Model Image
Manufacturer

Whirlpool

Model Number

JBL2088HES5

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
W10284690 W10284690 ADAPTER, SLIDE (LEFT)
W10284691 W10284691 ADAPTER, SLIDE (RIGHT)
WP627843 WP627843 ARM-EJECTR
WP67004028 WP67004028 ARM-SHUT
WP2182124 WP2182124 ARM-STRIPR
67006434 67006434 AXLE, ROLLER (2)
67003794 67003794 BAR, TEMP CONTROL
W10143564 W10143564 BASKET, FREEZER (LOWER)
W10143526 W10143526 BASKET-FZR
WP627985 WP627985 BIMETL-DEF
WP12825803 WP12825803 BLADE-FAN
WP2169142 WP2169142 BLADE-FAN
WP12777701 WP12777701 BLOCK- FIL
W10257665 W10257665 BOX
WP12227304WD WP12227304WD BRACE- CRI
WP2256087 WP2256087 BRACKET
WPW10281116 WPW10281116 BRACKET
WPW10281115 WPW10281115 BRACKET
WPW10330994 WPW10330994 BRACKET
WPW10330995 WPW10330995 BRACKET
67004721 67004721 BUCKET, CHILLER
67004718 67004718 BUCKET, LG REF DR
67004978 67004978 BUSHING (BLACK)
WP67001130 WP67001130 BUTTON- PL
N_P N_P CABINET (NOT A SERVICABLE PART)
W11395888 W11395888 CAP-FILTER
WP65889-4 WP65889-4 CAPACITOR
WP4317852 WP4317852 CEMENT, ALUMILASTIC (1 1/4 OZ.)
W10833902 W10833902 CLAMP
10526701 10526701 CLAMP, WIRE
31462A 31462A CLEANER, 10 OZ. STAINLESS STEEL
WP2315522 WP2315522 CLIP
W10819546 W10819546 CLIP
13058002 13058002 CLIP, EVAP. MOTOR
10623002 10623002 CLIP, EVAPORATOR
67002816 67002816 CLIP, WATERLINE
10547003 10547003 CLIP- DRIE
W11673433 W11673433 CLIP- EVAP
WPM0114003 WPM0114003 CLIP- SPEE
WP67003639 WP67003639 CLOSER
W10160407 W10160407 COMPRESSOR KIT (CONTAINS ITEMS 12, 17, 27, & 29)
WPW10346415 WPW10346415 CONDENSER
WPW10594329 WPW10594329 CONTROL
WPW10319823 WPW10319823 CONTROL BOARD
WPW10317076 WPW10317076 CONTROL BOARD
W10827015 W10827015 COVER
W11519867 W11519867 COVER
W11284721 W11284721 COVER
12816203 12816203 COVER
W10720642 W10720642 COVER
67003485 67003485 COVER, CORNER (BLK)
67003905 67003905 COVER, FZ LIGHT
67001012 67001012 COVER, TOP HINGE (BLK)
WP12568001 WP12568001 COVER- FIL
WP67003924 WP67003924 COVER- FZ
12726003 12726003 COVER- WAT
WPW10211855 WPW10211855 COVER-BACK
WP12806701 WP12806701 COVER-BOX
W11727809 W11727809 COVER-EVAP
W10208593 W10208593 COVER-VALV
12961602 12961602 COVER-WIRE
W11226688 W11226688 COVERWIRE
W10122561 W10122561 CUP, WATER FILL
12225602 12225602 DAM (LEFT SIDE)
12225702 12225702 DAM (RIGHT SIDE)
67004727 67004727 DIVIDER, BASKET (LWR)
67004127 67004127 DIVIDER, UPPER BASKET
WP67002321 WP67002321 DIVIDER- P
WP12566606ED WP12566606ED DOOR HINGE
WP12607104ED WP12607104ED DOOR HINGE
67004598 67004598 DOOR, CHILLER (RT)
13092257SQ 13092257SQ DOOR, FREEZER (STAINLESS)
12805403SP 12805403SP DOOR, LH CHILLER
13023894SQ 13023894SQ DOOR, REFRIGERATOR (STAINLESS (FOR JBL2088HES5))
13023896SQ 13023896SQ DOOR, REFRIGERATOR (STAINLESS (FOR JBR2088HES5))
WP67003637 WP67003637 DOOR-COMP
WPW10143759 WPW10143759 DRIER-UV
WP12656105 WP12656105 ENDCAP
WP12656018 WP12656018 ENDCAP
W10183292 W10183292 ENERGY GUIDE
WPW10128551 WPW10128551 EVAPORATOR MOTOR
W10367416 W10367416 EXTENSION
WP67006010 WP67006010 EXTR- GLAS
W10206339 W10206339 FASTENER
WP2300868 WP2300868 FITTING
WP67006185 WP67006185 FRAME
67004720 67004720 FRAME, CHILLER
WPW10289690 WPW10289690 FRONT COVER
WP67005912 WP67005912 FRONT, CRISPER PAN
W10815413 W10815413 FUNNEL
12918001 12918001 FUNNEL, FILL TUBE
W10856123 W10856123 GASKET
W11159728 W11159728 GASKET
W11250029 W11250029 GASKET
W10436252 W10436252 GASKET, DOOR (BLACK)
67006429 67006429 GASKET, HV CONTROL
67002329 67002329 GASKET, PANTRY
WPB8381501 WPB8381501 GASKET- DR
W10164039 W10164039 GASKET-FIP
12002497 12002497 GEAR
WP67006655 WP67006655 GLASS SHELF
WP12463911 WP12463911 GLASS SHELF
W11125512 W11125512 GLASS SHELF
WPW10235370 WPW10235370 GLIDE
WP542638 WP542638 GREASE
WPW10175909 WPW10175909 GRILLE
WPW10534153 WPW10534153 GRILLE-FRT
WPW10169124 WPW10169124 GROMMET
WPW10137529 WPW10137529 GROMMET
W10121318 W10121318 GROMMET
W11677725 W11677725 GUIDE
W11448709 W11448709 GUIDE, FILL TUBE
12850918 12850918 HANDLE
12850919 12850919 HANDLE
W10222811 W10222811 HARNS-WIRE
W10280418 W10280418 HARNS-WIRE
W10224290 W10224290 HARNS-WIRE
W10235312 W10235312 HARNS-WIRE
W11346623 W11346623 HEAD-FILTR
W10825088 W10825088 HEATER
67004602 67004602 HOOK, CHILLER FRAME
W11416469 W11416469 HOUSING
12656202 12656202 HOUSING
12806601 12806601 HOUSING, LIGHT
WP2195914 WP2195914 HOUSING-IM
D7824706Q D7824706Q ICE MAKER ASSEMBLY.
67003900 67003900 INSERT, DAMPER COVER
WPA3223101 WPA3223101 INSERT- PL
WP13012402 WP13012402 INSULATION
W11706807 W11706807 INSULATION
12820505 12820505 INSULATION
12002041 12002041 KIT, EVAP REPLACEMENT
799833 799833 KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY)
W11498983 W11498983 KNOB
W10251971 W10251971 LADDER
W10273463 W10273463 LADDER
WPW10141622 WPW10141622 LEVELER
W11679940 W11679940 LIGHT BULB
67002293 67002293 LINKAGE, CHILLER
67004601 67004601 LINKAGE, CHILLER CTR
8201515 8201515 MODULE ASSEMBLY (INCLUDES ITEMS 21 & 22)
67003906 67003906 MODULE, FZ CONTROL
Y67003896 Y67003896 MODULE, LIGHT
WPW10190929 WPW10190929 MOLD-ICE
W11613295 W11613295 MOTOR-COND
WP12945201 WP12945201 MOUNT, HANDLE
12848704 12848704 NAMEPLATE
W10269084 W10269084 OVERLAY
799344 799344 PAINT
4392900 4392900 PAINT
285006 285006 PAINT, PRESSURIZED SPRAY (12OZ. BLACK)
WP67002659 WP67002659 PAN- CRISP
WPW10655368 WPW10655368 PAN-DRIP
WP67001255 WP67001255 PAN-ICE
W11490183 W11490183 PAN-UTILTY
WP67006642 WP67006642 PIN
W11727651 W11727651 PLATE
12707303SP 12707303SP PLATE
WP67001668 WP67001668 PLATE- FIL
M0310731 M0310731 PLUG, BUTTON (3) (BLACK)
350942 350942 PRIMER
67005999 67005999 RACK, BOTTLE
W11229977 W11229977 RESERVOIR
67004717 67004717 RETAINER, DOOR
WP67005149 WP67005149 ROLLER
WPW10515762 WPW10515762 ROLLER-CAB
WPW10515763 WPW10515763 ROLLER-CAB
WP489128 WP489128 SCREW
WP489464 WP489464 SCREW
WP67006415 WP67006415 SCREW
W10709795 W10709795 SCREW
67006608 67006608 SCREW
WP33001882 WP33001882 SCREW
W10709798 W10709798 SCREW
WPW10133608 WPW10133608 SCREW
WP400021-1 WP400021-1 SCREW
WP489474 WP489474 SCREW
WP90767 WP90767 SCREW
WP98165 WP98165 SCREW
WP489349 WP489349 SCREW
WP67006380 WP67006380 SCREW
WP8281196 WP8281196 SCREW
W10829281 W10829281 SCREW
8533917 8533917 SCREW
12992301 12992301 SCREW
WP681249 WP681249 SCREW
489136 489136 SCREW
67006425 67006425 SCREW (3)
67006564 67006564 SCREW (8)
WPM0500703 WPM0500703 SEAL- O RI
WP505587 WP505587 SEALER
WP503695 WP503695 SEALER
212643 212643 SEALER-GUM
W11028221 W11028221 SHAFT
W11556315 W11556315 SHROUD
WPW10167023 WPW10167023 SHROUD
WP67005864 WP67005864 SLIDE
W11658403 W11658403 SLIDE
WP67003793 WP67003793 SLIDE- TEM
W11447232 W11447232 SOCKET
350930 350930 SPRAY
4392901 4392901 SPRAY
WPW10244032 WPW10244032 START-DEV
W11708403 W11708403 STOP-DOOR
12745704 12745704 STRAP, BALE
WP12227305WD WP12227305WD SUPPORT
12831101 12831101 SWEEP, DUAL TUBE
W11384469 W11384469 SWITCH
W11396033 W11396033 SWITCH
WP12575501 WP12575501 SWITCH- LI
W11238399 W11238399 TAPE
W10238843 W10238843 TECH SHEET
833938 833938 TERMINAL
WP1117510 WP1117510 TORX KEY
WP67001719 WP67001719 TRACK
W10332340 W10332340 TRAY, BASKET (LOWER)
WP67001279 WP67001279 TRAY- DAIR
W11547653 W11547653 TRAY-DRIP
WPW10231478 WPW10231478 TRIM-SHELF
W10217746 W10217746 TUBE
W10619951 W10619951 TUBE-DRAIN
72017 72017 TUCHUP
72032 72032 TUCHUP
W10137647 W10137647 USE & CARE GUIDE
WP12544124 WP12544124 VALVE
WP978025 WP978025 VALVE
978030 978030 VALVE
978029 978029 VALVE
978027 978027 VALVE
978026 978026 VALVE
876764 876764 VALVE
978028 978028 VALVE, ACCESS (1/2``)
EDR4RXD1 EDR4RXD1 WATER FILTER
W11120581 W11120581 WATER TUBE
W11176463 W11176463 WATER TUBE
WPD7813010 WPD7813010 WIRE HARNESS
