Model Image
Manufacturer

Whirlpool

Model Number

KDRP462LSS05

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
4453116 4453116 ADAPTER (/2`` MALE)
4453115 4453115 ADAPTER, 1/2`` FEMALE
591014 591014 ADHESIVE LOCTITE (1/3 OZ.)
W10138103 W10138103 ANCHOR-TIP
W10814910 W10814910 ASSY, DOOR GLASS
4456499 4456499 ASSY, OUTLET TUBE
8300193 8300193 BACK, CHASSIS
8301087 8301087 BACKER, TRIM LOWER
4454960 4454960 BACKSPLASH
8300965 8300965 BASE, CHASSIS
4455192 4455192 BEZEL, KNOB
W10491987 W10491987 BLOCK, FOAM
WP8203546 WP8203546 BLOCK, TERMINAL
W10810687 W10810687 BLOWER
8301632 8301632 BOX, BLOWER
8301292 8301292 BOX, BURNER LOWER
4452434 4452434 BRACE, REAR
3192811 3192811 BRACKET, BURNER
8301489 8301489 BRACKET, CONTROL MOUNTING
8303528 8303528 BRACKET, DISPLAY
8300805 8300805 BRACKET, DISPLAY MOUNTING
8301705 8301705 BRACKET, GRIDDLE VALVE
4455804 4455804 BRACKET, HANDLE (L.HAND)
4455803 4455803 BRACKET, HANDLE (RIGHT HAND)
W10157553 W10157553 BRACKET, IGNITOR (GRILL)
4452152 4452152 BRACKET, MOUNTING BOTTOM TRIM
4455604 4455604 BRACKET, MOUNTING REGULATOR
8285005 8285005 BRACKET, SPARK MODULE
4455510 4455510 BRACKET, SUPPORT
WP4455352 WP4455352 BRKT-MNTG
WP4452164 WP4452164 BULB, LIGHT
4448520 4448520 BUMPER, DOOR
4457090 4457090 BURNER BOX
WP4455849 WP4455849 BURNER HEAD ((TURBI))
4456904 4456904 BURNER SWITCH & HARNESS ASSEMBLY
1129449 1129449 BUSHING
3191506 3191506 BUSHING, CONDUIT
WP4457218 WP4457218 BUTTON, CANCEL
WP4452997 WP4452997 BUTTON, ENTER
WP4452163 WP4452163 CAMERA LENS, LIGHT
WP8284669 WP8284669 CAP, BUNER 6K (RF, LR) COAL BLACK
WP4455243 WP4455243 CAP, BURNER
8186393 8186393 CNTRL-OVEN
8301668 8301668 CONDUIT
WP8300795 WP8300795 CONTROL, ZODIAC
4456964 4456964 COOKTOP, BLACK
8300800 8300800 COVER, ACCESS
8301041 8301041 COVER, CONTROL PANEL
4455922 4455922 COVER, PANEL
WPW10160821 WPW10160821 COVER-FAN
WP4451747 WP4451747 COVER-REAR
W10157550 W10157550 DEFLECTOR
8301225 8301225 DEFLECTOR, CENTER
4455852 4455852 DOOR HANDLE
WP9760574 WP9760574 DOOR HINGE
WP9760579 WP9760579 DOOR HINGE
8302156 8302156 DOOR LATCH, MOTORIZED
8300152 8300152 DOOR LINER
4455177 4455177 ELBOW, VENT BOTTOM
4455178 4455178 ELBOW, VENT TOP
WP9760769 WP9760769 ELEMENT
9760770 9760770 ELEMENT, BAKE
9760773 9760773 ELEMENT, BROIL
8301491 8301491 FACE, CONTROL PANEL
WP4451583 WP4451583 FAN, CONVECTION
WP4452226 WP4452226 FAN-CONVCT
4452430 4452430 FOOT ASSEMBLY
8300150 8300150 FRAME, FRONT
8284918 8284918 FRAME, WAVE TRAY
4453327 4453327 GASKET
W10858111 W10858111 GASKT-DOOR
W10131086 W10131086 GLASS, DISPLAY
WP4449263 WP4449263 GLASS, INNER
WP4449259 WP4449259 GLASS, INNER
WPW10106700 WPW10106700 GRATE, BURNER
8284741 8284741 GRATE, GRILL
WP3195996 WP3195996 GRILL, BROILER (OPTIONAL)
WP4448444 WP4448444 GROMMET
8284960 8284960 GUARD, REAR SPILL
8285030 8285030 GUARD, SPILL
LIT3191638 LIT3191638 GUIDE BOOK STICKER
4455644 4455644 GUSSET
9760722 9760722 HARNESS, SWITCH GRILL
4456627 4456627 HARNESS, WIRE (IGNITOR 28``)
4456628 4456628 HARNESS, WIRE (IGNITOR 42``)
4456553 4456553 HARNESS, WIRE (MAIN)
4457083 4457083 HARNESS, WIRE SPARK MODULE
WP4455979 WP4455979 HEAD, BURNER (AUXI)
WP4455605 WP4455605 HINGE RECIEVER (LEFT HAND)
WP4455606 WP4455606 HINGE RECIEVER (RIGHT HAND)
WPW10155786 WPW10155786 HOLDER, ORIFICE (TURBO (2))
WP9782447 WP9782447 HOLDER-ORF
WP8284941 WP8284941 IGNTR-SURF
WPW10110696 WPW10110696 INSULATION
8300159 8300159 INSULATION, BACK
8300797 8300797 INSULATION, DOOR
8300158 8300158 INSULATION, WRAP
WPW10078400 WPW10078400 KNOB, CONTROL
W10078410 W10078410 KNOB, GRILL
4455141 4455141 KNOB, SELECTOR
4455115 4455115 KNOB, TEMP/TIME
WP4448972 WP4448972 LIGHT, OVEN (2)
100000 100000 LINER, OVEN (NOT SERVICEABLE)
LIT8301171 LIT8301171 LITERATURE PARTS (CONVERSION INSTRUCTIONS)
LIT8301169 LIT8301169 LITERATURE PARTS (INSTALLATION INSTRUCTIONS)
LIT4456556 LIT4456556 LITERATURE PARTS (TECH SHEET)
LIT4456611 LIT4456611 LITERATURE PARTS (USE & CARE GUIDE)
8285052 8285052 LOG BURNER, GRILL
WP8301045 WP8301045 MANIFOLD
WP4452999 WP4452999 MODULE, DISPLAY
W10120890 W10120890 MODULE, GRILL
W10368699 W10368699 NAMEPLATE (FOR MODEL KUDS01DJSS)
WP488130 WP488130 NUT
WP4450118 WP4450118 NUT
WP4452227 WP4452227 NUT
WP112432 WP112432 NUT, T-BLOCK (4)
WP2004333 WP2004333 PALNUT (2)
W10123240 W10123240 PAN, BROILER
WP3196076 WP3196076 PAN, BROILER
8300208 8300208 PANEL, CONTROL
814381 814381 PIN HINGE KIT
WP4455109 WP4455109 PLATE, SIMMER
W10157590 W10157590 PLATE, WAVE
8284917 8284917 PLATE, WAVE TRAY
WP8284796 WP8284796 PLUG, MANIFOLD
9759437 9759437 RACK, OVEN
W10758127 W10758127 RACK, ROASTER
WP9759091 WP9759091 REGULATOR
WP4448933 WP4448933 RETAINER
4451668 4451668 RETAINER, GLASS
8300190 8300190 RETAINER, GLASS
WPW10158497 WPW10158497 RETAINER, GLASS-CLIP (BLACK STAINLESS)
3400855 3400855 SCREW
WP3186217 WP3186217 SCREW
WP3177991 WP3177991 SCREW
W11684512 W11684512 SCREW
WP3400015 WP3400015 SCREW
WP12990527 WP12990527 SCREW
WP3196557 WP3196557 SCREW
W11233072 W11233072 SCREW
4449748 4449748 SCREW
WP4449746 WP4449746 SCREW
WP4449040 WP4449040 SCREW
WP3400832 WP3400832 SCREW
WP4449743 WP4449743 SCREW (2)
WP4449154 WP4449154 SCREW (BLACK) (WHITE)
3400518 3400518 SCREW, 5/16-12 X 5/8
WP3368921 WP3368921 SCREW, 7-18 X 3/4
WP4449809 WP4449809 SCREW, 8-18 X 3/8
WPW10132940 WPW10132940 SCREW, 8-32 X 9/16
4450800 4450800 SCREW, GROUND
4453191 4453191 SEAL, ACCESS PANEL
8300153 8300153 SEAL, DOOR TOP
4453192 4453192 SEAL, RIBBON CABLE
W10491984 W10491984 SEAL, SWITCH SHAFT
WP3188425 WP3188425 SEAL-SWTCH
WP482338 WP482338 SEALER, SILASTIC (3OZ.)
WPW10131825 WPW10131825 SENSOR
WP8301089 WP8301089 SHIELD, HEAT
4457252 4457252 SIDE CHASSIS (LEFT SIDE)
4457251 4457251 SIDE CHASSIS (RIGHT SIDE)
8285606 8285606 SIDE, BURNER BOX (LEFT HAND)
8285607 8285607 SIDE, BURNER BOX (RIGHT HAND)
W10782197 W10782197 SIDE, CHASSIS
4452442 4452442 SIDE, CONTROL TOP
4455719 4455719 SPACER RING
4452260 4452260 SPACER, FOAM
4452222 4452222 SPACER, HARNESS
WPW10110491 WPW10110491 SPARK MODULE
8284782 8284782 SPUD KIT
4454974 4454974 SUPPORT RAIL (R.H.& L.H.)
8284712 8284712 SUPPORT, BACKSPLASH
8301056 8301056 SUPPORT, CONTROL PANEL
8300184 8300184 SUPPORT, INSULATION
4456962 4456962 SUPPORT, REAR
WP4451985 WP4451985 SUPPRESSOR
WP4452842 WP4452842 SWTCH-LITE
WP8300802 WP8300802 THERMOSTAT (TOD) (TEMP.) SPST
WPW10339879 WPW10339879 TIE-WIRE
8301469 8301469 TOP, CHASSIS
WP9760587 WP9760587 TRANSFORMER, SINGLE CONTROL
WP9760588 WP9760588 TRANSFORMR
8284791 8284791 TRAY, DRIP
8300799 8300799 TRAY, HIDDEN BAKE
4453205 4453205 TRIM, FRONT (LEFT SIDE)
4452804 4452804 TRIM, FRONT (RIGHT SIDE)
8284851 8284851 TRIM, ISLAND
WP3400805 WP3400805 TRIM-CKTOP, SI (SCREW)
8301066 8301066 TUBE, GRILL
8300156 8300156 TUBE, MANIFOLD TO REGULATOR
W10861715 W10861715 TUBE-VENT
8300187 8300187 TUBING, GAS BURNER - LF
8300188 8300188 TUBING, GAS BURNER - LR
8300231 8300231 TUBING, GAS BURNER - RF
8300230 8300230 TUBING, GAS BURNER - RR
WP4456816 WP4456816 VALVE, BURNER (SMALL (1))
4456818 4456818 VALVE, BURNER (TURBO)
4456819 4456819 VALVE, GAS GRILL
8301058 8301058 VALVE, GRIDDLE
4452803 4452803 VENT, BOTTOM LOWER
8300978 8300978 VENT, BOTTOM UPPER
4455983 4455983 VENT, CENTER
W10145009 W10145009 VENT, DEFLECTOR (WHITE)
4451759 4451759 VENT, EXHAUST
242828 242828 WIRE (12 GA. 150 C BLACK)
242829 242829 WIRE (12 GA. 150 C RED)
242820 242820 WIRE (14 GA. 150 C BLACK)
242821 242821 WIRE (14 GA. 150 C BLUE)
242822 242822 WIRE (14 GA. 150 C BROWN)
242823 242823 WIRE (14 GA. 150 C GREEN)
242824 242824 WIRE (14 GA. 150 C ORANGE)
242825 242825 WIRE (14 GA. 150 C RED)
242826 242826 WIRE (14 GA. 150 C WHITE)
242827 242827 WIRE (14 GA. 150 C YELLOW)
8316784 8316784 WIRE (14 GA. 200 C BROWN)
242831 242831 WIRE (14 GA. 200 C RED)
242832 242832 WIRE (14 GA. 200 C YELLOW)
