Model Image
Manufacturer

Whirlpool

Model Number

KBMC140HSS0

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
4375426 4375426 AIR BLEED
4375314 4375314 AIR DUCT, MICROWAVE MAGNETRON
W10123223 W10123223 BACK, CONTROL
4448935 4448935 BAFFLE, BLOWER
4452541 4452541 BASE, CHASSIS
285006 285006 BLACK
72032 72032 BLACK
WP8203546 WP8203546 BLOCK, TERMINAL
WP8184080 WP8184080 BLOCK-SLID
W11361286 W11361286 BLOWER
4375332 4375332 BRACKET
4375299 4375299 BRACKET, CAPACITOR
4450027 4450027 BRACKET, DUCT
WP4449746 WP4449746 BRACKET, HANDLE (SCREW)
4449142 4449142 BRACKET, MOUNTING (LEFT SIDE)
4449141 4449141 BRACKET, MOUNTING (RIGHT SIDE)
WP4452331 WP4452331 BRKT-MNTG
4375255 4375255 BUSHING
4375435 4375435 CABLE
4375441 4375441 CAP, FAN
4451605 4451605 CAP, SPACER
WP4375020 WP4375020 CAPACTR-MG
4375433 4375433 CHAMBER, HEAT
4375257 4375257 CHAMBER, REFLECTOR
4452554 4452554 CHASSIS, BACK
WP261869 WP261869 CITRINE WHITE
4448664 4448664 CLAMP
W10205117 W10205117 CLIP, RETAINER (BLACK MODEL)
4450950 4450950 CONDUIT, COMBO
LIT4450786 LIT4450786 COOKING GUIDE
WP4375338 WP4375338 COVER PLATE (LOWER)
4450378 4450378 COVER, TOP
WP4452367 WP4452367 COVER-TOP
WP4375340 WP4375340 COVR-CHOKE
72017 72017 DRAWER, STORAGE PAINT, TOUCH-UP (1/2OZ.) (WHITE)
4375317 4375317 DUCT, AIR
4451634 4451634 DUCT, EXHAUST
4375419 4375419 DUCT, HEATER
4375260 4375260 DUCT, INLET
4375417 4375417 ELEMENT, HEATER
4449906 4449906 EXTENSION FILLER
W11512064 W11512064 FAN
WP4375322 WP4375322 FAN WHEEL
4449086 4449086 FILLER, SIDE (LEFT)
WP4449083 WP4449083 FILLER, SIDE (RIGHT SIDE)
WP8303556 WP8303556 FRAME-DOOR
WP4375321 WP4375321 FUSE
WP4448937 WP4448937 GLASS, MIDDLE
4452995 4452995 GLASS, OUTER (BISCUIT)
WP4452211 WP4452211 GLASS, OUTER (BLACK)
WP4452259 WP4452259 GLASS, OUTER (STAINLESS STEEL)
4452789 4452789 GLASS, OUTER (WHITE)
4449964 4449964 GROMMET
LIT3191638 LIT3191638 GUIDE BOOK STICKER
4452871 4452871 HANDLE, DOOR (BISCUIT)
4452502 4452502 HANDLE, DOOR (BLACK)
WP9760544 WP9760544 HANDLE, DOOR (STAINLESS)
4452503 4452503 HANDLE, DOOR (WHITE)
4393900 4393900 HANDLE, PAN
4452612 4452612 HARNESS, MAIN
WP4375323 WP4375323 HINGE, DOOR (LEFT)
WP4375324 WP4375324 HINGE, DOOR (RIGHT SIDE)
W10245194 W10245194 HOLDER, FUSE
4375432 4375432 INSULATION
4375420 4375420 INSULATION
4375409 4375409 INSULATION (LEFT SIDE)
4375410 4375410 INSULATION (RIGHT SIDE)
4452248 4452248 INSULATION, BOARD
4452249 4452249 INSULATION, BOARD SUPPORT
4375316 4375316 INSULATION, SWITCH
4452492 4452492 INSULATION-GRILL
4452491 4452491 INSULATION-TOP
4452345 4452345 INSULATOR, DIALECTRIC
4389404 4389404 INSULATOR, DOOR (BLACK)
WPW10440740 WPW10440740 LAMP
4452400 4452400 LEAD, GROUND STRAP
100000 100000 LEFT-THREADED NUT (SERVICED WITH MOTOR ITEM 61)
W11193483 W11193483 LENS, LAMP
LIT4449264 LIT4449264 LITERATURE PARTS (EASY SET GUIDE)
LIT4451052 LIT4451052 LITERATURE PARTS (GUIDE-EASY USE M/W)
LIT4452615 LIT4452615 LITERATURE PARTS (INSTALLATION INSTRUCTIONS)
LIT4452613 LIT4452613 LITERATURE PARTS (TECH SHEET)
LIT4452614 LIT4452614 LITERATURE PARTS (USE & CARE GUIDE)
WP4375424 WP4375424 MAGNETRON
8302985 8302985 MICROCOMPUTER
4375278 4375278 MOTOR, BLOWER
4375429 4375429 MOTOR, FAN
W10642989 W10642989 MOTOR, TURNTABLE
WP4450118 WP4450118 NUT
4375258 4375258 NUT
WP112432 WP112432 NUT, T-BLOCK (4)
261900 261900 PAINT, SPRAY (CITRINE WHITE (6 OZ.))
WPW10120480 WPW10120480 PAN-CRISP
4452974 4452974 PANEL, CONTROL (BISCUIT)
4452604 4452604 PANEL, CONTROL (BLACK)
4452605 4452605 PANEL, CONTROL (WHITE)
4451791 4451791 PANEL, CONTROL STAINLESS STEEL
4452247 4452247 PLATE, COVER
4375339 4375339 PLATE, DOOR
4375331 4375331 PLATE, GRILL
4451789 4451789 PLATE, MOUNTING
4375411 4375411 PLATE, SIDE - BOTTOM
WP8186528 WP8186528 Q TUBE ASSEMBLY
4452220 4452220 RACK
4452550 4452550 RAIL, SIDE (LEFT SIDE)
4452549 4452549 RAIL, SIDE (RIGHT SIDE)
W11607085 W11607085 RANGE THERMOSTAT
WP4375079 WP4375079 RANGE THERMOSTAT
4452548 4452548 REAR CHANNEL
WPW10687786 WPW10687786 RECTIFIER
423107022541 423107022541 REFLECTOR
4375256 4375256 REFLECTOR
W10205119 W10205119 RETAINER
WPW10158497 WPW10158497 RETAINER, GLASS-CLIP (BLACK STAINLESS)
4450864 4450864 RETAINER,GLASS CLIP (WHITE)
4375252 4375252 RING, RUBBER
4375313 4375313 SCREW
489392 489392 SCREW
8206180 8206180 SCREW
3400406 3400406 SCREW
WP4450038 WP4450038 SCREW
WP3400832 WP3400832 SCREW
WP4449040 WP4449040 SCREW
WP3400016 WP3400016 SCREW (2)
WP4449154 WP4449154 SCREW (BLACK) (WHITE)
4375428 4375428 SCREW TO VALVE
WP4449809 WP4449809 SCREW, 8-18 X 3/8
WPW10132940 WPW10132940 SCREW, 8-32 X 9/16
4450800 4450800 SCREW, GROUND
4340001 4340001 SCREW, HOUSING
WP4448950 WP4448950 SCREW, INSTALL (2)
WP482338 WP482338 SEALER, SILASTIC (3OZ.)
4375422 4375422 SENSOR, TEMP.
WP8183788 WP8183788 SHAFT-TURN
4375431 4375431 SHIELD, HEAT
4375439 4375439 SHIELD, HEAT RIGHT
4375341 4375341 SIDE PLATE (LEFT)
4375342 4375342 SIDE PLATE (RIGHT)
4452559 4452559 SIDE, CHASSIS (R.H. & L.H.)
W10790240 W10790240 SIDE, CONTROL TOP (LEFT)
W10755214 W10755214 SIDE, CONTROL TOP (RIGHT)
4452260 4452260 SPACER, FOAM
350930 350930 SPRAY (13 OZ.) (WHITE)
W10465869 W10465869 SPRING, LAMP
WP4451009 WP4451009 SPRING, TORSION (RIGHT HAND)
WP4452396 WP4452396 SPRING, TORSION (STAINLESS MODEL)
4375330 4375330 STRAP, DOOR
WP4375442 WP4375442 SUPPORT
4452552 4452552 SUPPORT RAILS (LEFT SIDE)
4452551 4452551 SUPPORT RAILS (RIGHT SIDE)
4375253 4375253 SUPPORT, TUBE
WP4451934 WP4451934 SUPPRESSOR
W10727408 W10727408 SWITCH
W10211972 W10211972 SWITCH
4456883 4456883 SWITCH, MEMBRANE (BISCUIT)
4453028 4453028 SWITCH, MEMBRANE (BLACK)
4453025 4453025 SWITCH, MEMBRANE (STAINLESS)
4453029 4453029 SWITCH, MEMBRANE (WHITE)
461967842541 461967842541 THERMOACTUATOR
4375281 4375281 THERMOSTAT
4375279 4375279 THERMOSTAT
WP4450551 WP4450551 TOP-CABNT
WP9760589 WP9760589 TRANSFORMER, CONTROL PANEL
WP9760588 WP9760588 TRANSFORMR
WP4375286 WP4375286 TRANSFORMR
W11373838 W11373838 TRAY-COOK
4452976 4452976 TRIM, BOTTOM (BISCUIT)
4452621 4452621 TRIM, BOTTOM (BLACK)
4452569 4452569 TRIM, BOTTOM (STAINLESS)
4452623 4452623 TRIM, BOTTOM (WHITE)
4452972 4452972 TRIM, SIDE (LH BISCUIT)
4452625 4452625 TRIM, SIDE (LH BLACK)
4452557 4452557 TRIM, SIDE (LH STAINLESS)
4452627 4452627 TRIM, SIDE (LH WHITE)
4452971 4452971 TRIM, SIDE (RH BISCUIT)
4452624 4452624 TRIM, SIDE (RH BLACK)
4452556 4452556 TRIM, SIDE (RH STAINLESS)
4452626 4452626 TRIM, SIDE (RH WHITE)
4375425 4375425 VALVE
4450791 4450791 VENT-CNTRL PANEL
4375416 4375416 WASHER
4375254 4375254 WASHER
4450831 4450831 WIRE, GROUND
