Whirlpool

Model Number

JGC8645ADB

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WP7540P030-60 WP7540P030-60 BASE, BURNER
74005969 74005969 BOX BURNE
74005976 74005976 BRACKET S
W10175142 W10175142 BRACKET, HOLDDOWN
74005952 74005952 BRACKET, SEALED BURNER
WP8020P088-60 WP8020P088-60 BRKT-MNTG
74007182 74007182 BURNER, BASE (SM)
WP7540P028-60 WP7540P028-60 BURNR-BASE
74007191 74007191 CAP, BURNER (SMR-MT BLK)
WP74007203 WP74007203 CAP-BURNER
WP74007196 WP74007196 CAP-BURNER
3188867 3188867 CORD, POWER
7724P004-60 7724P004-60 COVER, BURNER VALVE
4005F816-51 4005F816-51 COVER, SPARK MODULE
74009549 74009549 GRATE (LT-BLK)
74009550 74009550 GRATE (RT-BLK)
74005980 74005980 GRATE CN
WP74005934 WP74005934 GROMMET
74007136 74007136 GUIDE, COOKING (TRILINGUAL)
74005961 74005961 HARNESS M
74005964 74005964 HARNESS S
74005963 74005963 HARNESS S
74005978 74005978 HOLDER W O
74005977 74005977 HOLDER W O
WP7507P238-60 WP7507P238-60 HOLDER-ORF
7507P241-60 7507P241-60 IGNITOR, (RIGHT FRONT)
WP7432P109-60 WP7432P109-60 IGNTR-OVEN
74005988 74005988 KIT, LP ORIFICE
WP74005939 WP74005939 KNOB- BURN
WP74005940 WP74005940 KNOB- BURN
WP8009P031-60 WP8009P031-60 LEVER-LOCK
74005527 74005527 MANUAL, USE & CARE
WP7103P178-60 WP7103P178-60 NUT
71002728 71002728 ORIFICE
WP71002727 WP71002727 ORIFICE, LP (6000)
74005970 74005970 PIPE MANI
74005971 74005971 PIPE MANI
WP71002749 WP71002749 RANGE SPARK MODULE
W11106948 W11106948 REGULATOR-
705833 705833 RELIEF, STRAIN
WP90767 WP90767 SCREW
W10491986 W10491986 SCREW
WP3400202 WP3400202 SCREW
WP7509P062-60 WP7509P062-60 SPUD-ORFCE
WP74005954 WP74005954 SWITCH- IG
74005953 74005953 SWITCH- IG
74005979 74005979 SWITCH- IG
74005983 74005983 TOP, MAIN (BLK)
74005975 74005975 TUBE BURN
74005974 74005974 TUBE BURN
74005950 74005950 TUBE BURN
74005951 74005951 TUBE BURN
74005949 74005949 TUBE BURN
74005948 74005948 TUBE BURN
74005972 74005972 TUBE, CROSSOVER
74005973 74005973 VALVE TOP
74005947 74005947 VALVE, TOP BURNER
74005946 74005946 VALVE- TOP
74005945 74005945 VALVE- TOP
74005944 74005944 VALVE- TOP
WP7538P003-60 WP7538P003-60 VENTURI
15002812 15002812 WIRING INFORMATION
