Model Image
Manufacturer

Whirlpool

Model Number

KBMC140HBL04

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WP482338 WP482338 ADHESIVE
4375426 4375426 AIR BLEED
4375314 4375314 AIR DUCT, MICROWAVE MAGNETRON
WP8302345 WP8302345 ASSY, CONTROL
W10123223 W10123223 BACK, CONTROL
4448935 4448935 BAFFLE, BLOWER
4456487 4456487 BASE, CHASSIS
WP8184080 WP8184080 BLOCK-SLID
WP8203546 WP8203546 BLOCK-TERM
W11361286 W11361286 BLOWER
4375332 4375332 BRACKET
4455476 4455476 BRACKET
4455475 4455475 BRACKET
4375299 4375299 BRACKET, CAPACITOR
4450027 4450027 BRACKET, DUCT
4451632 4451632 BRACKET, FILTER
4449142 4449142 BRACKET, MOUNTING (LEFT SIDE)
4449141 4449141 BRACKET, MOUNTING (RIGHT SIDE)
WP4452331 WP4452331 BRKT-MNTG
4375255 4375255 BUSHING
4375435 4375435 CABLE
W11193483 W11193483 CAMERA LENS-LAMP
4451605 4451605 CAP, SPACER
WP4375020 WP4375020 CAPACTR-MG
4375433 4375433 CHAMBER, HEAT
4375257 4375257 CHAMBER, REFLECTOR
4452554 4452554 CHASSIS, BACK
4448664 4448664 CLAMP
4450950 4450950 CONDUIT, COMBO
WP4375338 WP4375338 COVER PLATE, UPPER
4452247 4452247 COVER, PLATE
4450378 4450378 COVER, TOP
WP4452367 WP4452367 COVER-TOP
WP4375340 WP4375340 COVR-CHOKE
WPW10687786 WPW10687786 DIODE
WP4375324 WP4375324 DOOR HINGE
WP4375323 WP4375323 DOOR HINGE
4375339 4375339 DOOR, PLATE
4375317 4375317 DUCT, AIR
4375419 4375419 DUCT, HEATER
4375260 4375260 DUCT, INLET
4449264 4449264 EASY SET GUIDE
4375417 4375417 ELEMENT, HEATER
4451634 4451634 EXHAUST DUCT
4449906 4449906 EXTENSION FILLER
W11512064 W11512064 FAN
4375441 4375441 FAN CAP
WP4375322 WP4375322 FAN WHEEL
4449086 4449086 FILLER, SIDE (LEFT SIDE)
WP4449083 WP4449083 FILLER, SIDE (RIGHT SIDE)
WP4451592 WP4451592 FILTER
WP8303556 WP8303556 FRAME-DOOR
WP4375321 WP4375321 FUSE
WP4452259 WP4452259 GLASS DOOR
WP4448937 WP4448937 GLASS, MIDDLE
4452995 4452995 GLASS, OUTER (BISCUIT)
WP4452211 WP4452211 GLASS, OUTER (BLACK)
4452789 4452789 GLASS, OUTER (WHITE)
4449964 4449964 GROMMET
4451052 4451052 GUIDE-EASY USE M/W
4452871 4452871 HANDLE, DOOR (BISCUIT)
4452502 4452502 HANDLE, DOOR (BLACK)
WP9760544 WP9760544 HANDLE, DOOR (STAINLESS)
4452503 4452503 HANDLE, DOOR (WHITE)
4453215 4453215 HARNESS, MAIN
8303838 8303838 HARNESS, MAIN FILTER
W10245194 W10245194 HOLDER, FUSE
4452615 4452615 INSTALLATION INSTRUCTIONS
4375432 4375432 INSULATION
4375420 4375420 INSULATION
4375409 4375409 INSULATION (LEFT SIDE)
4375410 4375410 INSULATION (RIGHT SIDE)
4375316 4375316 INSULATION, SWITCH
4452492 4452492 INSULATION-GRILL
4452491 4452491 INSULATION-TOP
4452248 4452248 INSULATOR, BOARD
4452249 4452249 INSULATOR, BOARD SUPPORT
4452345 4452345 INSULATOR, DIALECTRIC
4389404 4389404 INSULATOR, DOOR (BLACK)
4452400 4452400 LEAD, GROUND STRAP
100000 100000 LEFT-THREADED NUT (SERVICED WITH MOTOR ITEM 61)
WPW10440740 WPW10440740 LMP-BASLES
WP4375424 WP4375424 MICROWAVE MAGNETRON
4375278 4375278 MOTOR, BLOWER
4375429 4375429 MOTOR, FAN
WP4450118 WP4450118 NUT
WP112432 WP112432 NUT
4375258 4375258 NUT
WP261869 WP261869 PAINT CW
350930 350930 PAINT, PRESSURIZED SPRAY (12 OZ. WHITE)
285006 285006 PAINT, PRESSURIZED SPRAY (12OZ. BLACK)
261900 261900 PAINT, SPRAY (CITRINE WHITE)
72032 72032 PAINT, TOUCH-UP (1/2OZ. BLACK)
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
4393900 4393900 PAN HANDLE
WPW10120480 WPW10120480 PAN-CRISP
4452974 4452974 PANEL, CONTROL (BISCUIT)
4452604 4452604 PANEL, CONTROL (BLACK)
4451791 4451791 PANEL, CONTROL (STAINLESS)
4452605 4452605 PANEL, CONTROL (WHITE)
4375331 4375331 PLATE, GRILL
4451789 4451789 PLATE, MOUNTING
4375411 4375411 PLATE, SIDE - BOTTOM
WP8186528 WP8186528 Q TUBE ASSEMBLY
4452220 4452220 RACK
4456546 4456546 RAIL, SIDE (LEFT SIDE)
4456545 4456545 RAIL, SIDE (RIGHT SIDE)
W11607085 W11607085 RANGE THERMOSTAT
WP4375079 WP4375079 RANGE THERMOSTAT
4452548 4452548 REAR CHANNEL
423107022541 423107022541 REFLECTOR
4375256 4375256 REFLECTOR
WPW10158497 WPW10158497 RETAINER
W10205119 W10205119 RETAINER
W10205117 W10205117 RETAINER, GLASS CLIP (BLACK)
4450864 4450864 RETAINER,GLASS CLIP (WHITE)
4375252 4375252 RUBBER RING
3191638 3191638 SAFER COOKING TIPS
9759133 9759133 SAFER COOKING TIPS
WP4448950 WP4448950 SCREW
WPW10132940 WPW10132940 SCREW
WP4449746 WP4449746 SCREW
WP4450038 WP4450038 SCREW
WP4449040 WP4449040 SCREW
4375313 4375313 SCREW
W11684512 W11684512 SCREW
489392 489392 SCREW
8206180 8206180 SCREW
WP4449154 WP4449154 SCREW
3400406 3400406 SCREW
WP4449809 WP4449809 SCREW
WP3400832 WP3400832 SCREW
4375428 4375428 SCREW TO VALVE
4450800 4450800 SCREW, GROUND
4340001 4340001 SCREW, HOUSING
4375422 4375422 SENSOR, TEMP.
WP8183788 WP8183788 SHAFT-TURN
4375431 4375431 SHIELD, HEAT
4375439 4375439 SHIELD, HEAT RIGHT
4375341 4375341 SIDE PLATE (LEFT)
4375342 4375342 SIDE PLATE (RIGHT)
4452559 4452559 SIDE, CHASSIS (R.H. & L.H.)
W10790240 W10790240 SIDE, CONTROL TOP (LEFT)
W10755214 W10755214 SIDE, CONTROL TOP (RIGHT)
4455471 4455471 SPACER
WP4451009 WP4451009 SPRING
WP4452396 WP4452396 SPRING
W10465869 W10465869 SPRING, LAMP
4375330 4375330 STRAP, DOOR
WP4375442 WP4375442 SUPPORT
4456399 4456399 SUPPORT RAILS
4375253 4375253 SUPPORT, TUBE
WP4451934 WP4451934 SUPPRESSOR
W10727408 W10727408 SWITCH
4456883 4456883 SWITCH, MEMBRANE (BISCUIT)
4456880 4456880 SWITCH, MEMBRANE (BLACK)
4456877 4456877 SWITCH, MEMBRANE (STAINLESS)
4456881 4456881 SWITCH, MEMBRANE (WHITE)
W10211972 W10211972 SWITCH, MICRO V15T16-CZ200
8303854 8303854 TECH SHEET
461967842541 461967842541 THERMOACTUATOR
4375281 4375281 THERMOSTAT
4375279 4375279 THERMOSTAT
WP4450551 WP4450551 TOP-CABNT
WP9760589 WP9760589 TRANSFORMER-CNTRL CONTROL
WP9760588 WP9760588 TRANSFORMR
WP4375286 WP4375286 TRANSFORMR
W11373838 W11373838 TRAY-COOK
4456544 4456544 TRIM, BOTTOM (BISCUIT)
4456540 4456540 TRIM, BOTTOM (BLACK)
4456538 4456538 TRIM, BOTTOM (STAINLESS)
4456542 4456542 TRIM, BOTTOM (WHITE)
4452972 4452972 TRIM, SIDE (LH BISCUIT)
4452625 4452625 TRIM, SIDE (LH BLACK)
4452557 4452557 TRIM, SIDE (LH STAINLESS)
4452627 4452627 TRIM, SIDE (LH WHITE)
4452971 4452971 TRIM, SIDE (RH BISCUIT)
4452624 4452624 TRIM, SIDE (RH BLACK)
4452556 4452556 TRIM, SIDE (RH STAINLESS)
4452626 4452626 TRIM, SIDE (RH WHITE)
8300890 8300890 USE & CARE GUIDE
4375425 4375425 VALVE
4456145 4456145 VENT-CNTRL PANEL
4375416 4375416 WASHER
4375254 4375254 WASHER
4450831 4450831 WIRE, GROUND
