEPTACLE, BULB
63001003 63001003 RELAY- PTC
63001062 63001062 RETAINER
WP1163283 WP1163283 SCREW
63001277 63001277 SCREW
WP400021-1 WP400021-1 SCREW
63001488 63001488 SCREW
63001226 63001226 SCREW
W10142289 W10142289 SCREW
63001234 63001234 SCREW
63001231 63001231 SCREW
2256637 2256637 SCREW
65275-81 65275-81 SCREW
67006425 67006425 SCREW
63001092 63001092 SCREW
63001276 63001276 SCREW
WP489399 WP489399 SCREW
63001093 63001093 SCREW
63001091 63001091 SCREW
8169475 8169475 SCREW
WP8281227 WP8281227 SCREW
61005388 61005388 SCREW
63001255 63001255 SCREW
WP489128 WP489128 SCREW
63001429 63001429 SEAL
63001427 63001427 SEAL
63001426 63001426 SEAL
63001425 63001425 SEAL
63001424 63001424 SEAL
63001379 63001379 SEAL CRIS
63001360 63001360 SEAL DAMP
63001384 63001384 SEAL EVAP
63001385 63001385 SEAL EVAP
63001381 63001381 SEAL, CRISPER SHELF (REAR)
63001399 63001399 SEAL, F.F. DOOR (WHT)
63001418 63001418 SEAL, FRZ. DOOR (WHT)
Y00000000 Y00000000 SEE NOTE (BASE PAN NOT AVAILABLE)
16025860 16025860 SERV MAN
63001516 63001516 SHELF ASSEMBLY., PICK OFF
63001524 63001524 SHELF SPI
63001522 63001522 SHELF SPI
63001375 63001375 SHELF, CRISPER
63001398 63001398 SHELF, DAIRY COMPT.
63001389 63001389 SHELF, FRZ.
63001419 63001419 SHELF, PICK OFF
63001401 63001401 SHELF, PICK OFF
63001015 63001015 SHROUD CO
WP487627 WP487627 SLEEVE
63001500 63001500 SLIDE CON
WP63001008 WP63001008 SPRING, COMPRESSOR
63001479 63001479 STOP AIR
63001438 63001438 STOP DOOR
63001394 63001394 STOP- DOOR
63001045 63001045 SUPPORT C
W11291138 W11291138 SWITCH
16023494 16023494 TECH SHT,TOP MT
63001388 63001388 THERMOSTAT, DEFROST (2 WIRE)
63001353 63001353 TIMER- DEF
63001386 63001386 TRAY DRIP
WPB5705307 WPB5705307 TUBE
63001506 63001506 TUNNEL ASY
63001486 63001486 WASHER
WP63001007 WP63001007 WASHER, COMPRESSOR
63001079 63001079 WASHER, HINGE
63001443 63001443 WHEEL ASSEMBLY. (FRT)
63001001 63001001 WHEEL REA
63001011 63001011 WIRE GROU
63001450 63001450 WIRE HARNE
63001359 63001359 WIRE HARNE
63001028 63001028 WIRE HARNE
63001012 63001012 WIRE HARNE
WP61001882 WP61001882 WIRE HARNESS
63001059 63001059 WIRE HARNESS, FRZ.
15003630 15003630 WIRING INFORMATION
