Model Image
Manufacturer

Whirlpool

Model Number

FGP337KW0

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
285006 285006 ACCESSORIES SIDE PANEL KITS PAINT, PRESSURIZED SPRAY (12 OZ.) (SUPERIOR BLACK)
WP72107 WP72107 ALMOND
350956 350956 ALMOND
98017831 98017831 ANTI-TIP KIT
98003849 98003849 BAFFL-BRNR
98003847 98003847 BAFFLE-BTM
98006710 98006710 BLOCK-BAL
WP98004449 WP98004449 BOTTM-OVEN
98004761 98004761 BRKT-BROIL
W11499074 W11499074 BRKT-HINGE
98007126 98007126 BRKT-STAND
98007183 98007183 BRKT-SUPRT
98011213 98011213 BRKT-TIMER
98005500 98005500 BRKT., VENTURI (4)
98004723 98004723 BUMPER
98004227 98004227 BUMPER
98004052 98004052 BUMPER, DOOR (2)
98004314 98004314 BURNER, OVEN
WP98004410 WP98004410 BURNER, TOP
98007390 98007390 BUTTON, PLUG (15/32``)
98007388 98007388 BUTTON, PLUG (25/32``)
WP98005518 WP98005518 CAP, BURNER
98007205 98007205 CAP-VENT
98006715 98006715 CHANNEL
WPW10278150 WPW10278150 CLIP
W11229684 W11229684 CLIP
98005026 98005026 CLIP
98005502 98005502 CLIP
98005642 98005642 CLIP
98006653 98006653 CLIP
98008341 98008341 CLIP
98004952 98004952 CLIP, GLASS (LEFT)
98004953 98004953 CLIP, GLASS (RIGHT)
98005755 98005755 CONTROL BOARD
98009675 98009675 COOKTOP (ALMOND)
98009677 98009677 COOKTOP (WHITE)
98006083 98006083 COVER-REAR
98003809 98003809 COVER-REAR
98007192 98007192 COVR-MODLE
WP98006793 WP98006793 DOOR TRIM
72017 72017 DRAWER, STORAGE PAINT, TOUCH-UP (1/2OZ.) (WHITE)
98004632 98004632 ENDCAP-PNL
98004633 98004633 ENDCAP-PNL
98005336 98005336 ENDCAP-PNL
98005337 98005337 ENDCAP-PNL
98005506 98005506 FITTING, FEMALE
98005516 98005516 FITTING, TUBE
WPW10116396 WPW10116396 FLUE-BOX
241430 241430 FOIL, ALUMINUM OVEN (18`` X 25`)
WPW10058460 WPW10058460 FOOT-LEVEL
WP3196037 WP3196037 FOOT-LEVEL
98006750 98006750 FRAME, FRONT
98005328 98005328 GLASS, DOOR (ALMOND)
98005357 98005357 GLASS, DOOR (WHITE)
98004042 98004042 GLASS-DOOR
8190014 8190014 GRATE-KIT
261582 261582 GREASE
WP98003480 WP98003480 GRID-PAN
98004715 98004715 GUIDE-DRWR
WP3405184 WP3405184 HANDLE
3405185 3405185 HANDLE, BRLR DOOR (ALMOND)
WP98005318 WP98005318 HANDLE, OVEN DOOR
WP98005317 WP98005317 HANDLE, OVEN DOOR (BLACK)
6610240 6610240 HARNESS, CLOCK
98005561 98005561 HARNESS, SWITCH
98005549 98005549 HARNESS, T-STAT
WP98004734 WP98004734 HINGE, DOOR (2)
12400035 12400035 IGNITER, OVEN OVEN PILOT)
W10918546 W10918546 IGNTR-OVEN
WPW10209656 WPW10209656 IGNTR-SURF
W11684802 W11684802 INSULATION
8190667 8190667 INSULATION
W11311894 W11311894 INSULATION
WPW10208653 WPW10208653 INSULATION
799832 799832 KIT, PORCELAIN REPAIR (WHITE)
WP98006104 WP98006104 KNOB, BURNER (4)
WP98008444 WP98008444 KNOB, THERMOSTAT
8009 8009 LIGHT BULB
98005768 98005768 LINER-BACK
98004698 98004698 LINER-BRLR
98010182 98010182 LINER-DOOR
LIT98007261 LIT98007261 LITERATURE PARTS (GUIDE, USE & CARE)
LIT98007121 LIT98007121 LITERATURE PARTS (INSTALLATION INSTR (TEMPLATE))
LIT98007135 LIT98007135 LITERATURE PARTS (INSTRUCTIONS INSTALLATION)
LIT98007130 LIT98007130 LITERATURE PARTS (SAFER COOKING TIPS)
LIT98007032 LIT98007032 LITERATURE PARTS (TECH SHEET)
WP98010185 WP98010185 LOWER TRIM, DOOR (WHITE)
98005978 98005978 LP SPUD KIT (FOR USE WITH LP)
98009179 98009179 NUT
WP98004650 WP98004650 NUT, PUSH
978883 978883 PAINT
799344 799344 PAINT
350942 350942 PAINT, PRESSURIZED SPRAY (12 OZ.) (PRIMER, WHITE)
511873 511873 PAINT, TOUCH-UP 1/2 OZ. (WHITE PORCELAIN)
WP98016005 WP98016005 PAN-BROILR
98007256 98007256 PANEL, BACKGUARD (BLACK)
98007257 98007257 PANEL, BACKGUARD (WHITE)
98009340 98009340 PANEL, DOOR (ALMOND)
WP98009342 WP98009342 PANEL-DRWR
WP98010042 WP98010042 PANEL-SIDE
98010044 98010044 PANEL-SIDE
98007251 98007251 PANL-MNFLD
814381 814381 PIN HINGE KIT
98004053 98004053 PIN-HINGE
98010087 98010087 PIPE-MNFLD
WP9757891 WP9757891 POWER CORD
98006867 98006867 RACK, BROILER
WPW10312013 WPW10312013 RACK-OVEN
98003830 98003830 RAIL-BASE
W11590249 W11590249 RANGE SPARK MODULE
8212471 8212471 REFINISHING MATERIAL (TOUCH-UP SELF-CLEAN(1/2 PT))
98005520 98005520 REGULATOR
98005713 98005713 RETAINER
98004629 98004629 RETAINER
98004938 98004938 RETAINER
98004564 98004564 RETAINER
98004965 98004965 RETAINER, BOTTOM
WP3400832 WP3400832 SCREW
WP59002061 WP59002061 SCREW
WP98004218 WP98004218 SCREW
WP3400805 WP3400805 SCREW
3196166 3196166 SCREW
W10856125 W10856125 SCREW
WP98006631 WP98006631 SCREW
W10837674 W10837674 SCREW
WP3400882 WP3400882 SCREW
W11428245 W11428245 SCREW
W10837731 W10837731 SCREW
W11233072 W11233072 SCREW
WPW10277003 WPW10277003 SCREW
W11676351 W11676351 SCREW
W11206744 W11206744 SCREW
98006728 98006728 SCREW (ALMOND)
98009174 98009174 SEAL, OVEN
98007195 98007195 SHIELD
98007191 98007191 SHIELD-HT
98004451 98004451 SIDE-OVEN
98004452 98004452 SIDE-OVEN
98007127 98007127 SLEEVE
W10856866 W10856866 SOCKT-LITE
350930 350930 SPRAY (13 OZ.) (WHITE)
98008379 98008379 SPRNG-DOOR
98008380 98008380 SPRNG-DOOR
98004453 98004453 SUPPORT
98003791 98003791 SUPPORT
98015363 98015363 SUPPORT, REAR
3149360 3149360 SWITCH, ROCKER (WHITE)
98006392 98006392 SWTCH-LITE
WPW10641988 WPW10641988 THERMOSTAT
98006739 98006739 TIE-WIRE
98005756 98005756 TIMER (WHITE)
98004447 98004447 TOP-OVEN
WP98010187 WP98010187 TRIM, LOWER DOOR
98006884 98006884 TRIM-DOOR
98006885 98006885 TRIM-DOOR
98006794 98006794 TRIM-DOOR
98011202 98011202 TUBING (REGLTR TO OVEN VALVE)
98007186 98007186 TUBING, INLET
WP98005574 WP98005574 VALVE, BURNER (4)
WP98014016 WP98014016 VALVE, OVEN
WP6610244 WP6610244 VENTURI
WP6610243 WP6610243 VENTURI
98007193 98007193 WASHER
242831 242831 WIRE
242827 242827 WIRE
242825 242825 WIRE
242823 242823 WIRE
3184020 3184020 WIRE
242828 242828 WIRE (12 GA. 150 C BLACK)
242820 242820 WIRE (14 GA. 150 C BLACK)
242821 242821 WIRE (14 GA. 150 C BLUE)
242822 242822 WIRE (14 GA. 150 C BROWN)
242824 242824 WIRE (14 GA. 150 C ORANGE)
8316784 8316784 WIRE (14 GA. 200 C BROWN)
242829 242829 WIRE, RED 12 GA. 150~C
242826 242826 WIRE, WHITE 14 GA. 150~C
242832 242832 WIRE, YELLOW 14 GA. 200~C
98004294 98004294 WIRE-INSUL
