Model Image
Manufacturer

Whirlpool

Model Number

KBRA22KMBL00

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
978030 978030 ACCESS VALVE (3/4``)
12002500 12002500 ADAPTER (RIGHT SIDE)
350956 350956 ALMOND
WP72107 WP72107 ALMOND
67006434 67006434 AXLE, ROLLER (2)
606755 606755 BAG, INSULATION (36-5/8`` X 46``)
WP12591403 WP12591403 BASE
13016002 13016002 BASKET, LOWER
67004986 67004986 BASKET, UPPER
WP67001040 WP67001040 BELT- DAMP
72032 72032 BLACK
WP12587601 WP12587601 BLADE- CON
WP2169142 WP2169142 BLADE-FAN
WP67005633 WP67005633 BRACKET
WPW10280613 WPW10280613 BRACKET
WPW10280608 WPW10280608 BRACKET
8171239 8171239 BRACKET, FAN MOTOR
WP12812501WD WP12812501WD BRACKET- D
WP12812502WD WP12812502WD BRACKET- D
67002930 67002930 BUCKET, MED REF DR
67004978 67004978 BUSHING (BLACK)
WP67004975 WP67004975 BUSHING (WHITE)
WP2165792K WP2165792K BUTTERTRAY
WP67001130 WP67001130 BUTTON- PL
WP12246608 WP12246608 BUTTON- PL
100000 100000 CABINET (NOT A SERVICEABLE PART)
WP67005626 WP67005626 CADDY- CAN
WP65889-4 WP65889-4 CAPACITOR
WP4317852 WP4317852 CEMENT, ALUMILASTIC (1 1/4 OZ.)
W11673433 W11673433 CLIP
67001067 67001067 CLIP, DRAIN TUBE
8170901 8170901 CLIP, DRIER
4344219 4344219 CLIP, EVAPORATOR
WP12627302 WP12627302 CLIP- TOE
WP67003638 WP67003638 CLOSER
12002311 12002311 CLOSER
WP67003639 WP67003639 CLOSURE, DOOR (BLACK)
4396418 4396418 COMPLETE ICE MAKER ASSEMBLY
W10309989 W10309989 COMPRESSOR
WP67006132 WP67006132 CONDENSER
WP67003410 WP67003410 CONTROL
12694401 12694401 COVER, CONTROL
67001285 67001285 COVER, CONTROL
12587703C 12587703C COVER, CORNER (BISQUE)
67003485 67003485 COVER, CORNER (BLK)
67003484 67003484 COVER, CORNER (WHT)
8170883 8170883 COVER, EVAPORATOR
8170976 8170976 COVER, HINGE (BISCUIT)
8170832 8170832 COVER, REF. LIGHT
67001012 67001012 COVER, TOP HINGE (BLK)
67001014 67001014 COVER, TOP HINGE (WHT)
12575101WD 12575101WD COVER, UNIT
WP67001098 WP67001098 COVER-TUBE
WP628356 WP628356 CUP-FILL
8170890 8170890 DAM (LEFT SIDE)
8170891 8170891 DAM (RIGHT SIDE)
8171227 8171227 DIVIDER, BASKET (LOWER)
67004127 67004127 DIVIDER, BASKET (UPPER)
12658538SQ 12658538SQ DOOR ASSEMBLY SS
12658928SQ 12658928SQ DOOR ASSEMBLY SS
WP12744905 WP12744905 DOOR COMP
8171197 8171197 DOOR GASKET, MAGNETIC (WHITE)
W10443315 W10443315 DOOR GASKET, MAGNETIC (WHITE)
WP12566606ED WP12566606ED DOOR HINGE
W10215663 W10215663 DOOR HINGE
WP12607104ED WP12607104ED DOOR HINGE
12658533BQ 12658533BQ DOOR, REFRIGERATOR (BLACK)
12477402 12477402 DRAIN PAN
72017 72017 DRAWER, STORAGE PAINT, TOUCH-UP (1/2OZ.) (WHITE)
W10843121 W10843121 DRIER-TUBE
W10136387A W10136387A EGG-CONTNR
978883 978883 ENAMEL, ALMOND (1 QT. UNCUT)
8171244 8171244 ENERGY TAG
12001919 12001919 EVAPORATOR
W11177593 W11177593 FEET-LVLNG
67003796 67003796 FIBER, ACOUSTIC
2174017 2174017 FRAME & ROLLER ASSEMBLY
8171223 8171223 FRAME, CRISPER
8171218 8171218 FREEZER DOOR PANEL (INCLUDES INSULATION) (BISCUIT)
8171217 8171217 FREEZER DOOR PANEL (INCLUDES INSULATION) (BLACK)
8171219 8171219 FREEZER DOOR PANEL (INCLUDES INSULATION) (WHITE)
W10815413 W10815413 FUNNEL
12658901SQ 12658901SQ FZ DR FOAM
W11159742 W11159742 GASKET
W10856123 W10856123 GASKET
8170924 8170924 GASKET
WPW10436248 WPW10436248 GASKET ASSEMBLY
WPW10436250 WPW10436250 GASKET ASSEMBLY
WPB8381501 WPB8381501 GASKET- DR
12002497 12002497 GEAR (INCLDS. BOTH)
67001037 67001037 GEAR, DAMPER
2174142 2174142 GLASS, CRISPER COVER
WP542638 WP542638 GREASE, SILICONE (1/2 OZ.)
WPW10175909 WPW10175909 GRILLE
8170997 8170997 GRILLE ASSEMBLY (INCLUDES CLIPS) (BISCUIT)
WP67003843 WP67003843 GRILLE-FRT
WP67003849 WP67003849 GRILLE-FRT
67005680 67005680 GROMMET (2)
798392 798392 GROMMET (3)
8170888 8170888 GROMMET, SCREW
WP61004743 WP61004743 GROMMET- B
WP67002780 WP67002780 GROMMET- F
2255516T 2255516T HANDLE (BISCUIT)
2304832B 2304832B HANDLE (BLACK)
8171176 8171176 HANDLE (STAINLESS STEEL)
8171184 8171184 HANDLE (WHITE)
8170874 8170874 HANDLE, BASKET
8171200 8171200 HARNESS, EVAP. HEATER
8171241 8171241 HARNESS, UNIT
WP67001794 WP67001794 HEATER- DE
12465001WD 12465001WD HINGE BOTTOM (WHITE)
8171003 8171003 HINGE COVER, BOTTOM (BISCUIT)
WP12561901B WP12561901B HINGE COVER, BOTTOM (BLACK)
12561901W 12561901W HINGE COVER, BOTTOM (WHITE)
W11689473 W11689473 HINGE- CEN
WP67002085 WP67002085 HOUSING
W11702858 W11702858 HOUSING
WP12724501 WP12724501 HOUSING, REF. LIGHT
4343700 4343700 ICE CONTAINER ASSEMBLY
12650002 12650002 INSULATION
799833 799833 KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY)
876029 876029 KIT, FOAM SLAB (30`` X 32-1/2`` X 1-1/2``)
833938 833938 KIT, TERMINAL CONNECTOR
67001033 67001033 KNOB
67002512 67002512 KNOB, FRONT
67003420 67003420 KNOB, FZ CONTROL
8170870 8170870 LADDER, CENTER
12710604 12710604 LADDER- SI
W11679940 W11679940 LIGHT BULB
67002945 67002945 LOGO, LIGHT MODULE
876370 876370 MISCELLANEOUS, INSULATION (2 PIECES, 3`` X 24`` X 48``)
WP12476002 WP12476002 MODULE- FZ
833697 833697 MOTOR-COND
WPW10128551 WPW10128551 MOTOR-EVAP
2212760 2212760 NAMEPLATE
2212761 2212761 NAMEPLATE (BISCUIT)
2212762 2212762 NAMEPLATE (BLACK)
W10613606 W10613606 OVERLOAD (INCLUDES RELAY)
786032 786032 PAINT, BULK (1 QT.) (BLACK (UNCUT))
799344 799344 PAINT, BULK (1 QT.) (WHITE (UNCUT))
285006 285006 PAINT, PRESSURIZED SPRAY (12OZ. BLACK)
511873 511873 PAINT, TOUCH-UP 1/2 OZ. (WHITE PORCELAIN)
2173902 2173902 PAN SHELF & ROLLER ASSEMBLY
2188816 2188816 PAN, CRISPER (INCLUDES ROLLERS)
WP67001255 WP67001255 PAN-ICE
2175435 2175435 PAN-MEAT
67001045 67001045 PANEL, FZ CONTROL
67007018 67007018 PIN HINGE BOTTOM
8170921 8170921 PLATE, COVER
M0310343 M0310343 PLUG, BUTTON
4343926 4343926 PLUG, BUTTON (BLACK)
A3080001 A3080001 PLUG, BUTTON (BLK)
A3080002 A3080002 PLUG, BUTTON (WHT)
67004838 67004838 PLUG, VENT (BLACK)
10712401 10712401 PLUG, VENT (WHT)
WP2189000 WP2189000 PLUG-HNDLE
W10709784 W10709784 PLUG-HNDLE
WP2189009 WP2189009 PLUG-HNDLE
WP67006506 WP67006506 POWER CORD
350942 350942 PRIMER WHITE (13 OZ. SPRAY CAN)
8170880 8170880 RACK, ICE TRAY
12658533CQ 12658533CQ REFRIGERATOR DOOR PANEL (INCLUDES INSULATION) (BISCUIT)
12658534SQ 12658534SQ REFRIGERATOR DOOR PANEL (INCLUDES INSULATION) (STAINLESS STEEL RH)
WP12658533WQ WP12658533WQ REFRIGERATOR DOOR PANEL (INCLUDES INSULATION) (WHITE)
WP67005149 WP67005149 ROLLER
WP12580304 WP12580304 ROLLER ASSEMBLY
WP67006908 WP67006908 SCREW
4391961 4391961 SCREW
W10856125 W10856125 SCREW
W10709801 W10709801 SCREW
WPM0223816 WPM0223816 SCREW
12992301 12992301 SCREW
WPW10348409 WPW10348409 SCREW
WP3387230 WP3387230 SCREW
71003131 71003131 SCREW
WP98165 WP98165 SCREW
WP489474 WP489474 SCREW
3400873 3400873 SCREW
67006491 67006491 SCREW
WP489349 WP489349 SCREW
WP67006380 WP67006380 SCREW
WP8281196 WP8281196 SCREW
M0216705 M0216705 SCREW (2)
67006425 67006425 SCREW (3)
681390 681390 SCREW, 8-32 X 3/8
M0221523 M0221523 SCREW, SHLDR
M0260242 M0260242 SCREW, TF
WPM0500703 WPM0500703 SEAL- O RI
WP854334 WP854334 SEAL-STRIP
WP503695 WP503695 SEALER
WP505587 WP505587 SEALER MASTIC (1 QUART)
212643 212643 SEALER, PERMAGUM (4 - 12`` STRIPS)
W11715937 W11715937 SHAFT
4344313 4344313 SHELF, SPILLGUARD (3)
67001090 67001090 SHROUD, CONDENSER FAN
67002777 67002777 SHROUD, EVAP FAN
12002683 12002683 SLIDE
W11447232 W11447232 SOCKET
WP10972101 WP10972101 SPACER- IC
350930 350930 SPRAY (13 OZ.) (WHITE)
67003781 67003781 STOP, DOOR (BISQUE)
12968202W 12968202W STOP, DOOR (WHITE)
W11708403 W11708403 STOP-DOOR
WP12576801 WP12576801 STRAP
67002936 67002936 STUD, HANDLE
WP67004790 WP67004790 STUD, HANDLE
WP2172748 WP2172748 SUPPORT
67004657 67004657 SUPPORT, CRISPER (LEFT SIDE)
67004658 67004658 SUPPORT, CRISPER (RIGHT SIDE)
W11384469 W11384469 SWITCH
W11396033 W11396033 SWITCH, LIGHT
W11238399 W11238399 TAPE
8171242 8171242 TECH SHEET
67001034 67001034 TENSIONER, BELT
WP67003000 WP67003000 THERMOSTAT
12001937 12001937 THERMOSTAT KIT
WP67001036 WP67001036 TIMER- DEF
978026 978026 TOP PARTS NOT ILLUSTRATED AND OPTIONAL PARTS (NOT INCLUDED) (VALVE, ACCESS (5/16``))
WP1117510 WP1117510 TORX KE
WP841180A WP841180A TRAY
WP67001279 WP67001279 TRAY- DAIR
WPW10292802 WPW10292802 TRAY-DRIP
WP12690502 WP12690502 TRIM, DOOR SHELF
WP12866902 WP12866902 TUBE, DRAIN
67001066 67001066 TUBE, DRAIN
8171243 8171243 USE & CARE GUIDE
978027 978027 VALVE, ACCESS ((3/8``) TUBE)
978028 978028 VALVE, ACCESS (1/2``)
WP978025 WP978025 VALVE, ACCESS (1/4``)
978029 978029 VALVE, ACCESS (5/8)
876764 876764 VALVE,ACCESS (3/16)
67004789 67004789 WASHER
