Model Image
Manufacturer

Whirlpool

Model Number

GH5184XPT7

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
W10110597 W10110597 ADAPTER
8184590 8184590 BLADE-STIR
W10117908 W10117908 BLOCK-FUSE
8184670 8184670 BRKT-SUPPT
W10114256 W10114256 BRKT-SUPPT
W10244598 W10244598 BRKTSUPPT
8206232A 8206232A BULB-LIGHT
8205211 8205211 CAM-PLATE
W10325860 W10325860 CAPACTR-DM
W10217709 W10217709 CAPACTR-DM
W10615742 W10615742 CLIP
8205416 8205416 COMPLETE DOOR (STAINLESS)
8205421 8205421 CONTROL BOARD
8205195 8205195 COOK GUIDE LABEL
8205640 8205640 CORD-POWER
W10110595 W10110595 COVER
8184884 8184884 COVER, FAN
8184604 8184604 COVER, INLET INCLUDES NAILS AND BUSHINGS
8184897 8184897 COVER-PLT
W10110596 W10110596 COVER-PLT
W10114259 W10114259 COVER-PLT
8204676 8204676 COVR-DUCT
W10110593 W10110593 COVR-LIGHT
8184202 8184202 COVR-TERML
W10110598 W10110598 COVR-TERML
8184889 8184889 COVRLIGHT
8169635 8169635 CUSHION
8204674 8204674 DAMPER
W10843943 W10843943 DAMPER
8185031 8185031 DEFLCTR-AR
8184667 8184667 DEFLCTR-AR
W10272107 W10272107 DOOR HANDLE
8205413 8205413 DOOR/MW
8205414 8205414 DOOR/MW
8205415 8205415 DOOR/MW
W10435116 W10435116 DRIVER, TURNTABLE COUPLER
8184875 8184875 FAN
8206086 8206086 FERRITE
W10113040A W10113040A FILTER
W10112514A W10112514A FILTER
8205853 8205853 FILTER
W11707984 W11707984 FUSE-THRML
8184141 8184141 GLASS-LAMP
W10450172 W10450172 GRILL-VENT
W10450188 W10450188 GRILL-VENT
W10450187 W10450187 GRILL-VENT
W10450189 W10450189 GRILL-VENT
8185350 8185350 GUIDE-AIR
W10246505 W10246505 HANDLE (BLACK)
W10295692 W10295692 HANDLE, DOOR (WHITE)
8205947 8205947 HARD-MOUNT
8184887 8184887 HARNS-WIRE
8206185 8206185 HARNS-WIRE
W10258106 W10258106 HARNS-WIRE
W10110601 W10110601 HARNS-WIRE
W10110602 W10110602 HARNS-WIRE
W10114260 W10114260 HARNS-WIRE
W10114261 W10114261 HARNS-WIRE
W10114262 W10114262 HARNS-WIRE
W10114263 W10114263 HARNS-WIRE
W10114264 W10114264 HARNS-WIRE
W10114265 W10114265 HARNS-WIRE
W10114254 W10114254 HINGE-DOOR
W10114255 W10114255 HINGE-DOOR
W10114258 W10114258 HOLDER
8184894 8184894 HOUSING
W10244596 W10244596 HOUSNGLMP
8206579 8206579 INSTRCTN, INSTLLTN
8185189 8185189 INTERLOCK
8206565 8206565 INTERLOCK
W10217710 W10217710 INVERTER
WP8533914 WP8533914 LOCKWASHER
8206317 8206317 MAGNETRON
100000 100000 MISCELLANEOUS
WPW10114253 WPW10114253 MOTOR, FAN ASSEMBLY
W10642989 W10642989 MOTOR, TURNTABLE
8184581 8184581 MOTOR-STIR
W10841143 W10841143 NAIL
W10244602 W10244602 NUT
W10246264 W10246264 PANLCNTRL
W10247210 W10247210 PANLCNTRL
W10247211 W10247211 PANLCNTRL
W10247212 W10247212 PANLCNTRL
8184922 8184922 PIN-HINGE
WPW10269225 WPW10269225 PLATE-MTNG
W10244597 W10244597 PLATEGIDE
W10315274 W10315274 RACK-MEAL
8205549 8205549 RACK-MEAL
8184203 8184203 REFLECTOR
8184959 8184959 REFLECTOR, LAMP
W11252182 W11252182 RING-TURN
8185190 8185190 ROD-REL
WP8169704 WP8169704 SCREW
4393832 4393832 SCREW
8189541 8189541 SCREW
WP4393834 WP4393834 SCREW
W11380570 W11380570 SCREW
8205438 8205438 SCREW
8169479 8169479 SCREW
8184200 8184200 SCREW
8184199 8184199 SCREW
8184198 8184198 SCREW
8169474 8169474 SCREW
8169475 8169475 SCREW
W10244600 W10244600 SCREW
W10244601 W10244601 SCREW
8206446 8206446 SENSOR
8204754 8204754 SHIELD
8206460 8206460 SHIELD
8184129 8184129 SPACER
8184109 8184109 SPACER
8169438 8169438 SPRING
8204789 8204789 SUPPORT
W10211972 W10211972 SWITCH
W10211974 W10211974 SWITCH
W10132015 W10132015 TECH SHEET
8205926 8205926 TEMPLATE
8184582 8184582 THERMOSTAT/BRACKET
W10479659 W10479659 THRMST-FIX
8183999 8183999 THRMST-FIX
8205578 8205578 THRMST-FIX
8183994 8183994 THRMST-FIX
4393799 4393799 TURNTABLE
W10170440 W10170440 U & C GUIDE
4393861 4393861 WHEEL (3)
W10615910 W10615910 WIRE HARNESS
8206549 8206549 WRAPER-CAB
8206550 8206550 WRAPER-CAB
8206551 8206551 WRAPER-CAB
