Model Image
Manufacturer

Whirlpool

Model Number

CB19G7B13

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
67006434 67006434 AXLE, ROLLER (2)
67006914 67006914 BASEPAN
W10503182 W10503182 BASKET, FREEZER (LOWER)
67004985 67004985 BASKET, FREEZER (UPPER)
WP67001040 WP67001040 BELT- DAMP
W10156818 W10156818 BLADE, FAN
WP2169142 WP2169142 BLADE-FAN
67005491 67005491 BLOCK, CONDENSER
WPW10330991 WPW10330991 BRACKET
WPW10330993 WPW10330993 BRACKET
WPW10280608 WPW10280608 BRACKET
WPW10280613 WPW10280613 BRACKET
WPW10284680 WPW10284680 BRACKET
WPW10284681 WPW10284681 BRACKET
WP67004953 WP67004953 BRACKET
12906303WD 12906303WD BRACKET, FOOT (2)
12737704 12737704 BUCKET, SHORT (1)
67001141 67001141 BUCKET, SMALL (2)
WP67001021 WP67001021 BUCKET- ME
67004978 67004978 BUSHING (4) (BLACK)
WP67004977 WP67004977 BUSHING- D
WP67001130 WP67001130 BUTTON- PL
100000 100000 CABINET (NOT A SERVICABLE PART)
WP4317852 WP4317852 CEMENT, ALUMILASTIC (1 1/4 OZ.)
31462A 31462A CLEANER, 10 OZ. STAINLESS STEEL
W10131991 W10131991 CLIP
13058002 13058002 CLIP
67001067 67001067 CLIP, DRAIN TUBE
10623002 10623002 CLIP, EVAPORATOR
10547003 10547003 CLIP- DRIE
W11673433 W11673433 CLIP- EVAP
WP67003638 WP67003638 CLOSER
WP67003639 WP67003639 CLOSER
W10170276 W10170276 COMPRESSOR
67006133 67006133 CONDENSER
WP10423131 WP10423131 CONTAINER
WP67003000 WP67003000 CONTROL- F
67003485 67003485 COVER, CORNER (BLACK)
67003484 67003484 COVER, CORNER (WHITE)
12694401 12694401 COVER, DAMPER
12226107 12226107 COVER, EVAPORATOR
67001012 67001012 COVER, HINGE (BLACK)
67001014 67001014 COVER, HINGE (WHITE)
67001285 67001285 COVER, LIGHT
67002301 67002301 COVER, LIGHT
67006101 67006101 COVER, UNIT
67001173 67001173 COVER, WATER VALVE
WP67001098 WP67001098 COVER-TUBE
W10833528 W10833528 CRISPER PAN
12225601 12225601 DAM (LEFT SIDE)
67001084 67001084 DAM (RIGHT SIDE)
WP67003410 WP67003410 DAMPER GEA
67006644 67006644 DIVIDER, BASKET (LOWER)
67004127 67004127 DIVIDER, BASKET (UPPER)
WP12607104ED WP12607104ED DOOR HINGE
WP12566606ED WP12566606ED DOOR HINGE
12658529BQ 12658529BQ DOOR, REFRIGERATOR (BLACK)
12658529WQ 12658529WQ DOOR, REFRIGERATOR (WHITE)
WP67003637 WP67003637 DOOR-COMP
13092201BQ 13092201BQ DOR-FIP BL
13092201WQ 13092201WQ DOR-FIP WH
WPW10143759 WPW10143759 DRIER-UV
12002051 12002051 EVAPORATOR
WPW10128551 WPW10128551 EVAPORATOR MOTOR
10459930 10459930 EXTR- FRON
W11177593 W11177593 FEET-LVLNG
4396418 4396418 FIELD INSTALLABLE ICE MAKER (AMKIT02)
WPW10671240 WPW10671240 FRAME
WP67003400 WP67003400 FRAME- GLA
W10815413 W10815413 FUNNEL
W10856123 W10856123 GASKET
WPW10443311 WPW10443311 GASKET ASSEMBLY
WPW10436247 WPW10436247 GASKET ASSEMBLY
WPW10443309 WPW10443309 GASKET ASSEMBLY
WPW10436245 WPW10436245 GASKET ASSEMBLY
B5759649 B5759649 GASKET MC
A3189394 A3189394 GASKET, BOTTOM
67001038 67001038 GASKET, DAMPER
WPB8381501 WPB8381501 GASKET- DR
12002497 12002497 GEAR
WP67006877 WP67006877 GLASS SHELF
WP67001054 WP67001054 GLIDE LT
WP67001053 WP67001053 GLIDE RT
WP542638 WP542638 GREASE
WPW10175909 WPW10175909 GRILLE
WPW10534166 WPW10534166 GRILLE-FRT
WPW10534167 WPW10534167 GRILLE-FRT
W10121318 W10121318 GROMMET
WPW10169124 WPW10169124 GROMMET
WPW10137529 WPW10137529 GROMMET
67005680 67005680 GROMMET (2)
WP61004743 WP61004743 GROMMET- B
W11448709 W11448709 GUIDE, FILL TUBE
WPW10119668 WPW10119668 HANDLE
WPW10179172 WPW10179172 HANDLE
WPW10179174 WPW10179174 HANDLE
WPW10119666 WPW10119666 HANDLE, DOOR (WHITE)
W10130480 W10130480 HARNESS F
67001043 67001043 HARNESS, CONTROLS (REFRIGERATOR)
13060302 13060302 HARNESS, UNIT INCLUDES CORD
W10119855 W10119855 HARNS-WIRE
WP67002135 WP67002135 HEATER- DE
W11689473 W11689473 HINGE- CEN
W11702858 W11702858 HOUSING
WP67002085 WP67002085 HOUSING
67003803 67003803 INSULATION
799833 799833 KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY)
67002512 67002512 KNOB, FRONT
67003420 67003420 KNOB, FZ CONTROL
67001033 67001033 KNOB, GEAR
W11685757 W11685757 LABEL
67001073 67001073 LADDER, CENTER
67001302 67001302 LADDER, SIDE
W11679940 W11679940 LIGHT BULB
67001760 67001760 LOGO, LIGHT MODULE
WP12724501 WP12724501 MODULE, LIGHT
WP12476002 WP12476002 MODULE- FZ
W11613295 W11613295 MOTOR-COND
67005429 67005429 NAMEPLATE (BLACK)
67005427 67005427 NAMEPLATE (WHITE)
799344 799344 PAINT
4392900 4392900 PAINT, BULK (1 QT.) (BISCUIT (UNCUT))
4392901 4392901 PAINT, PRESSURIZED SPRAY (12 OZ. BISCUIT AND BISQUE)
285006 285006 PAINT, PRESSURIZED SPRAY (12 OZ. BLACK)
72032 72032 PAINT, TOUCH-UP (1/2OZ. BLACK)
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
12477402 12477402 PAN, DRAIN
WP67001308 WP67001308 PAN- DELI
67001045 67001045 PANEL CONTROL
WP67006642 WP67006642 PIN
12479901 12479901 PLATE COV
10712401 10712401 PLUG
WPA3076901 WPA3076901 PLUG, BUTTON
67004838 67004838 PLUG, BUTTON (2) (BLACK)
M0310731 M0310731 PLUG, BUTTON (3) (BLACK)
M0310343 M0310343 PLUG-HOLE
350942 350942 PRIMER
WPW10671238 WPW10671238 RAIL-CENTR
67001139 67001139 RETAINER, DOOR
WP67005149 WP67005149 ROLLER
WP12580304 WP12580304 ROLLER ASSEMBLY. (2)
71003131 71003131 SCREW
WP8281196 WP8281196 SCREW
WP67006380 WP67006380 SCREW
WP489349 WP489349 SCREW
WP489128 WP489128 SCREW
67006425 67006425 SCREW
W10709797 W10709797 SCREW
WP98165 WP98165 SCREW
WP489474 WP489474 SCREW
WP12992902 WP12992902 SCREW
M0216705 M0216705 SCREW
12992301 12992301 SCREW
W10709798 W10709798 SCREW
WP33001882 WP33001882 SCREW
WP67004954 WP67004954 SCREW
67006608 67006608 SCREW
W10709795 W10709795 SCREW
W11233072 W11233072 SCREW
12846902 12846902 SCREW (2)
67006564 67006564 SCREW (8)
67006806 67006806 SCREW, HANDLE (BLACK)
67006668 67006668 SCREW, HANDLE (WHITE)
W10709807 W10709807 SCREW, HANDLE HOLE (BLACK)
12991103 12991103 SCREW, HANDLE HOLE (WHITE)
WPM0500703 WPM0500703 SEAL- O RI
WP854334 WP854334 SEAL-STRIP
WP503695 WP503695 SEALER
WP505587 WP505587 SEALER
212643 212643 SEALER-GUM
W10802329 W10802329 SHAFT, RACK
12204808 12204808 SHELFGLAS
12575309 12575309 SHROUD
WPW10167023 WPW10167023 SHROUD
W11658402 W11658402 SLIDE
WP67005864 WP67005864 SLIDE
W11447232 W11447232 SOCKET
350930 350930 SPRAY
8201769 8201769 START-DEV
W10613606 W10613606 START-DEV
67003782 67003782 STOP, DOOR (BLACK)
12968202W 12968202W STOP, DOOR (WHITE)
WP12227302WD WP12227302WD SUPPORT
W11396033 W11396033 SWITCH
W11384469 W11384469 SWITCH
12863063 12863063 TAG- ENERG
W11238399 W11238399 TAPE
W10169671 W10169671 TECH SHEET
67001034 67001034 TENSIONER, BELT
833938 833938 TERMINAL
WP67003426 WP67003426 THERMOSTAT
WP67001036 WP67001036 TIMER- DEF
WP1117510 WP1117510 TORX SCREW WRENCH, TORX KEY
WP841180A WP841180A TRAY
W11337775 W11337775 TRAY, DRIP
WP67001279 WP67001279 TRAY- DAIR
10946012 10946012 TRIM, REAR SHELF
WPW10231481 WPW10231481 TRIM-SHELF
12866904 12866904 TUBE
67001066 67001066 TUBE, DRAIN
W10137651 W10137651 USE & CARE GUIDE
978030 978030 VALVE
978029 978029 VALVE
978027 978027 VALVE
978026 978026 VALVE
876764 876764 VALVE
WP978025 WP978025 VALVE
978028 978028 VALVE, ACCESS (1/2``)
