Model Image
Manufacturer

Whirlpool

Model Number

ED5LHAXMB00

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
978030 978030 ACCESS VALVE (3/4``)
W10896764 W10896764 AIR BAFFLE
WPW10151374 WPW10151374 AIR DIFFUSER ASSEMBLY
2261265 2261265 AIR SEAL, THERMISTOR
WP72107 WP72107 ALMOND
350956 350956 ALMOND
WP2255432T WP2255432T ARM-DISPSR
2255227 2255227 ARM-PIVOT
WP2198574 WP2198574 AUGER
606755 606755 BAG, INSULATION (36-5/8`` X 46``)
2223535 2223535 BASKET, SLOPE
WP2301190 WP2301190 BASKET, SQUARE
WP2304309 WP2304309 BASKET, TILT OUT
2255413 2255413 BEARING
WPW10225581 WPW10225581 BIMETL-DEF
WP627985 WP627985 BIMETL-DEF
WPW10321304 WPW10321304 BIN CONTROL LEVER
72032 72032 BLACK
2257020 2257020 BLADE, FIXED
W10278731 W10278731 BLADE, ROTARY A
W10278732 W10278732 BLADE, ROTARY B
W10278733 W10278733 BLADE, ROTARY C
2257021 2257021 BLADE, STIRRING
2198602 2198602 BLOCK, BLADE
2256035 2256035 BRACKET
WP2180226 WP2180226 BRACKET
WP2181929 WP2181929 BRACKET
WP2206629B WP2206629B BRACKET, DOOR STOP (BLACK)
WP2212322 WP2212322 BRACKET, ICE MAKER MOUNTING
WP2198641 WP2198641 BRACKET, ICEMAKER COVER
2198655 2198655 BRACKET, MOTOR
WP2315403 WP2315403 BUTTON-BIN
100000 100000 CABINET (NOT A SERVICEABLE PART)
2255226 2255226 CAM
WP2317782 WP2317782 CAMERA LENS-LIGHT
W11298978 W11298978 CAMERA LENS-LIGHT
WP2186494W WP2186494W CAP, WATER FILTER
WP2186494T WP2186494T CAP, WATER FILTER ( TEMPEST GRAY)
WP2186494B WP2186494B CAP, WATER FILTER (BLACK)
WP4387764 WP4387764 CAPACITOR ((PRODUCTION))
WPW10662129 WPW10662129 CAPACITOR (PRODUCTION)
4387478 4387478 CAPACITOR (SERVICE)
WP4317852 WP4317852 CEMENT, ALUMILASTIC (1 1/4 OZ.)
WP488366 WP488366 CLAMP
549193 549193 CLAMP, SERVICE CORD
WP2195327 WP2195327 CLIP
2208280 2208280 CLIP
W10683556 W10683556 CLIP
2155547 2155547 CLIP
2223314 2223314 CLIP
WP1108439 WP1108439 CLIP
WP1115374 WP1115374 CLIP
WP2161324 WP2161324 CLIP
2161330 2161330 CLIP
489396 489396 CLIP
WP628379 WP628379 CLIP
WP2155013 WP2155013 CLIP, GRILLE RETAINER (2)
2215823 2215823 CLIP-AIR, DUCT
WP2256101 WP2256101 COMPARTMENT DOOR
2198597 2198597 COMPLETE ICEMAKER ASSEMBLY
W10309994 W10309994 COMPRESSOR
8201683 8201683 CONDENSER ASSEMBLY
WP2154473 WP2154473 CONNECTOR
WP2198677 WP2198677 CONNECTOR, WATER FITTING
2255623 2255623 CONTRL-BOX
W11629974 W11629974 CONTROL BOARD
2255222 2255222 CONTROL BOX
2187965 2187965 CONTROL BOX HARNESS
WPW10135090 WPW10135090 CONTROL, ELECTRONIC
WP2220458 WP2220458 COUPLING
WP2220457 WP2220457 COUPLING, TOP
2255460 2255460 COVER
2198626 2198626 COVER
W10133000 W10133000 COVER
WP2198587 WP2198587 COVER, EMITTER
WP2255720 WP2255720 COVER, ICEMAKER
W10508993 W10508993 COVER, MEAT PAN
2217039 2217039 COVER, MEAT PAN
2255558 2255558 COVER, RECEIVER
2206314 2206314 COVER-EVAP
WP2162358 WP2162358 COVER-TERM
W10466698 W10466698 COVER-UNIT
WP2188755 WP2188755 COVER-UNIT
WP2188656 WP2188656 CRISPER PAN
2255574 2255574 CRUSHER BIN
WP628356 WP628356 CUP-WATER FILL
2179350 2179350 DEFLECTOR
L2206682B L2206682B DOOR ASSEMBLY BL
L2261180B L2261180B DOOR ASSEMBLY BL
L2206682T L2206682T DOOR ASSEMBLY BT
L2261180T L2261180T DOOR ASSEMBLY BT
L2206682W L2206682W DOOR ASSEMBLY WH
L2261180W L2261180W DOOR ASSEMBLY WH
WPW10329686 WPW10329686 DOOR CLOSER, LOWER CAM
WP2182179 WP2182179 DOOR CLOSER, UPPER CAM
2159083 2159083 DOOR GASKET, MAGNETIC (SERVICE) (BLACK)
2159082 2159082 DOOR GASKET, MAGNETIC (SERVICE) (BLACK)
2159075 2159075 DOOR GASKET, MAGNETIC (SERVICE) (MIST BEIGE)
2159074 2159074 DOOR GASKET, MAGNETIC (SERVICE) (MIST BEIGE)
8201707 8201707 DOOR HINGE
2256015 2256015 DOOR LATCH, BIN
WP2156022 WP2156022 DOOR TRIM
WP2171157 WP2171157 DOOR TRIM
WPW10307490 WPW10307490 DOOR TRIM
WP2223334 WP2223334 DOOR TRIM
WP2180353 WP2180353 DOOR-CHUTE
72017 72017 DRAWER, STORAGE PAINT, TOUCH-UP (1/2OZ.) (WHITE)
W10843121 W10843121 DRIER ((SERVICE))
2212377 2212377 DUCT-AIR
2198580 2198580 DUCT-AIR
WP627843 WP627843 EJECTOR
2304102 2304102 ELECTRONIC CONTROL
2261334 2261334 ESCUTCHEON, CONTROL BOX
2194744 2194744 ESCUTCHEON, MEAT PAN CONTROL
WP2188823 WP2188823 EVAPORATOR
2194969T 2194969T EXTENSION, HANDLE (BISCUIT)
WP2194969W WP2194969W EXTENSION, HANDLE (WHITE)
WP2194973W WP2194973W EXTENSION, HANDLE TOP (WHITE)
2194973B 2194973B EXTENSION, TOP (BLACK)
WP2169142 WP2169142 FAN BLADE
4389144 4389144 FAN MOTOR
WP2190685 WP2190685 FAN, BLADE
WP2182120 WP2182120 FAN-SCROLL
489285 489285 FASTNER, PUSH-ON
2196097 2196097 FILLER
2196094 2196094 FILLER WRAPPER (WHITE)
2196150 2196150 FILLER, WRAPPER (BISCUIT)
EDR5RXD1 EDR5RXD1 FILTER
8201537 8201537 FITTING
WP4373559 WP4373559 FITTING
WP2256096 WP2256096 FITTING
W11566763 W11566763 FITTING, DRAIN
2172957 2172957 FLAP-EXTNS
WP2198633 WP2198633 FLIPPER
WP2195975 WP2195975 FRAME
2186649T 2186649T FREEZER DOOR (INCLUDES ITEM 8 AND DISPENSER FRONT PARTS)HANDLE, CENTER (BISCUIT)
WPW10289690 WPW10289690 FRONT COVER
WP2261178T WP2261178T FRONT COVER ASSEMBLY (INCLUDES ITEMS 18, 19, 20 & 21) (BISCUIT)
WP2261178B WP2261178B FRONT COVER ASSEMBLY (INCLUDES ITEMS 18, 19, 20 & 21) (BLACK)
WP2261178W WP2261178W FRONT COVER ASSEMBLY (INCLUDES ITEMS 18, 19, 20 & 21) (WHITE)
4386774 4386774 FRONT ROLLER (2)
WP2155789 WP2155789 GASKET
4388500 4388500 GASKET
W10864399 W10864399 GLASS COVER
WP542638 WP542638 GREASE, SILICONE (1/2 OZ.)
W10803964 W10803964 GRILLE
WP2198468T WP2198468T GRILLE ( TEMPEST GRAY)
WP2206670B WP2206670B GRILLE, OVERFLOW
WP2206670T WP2206670T GRILLE, OVERFLOW (BISCUIT)
WP2206670W WP2206670W GRILLE, OVERFLOW (WHITE)
W11661108 W11661108 GROMMET
WP4387558 WP4387558 GROMMET
WP2176759 WP2176759 GROMMET, FAN (2)
2186495 2186495 GUARD, FAN
WP2180224 WP2180224 GUIDE, ICE
WP2186649B WP2186649B HANDLE, CENTER
WP2186649W WP2186649W HANDLE, CENTER (WHITE)
WP2187467 WP2187467 HARNESS, WIRING ICEMAKER
2198619 2198619 HARNS-WIRE
2187406 2187406 HARNS-WIRE
2149294 2149294 HEAT SHIELD
WP2323198 WP2323198 HEATER, DEFROST
2203408T 2203408T HINGE COVER (BISCUIT)
WP2203407W WP2203407W HINGE COVER (FC)
WP2203408W WP2203408W HINGE COVER (RC) (WHITE)
WP2203407B WP2203407B HINGE COVER, FC
2203407T 2203407T HINGE COVER, FC (BISCUIT)
WP2203408B WP2203408B HINGE COVER, RC (BLACK)
WP2203770 WP2203770 HINGE, TOP (FC)
WP2203771 WP2203771 HINGE, TOP (RC)
WP2212369 WP2212369 HOLDER
WP941839 WP941839 HOLE COVER, EVAPORATOR
940014 940014 HOLE PLUG, CONTROL BOX
WP2179343 WP2179343 HOUSING, HUMIDITY
WP2186443 WP2186443 HOUSING, WATER
WP2195914 WP2195914 HOUSING-IM
WP2198573 WP2198573 ICE BIN
W10823377 W10823377 ICE DOR KT
W10297244 W10297244 ICE STRIPPER
WP2258243 WP2258243 ICE-CONTNR
W10408179 W10408179 INLET VALVE
2216997 2216997 INSERT
876370 876370 INSULATION
WP625834 WP625834 INSULATION, SWITCH
799833 799833 KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY)
876029 876029 KIT, FOAM SLAB (30`` X 32-1/2`` X 1-1/2``)
2255232 2255232 KNOB-THERM
2255992 2255992 KNOB-THERM
2198609 2198609 LADDER
2198610 2198610 LADDER
WP2319866 WP2319866 LADDER
WP2198643 WP2198643 LENS
2255225 2255225 LENS-LIGHT
WP2255431B WP2255431B LEVER, ICE (BLACK DISPENSER)
WP2255431W WP2255431W LEVER, ICE (WHITE DISPENSER)
W10851295 W10851295 LEVER, ICE DISPENSER (BISCUIT)
WP2255432W WP2255432W LEVER, WATER (WHITE DISPENSER)
WP2255432B WP2255432B LEVER, WATER DISPENSER
8009 8009 LIGHT BULB
WP22002263 WP22002263 LIGHT BULB
WP2302848 WP2302848 LIGHT SHIELD
LIT2261182 LIT2261182 LITERATURE PARTS (ENERGY GUIDE)
LIT2255774 LIT2255774 LITERATURE PARTS (SERVICE & WIRING SHEET)
8201651 8201651 LOUVER-CAB
LIT2220407 LIT2220407 MODULAR ICEMAKER SERVICE SHEET
8201515 8201515 MODULE ASSEMBLY (INCLUDES ITEMS 21 & 22)
WPW10190929 WPW10190929 MOLD & HEATER ASSEMBLY (ALSO ORDER) 542638 SILICONE GREASE
W11170227 W11170227 MOTOR
W10124096 W10124096 MOTOR, FAN
W10190935 W10190935 MOTOR-MODL
WP2213265 WP2213265 NAMEPLATE
8201513 8201513 NUT
3400971 3400971 NUT, HEX
WP4387835 WP4387835 OVERLOAD (SERVICE INCLUDES RELAY)
LIT2255705 LIT2255705 OWNERS MANUAL
978883 978883 PAINT
799344 799344 PAINT
4392900 4392900 PAINT, BULK (1 QT.) (BISCUIT (UNCUT))
786032 786032 PAINT, BULK (1 QT.) (BLACK (UNCUT))
285006 285006 PAINT, PRESSURIZED SPRAY (12 OZ. BLACK)
4392901 4392901 PAINT, PRESSURIZED SPRAY (12 OZ.) (BISCUIT PAINT, BULK (1 QT.))
511873 511873 PAINT, TOUCH-UP 1/2 OZ. (WHITE PORCELAIN)
WP2188664 WP2188664 PAN-MEAT
W11497323 W11497323 PAN-SNACK
WP2198634 WP2198634 PIN
WP2196195 WP2196195 PIN
350942 350942 PRIMER
WP2256126 WP2256126 RESERVOIR
WP2256085 WP2256085 RETAINER
WP2315522 WP2315522 RETAINER THERMOSTAT
WP2155590 WP2155590 RETAINER, FAN MOTOR
WP2194719 WP2194719 RETAINER, LEVERS
2255228 2255228 ROD
WPW10250570 WPW10250570 ROLLER (REAR) (2)
489229 489229 ROLLPIN
2198595 2198595 SCOOP AIR
8533917 8533917 SCREW
W11544659 W11544659 SCREW
8281160 8281160 SCREW
8281162 8281162 SCREW
WPW10142283 WPW10142283 SCREW
WP681249 WP681249 SCREW
W10759522 W10759522 SCREW
WP489491 WP489491 SCREW
WP8281227 WP8281227 SCREW
W10850698 W10850698 SCREW
WP8281164 WP8281164 SCREW
W10856122 W10856122 SCREW
2198671 2198671 SCREW
WP489500 WP489500 SCREW
WPW10141645 WPW10141645 SCREW
WP488729 WP488729 SCREW
WP488488 WP488488 SCREW
798639 798639 SCREW
WP8281163 WP8281163 SCREW
WP489128 WP489128 SCREW
WP3196175 WP3196175 SCREW
WP3400906 WP3400906 SCREW
W11661574 W11661574 SCREW
489340 489340 SCREW
WPW10141625 WPW10141625 SCREW
WP3196557 WP3196557 SCREW
627068 627068 SCREW
489136 489136 SCREW
WP3400065 WP3400065 SCREW (2)
W11233072 W11233072 SCREW (5)
WP489497 WP489497 SCREW (8)
WP3-24004-109 WP3-24004-109 SCREW (USE ON CRISPER COVER, AS SHOWN, IF APPLICABLE)
WP489483 WP489483 SCREW 13 3400858 SCREW
W10142289 W10142289 SCREW 8-18 X 5/8
WP3400012 WP3400012 SCREW PANEL (ALSO ORDER ITEM NO.15)
WP3400852 WP3400852 SCREW,
WP489427 WP489427 SCREW, 1/4-20X5/8
WP489464 WP489464 SCREW, 1/4-28 X 1
2006254 2006254 SCREW, 6-19 X .250
WP489478 WP489478 SCREW, 8-18 X .50
4392899 4392899 SCREWS10-16X.375 PAINT, TOUCH-UP (1/2OZ.) (BISCUIT)
WP2198628 WP2198628 SEAL
WP503695 WP503695 SEALER
WP505587 WP505587 SEALER MASTIC (1 QUART)
212643 212643 SEALER, PERMAGUM (4 - 12`` STRIPS)
WP2211581 WP2211581 SHELF ASSEMBLY
WPW10141748 WPW10141748 SHELF, CANTILEVER (2)
WP2205837K WP2205837K SHELF, WIRE
2211746 2211746 SHELFWIRE
2219878 2219878 SHIELD
2261231 2261231 SHIELD
2261232 2261232 SHIELD
2255666 2255666 SHIELD
2255991 2255991 SHIELD
WP2181911 WP2181911 SHIM
W11661094 W11661094 SLEEVE
WP2212365 WP2212365 SLEEVE, COUPLING
2182757 2182757 SLIDE MEAT PAN CONTROL
WP2261448 WP2261448 SLIDE, BASKET (LEFT SIDE)
WP2179342 WP2179342 SLIDE, HUMIDITY CONTROL
2212321 2212321 SLIDE, ICE MAKER
2315398 2315398 SLIDE, ICEMAKER SHUT OFF
WPW10119935 WPW10119935 SOCKET
2180200 2180200 SOCKET
W11606038 W11606038 SOCKET
WP1119007 WP1119007 SPACER, FLAT (2)
WP1119005 WP1119005 SPACER, STEP
WP486692 WP486692 SPEED NUT (1/4-20)
350930 350930 SPRAY (13 OZ.) (WHITE)
WP2198635 WP2198635 SPRING
WP2188917 WP2188917 SPRING
W10852956 W10852956 SPRING
WPW10224328 WPW10224328 SPRING
WP2198608 WP2198608 SPRING, LATCH
489203 489203 SPRING, WASHER
8201786 8201786 START-DEV
WP2195051 WP2195051 STRAIN RELIEF
W11223328 W11223328 STUD, REAR
4388358 4388358 SUPPORT KIT (CONTAINS RIGHT AND LEFT)
WP2162361 WP2162361 SWITCH
W11457217 W11457217 SWITCH
W11384469 W11384469 SWITCH, ROCKER ARM (REFRIGERATOR DOOR SIDE)
W11238399 W11238399 TAPE
833938 833938 TERMINAL
WP2188819 WP2188819 THERMISTOR
WP2182181 WP2182181 THIMBLE, TOP
WPW10339879 WPW10339879 TIE-WIRE
978026 978026 TOP PARTS NOT ILLUSTRATED AND OPTIONAL PARTS (NOT INCLUDED) (VALVE, ACCESS (5/16``))
WP1117510 WP1117510 TORX KE
2223708 2223708 TRACK
2223709 2223709 TRACK
WP2261449 WP2261449 TRACK
WPW10614158 WPW10614158 TRAY, EVAPORATOR
WP2179234 WP2179234 TRIM, CRISPER PAN
WP2194969B WP2194969B TRIM, DOOR-BOTTOM (BLACK )
WP2179243 WP2179243 TRIM, SNACK PAN
WP2195905 WP2195905 TRIM-BASKT
2194973T 2194973T TRIM-HANDL
W11512417 W11512417 TRIVET
2255798 2255798 TUBE
WP2205765 WP2205765 TUBE SUCTION
8201597 8201597 TUBE, FILTER INLET
2198665 2198665 TUBE, P.C. BOARD
2304904 2304904 UNIT MOUNTING FRAME
2305374 2305374 UNIT MOUNTING RAIL
8201626 8201626 UNIT, HARNESS
978027 978027 VALVE, ACCESS ((3/8``) TUBE)
978028 978028 VALVE, ACCESS (1/2``)
WP978025 WP978025 VALVE, ACCESS (1/4``)
978029 978029 VALVE, ACCESS (5/8)
876764 876764 VALVE,ACCESS (3/16)
WP2212370 WP2212370 WASHER
3400972 3400972 WASHER
WP489235 WP489235 WASHER RING
WP2198661 WP2198661 WASHER, COUPLING
WPW10350006 WPW10350006 WATER TUBE
W11234406 W11234406 WIRE HARNESS
2311637 2311637 WIRE HARNESS, DUAL CRISPER
Main Menu x
