Model Image
Manufacturer

Whirlpool

Model Number

IK8FXNGFDM00

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
876370 876370 "INSULATION (2 PIECES, 3"" X 24"" X 48"")"
876029 876029 "KIT, FOAM SLAB (30"" X 32 1/2"" X 1 1/2"")"
W10646481 W10646481 ARM-SHUT
W11594405 W11594405 AXLE
W11175807 W11175807 AXLE-ROLL
W11736795 W11736795 BAFFLE-AIR
606755 606755 BAG
WPW10139483 WPW10139483 BLADE-FAN
WP2163777 WP2163777 BLADE-FAN
W11402852 W11402852 BRACKET
W11745278 W11745278 BRACKET
W11500948 W11500948 BRACKET
W10314197 W10314197 BRACKET
2254454 2254454 BRACKET, EVAPORATOR FAN REAR
WP2254517 WP2254517 BUTTON-PLG
WP941839 WP941839 BUTTON-PLG
WPW10520307 WPW10520307 BUTTON-PLG
N_P N_P CABINET (NOT SERVICED)
WPW10313918 WPW10313918 CAMERA LENS-LIGHT
W10849198 W10849198 CAP-SCREW
WPW10662129 WPW10662129 CAPACITOR
4387478 4387478 CAPACITOR (SERVICE)
WP4317852 WP4317852 CEMENT, ALUMILASTIC (1 1/4 OZ.)
W10861184 W10861184 CLAMP
549193 549193 CLAMP, POWER CORD
W10812039 W10812039 CLIP
WP628379 WP628379 CLIP
W11661170 W11661170 CLIP
2219077 2219077 CLIP, HARNESS
WPW10507886 WPW10507886 COMPRESSOR
W11512423 W11512423 CONDENSER
W10628683 W10628683 CONTRL-BOX
W11244470 W11244470 CONTROL
WPW10643378 WPW10643378 CONTROL BOARD
W11352623 W11352623 CONTROL BOX
W10854527 W10854527 COVER
W10677275 W10677275 COVER
W11256504 W11256504 COVER
W10300902 W10300902 COVER
W10763751 W10763751 COVER, HOLE
W11024683 W11024683 COVER-EVAP
WPW10339203 WPW10339203 COVER-TUBE
W11476772 W11476772 COVER-UNIT
W10860753 W10860753 CRISPER PAN
W11676540 W11676540 CUP-FILL
W11026417 W11026417 DAMPER-AIR
W10861170 W10861170 DIFFUSER
LW10680730 LW10680730 DOOR ASSEMBLY
LW10680727 LW10680727 DOOR ASSEMBLY
WP2254618 WP2254618 DOOR HINGE
WP2261963 WP2261963 DOOR HINGE
WP2218113 WP2218113 DOOR-COMP
WP2188234 WP2188234 DOOR-SHELF
W10843121 W10843121 DRIER-TUBE
W10919804 W10919804 DUCT-AIR
WP2156003 WP2156003 ENDCAP
W10685034 W10685034 ENERGY LABEL
W10836706 W10836706 EVAPORATOR
WP2315539 WP2315539 EVAPORATOR MOTOR
W10646247 W10646247 EXTENSION
WPW10601149 WPW10601149 FITTING
WPW10289690 WPW10289690 FRONT COVER
WP1106508 WP1106508 GASKET
W10849448 W10849448 GASKET
W11036546 W11036546 GASKET-DOR
W11028007 W11028007 GASKET-DOR
W11674475 W11674475 GLASS SHELF
W11674478 W11674478 GLASS SHELF
W11674479 W11674479 GLASS SHELF
WP542638 WP542638 GREASE
W10638176 W10638176 GRILLE
W10852725 W10852725 GROMMET
W11661108 W11661108 GROMMET
WP2264462 WP2264462 GROMMET
W10240002 W10240002 HANDLE
W11551368 W11551368 HARNS-WIRE
W11436564 W11436564 HARNS-WIRE
W11643622 W11643622 HARNS-WIRE
W10856574 W10856574 HEAT-PROBE
WPW10316428 WPW10316428 HEATER
W11026307 W11026307 HINGE-PIN
WPW10313917 WPW10313917 HOUSING
4317943 4317943 ICEMAKER ASSEMBLY
WPW10279909 WPW10279909 INLET VALVE
4387491 4387491 INSERT, TUBE
W11553819 W11553819 INSULATION
833938 833938 KIT, TERMINAL CONNECTOR
8003RP 8003RP KIT, WATER INLET
W10920316 W10920316 LENS-LIGHT
W10854419 W10854419 LEVELER
W11518235 W11518235 LIGHT BULB
W11216993 W11216993 LIGHT BULB
W11127829 W11127829 MOTOR-COND
W10850162 W10850162 ORIFICE
4392900 4392900 PAINT, BULK (1 QT. BISCUIT/BISQUE)
799344 799344 PAINT, BULK (1 QT. WHITE (UNCUT))
4392901 4392901 PAINT, PRESSURIZED SPRAY (12 OZ. BISCUIT/BISQUE)
350942 350942 PAINT, PRESSURIZED SPRAY (12 OZ. WHITE PRIMER)
350930 350930 PAINT, PRESSURIZED SPRAY (12 OZ. WHITE)
285006 285006 PAINT, PRESSURIZED SPRAY (12OZ. BLACK)
4392899 4392899 PAINT, TOUCH-UP (1/2OZ. BISCUIT/BISQUE)
72032 72032 PAINT, TOUCH-UP (1/2OZ. BLACK)
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
W11625904 W11625904 PAN-ICE
WP2174706 WP2174706 PIN-HITCH
W11164152 W11164152 ROLLER
WPW10475495 WPW10475495 ROLLER-CAB
W11256723 W11256723 ROLLER-CAB
W11096015 W11096015 ROLLER-CAB
WP489128 WP489128 SCREW
WP488921 WP488921 SCREW
WP3400065 WP3400065 SCREW
WP489478 WP489478 SCREW
W11544659 W11544659 SCREW
WP488163 WP488163 SCREW
WPW10141625 WPW10141625 SCREW
WP489497 WP489497 SCREW
WP489442 WP489442 SCREW
W10001280 W10001280 SCREW
WP681249 WP681249 SCREW
W10829281 W10829281 SCREW
WP505587 WP505587 SEALER
WP503695 WP503695 SEALER
212643 212643 SEALER, GUM (4 FEET)
W10669164 W10669164 SERVICE & WIRING SHEET
WPW10314195 WPW10314195 SHIELD
W11169703 W11169703 SHIM
WP2183852 WP2183852 SHIM
W11590562 W11590562 SLIDE
W11661565 W11661565 SOCKET
WPW10448874 WPW10448874 START-DEV
W10718082 W10718082 SUPPORT
W10624648 W10624648 SUPPORT PLATE, COMPRESSOR
W11384469 W11384469 SWITCH
W11238399 W11238399 TAPE
WPW10383615 WPW10383615 THERMISTOR
W11438736 W11438736 THERMISTOR
WP2183003 WP2183003 THIMBLE
WPW10339879 WPW10339879 TIE-WIRE
WP1117510 WP1117510 TORX SCREW WRENCH, TORX KEY
W11595232 W11595232 TRACK
W11595233 W11595233 TRACK
W11595235 W11595235 TRACK
W10633582 W10633582 TRAY-EVAP
W10809774 W10809774 TRIM, SHELF FRONT
W10809773 W10809773 TRIM, SHELF FRONT
W11170805 W11170805 TRIM-DOOR
W11129820 W11129820 TRIM-DOOR
W11106290 W11106290 TRIM-DOOR
W11126055 W11126055 TRIM-DOOR
W11097831 W11097831 TRIM-DOOR
W10628685 W10628685 TRIM-SHELF
W11167827 W11167827 TRIM-SHELF
W10628689 W10628689 TRIM-SHELF
W11167828 W11167828 TRIM-SHELF
W11676464 W11676464 TUBE
W10633577 W10633577 TUBE
W10633584 W10633584 TUBE
W10633573 W10633573 TUBE-DRAIN
W10685032 W10685032 USE & CARE GUIDE
WP978025 WP978025 VALVE
978030 978030 VALVE, ACCESS
876764 876764 VALVE, ACCESS
978026 978026 VALVE, ACCESS
978029 978029 VALVE, ACCESS
978027 978027 VALVE, ACCESS
978028 978028 VALVE, ACCESS
W10847959 W10847959 WASHER
WP489467 WP489467 WASHER
W10823511 W10823511 WATER TUBE
511873 511873 WHITE PORCELAIN (2 OZ.)
W11611445 W11611445 WIRE HARNESS
