Model Image
Manufacturer

Whirlpool

Model Number

JGS9900CDF00

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
74004438 74004438 ACCESSORY PARTS, CORD, POWER
WP7101P485-60 WP7101P485-60 ANCHOR-TIP
3804F294-51 3804F294-51 BACK, MAIN
3601F339-45 3601F339-45 BAFFL-BRNR
3601F358-45 3601F358-45 BAFFL-BRNR
3601F373-51 3601F373-51 BAFFLE
3601F221-45 3601F221-45 BAFFLE,VENT COVER
WP74011650 WP74011650 BLACK CAP, BURNER (INNER) (LEFT FRONT)
2205F051-19 2205F051-19 BOTTM-OVEN
4020W035-80 4020W035-80 BOTTOM-PE
WP3424F039-09 WP3424F039-09 BOWL, DUAL
WP3801F656-51 WP3801F656-51 BRACKET
3801F681-45 3801F681-45 BRACKET
3801F886-51 3801F886-51 BRKT-MNTG
3801F906-51 3801F906-51 BRKT-MNTG
3801F912-51 3801F912-51 BRKT-MNTG
8405P073-60 8405P073-60 BRKT-MNTG
WP74009925 WP74009925 BULB- HALO
74007735 74007735 BURNER ASSEMBLY (LRG)
74007736 74007736 BURNER ASSEMBLY (X-LRG)
74011652 74011652 BURNER ASY (DUAL)
74010094 74010094 BURNER, BAKE
74011731 74011731 BURNER, BROILER
4011F476-51 4011F476-51 BURNR-BASE
WP7505P339-60 WP7505P339-60 BURNR-TOP
3804F307-51 3804F307-51 C
WP74011651 WP74011651 CAP-BURNER
WP8284669 WP8284669 CAP-BURNER
WP74007750 WP74007750 CAP-BURNER
WP74007749 WP74007749 CAP-BURNER
8106P068-60 8106P068-60 CARD, FLOW TESTER
WP7111P047-60 WP7111P047-60 CLAMP, HOSE
5700D526-60 5700D526-60 CLAMP-MTR
WP8507P236-60 WP8507P236-60 CONTROL BOARD
W10235815 W10235815 COOKTOP
W10235921 W10235921 COOKTOP
4005F736-45 4005F736-45 COVER
3605F350-19 3605F350-19 COVER
4005F815-51 4005F815-51 COVER
W10840495 W10840495 COVER
4005F789-09 4005F789-09 COVER
4005F421-45 4005F421-45 COVER IGN
4005F750-51 4005F750-51 COVER- DOO
4005F612-51 4005F612-51 COVER-BLCK
WP7724P200-60 WP7724P200-60 COVER-VENT
4005F810-51 4005F810-51 COVR-ACESS
74010819 74010819 DOOR LATCH ASY
WPY702326 WPY702326 DUCT, FLEXIBLE
W10183566 W10183566 EXTRUSION
WPW10586440 WPW10586440 FAN-BLWR
WPW10206590 WPW10206590 FAN-CONVCT
WP8310P007-60 WP8310P007-60 FILTER
74011737 74011737 FITTING, BAKE
74011738 74011738 FITTING, ORIFICE (BROIL BNR)
8407P013-60 8407P013-60 FLUE-BOX
N_P N_P FOLLOWING PARTS NOT ILLUSTRATED,
3603F075-70 3603F075-70 FRAME, DOOR (BLACK)
3603F075-71 3603F075-71 FRAME-DOOR
WP74010776 WP74010776 GASKET- FI
WPW10162384 WPW10162384 GASKT-DOOR
7201P143-60 7201P143-60 GASKT-DOOR
WPW10272330 WPW10272330 GLASS DOOR
WPW10272332 WPW10272332 GLASS DOOR
74003645 74003645 GLASS, INNER
W10235391 W10235391 GLASSDOOR
74011740 74011740 GRATE (BLACK (LEFT))
WP7518P332-60 WP7518P332-60 GRATE-BRNR
74011875 74011875 GRILL, AIR (BLK)
WP3806F011-80 WP3806F011-80 HANGER, ACCESS PANEL
74011728 74011728 HARNESS, MAIN
74009965 74009965 HARNESS, SIDE MOUNT LOCK
5175P365-60 5175P365-60 HARNESS- D
5171P537-60 5171P537-60 HARNS-WIRE
W10173466 W10173466 HARNS-WIRE
74011475 74011475 HINGE, DOOR
W10223163 W10223163 HNDLE-DOOR
W10223164 W10223164 HNDLE-DOOR
W10223165 W10223165 HNDLE-DOOR
74011741 74011741 HOLDER, ORIFICE (5K)
WP7527P061-60 WP7527P061-60 HOLDER-ORF
WP7527P086-60 WP7527P086-60 HOLDER-ORF
WP7527P087-60 WP7527P087-60 HOLDER-ORF
W10826866 W10826866 IGNTR-OVEN
W11596211 W11596211 IGNTR-OVEN
WP74009336 WP74009336 IGNTR-SURF
W10253463 W10253463 INSTALLATION INSTRUCTIONS
7002P246-60 7002P246-60 INSULATION
7002P479-60 7002P479-60 INSULATION
7002P447-60 7002P447-60 INSULATION
WPW10208653 WPW10208653 INSULATION
7003P154-60 7003P154-60 INSULATOR
WPW10258123 WPW10258123 KIT, LP GAS
12002268 12002268 KIT, VALVE/SCREW 5K(MUELLER)
12002269 12002269 KIT, VALVE/SCREW 9K(MUELLER)
W10255424 W10255424 KNOB
W10255423 W10255423 KNOB
WP74011220 WP74011220 LIGHT ASY-
WP2402W312-19 WP2402W312-19 LINER-DOOR
74010860 74010860 LOCATOR, GRATE
7513P473-60 7513P473-60 MANIFOLD P
WPW10201322 WPW10201322 MOTOR-BLWR
WPW10273267 WPW10273267 MOTOR-BLWR
W10214169 W10214169 NAMEPLATE
W10190723 W10190723 NAMEPLATE
W10190724 W10190724 NAMEPLATE
WP3400029 WP3400029 NUT
7103P212-60 7103P212-60 NUT
74007451 74007451 NUT, MOUNTING
WP7103P114-60 WP7103P114-60 NUT- SNAP
WP74001574 WP74001574 NUT- SNAP
7103P030-60 7103P030-60 NUT- WING
74011543 74011543 OVERLAY (BLACK)
WP7922P058-60 WP7922P058-60 OVERLAY (WHITE)
511873 511873 PAINT
4392900 4392900 PAINT
799344 799344 PAINT
350942 350942 PAINT, PRESSURIZED SPRAY (12 OZ.) (PRIMER, WHITE)
WP2416F086-70 WP2416F086-70 PANEL
2618F206-51 2618F206-51 PANEL
2416F086-71 2416F086-71 PANEL
2618F202-51 2618F202-51 PANEL- SHI
WPW10312498 WPW10312498 PANEL-DRWR
W10236210 W10236210 PANL-CNTRL
2801L037-80 2801L037-80 PLENUM
2801W034-80 2801W034-80 PLENUM-AIR
WP7402P104-60 WP7402P104-60 POWER CORD
WP7430P038-60 WP7430P038-60 PROBE-MEAT
WP7801P173-60 WP7801P173-60 RACK-OVEN
WPW10475147 WPW10475147 RANGE SPARK MODULE
WP7408P086-60 WP7408P086-60 RECEPTACLE
8212471 8212471 REFINISHING MATERIAL (TOUCH-UP SELF-CLEAN(1/2 PT))
74011878 74011878 REGULATOR, PRESSURE
8038P003-60 8038P003-60 RETAINER
3804F308-51 3804F308-51 RETAINER-
4026F009-51 4026F009-51 RING
4026F008-51 4026F008-51 RING
W11347848 W11347848 SCREW
WP90767 WP90767 SCREW
WP7101P434-60 WP7101P434-60 SCREW
WP74010805 WP74010805 SCREW
WP4159193 WP4159193 SCREW
WP3387230 WP3387230 SCREW
WP7101P639-60 WP7101P639-60 SCREW
WP74003976 WP74003976 SCREW
WP98008545 WP98008545 SCREW
WP8273062 WP8273062 SCREW
74003975 74003975 SCREW (8ABX3/8-BLK)
74008798 74008798 SCREW W/SHOULDER (NO.8)
2822W003-80 2822W003-80 SCROLL-FAN
12001655 12001655 SENSOR
3604F433-51 3604F433-51 SHIELD
3604F416-51 3604F416-51 SHIELD
WP3604F446-45 WP3604F446-45 SHIELD, VENT
3604F418-51 3604F418-51 SHIELD- DO
3401F091-45 3401F091-45 SHIELD-HT
W10857933 W10857933 SPACER
4392901 4392901 SPRAY
285006 285006 SPRAY
350930 350930 SPRAY
3807F751-51 3807F751-51 SUPPORT
W10271711 W10271711 SUPPORT
8020P074-60 8020P074-60 SUPPORT, GLASS
WP74011647 WP74011647 SWITCH HAR
WP74011648 WP74011648 SWITCH HAR
WP7450P108-60 WP7450P108-60 SWTCH-LITE
7450P030-60 7450P030-60 SWTCH-LMIT
9762761 9762761 TIPS, SAFE COOKING (ENGLISH)
W10065852 W10065852 TIPS, SAFE COOKING (FRENCH)
WP3608F138-70 WP3608F138-70 TRIM-SIDE
WP7506P464-60 WP7506P464-60 TUBE- SUPP
7506P480-60 7506P480-60 TUBE-BRNR
7506P481-60 7506P481-60 TUBING, BAKE
7506P479-60 7506P479-60 TUBING, INNER DUAL
7506P482-60 7506P482-60 TUBING-GAS
7506P475-60 7506P475-60 TUBING-GAS
72032 72032 TUCHUP
72017 72017 TUCHUP
4392899 4392899 TUCHUP
W10235527 W10235527 USE & CARE GUIDE
WP7502P493-60 WP7502P493-60 VALVE (LEFT FRONT)
74011867 74011867 VALVE, BURNER
WP74006345 WP74006345 VALVE- OVE
3804F315-51 3804F315-51 VENT-OVEN
8026P092-60 8026P092-60 VENT-OVEN
74009194 74009194 WASHER, HANDLE
WPY707985 WPY707985 WHEEL-FAN
W10235694 W10235694 WIRING DIAGRAM
