Model Image
Manufacturer

Whirlpool

Model Number

GH7208XRS1

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WPW10286198 WPW10286198 AC LINE FILTER
8205262RB 8205262RB ACCESSORIES, STEAMER, MICROWAVE
W10596040 W10596040 ASSEMBLY, MOUNTING NUT
W10222517 W10222517 BASE
W10113785 W10113785 BASE
8206060 8206060 BRKT-MOUNT
W10115572 W10115572 BRKT-MOUNT
8206065 8206065 BRKT-SUPPT
8206212 8206212 BRKT-THERM
W10510202 W10510202 BULB-LIGHT
8206047 8206047 BUTTON
8206048 8206048 BUTTON
8206045 8206045 BUTTON
W10418890 W10418890 BUTTON
W10244759 W10244759 CAM PLATE, LOWER
W10113786 W10113786 CAM-PLATE
8206080 8206080 CAPACTR-MG
W10222514 W10222514 CASE, OUTER (WHITE)
8206037 8206037 CLIP
8206038 8206038 CLIP
8206223 8206223 CLIP
8206034 8206034 CLIP
8206263 8206263 CONNECTOR
8206106 8206106 CONNECTOR
WPW10115589 WPW10115589 CONTROL BOARD
WPW10391282 WPW10391282 CONTROL BOARD
WP8206602 WP8206602 CONTROL BOARD
WPW10403039 WPW10403039 CONTROL BOARD
8206603 8206603 CONTROL BOARD
8205279 8205279 COOK GUIDE LABEL
W10703381 W10703381 CORD-POWER
W10115591 W10115591 COVER
8205239 8205239 COVER-PLT
8184897 8184897 COVER-PLT
8206051 8206051 COVER-PLT
8206224 8206224 COVER-SEN
8206105 8206105 COVR-DUCT
8206085 8206085 COVR-INVT
8206476 8206476 COVR-LIGHT
8169646 8169646 COVR-LIGHT
W10115581 W10115581 COVR-LIGHT
W10115578 W10115578 COVR-LIGHT
8206103 8206103 COVR-TERML
W10843943 W10843943 DAMPER
8206163 8206163 DEFLCTR-AR
8205980 8205980 DEFLCTR-AR
W10244735 W10244735 DIFFUSER
8206150 8206150 DOOR CONTROL ASSEMBLY (BISCUIT)
WP8206121 WP8206121 DOOR HANDLE
WP8184837 WP8184837 ELEMENT
8206086 8206086 FERRITE
W10120839A W10120839A FILTER
W10120840A W10120840A FILTER
W10115585 W10115585 FRAME-DOOR
W10115586 W10115586 FRAME-DOOR
W10115587 W10115587 FRAMEDOOR
W11707984 W11707984 FUSE-THRML
8206166 8206166 GASKET-DOR
8206148 8206148 GLASS-DOOR
8206149 8206149 GLASS-DOOR
W10115584 W10115584 GLASS-DOOR
W10189668 W10189668 GLASS-LAMP
8206020 8206020 GUIDE-AIR
8206494 8206494 GUIDE-AIR
W10115590 W10115590 GUIDE-AIR
W10244764 W10244764 HANDLE (WHITE)
W10851464 W10851464 HANDLE-PAN
8205979 8205979 HARD-MOUNT
W10553076 W10553076 HARNS-WIRE
8206185 8206185 HARNS-WIRE
8206186 8206186 HARNS-WIRE
W10470176 W10470176 HARNS-WIRE
W10470179 W10470179 HARNS-WIRE
W10470175 W10470175 HARNS-WIRE
W10470186 W10470186 HARNS-WIRE
W10554449 W10554449 HARNS-WIRE
W10112290 W10112290 HARNS-WIRE
WPW10510203 WPW10510203 HEATER
8206071 8206071 HEATER
8206122 8206122 HNDLE-DOOR
8206123 8206123 HNDLE-DOOR
8206053 8206053 HOLDER
8206089 8206089 HOLDER
W10117908 W10117908 HOLDER, FUSE
8206076 8206076 HOUSING
8206081 8206081 HOUSING
8206092 8206092 HOUSNG-BLW
8206112 8206112 HOUSNG-BLW
W10113781 W10113781 HOUSNG-LMP
8206139 8206139 INNER DOOR
8205272 8205272 INSTALLATION INSTRUCTIONS
8205572 8205572 INTERLOCK
8206209 8206209 INTERLOCK
W10217711 W10217711 INVERTER
8206083 8206083 LID-VALVE
8206094 8206094 LMP-BASLES
8204670 8204670 LMP-BASLES
8206079 8206079 MAGNETRON
100000 100000 MISCELLANEOUS
WP8206069 WP8206069 MOTOR-FAN
8206075 8206075 MOTOR-FAN
W11661547 W11661547 MOTOR-TURN
W10245708 W10245708 OUTER DOOR FRAME (STAINLESS STEEL)
W10748097 W10748097 PAN-CRISP
8206058 8206058 PANEL
8206056 8206056 PANEL
8206041 8206041 PANEL
8206042 8206042 PANEL
8206043 8206043 PANEL
W10245706 W10245706 PANEL
W10115571 W10115571 PANEL
8206210 8206210 PISTON
8206061 8206061 PLATE
W10527358 W10527358 PLATE
8206007 8206007 PLATE
8206097 8206097 PLATE
8184132 8184132 PLATE
8206099 8206099 PLATE
8206077 8206077 PLATE
8206024 8206024 PLATE
W10115570 W10115570 PLATE
W10282660 W10282660 PLATE, MICA
WPW10560782 WPW10560782 PLATE-MTNG
W10115575 W10115575 PLATE-MTNG
8205745 8205745 QUICK REFERENCE
WP8205995 WP8205995 RACK
WP8206264 WP8206264 RACK-MEAL
W11553234 W11553234 RANGE THERMOSTAT
8184194 8184194 REFLECTOR
W10113782 W10113782 RESISTOR
W10113783 W10113783 RESISTOR
8206222 8206222 RING-TURN
8206206 8206206 SCREEN
8206207 8206207 SCREEN
8206475 8206475 SCREEN
4393836 4393836 SCREW
W11380570 W11380570 SCREW
4393832 4393832 SCREW
8182518 8182518 SCREW
8206179 8206179 SCREW
8206180 8206180 SCREW
8206181 8206181 SCREW
8169478 8169478 SCREW
8206167 8206167 SCREW
W10115593 W10115593 SCREW
8184109 8184109 SEAL, WATERPROOF
8206023 8206023 SENSOR
W10115577 W10115577 SENSOR
8206477 8206477 SHIELD
W10115582 W10115582 SHIELD
W10245707 W10245707 SIDE PANEL, RIGHT (STAINLESS STEEL)
W10143958 W10143958 SOCKET, LAMP (2)
8206082 8206082 SOLENOID
8206170 8206170 SPACER
8206178 8206178 SPACER
W10113784 W10113784 SPACER
8206084 8206084 SPRING
8206091 8206091 SPRING
8206499 8206499 SPRING (4)
W10113792 W10113792 SPRING, HOOK
8206039 8206039 SUPPORT
8206107 8206107 SUPPORT
8206031 8206031 SUPPORT
8205994 8205994 SUPPORT
8206011 8206011 SUPPORT
8206016 8206016 SUPPORT
8206015 8206015 SUPPORT
W10115568 W10115568 SUPPORT
W10269458 W10269458 SWITCH, MICRO SZM-V16-FC-62
W10211974 W10211974 SWITCH, MICRO V15T16-CP200
W10211972 W10211972 SWITCH, MICRO V15T16-CZ200
8205293 8205293 TECH SHEET
8205274 8205274 TEMPLATE, UPPER
8206026 8206026 THRMST-FIX
8206035 8206035 THRMST-FIX
W10599629 W10599629 THRMST-FIX
W10291311 W10291311 TRIM, DOOR (STAINLESS STEEL)
8206144 8206144 TRIM-DOOR
8206146 8206146 TRIM-DOOR
W10115583 W10115583 TRIM-DOOR
8205992 8205992 TURNTABLE
8205283 8205283 USE & CARE GUIDE
8206168 8206168 WASHER
8206073 8206073 WASHER
W10115573 W10115573 WASHER
8206074 8206074 WHEEL-FAN
W10470191 W10470191 WIRE HARNESS
W10470173 W10470173 WIRE HARNESS
W10470182 W10470182 WIRE HARNESS
W10244733 W10244733 WRAPER-CAB
8206029 8206029 WRAPER-CAB
W10115569 W10115569 WRAPER-CAB
