Model Image
Manufacturer

Whirlpool

Model Number

GCG2901XSW1

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WP691581 WP691581 ACTUATOR
279264 279264 AIR CHANNEL BOX
WP72107 WP72107 ALMOND
350956 350956 ALMOND
WP342847 WP342847 BAFFLE, DRUM
693986 693986 BASE, BURNER
WP348780 WP348780 BASE, MOTOR
WP3394508 WP3394508 BEARNG-RNG
341241 341241 BELT, DRIVE
3400500 3400500 BOLT, 5/16-18 X 3/4
279900 279900 BOX
WP694298 WP694298 BRACKET
3388375 3388375 BRACKET
3388374 3388374 BRACKET
694538 694538 BRACKET, COIL
3976435 3976435 BRACKET, SUPPORT
279793 279793 BULKHEAD
238614 238614 BUMPER AND ISOLATION
WP693140 WP693140 BURNER
279536 279536 BURNER-GAS
WP3348587 WP3348587 BUTTON (4)
3399581 3399581 CABINET (INCLUDES ILLUS. NO.`S 5,7,16,41, & 57) (ALMOND)
3399580 3399580 CABINET (INCLUDES ILLUS. NO.`S 5,7,16,41, & 57) (WHITE)
WP339855 WP339855 CAM
WP343777 WP343777 CAM
WP3387974 WP3387974 CAM (3 PIN (60 MIN.))
WP3348109 WP3348109 CAMERA LENS-LIGHT
63789 63789 CAP, END (L.H.)
63795 63795 CAP, END. (R.H.)
WP3389441 WP3389441 CATCH, DOOR
279505 279505 CHUTE
341029 341029 CLAMP
WP660658 WP660658 CLAMP, MOTOR
279771 279771 CLIP
WP98997 WP98997 CLIP
279220 279220 CLIP
353253 353253 CLIP
693141 693141 CLIP
WP297092 WP297092 CLIP
279638 279638 CLIP
WP98234 WP98234 CLIP (2)
694510 694510 CLIP, HARNESS
341776 341776 CLIP, LOCK
279834 279834 COIL, 60 HZ. (2 TERMINAL) MAIN)
49572A 49572A CONVERSION KIT (TYPE 1 AND 2) TO TYPE (4) L.P.G.
279243 279243 CONVERSION KIT TYPE 1 (NATURAL) TO TYPE 3 (MANUFACTURED)
W11736322 W11736322 COVER
697368 697368 COVER
WP697367 WP697367 COVER, LINT SCREEN (WHITE)
WP689314 WP689314 DOOR
280077 280077 DOOR
279570 279570 DOOR LATCH
WP348205 WP348205 DOOR, FRONT
72017 72017 DRAWER, STORAGE PAINT, TOUCH-UP (1/2OZ.) (WHITE)
279827 279827 DRIVE MOTOR
3396775 3396775 DRUM ASSEMBLY
WP90296 WP90296 FASTENER, FLAT (2)
49621 49621 FEET-LVLNG
WP3392519 WP3392519 FUSE-THRML
279923 279923 GAS VALVE
261890 261890 GOLDEN HARVEST
261891 261891 GOLDEN HARVEST (UNCUT)
WP689308 WP689308 HANDLE, DOOR (ALMOND)
WP686711 WP686711 HANDLE, DOOR (WHITE)
3391227 3391227 HARNESS, WIRING (COMPLETE)
WP61894 WP61894 HEATER, THERMOSTAT (NOTE: USED WITH 660039 THERMOSTAT ONLY)
WPW10044470 WPW10044470 HINGE
WPW10044480 WPW10044480 HINGE
WP348023 WP348023 HINGE AND PIN ASSEMBLY (2)
WP8066217 WP8066217 HINGE, TOP (2))
WP8577230 WP8577230 HOUSING
WP691366 WP691366 IDLER PULLEY ASSEMBLY
279311 279311 IGNITOR
LIT687457 LIT687457 INSTRUCTIONS, INSTALLATION
LIT348772 LIT348772 INSTRUCTIONS, MULTI-VENTING
WP694424 WP694424 LEAK LIMITER
350941 350941 LEVELER (THINNER)
694583 694583 LEVER, TIMER
3388650 3388650 LIGHTS, INDICATOR
LIT3391236 LIT3391236 LIST, SERVICE PARTS
WP18776 WP18776 LOCK, FRONT TOP (2)
261889 261889 NEW AVOCADO (UNCUT)
303776 303776 NO DESCRIPTION AVALIABLE
WP358160 WP358160 NUT
WP358473 WP358473 NUT
WP689559 WP689559 NUT
233076 233076 NUT
98460 98460 NUT
358472 358472 NUT, PUSH-IN (4)
WP234826 WP234826 ORIFICE, BURNER (TYPE 1)
15775 15775 ORIFICE, BURNER (TYPE 2)
15419 15419 ORIFICE, BURNER (TYPE 3)
WP234868 WP234868 ORIFICE, BURNER (TYPE 4 (PROPANE))
WP229742 WP229742 ORIFICE, BURNER (TYPE 4 (PROPANE))
799344 799344 PAINT
978883 978883 PAINT
72109 72109 PAINT, TOUCH-UP 1/2 OZ. (AVOCADO)
72110 72110 PAINT, TOUCH-UP 1/2 OZ. (GOLDEN HARVEST)
280063 280063 PANEL
279997 279997 PANEL
347736 347736 PANEL, REAR
8066156 8066156 PANEL, REAR
3389679 3389679 PANEL-CNTL
696237 696237 PIPE
3393767 3393767 PIPE, TAIL
W10295523 W10295523 PLUG
691707 691707 PLUG, TERMINAL (USES TERMINAL 94614)
W11222083 W11222083 POWER CORD
350938 350938 PRIMER, GRAY
WP8066184 WP8066184 PULLEY-MTR
3348574 3348574 PUSHBUTTON
WP338906 WP338906 RADIANT, SENSOR
WP694674 WP694674 RANGE THERMOSTAT
3347730 3347730 RECEPTACLE (6-WAY)
98669 98669 RIVET
339392 339392 SCREEN
WP3390631 WP3390631 SCREW
WP488729 WP488729 SCREW
WP694091 WP694091 SCREW
WPW10366705 WPW10366705 SCREW
WP98129 WP98129 SCREW
WP310410 WP310410 SCREW
WP489069 WP489069 SCREW
98831 98831 SCREW
WP693995 WP693995 SCREW
WP965173 WP965173 SCREW
WP388326 WP388326 SCREW
WP681414 WP681414 SCREW
304795 304795 SCREW
WP3400036 WP3400036 SCREW, 10-24 X 1
690372 690372 SCREW, 11-16 X 7/8
WP90767 WP90767 SCREW, 8 A X 3/8
694421 694421 SCREW, BRACKET MOUNTING (8-32 X 1/2) (2)
WP694423 WP694423 SCREW, REGULATOR ADJUSTMENT
239087 239087 SEAL
WP3394196 WP3394196 SEAL
WP339956 WP339956 SEAL FOAM
W11613302 W11613302 SEAL-DOOR
WPW10359270 WPW10359270 SHAFT
WPW10359269 WPW10359269 SHAFT, DRUM ROLLER (R.H.)
W11233063 W11233063 SHIELD
261888 261888 SPRAY
350930 350930 SPRAY (13 OZ.) (WHITE)
WP694422 WP694422 SPRING, REGULATOR ADJUSTMENT
22965 22965 STRAP
349241T 349241T SUPPORT
686770 686770 SUPPORT PROTECTOR
337445 337445 SUPPORT, HEATER BOX (2)
W10820036 W10820036 SWITCH-LID
WPW10330137 WPW10330137 SWITCH-PB
WP341196 WP341196 THERMOSTAT, 205~F (96~C) (ALTERNATE)
279737 279737 TIMER
279841 279841 TOE PANEL
279835 279835 TOEPNL
3393386 3393386 TOP (ALMOND)
3393385 3393385 TOP (WHITE)
WPW10512946 WPW10512946 TRI-RING (4)
661580 661580 VALVE, GAS (COMPLETE)
WP348197 WP348197 WASHER
WP3388703 WP3388703 WASHER
WP694089 WP694089 WHEEL
10875 10875 WIRE (16 GA. 80 C BLUE)
WP3401850 WP3401850 WIRE HARNESS
303485 303485 WIRE, GROUND
69085-3 69085-3 WIRE, GROUND
690236 690236 WIRE, GROUND (MOTOR)
