Model Image
Manufacturer

Whirlpool

Model Number

JDSP548HM01

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
W11200313 W11200313 "HARNESS, MAIN (18"")"
W11200316 W11200316 "HARNESS, MAIN (30"")"
W10282812 W10282812 "INSULATION, BACK, 18"""
W10285449 W10285449 ACCESSORIES, BACKSPLASH 48-IN WITH SHELF
W10352736 W10352736 ACCESSORY PARTS, BACKSPLASH (ADJUSTABLE)
W10123240 W10123240 ACCESSORY PARTS, RACK, BROILER PAN AND ROASTING
31462A 31462A ACCESSORY PARTS, STAINLESS STEEL CLEANER & POLISH
4453116 4453116 ADAPTER, MALE
WP7101P485-60 WP7101P485-60 ANCHOR-TIP
W11318855 W11318855 ANTENNA
W11238043 W11238043 BACKSPLASH, KIT, HIGH ALTITUDE
W11232487 W11232487 BAFFLE, CONVECTION
W10908710 W10908710 BASE, LEVELING LEG
W11317890 W11317890 BEZEL-KNOB
W11317892 W11317892 BEZEL-KNOB
W11317889 W11317889 BEZEL-KNOB
W11243764 W11243764 BLOCK, TERMINAL
W11248652 W11248652 BLOWER
W11243763 W11243763 BOARD, TRANSIENT SUPPRESSOR
8186352 8186352 BOILER
W11320545 W11320545 BOTTM-MAIN
W11353392 W11353392 BOX, TERMINAL
W11544575 W11544575 BRACKET, ANTI-TIP
W11047754 W11047754 BRACKET, BLOWER MOUNT
W11112336 W11112336 BRACKET, BROIL FRONT
W11158843 W11158843 BRACKET, BROIL TOP
W10130760 W10130760 BRACKET, MOVING CONSOLE (LEFT)
W10130759 W10130759 BRACKET, MOVING CONSOLE (RIGHT)
W10331561 W10331561 BRACKET, STEAM MOUNT
W11317495 W11317495 BRASS, GRIDDLE
W11323014 W11323014 BRASS, LARGE BURNER CAP (SINGLE)
W11323012 W11323012 BRASS, LARGE KIT, BEZEL (SET OF 4)
W11323067 W11323067 BRASS, OVEN
W11323068 W11323068 BRASS, OVEN BEZEL (SINGLE)
W11323015 W11323015 BRASS, SMALL
W11316873 W11316873 BRASS, SURFACE AND GRIL
W11317894 W11317894 BRKT-MNTG
W11320155 W11320155 BRKT-MNTG
W11319226 W11319226 BRKT-MNTG
W11320153 W11320153 BRKT-MNTG
WPW10351278 WPW10351278 BUMPER
W11319673 W11319673 BURNR-HEAD
W11319683 W11319683 BURNR-HEAD
W11318857 W11318857 BUTTN-PUSH
W11319196 W11319196 BUTTN-PUSH
W11369237 W11369237 CABINET, APPLIANCE MANAGER
W10294500 W10294500 CAMERA LENS, INDICATOR LIGHT
W10169756 W10169756 CAMERA LENS, LIGHT
W11319224 W11319224 CAP-BURNER
W11368831 W11368831 CHANNEL, WIRE
W11323024 W11323024 CHROME, GRIDDLE
W11317499 W11317499 CHROME, OVEN
W11323061 W11323061 CHROME, SURFACE AND GRILL
W11323062 W11323062 CHROME, SURFACE AND GRILL
WP488366 WP488366 CLAMP
WP489503 WP489503 CLAMP
W10355051 W10355051 CLEANER, COOKTOP
W11318207 W11318207 CLIP
W11428599 W11428599 CNVRSN-KIT
W10115819 W10115819 COLUMN, CENTRAL
W11234290 W11234290 CONTROL BOARD
W11388048 W11388048 CONTROL BOARD
W11317945 W11317945 CONTROL BOARD
W11492294 W11492294 CONTROL BOARD
W11289593 W11289593 CONTROL PANEL
W11316702 W11316702 COOKTOP
W11316701 W11316701 COOKTOP
W11316700 W11316700 COOKTOP
W11170823 W11170823 COVER PLATE, TERMINAL HOLE
W11177696 W11177696 COVER, BOILER ORIFICE
W11111391 W11111391 COVER, BROIL TERMINAL
W10160858 W10160858 COVER, DOOR LATCH
W11368180 W11368180 COVER, FAN
W10160195 W10160195 COVER, GRILL/GRIDDLE
W10115843 W10115843 COVER, IGNITION
W11320410 W11320410 COVER-CNTL
W11320411 W11320411 COVER-CNTL
W11320405 W11320405 COVER-LTCH
W11320599 W11320599 COVER-REAR
W11320600 W11320600 COVER-REAR
W11388050 W11388050 COVER-REAR
W11320407 W11320407 COVR-ACESS
W11202366 W11202366 DIAGRAM, WIRING
W11029221 W11029221 DOOR DOOR LATCH
W11318200 W11318200 DOOR HANDLE
W11317893 W11317893 DOOR HANDLE
W11318204 W11318204 DOOR HINGE
W11318202 W11318202 DOOR HINGE
W11568813 W11568813 DOOR HINGE
W11568941 W11568941 DOOR HINGE
W11320147 W11320147 DRAWER
W11320536 W11320536 DUCT
W11050145 W11050145 DUCT-CHASSIS, REAR
489504 489504 E-RING
W11643125 W11643125 ELEMENT
W10116010 W10116010 ELEMENT, BROIL
W11210530 W11210530 ELEMENT, BROIL
W10116434 W10116434 ELEMENT, CONVECTION
W11045324 W11045324 ELEMENT, HIDDEN BAKE
W10115995 W10115995 ELEMENT, HIDDEN BAKE
W11319602 W11319602 ELMNT-GRIL
W10160877 W10160877 ENCLOSURE, STEAM VALVE
W11320150 W11320150 FAN-CONVCT
WPW10049700 WPW10049700 FILTER
N_P N_P FOLLOWING PARTS NOT ILLUSTRATED
WP9759117 WP9759117 FOOT-LEVEL
W10859931 W10859931 FOOT-LEVEL
W11318335 W11318335 FRAME-GLAS
W11318831 W11318831 FRAME-GLAS
WPW10272594 WPW10272594 FRAME-WNDW
W11175143 W11175143 GASKET
W11115326 W11115326 GASKET, CAVITY (18 IN)
W11675844 W11675844 GASKET-OVN
W11315558 W11315558 GLASS DOOR
W11317951 W11317951 GLASS DOOR
W11315556 W11315556 GLASS DOOR
W11318823 W11318823 GLASS DOOR
W11193191 W11193191 GLASS, BROIL ELEMENT
W11516462 W11516462 GRATE-BRNR
W11516481 W11516481 GRATE-BRNR
W11516449 W11516449 GRATE-BRNR
W11602622 W11602622 GRIDDLE
W11184746 W11184746 GUIDE, INTERNET CONNECTIVITY
W11177312 W11177312 GUIDE, QUICK START
W11114330 W11114330 GUIDE, USE AND CARE
W10780278 W10780278 HARNESS, DOOR LOCK
W11317948 W11317948 HINGE-RECV
W11318331 W11318331 HINGE-RECV
W11319747 W11319747 HOLDER-ORF
W11319743 W11319743 HOLDER-ORF
W11319740 W11319740 HOLDER-ORF
W11319745 W11319745 HOLDER-ORF
W11319746 W11319746 HOLDER-ORF
W11319741 W11319741 HOLDER-ORF
WPW10076930 WPW10076930 HOSE
W10116067 W10116067 HOSE, SILICONE (RED)
W11238756 W11238756 IGNITER (LEFT CENTER REAR)
W11580024 W11580024 IGNTR-SURF
W11573760 W11573760 IGNTR-SURF
W11318834 W11318834 INFINITE CONTROL SWITCH
W11114333 W11114333 INSTRUCTIONS, INSTALLATION
W11688507 W11688507 INSULATION
W11317950 W11317950 INSULATION
W11688537 W11688537 INSULATION
W11688744 W11688744 INSULATION
W11688396 W11688396 INSULATION
W11661177 W11661177 INSULATION
W11319228 W11319228 INSULATION
W11320149 W11320149 INSULATOR
8186589 8186589 JACK-PROBE
W11317536 W11317536 KNOB
W11317539 W11317539 KNOB
W11317537 W11317537 KNOB
W11368944 W11368944 KNOB
W11317886 W11317886 KNOB
WPW10169757 WPW10169757 LIGHT BULB
W10116114 W10116114 LIGHT, INDICATOR HOUSING
W11318856 W11318856 LIGHT-IND
W11233684 W11233684 LIGHT-OVEN
W11231343 W11231343 LOCKNUT
W11320025 W11320025 MANIFOLD
W11320019 W11320019 MANIFOLD
W11320017 W11320017 MANIFOLD
W11602621 W11602621 MODULE
W11685616 W11685616 MOTOR-FAN
W10794042 W10794042 NUT
W11198435 W11198435 NUT
999299 999299 NUT
WP3400029 WP3400029 NUT
WP3400968 WP3400968 NUT
WP112432 WP112432 NUT
W11092978 W11092978 ORIFICE, BOILER SLIP FIT
W10892418 W10892418 ORIFICE, MAIN (15.4K) (LEFT REAR AND RIGHT FRONT)
W10892440 W10892440 ORIFICE, MAIN (7.2K) (LEFT CENTER REAR)
W10892429 W10892429 ORIFICE, SIMMER (2.0K) (LEFT CENTER REAR)
W11550692 W11550692 PAD-GRATE
W11320144 W11320144 PANEL-CBNT
W11320145 W11320145 PANEL-CBNT
W11320598 W11320598 PANEL-VENT
W11320403 W11320403 PANEL-VENT
W11320402 W11320402 PANEL-VENT
W10261523 W10261523 PLATE, FAN
W11317946 W11317946 PLATE-COVR
WP9759118 WP9759118 PLATE-MTG
W11321066 W11321066 POWER CORD
WP9755542 WP9755542 PROBE-MEAT
W11318341 W11318341 PROBE-MEAT
W11111351 W11111351 RACK, OVEN (18 IN)
W11563568 W11563568 RACK-OVEN
W11319687 W11319687 RANGE SPARK MODULE
WP4449751 WP4449751 RANGE THERMOSTAT
W11106948 W11106948 REGULATOR
W11318328 W11318328 RETAINER
W11318344 W11318344 RETAINER
W11362015 W11362015 RETAINER, GASKET (9 IN LONG)
W10216179 W10216179 RING, WOK
WPW10138054 WPW10138054 ROLLER-CAB
W10850807 W10850807 SCREW
W10739592 W10739592 SCREW
WP4449154 WP4449154 SCREW
W11193480 W11193480 SCREW
W11712404 W11712404 SCREW
W11169708 W11169708 SCREW
3400518 3400518 SCREW
WP4449743 WP4449743 SCREW
W11509770 W11509770 SCREW
W10709795 W10709795 SCREW
W11233072 W11233072 SCREW
WP3400814 WP3400814 SCREW
WP90767 WP90767 SCREW
WP3196557 WP3196557 SCREW
W10674068 W10674068 SCREW
W11323260 W11323260 SCREW
W10162096 W10162096 SCREW
W10491985 W10491985 SCREW
4450800 4450800 SCREW, GROUNDING
W10270396 W10270396 SEAL, CHIMNEY
W10270402 W10270402 SEAL, VENT SLOPE (18 IN)
W10270397 W10270397 SEAL, VENT SLOPE (30 IN)
WPW10076760 WPW10076760 SENSOR
W10859573 W10859573 SENSOR
W11319618 W11319618 SENSOR
W10115869 W10115869 SHAFT, LONG
W10115793 W10115793 SHAFT, SHORT
W11202265 W11202265 SHEET, TECH
W10160855 W10160855 SHIELD, ELEMENT BROIL
W11320596 W11320596 SIDE-COMPT
W11321067 W11321067 SIDE-COMPT
W10818235 W10818235 SLOPE, EXHAUST VENT (18 IN)
W10818234 W10818234 SLOPE, EXHAUST VENT (30 IN)
W11123146 W11123146 SPEAKER
W11661909 W11661909 SPUD-ORFCE
W11643164 W11643164 SPUD-ORFCE
W11369238 W11369238 SUPPORT, CHANNEL
W10194453 W10194453 SWITCH, PRESSURE
W11388055 W11388055 TOP-OVEN
W10276497 W10276497 TRAY, GRIDDLE DRIP
W11330430 W11330430 TRAY, GRIDDLE INSULATION
W11320538 W11320538 TRAY-BAKE
W11320540 W11320540 TRAY-BAKE
W10291193 W10291193 TRIM, L-STRIP
W10271524 W10271524 TRIM, T-STRIP (BLACK)
W11320157 W11320157 TRIM-TOP
W11334757 W11334757 TUBE, COPPER STEAM
W10288078 W10288078 TUBE, VENT
W11318343 W11318343 TUBE-VENT
W11320154 W11320154 TUBING-GAS
W11320139 W11320139 TUBING-GAS
W11320027 W11320027 TUBING-GAS
W11320029 W11320029 TUBING-GAS
W10111418 W10111418 VALVE, SOLENOID
W11320597 W11320597 VENT-EXHST
W11317791 W11317791 WIRE HARNESS
W11317786 W11317786 WIRE HARNESS
W11317788 W11317788 WIRE HARNESS
W11317787 W11317787 WIRE HARNESS
W11320016 W11320016 WIRE HARNESS
