Model Image
Manufacturer

Whirlpool

Model Number

JJW9530AAW

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
71001852 71001852 BLADE FAN
WP74006613 WP74006613 BOARD, RELAY (UPPER)
71003398 71003398 BRACKET D
71003386 71003386 BRACKET H
WP9781049 WP9781049 CAMERA LENS-LIGHT
71001170 71001170 CLIP OVEN
WP71003424 WP71003424 CONTROL BOARD
WP71001858 WP71001858 CONVECTION MTR ASSEMBLY
71003508 71003508 COOKBOOK
702929 702929 COVER HOL
71001813 71001813 COVER MAI
74002380 74002380 COVER, HOLE
WP74008014 WP74008014 DOOR HINGE
WP71001845 WP71001845 DOOR LATCH, DOOR ASSEMBLY.
WPW10310258 WPW10310258 ELMNT-BAKE
WPW10310260 WPW10310260 ELMNT-BROL
71001843 71001843 EXTENSION, VENT
WP74004947 WP74004947 FAN MOTOR
71003180 71003180 FRAME OVE
71003395 71003395 FRAME, DOOR (WHT)
WP7201P017-60 WP7201P017-60 GASKET, WINDOW
74009648 74009648 GLASS DOOR
71003393 71003393 GLASS, DOOR (WHT)
71002801 71002801 GLASS, INNER
74007136 74007136 GUIDE, COOKING (TRILINGUAL)
16000326 16000326 GUIDE, QUICK REF - JENN-AIR
71003388 71003388 HANDLE, DOOR (WHT)
71001861 71001861 HARNESS C
71003404 71003404 HARNESS C
12001732 12001732 HARNESS, CONTROL (J10-UPR)
71001809 71001809 HARNESS, DOOR LOCK (UPR)
71001808 71001808 HARNESS, DOOR SWITCH (UPR)
71001868 71001868 HARNESS, MEAT PROBE
71003403 71003403 HARNESS, TOUCH PAD/CLOCK
71001798 71001798 HARNESS, WIRE CONTROL (J2)
WP74008015 WP74008015 HINGE-RECV
74008278 74008278 INSULATION
71001839 71001839 INSULATION
71002329 71002329 INSULATION (BACK-TOP)
71001820 71001820 INSULATION (TOP-BTM)
71001838 71001838 INSULATION, DOOR (BTM)
8009 8009 LIGHT BULB
71002967 71002967 LINER, OVEN DOOR
71003509 71003509 MANUAL, USE & CARE
WP3400029 WP3400029 NUT
M0282005 M0282005 NUT
9831122 9831122 NUT, HEX 3/8``
12001656 12001656 OVEN SENSOR REPLACEMENT (LONG)
71003005 71003005 OVEN WELD
71001814 71001814 PANEL, OVEN (SIDE/BTM/SIDE)
74006821 74006821 PANEL, TOP (INR)
Y74006818 Y74006818 PANEL, TOP (OUTER)
2624F056-51 2624F056-51 PANEL-BKGD
71003441 71003441 PANLCNTRL
71001815 71001815 PLATE HIN
71001854 71001854 PLATE, CONVECTION (FRT)
71001831 71001831 PLATE, DOOR LATCH
71001812 71001812 PLATE, HINGE TRAP
71003390 71003390 POCKET, HANDLE (WHT)
WP71001870 WP71001870 PROBE- TEM
4396923 4396923 PROCELAIN BROILER (PAN AND GRID)
74003595A 74003595A RACK-DEHYD
WPW10282527 WPW10282527 RACK-OVEN
71001866 71001866 RECEPTACLE, BULB
74009649 74009649 RECEPTACLE, PROBE
74005648 74005648 RETAINER, INSULATION
WP74003976 WP74003976 SCREW
WP7101P126-60 WP7101P126-60 SCREW
WPY706189 WPY706189 SCREW
WP400021-1 WP400021-1 SCREW
WP7101P434-60 WP7101P434-60 SCREW
W10759523 W10759523 SCREW
WP90767 WP90767 SCREW
12991103 12991103 SCREW
WPW10296816 WPW10296816 SCREW
WP355214 WP355214 SCREW
WP71001841 WP71001841 SEAL- DOOR
71003396 71003396 SHIELD HE
74007237 74007237 SPACER, DEHYDRATION
74007581 74007581 SUPPORT, TOP CONTROL
WP71002904 WP71002904 SWITCH, DOOR LIGHT
71001129 71001129 SWITCH, DOOR LOCK
WP71001844 WP71001844 THERMOSTAT
WPW10339879 WPW10339879 TIE-WIRE
71001804 71001804 TRIM CONT
74005644 74005644 TRIM, OVEN (LWR-WHT)
74005451 74005451 TRIM, SIDE (LT-WHT)
71003420 71003420 TRIM, SIDE (LT-WHT)
74005452 74005452 TRIM, SIDE (RT-WHT)
71003421 71003421 TRIM, SIDE (RT-WHT)
71002419 71002419 TUBE VENT
4011F438-45 4011F438-45 VENT (BTM)
71001847 71001847 VENT (TOP)
W10896751 W10896751 WASHER
71001403 71001403 WASHER AL
71001855 71001855 WHEEL CON
71001848 71001848 WIRE CABLE
71001869 71001869 WIRE, GROUND
15002514 15002514 WIRING INFORMATION
