Model Image
Manufacturer

Whirlpool

Model Number

KDRS807SSS03

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WP482338 WP482338 ADHESIVE
591014 591014 ADHESIVE LOCTITE (1/3 OZ.)
W11447673 W11447673 ANCHOR-TIP
9757680 9757680 ANTI-TIP INSTRUCTIONS
9759761 9759761 BACK, CHASSIS
W10156267 W10156267 BACKSPLASH
8304603SS 8304603SS BADGE
W10860133 W10860133 BAFFL-CONV
9759713 9759713 BASE, CHASSIS
WP9761958 WP9761958 BLOCK-TERM
W10810687 W10810687 BLOWER
W10589943 W10589943 BOX-BURNER
W10115858 W10115858 BOX-TERMNL
4453721 4453721 BRACE, DRAWER (LEFT)
4453720 4453720 BRACE, DRAWER (RIGHT)
9757811 9757811 BRACE, SIDE PANEL
9756454 9756454 BRACKET, APPLIANCE MANAGER
9763445 9763445 BRACKET, BURNER
W10246113 W10246113 BRACKET, HANDLE (LEFT)
W10246114 W10246114 BRACKET, HANDLE (RIGHT)
4452152 4452152 BRACKET, MOUNTING
9761784 9761784 BRACKET, MOUNTING
9761745 9761745 BRACKET, TOUCHSENSOR
9757461 9757461 BRACKET,SIDE PANEL
WP4455352 WP4455352 BRKT-MNTG
WP9759230 WP9759230 BRKT-MNTG
WP9759229 WP9759229 BRKT-MNTG
WP9757829 WP9757829 BRKT-MNTG
W10108030 W10108030 BRKT-MNTG
W10171411 W10171411 BRKT-MNTG
W10143041 W10143041 BRKT-MNTG
W10105790 W10105790 BUMPER
4448520 4448520 BUMPER, DOOR (3)
WP8285256 WP8285256 BURNR-HEAD
WP8285255 WP8285255 BURNR-HEAD
WPW10406797 WPW10406797 BURNR-HEAD
WPW10406243 WPW10406243 BURNR-HEAD
9757778 9757778 BUSHING SNAP SPLIT 1``
WP9761563CB WP9761563CB CAP, BURNER (12.5K (RR))
WP9758829CB WP9758829CB CAP-BURNER
WP8284669 WP8284669 CAP-BURNER
WP8285258 WP8285258 CAP-TOP
313660 313660 CLIP, GROUND WIRE
9762768 9762768 CLIP, RETAINER (3)
9759890 9759890 CLIP, SIDE PANEL
WPW10181439 WPW10181439 CONTROL BOARD
WPW10181438 WPW10181438 CONTROL BOARD
WPW10156270 WPW10156270 CONTROL PANEL
WPW10175863 WPW10175863 COOKTOP
9758583 9758583 COVER, BACK
4450039 4450039 COVER, BAKE TRAY
9761755 9761755 COVER, COOKTOP REAR
9757405 9757405 COVER, TERMINAL BOX
W10153100 W10153100 COVER-BLCK
WP9763436 WP9763436 COVER-REAR
W10153099 W10153099 COVR-ACESS
WP9760889 WP9760889 DOOR DOOR LATCH
WP9760579 WP9760579 DOOR HINGE
WP9760574 WP9760574 DOOR HINGE
WPW10164163 WPW10164163 DRAWR-UTIL
4455177 4455177 ELBOW, VENT BOTTOM
4455178 4455178 ELBOW, VENT TOP
WP9760769 WP9760769 ELEMENT
9760775 9760775 ELEMENT, WARMING
WPW10207398 WPW10207398 ELMNT-BAKE
WP9760774 WP9760774 ELMNT-BROL
9761796 9761796 ENCLOSURE, WARMING DRAWER
W10758272 W10758272 FAN-CONVCT
WP3196037 WP3196037 FOOT-LEVEL
WPW10058460 WPW10058460 FOOT-LEVEL
WPW10115831 WPW10115831 FRAME-FRNT
9763483BL 9763483BL GASKET, BACKSPLASH
W11675844 W11675844 GASKET-OVN
W10116195 W10116195 GASKT-VENT
WP9759225 WP9759225 GLASS DOOR
WP9757706 WP9757706 GLASS DOOR
WP9761749BL WP9761749BL GLASS, BACKSPLASH
W10155557 W10155557 GLASS-DOOR
WP9761625CB WP9761625CB GRATE, BURNER (RH)
WP9761557CB WP9761557CB GRATE-BRNR
WP4448444 WP4448444 GROMMET
W10177363 W10177363 GROMMET
9763467 9763467 GUIDE EASY SET
WP9757685 WP9757685 GUIDE-PANL
W10899599 W10899599 HANDLE, DOOR
WPW10292374 WPW10292374 HANDLE, DRAWER
9762921 9762921 HARNESS, COMMUNICATION
9763481 9763481 HARNESS, GROUND STRAP
9756921 9756921 HARNESS, TCB
W10157935 W10157935 HARNS-WIRE
W10141504 W10141504 HARNS-WIRE
WP4455605 WP4455605 HINGE-RECV
WP4455606 WP4455606 HINGE-RECV
WP9761639 WP9761639 HOLDER-ORF
WPW10128455 WPW10128455 HOLDER-ORF
WPW10128446 WPW10128446 HOLDER-ORF
WP9763494 WP9763494 IGNTR-SURF
WPW10110378 WPW10110378 IGNTR-SURF
W10154991 W10154991 INSTALLATION INSTRUCTIONS
WP4451722 WP4451722 INSULATION
9759884 9759884 INSULATION
9756470 9756470 INSULATION, BACK
9759885 9759885 INSULATION, PAD (2)
9759722 9759722 INSULATION, SIDE TRIM
9756817 9756817 INSULATION, WRAP
9759721 9759721 INSULATOR, TERMIANL BOX
8186589 8186589 JACK-PROBE
WPW10156265 WPW10156265 KNOB
WPW10156262 WPW10156262 KNOB
W10067870 W10067870 LENS-LIGHT
WP4173175 WP4173175 LIGHT BULB
WPW10734065 WPW10734065 LIGHT-OVEN
100000 100000 LINER, OVEN (NOT SERVICEABLE)
W10140551 W10140551 LINER-DOOR
WP9755546 WP9755546 LOCKNUT
WP9755547 WP9755547 LOCKWASHER
9757426 9757426 LP ORIFICE KIT TCB
9761641 9761641 MANIFOLD (TCB)
9761642 9761642 MANIFOLD, COOKTOP
WP9761566 WP9761566 MEMBRANE SWITCH
W10794022 W10794022 MOTOR-FAN
WPW10116349 WPW10116349 NUT
W10851603 W10851603 ORIFICE
9762442 9762442 ORIFICE (EXTERNAL)
9762443 9762443 ORIFICE (INTERNAL)
9762937 9762937 ORIFICE (LR, RF)
9762938 9762938 ORIFICE (RR)
8186387 8186387 OVEN, SIDE PANEL (BLACK)
WP261869 WP261869 PAINT CW
350930 350930 PAINT, PRESSURIZED SPRAY (12 OZ. WHITE)
285006 285006 PAINT, PRESSURIZED SPRAY (12OZ. BLACK)
261900 261900 PAINT, SPRAY (CITRINE WHITE)
72032 72032 PAINT, TOUCH-UP (1/2OZ. BLACK)
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
WPW10153092 WPW10153092 PANEL, BACKSPLASH
WPW10203763 WPW10203763 PANEL-DRWR
W10588269 W10588269 PANEL-DRWR
8285250 8285250 PLATE, CLOSURE
WP9755542 WP9755542 PROBE-MEAT
WPW10179152 WPW10179152 RACK-OVEN
WPW10110491 WPW10110491 RANGE SPARK MODULE
WP9759242 WP9759242 RANGE THERMOSTAT
WP9759944 WP9759944 RANGE THERMOSTAT
WP9757807 WP9757807 RANGE THERMOSTAT
W10108850 W10108850 REGULATOR
WP4457132 WP4457132 RETAINER
WP4448933 WP4448933 RETAINER
9762761 9762761 SAFE COOKING TIPS (ENGLISH)
W10065852 W10065852 SAFE COOKING TIPS (FRENCH)
WP3400015 WP3400015 SCREW
W10873471 W10873471 SCREW
WP3400702 WP3400702 SCREW
WP8273062 WP8273062 SCREW
WP3186217 WP3186217 SCREW
WP4449040 WP4449040 SCREW
WPW10132940 WPW10132940 SCREW
WP3400805 WP3400805 SCREW
W11684512 W11684512 SCREW
WP4449743 WP4449743 SCREW
W11233072 W11233072 SCREW
WP4449154 WP4449154 SCREW
WP4449809 WP4449809 SCREW
WP3400832 WP3400832 SCREW
W10491985 W10491985 SCREW
WP12990527 WP12990527 SCREW
WP3196557 WP3196557 SCREW
WP3368921 WP3368921 SCREW-TORX
8522415 8522415 SEAL, WINDOW
W10491987 W10491987 SEAL-FOAM
WP8274149 WP8274149 SENSOR
WPW10131825 WPW10131825 SENSOR
8301084 8301084 SHIELD, HEAT
4457114 4457114 SHIELD, HEAT BOTTOM
WP4457104 WP4457104 SHIELD, HEAT TOP
W10105370 W10105370 SHIELD-VNT
9759954 9759954 SIDE, BASE (LEFT)
9759953 9759953 SIDE, BASE (RIGHT)
W10782197 W10782197 SIDE, CHASSIS
W10083460 W10083460 SLIDE
WPW10155633 WPW10155633 SLIDE-DRWR
WPW10155632 WPW10155632 SLIDE-DRWR
4452222 4452222 SPACER, HARNESS
9759945 9759945 STANDOFF, REAR
WP9756821 WP9756821 SUPPORT
9757686 9757686 SUPPORT, DRAWER RAIL (LEFT)
9757687 9757687 SUPPORT, DRAWER RAIL (RIGHT)
9758676 9758676 SUPPORT, ELEMENT
9763501BL 9763501BL SUPPORT, FRONT & REAR
4451478 4451478 SUPPORT, INSULATION
W10109920 W10109920 TAPE
W10112147 W10112147 TECH SHEET
8303099 8303099 TOP CHASSIS
WPW10111628 WPW10111628 TRANSFORMR
WP4455037 WP4455037 TRAY-BAKE
W10140548 W10140548 TRIM
WPW10140547 WPW10140547 TRIM, SIDE (LEFT)
W10140549 W10140549 TRIM-CKTOP
W10140550 W10140550 TRIM-CKTOP
9761752 9761752 TUBE, MANIFOLD
9761071 9761071 TUBE, T.C.B. GAS (INNER)
9761072 9761072 TUBE, T.C.B. GAS (OUTER)
W10861715 W10861715 TUBE-VENT
9761068 9761068 TUBING, BURNER(LR)
9761069 9761069 TUBING, BURNER(RF)
9761070 9761070 TUBING, BURNER(RR)
W10108840 W10108840 TUBING-GAS
W10162199 W10162199 USE & CARE GUIDE
WP9760519 WP9760519 VALVE-BRNR
WP4456817 WP4456817 VALVE-BRNR
WP4456816 WP4456816 VALVE-BRNR
WPW10154789 WPW10154789 VENT, BOTTOM LOWER
WPW10160347 WPW10160347 VENT, BOTTOM UPPER
4451759 4451759 VENT, EXHAUST
9760481 9760481 WASHER, INSULATION BODY SIDE (4)
242828 242828 WIRE (12 GA. 150 C BLACK)
242820 242820 WIRE (14 GA. 150 C BLACK)
242821 242821 WIRE (14 GA. 150 C BLUE)
242822 242822 WIRE (14 GA. 150 C BROWN)
242823 242823 WIRE (14 GA. 150 C GREEN)
242824 242824 WIRE (14 GA. 150 C ORANGE)
242825 242825 WIRE (14 GA. 150 C RED)
242827 242827 WIRE (14 GA. 150 C YELLOW)
8316784 8316784 WIRE (14 GA. 200 C BROWN)
242831 242831 WIRE (14 GA. 200 C RED)
WP9756824 WP9756824 WIRE HARNESS
W11209404 W11209404 WIRE HARNESS
