Model Image
Manufacturer

Whirlpool

Model Number

KEBC247VSS02

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
241430 241430 ACCESSORIES, ALUMINUM FOIL (18`` X 25`)
4396923 4396923 ACCESSORIES, BROILER PAN & GRID
W10355010 W10355010 ACCESSORIES, KITCHEN & APPLIANCE CLEANER
W10123240 W10123240 ACCESSORIES, PREMIUM BROILER PAN & ROASTING RACK
W11042467 W11042467 ACCESSORIES, SS CLEANER
WP8300836 WP8300836 ASSEMBLY, DOOR GLASS (BLACK)
WP8300837 WP8300837 ASSEMBLY, DOOR GLASS (WHITE)
8302746 8302746 ASSEMBLY, MEMBRANE (WHITE)
W10378250 W10378250 ASSEMBLY, VENT BOTTOM TRIM (BLACK)
WPW10151036 WPW10151036 ASSEMBLY, VENT BOTTOM TRIM (STAINLESS)
W10378247 W10378247 ASSEMBLY, VENT BOTTOM TRIM (WHITE)
4452232 4452232 BACK, CHASSIS
W10123223 W10123223 BACK, CONTROL
4450525 4450525 BASE, CHASSIS
WPW10245259 WPW10245259 BLOCK-TERM
WPW10176670 WPW10176670 BLOWER
WPW10016550 WPW10016550 BLOWER
4452152 4452152 BRACKET, BOTTOM VENT
4455804 4455804 BRACKET, HANDLE (LEFT)
4455803 4455803 BRACKET, HANDLE (RIGHT)
8302390 8302390 BRACKET, SUPPORT (AIR STOP)
WP9759230 WP9759230 BRKT-MNTG
WP9759229 WP9759229 BRKT-MNTG
W10105790 W10105790 BUMPER
4448520 4448520 BUMPER, DOOR
4451605 4451605 CAP, SPACER
4455863 4455863 CHASSIS, TOP
4448664 4448664 CLAMP, CONDUIT
WP98997 WP98997 CLIP
16515 16515 CLIP, HARNESS
WP8301848 WP8301848 CONTROL BOARD
WPW10438752 WPW10438752 CONTROL BOARD
WPW10144975 WPW10144975 CONTROL PANEL
WPW10358920 WPW10358920 CONTROL PANEL
4450039 4450039 COVER, ACCESS
4452365 4452365 COVER, TOP FRONT
4450549 4450549 COVER, TOP REAR
WPW10160821 WPW10160821 COVER-FAN
WP4451747 WP4451747 COVER-REAR
9760675 9760675 DEFLECTOR, VENT
4455807 4455807 DEFLECTOR, VENT BOX (BLACK)
8302347 8302347 DIVIDER, CENTER VENT
WPW10195934 WPW10195934 DOOR DOOR LATCH
W10448666 W10448666 DOOR HANDLE
W10448665 W10448665 DOOR HANDLE (BLACK)
WP9760571 WP9760571 DOOR HINGE
WP9760572 WP9760572 DOOR HINGE
4455178 4455178 ELBOW, TOP VENT
4455177 4455177 ELBOW, VENT BOTTOM
WP9760769 WP9760769 ELEMENT
WPW10207398 WPW10207398 ELMNT-BAKE
WPW10207400 WPW10207400 ELMNT-BROL
W10758272 W10758272 FAN-CONVCT
9760754 9760754 FRAME, FRONT
WP4456654 WP4456654 FUSE-THRML
WP4455380 WP4455380 GASKT-DOOR
W10401220 W10401220 GLASS DOOR
WP9759226 WP9759226 GLASS DOOR
WP9759223 WP9759223 GLASS DOOR
WP4449247 WP4449247 GLASS DOOR
WP4448444 WP4448444 GROMMET
4449264 4449264 GUIDE, EASY SET
W10203458 W10203458 GUIDE, USE & CARE (ENGLISH)
W10223188 W10223188 GUIDE, USE & CARE (FRENCH)
W10179652 W10179652 HARNS-WIRE
9760570 9760570 HINGE, DOOR (LEFT)
9760569 9760569 HINGE, DOOR (RIGHT)
WP4455606 WP4455606 HINGE-RECV
WP4455605 WP4455605 HINGE-RECV
W10199968 W10199968 HNDLE-DOOR
W10045010 W10045010 INSTALLATION INSTRUCTIONS
W11688413 W11688413 INSULATION
WP4450363 WP4450363 INSULATION
WP4449314 WP4449314 INSULATION
8186589 8186589 JACK-PROBE
W10169756 W10169756 LENS-LIGHT
WPW10169757 WPW10169757 LIGHT BULB
WPW10307114 WPW10307114 LIGHT-OVEN
N_P N_P LINER, OVEN (NOT SERVICEABLE)
WP8303698 WP8303698 LINER-DOOR
WP9755546 WP9755546 LOCKNUT
WP9755547 WP9755547 LOCKWASHER
WP8302743 WP8302743 MEMBRANE SWITCH
W10794022 W10794022 MOTOR-FAN
WP112432 WP112432 NUT
WPW10116349 WPW10116349 NUT
WP4450118 WP4450118 NUT
W10358940 W10358940 PANEL, CONTROL (WHITE)
WP9755542 WP9755542 PROBE-MEAT
WP4448716 WP4448716 RACK, OVEN
814373 814373 RAIL-MTG
814374 814374 RAIL-MTG
WP9759242 WP9759242 RANGE THERMOSTAT
WPW10158497 WPW10158497 RETAINER
WP4448933 WP4448933 RETAINER
W10205117 W10205117 RETAINER, CLIP (BLACK)
4450864 4450864 RETAINER, CLIP (WHITE)
4457130 4457130 RETAINER, GLASS
WP4448950 WP4448950 SCREW
W11684512 W11684512 SCREW
WPW10132940 WPW10132940 SCREW
WP4449745 WP4449745 SCREW
WP4449809 WP4449809 SCREW
WP4450038 WP4450038 SCREW
4449748 4449748 SCREW
WP4449154 WP4449154 SCREW
WP4449040 WP4449040 SCREW
W11233072 W11233072 SCREW
WP4449743 WP4449743 SCREW
WP8281236 WP8281236 SCREW
WP3400832 WP3400832 SCREW
8300853 8300853 SEAL, DOOR TOP
W10491987 W10491987 SEAL-FOAM
WPW10131825 WPW10131825 SENSOR
4457101 4457101 SHIELD, HEAT
4457112 4457112 SHIELD, HEAT (BOTTOM)
W10782197 W10782197 SIDE, CHASSIS
W10790240 W10790240 SIDE, CONTROL TOP (LEFT)
W10755214 W10755214 SIDE, CONTROL TOP (RIGHT)
4452260 4452260 SPACER, FOAM
4449845 4449845 SUPPORT, BRACKET
4451476 4451476 SUPPORT, INSULATION
WP4451985 WP4451985 SUPPRESSOR
W10185219 W10185219 TECH SHEET
W10065852 W10065852 TIPS, SAFE COOKING (FRENCH)
9762761 9762761 TIPS, SAFER COOKING (ENGLISH)
WP9760587 WP9760587 TRANSFORMR
4455035 4455035 TRAY, HIDDEN BAKE
WPW10144986 WPW10144986 TRIM
WPW10144985 WPW10144985 TRIM
WP4455426 WP4455426 TRIM
W10358914 W10358914 TRIM, CENTER VENT
WP4455427 WP4455427 TRIM, SIDE LEFT (BLACK)
WP4455374 WP4455374 TRIM, SIDE LEFT (WHITE)
WP4455375 WP4455375 TRIM, SIDE RIGHT (WHITE)
W10861715 W10861715 TUBE-VENT
4448547 4448547 VENT, (CONTROL PANEL)
W10145009 W10145009 VENT, DEFLECTOR (WHITE)
4451759 4451759 VENT, EXHAUST
4451761 4451761 WIRING HARNESS PARTS (SUPPORT, WIRING)
4450953 4450953 WIRING HARNESS PARTS, CONDUIT, DOUBLE
8301909 8301909 WIRING HARNESS PARTS, HARNESS, DOOR LATCH
4452400 4452400 WIRING HARNESS PARTS, LEAD, GROUND STRAP
4455191 4455191 WIRING HARNESS PARTS, PLATE, BLOWER SERVICE
4450800 4450800 WIRING HARNESS PARTS, SCREW, GROUNDING
