Model Image
Manufacturer

Whirlpool

Model Number

KDRS505XSS04

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
31682 31682 ACCESSORY PARTS, APPLIANCE CLEANER
4378577 4378577 ACCESSORY PARTS, BRICK BAKING STONE
31617 31617 ACCESSORY PARTS, GAS GRATE & DRIP PAN CLEANER
31462A 31462A ACCESSORY PARTS, SS CLEANER & POLISH
8212510A 8212510A ACCESSORY PARTS, STAINLESS STEEL WIPES
WP7101P485-60 WP7101P485-60 ANCHOR-TIP
WPW10245259 WPW10245259 BLOCK-TERM
WP3801F656-51 WP3801F656-51 BRACKET
W10261388 W10261388 BRKT-MNTG
W10518258 W10518258 BRKT-MNTG
W10645182 W10645182 BRKT-MNTG
W10339476 W10339476 BRKT-MNTG
W10190166 W10190166 BRKT-SRVCE
WPW10276466 WPW10276466 BRKT-SUPRT
WPW10276470 WPW10276470 BRKT-SUPRT
W10260545 W10260545 BRKT-SUPRT
W10319059 W10319059 BRKT-SUPRT
W10319087 W10319087 BRKT-SUPRT
W10105790 W10105790 BUMPER
WPW10333445 WPW10333445 BURNR-BASE
WPW10406243 WPW10406243 BURNR-HEAD
WPW10406797 WPW10406797 BURNR-HEAD
WPW10406878 WPW10406878 BURNR-HEAD
WPW10336094 WPW10336094 BURNR-TOP
WPW10171140 WPW10171140 CAP-BURNER
WPW10299236 WPW10299236 CAP-BURNER
W10355010 W10355010 CLEANER
W10841090 W10841090 CLIP
WPW10365424 WPW10365424 CONTROL BOARD
WPW10295113 WPW10295113 CONTROL PANEL
WPW10424185 WPW10424185 CONTROL PANEL
W10401393 W10401393 COOKTOP
W10333442 W10333442 COVER
W10410461 W10410461 COVER
W10410463 W10410463 COVER
8303962BU 8303962BU COVER, FAN
W10312612 W10312612 COVER-BLCK
W10296773 W10296773 COVER-REAR
W10668730 W10668730 COVER-REAR
WPW10261386 WPW10261386 COVR-WIRE
WPW10292689 WPW10292689 COVR-WIRE
W10268560 W10268560 COVR-WIRE
W10268559 W10268559 COVR-WIRE
WPW10471348 WPW10471348 DOOR DOOR LATCH
WPW10289076 WPW10289076 DOOR HANDLE
WPW10335433 WPW10335433 DOOR HINGE
WPW10335434 WPW10335434 DOOR HINGE
WPW10485732 WPW10485732 DOOR HINGE
WPW10485733 WPW10485733 DOOR HINGE
W10271639 W10271639 ELEMENT
W11662148 W11662148 ELMNT-BAKE
W11101534 W11101534 ELMNT-BROL
WPW10611615 WPW10611615 ELMNT-BROL
W10317476 W10317476 ELMNT-BROL
W10319111 W10319111 ENDCAP-PNL
W10319109 W10319109 ENDCAP-PNL
W10636384 W10636384 EXTENSION
W10758272 W10758272 FAN-CONVCT
N_P N_P FOLLOWING PARTS NOT ILLUSTRATED
W11665456 W11665456 FOOT-LEVEL
WPW10308654 WPW10308654 FRAME-FRNT
W10606341 W10606341 FRAME-FRNT
WPW10272594 WPW10272594 FRAME-WNDW
WPW10272708 WPW10272708 FRAME-WNDW
WPW10269069 WPW10269069 GASKT-DOOR
W10337392 W10337392 GASKT-DOOR
WP9757706 WP9757706 GLASS DOOR
W11132120 W11132120 GLASS DOOR
W10346067 W10346067 GLASS-DOOR
W10346127 W10346127 GLASS-DOOR
W11189172 W11189172 GLIDE-DRWR
WPW10260069 WPW10260069 GRATE-KIT
WPW10311218 WPW10311218 GRIDDLE
W10225701 W10225701 HARNS-WIRE
W10408058 W10408058 HARNS-WIRE
W10592902 W10592902 HARNS-WIRE
WPW10272329 WPW10272329 HINGE-RECV
WPW10272328 WPW10272328 HINGE-RECV
W10647259 W10647259 HINGE-RECV
WPW10273135 WPW10273135 HOLDER-ORF
WPW10273141 WPW10273141 HOLDER-ORF
WPW10273133 WPW10273133 HOLDER-ORF
WPW10319347 WPW10319347 HOLDER-ORF
WPW10273139 WPW10273139 HOLDER-ORF
WPW10407676 WPW10407676 IGNTR-SURF
W10407677 W10407677 IGNTR-SURF
W10526086 W10526086 INSTRUCTIONS, INSTALLATION
WPW10321285 WPW10321285 INSULATION
WPW10321271 WPW10321271 INSULATION
WPW10308393 WPW10308393 INSULATION
WPW10322111 WPW10322111 INSULATION
WPW10204079 WPW10204079 INSULATION
WPW10271637 WPW10271637 INSULATION
W10274268 W10274268 INSULATION
W11684900 W11684900 INSULATION
W11685361 W11685361 INSULATION
7003P104-60 7003P104-60 INSULATOR,HEAT SHIELD
WPW10295131 WPW10295131 KNOB
8009 8009 LIGHT BULB
WPW10292008 WPW10292008 LINER-DOOR
W11103615 W11103615 LINER-DOOR
WPW10204705 WPW10204705 MANIFOLD
W10430933 W10430933 MANUAL, OWNERS
74009098 74009098 MODULE, SPARK
W11235883 W11235883 MOTOR-FAN
WPW10243391 WPW10243391 NAMEPLATE
WPW10116349 WPW10116349 NUT
350930 350930 PAINT, PRESSURIZED SPRAY (12 OZ. WHITE)
350956 350956 PAINT, SPRAY (ALMOND)
4392901 4392901 PAINT, SPRAY (BISCUIT/BISQUE)
285006 285006 PAINT, SPRAY (BLACK)
350938 350938 PAINT, SPRAY (GRAY PRIMER)
350942 350942 PAINT, SPRAY (WHITE PRIMER)
4392899 4392899 PAINT, TOUCH-UP (1/2OZ. BISCUIT/BISQUE)
72032 72032 PAINT, TOUCH-UP (1/2OZ. BLACK)
511873 511873 PAINT, TOUCH-UP (1/2OZ. WHITE PORCELAIN (2 OZ.))
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
W10123240 W10123240 PAN-BROILR
WPW10330375 WPW10330375 PANEL-SIDE
WPW10284717 WPW10284717 PANL-MNFLD
W11226497 W11226497 POWER CORD
W11550107 W11550107 RACK-OVEN
WPW10570870 WPW10570870 RACK-OVEN
W10253470 W10253470 RETAINER
W10485723 W10485723 RETAINER
W10340464 W10340464 RETAINER
98017516 98017516 SADDLE, BRACKET
WP4159193 WP4159193 SCREW
WP7101P434-60 WP7101P434-60 SCREW
WP4449154 WP4449154 SCREW
WP4449743 WP4449743 SCREW
WPW10132940 WPW10132940 SCREW
WPW10292297 WPW10292297 SCREW
WP4449040 WP4449040 SCREW
WPW10267456 WPW10267456 SCREW
WPY706189 WPY706189 SCREW
W10709795 W10709795 SCREW
WP8273062 WP8273062 SCREW
WP3400702 WP3400702 SCREW
W11233072 W11233072 SCREW
WP90767 WP90767 SCREW
W10217535 W10217535 SCREW
74003975 74003975 SCREW (8ABX3/8-BLK)
W10505256 W10505256 SHEET, OVEN PERFORMANCE
W10323649 W10323649 SHEET, TECH
WPW10299338 WPW10299338 SHIELD
W10324366 W10324366 SHIELD
W10538516 W10538516 SHIELD
8036P012-60 8036P012-60 SHIELD, POWER CORD
W10332449 W10332449 SHIELD-HT
W10332459 W10332459 SHIELD-HT
W10548601 W10548601 SHIELD-HT
W10319762 W10319762 SHIELD-HT
W10278697 W10278697 SHIELD-VNT
W11594027 W11594027 SOCKT-LITE
WPW10237689 WPW10237689 SPACER-PNL
W10357697 W10357697 SPACER-PNL
W11674161 W11674161 SPUD-ORFCE
W10260703 W10260703 SUPPORT
WP7403P899-60 WP7403P899-60 SWTCH-SFTY
9762761 9762761 TIPS, SAFE COOKING (ENGLISH)
W10065852 W10065852 TIPS, SAFE COOKING (FRENCH)
WP7430P044-60 WP7430P044-60 TOP-OVEN
W10322408 W10322408 TUBE-EXTNT
WPW10323793 WPW10323793 TUBE-VENT
W10337391 W10337391 TUBE-VENT
W10295055 W10295055 TUBING-GAS
W10524331 W10524331 TUBING-GAS
WPW10206288 WPW10206288 VALVE-BRNR
WPW10206287 WPW10206287 VALVE-BRNR
WPW10298678 WPW10298678 VALVE-BRNR
W10582429 W10582429 VALVE-GAS
W10911971 W10911971 VALVE-SOLN
WPW10204718 WPW10204718 WIRE HARNESS
WPW10318787 WPW10318787 WIRE HARNESS
8019P026-60 8019P026-60 WIRING HARNESS PARTS, CLIP, WIRE
