Model Image
Manufacturer

Whirlpool

Model Number

KERS205TWH5

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WP7101P485-60 WP7101P485-60 ANCHOR-TIP
3601F380-51 3601F380-51 BAFFEL, RETAINER
WPW10245259 WPW10245259 BLOCK-TERM
WPW10211368 WPW10211368 BOTTM-OVEN
WPW10170717 WPW10170717 BOTTOM, BURNER BOX
WP3801F656-51 WP3801F656-51 BRACKET
3801F945-51 3801F945-51 BRACKET, CONTROL
3801P858-45 3801P858-45 BRACKET, HANDLE (LEFT)
3801P857-45 3801P857-45 BRACKET, HANDLE (RIGHT)
3801P798-51 3801P798-51 BRACKET, OVEN
WP3196068 WP3196068 CAMERA LENS-LIGHT
W10355051 W10355051 CLEANER, COOKTOP
8019P013-60 8019P013-60 CLIP, WIRE
WP8507P331-60 WP8507P331-60 CONTROL BOARD
WPW10218257 WPW10218257 CONTROL PANEL
W10258713 W10258713 COOKTOP
W10292854 W10292854 COOKTOP
4005F804-51 4005F804-51 COVER, REAR WIRE
W10243045 W10243045 COVER-BLCK
W10205618 W10205618 COVER-REAR
W10243046 W10243046 COVER-REAR
W10260573 W10260573 COVERREAR
W10792991 W10792991 DOOR DOOR LATCH
WP3608F126-71 WP3608F126-71 DOOR TRIM
WP3405F037-80 WP3405F037-80 DRAWR-UTIL
WPW10276482 WPW10276482 ELMNT-BAKE
WP7406P493-60 WP7406P493-60 ELMNT-BROL
3807F703-70 3807F703-70 END CAP, LEFT (BLACK)
3807F703-71 3807F703-71 END CAP, LEFT (WHITE)
3807F702-70 3807F702-70 END CAP, RIGHT (BLACK)
3807F702-71 3807F702-71 END CAP, RIGHT (WHITE)
WP7427P109-60 WP7427P109-60 FAN, CONVECTION
241430 241430 FOIL, ALUMINUM OVEN (18`` X 25 )
W11665456 W11665456 FOOT-LEVEL
3801F886-51 3801F886-51 FRAME, GLASS INNER
W11562931 W11562931 GASKT-DOOR
74003645 74003645 GLASS, INNER
W10160906 W10160906 GLASS-DOOR
W10160907 W10160907 GLASSDOOR
W10278579 W10278579 HARNS-WIRE
W10278577 W10278577 HARNS-WIRE
W10278576 W10278576 HARNS-WIRE
W10278578 W10278578 HARNS-WIRE
74010546 74010546 HINGE, DOOR
W10153013 W10153013 HNDLE-DOOR
W10153015 W10153015 HNDLE-DOOR
W10153016 W10153016 HNDLE-DOOR
WP7403P238-60 WP7403P238-60 INFINITE CONTROL SWITCH
W10185365 W10185365 INSTALLATION INSTRUCTIONS
WPW10208653 WPW10208653 INSULATION
W10243056 W10243056 INSULATION
W10182346 W10182346 INSULATION
WP7002P361-60 WP7002P361-60 INSULATION, BOTTOM
7002P246-60 7002P246-60 INSULATION, DOOR
WP7002P362-60 WP7002P362-60 INSULATION, WRAP
7003P145-60 7003P145-60 INSULATOR, CORD
WPW10160371 WPW10160371 KNOB
WPW10160368 WPW10160368 KNOB
WPW10160370 WPW10160370 KNOB
8009 8009 LIGHT BULB
WP2402W297-19 WP2402W297-19 LINING, DOOR
WP488130 WP488130 NUT
WP7103P027-60 WP7103P027-60 NUT
74005230 74005230 NUT, LOCK (8-32)
799344 799344 PAINT, BULK (1 QT.) (WHITE (UNCUT))
350930 350930 PAINT, PRESSURIZED SPRAY (12 OZ. WHITE)
350942 350942 PAINT, PRESSURIZED SPRAY (12 OZ.) (PRIMER, WHITE)
285006 285006 PAINT, PRESSURIZED SPRAY 12 OZ.) (SUPERIOR BLACK)
511873 511873 PAINT, TOUCH-UP (1/2OZ. WHITE PORCELAIN (2 OZ.))
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
3401F084-45 3401F084-45 PAN, BAKE BRNR
4005P704-51 4005P704-51 PANEL, ACCESS
WPW10163038 WPW10163038 PANEL, DRAWER (BLACK)
WP3605P337-51 WP3605P337-51 PANEL, INNER
WP2618F172-69 WP2618F172-69 PANEL, SIDE (BLACK)
WP2618F172-58 WP2618F172-58 PANEL, SIDE (WHITE)
W10163040 W10163040 PANEL-DRWR
W10218255 W10218255 PANL-CNTRL
W10218258 W10218258 PANL-CNTRL
3605P146-51 3605P146-51 PLATE, CONDUIT
3605F305-19 3605F305-19 PLATE, CONVECTION
W11520287 W11520287 RACK-OVEN
WP74010551 WP74010551 RECEIVER-
8212471 8212471 REFINISHING MATERIAL (TOUCH-UP SELF-CLEAN(1/2 PT))
3804F316-51 3804F316-51 RETAINER, INSULATION
WPW10272883 WPW10272883 ROLLER
WP3406P034-51 WP3406P034-51 RUNNER, DRAWER
WPY706189 WPY706189 SCREW
W11164114 W11164114 SCREW
W10491985 W10491985 SCREW
WP4159193 WP4159193 SCREW
W11347848 W11347848 SCREW
W11233072 W11233072 SCREW
WP3400882 WP3400882 SCREW
WP3196175 WP3196175 SCREW
74008798 74008798 SCREW W/SHOULDER (NO.8)
WPW10181986 WPW10181986 SENSOR
WP74005231 WP74005231 SHAFT, ROLLER
3604F371-51 3604F371-51 SHIELD, HEAT
3604F382-09 3604F382-09 SHIELD, HEAT VISOR (BLACK)
WP3604F382-81 WP3604F382-81 SHIELD, HEAT VISOR (WHITE)
WP3604F381-19 WP3604F381-19 SHIELD, VENT
W11594027 W11594027 SOCKT-LITE
W10169552 W10169552 SPACER
W10169553 W10169553 SPACER
74008690 74008690 SPACER, SIDE PANEL
74008761 74008761 SPACER, SNAP-IN
74007134 74007134 SPRING, ELEMENT SUPPORT
8038P037-60 8038P037-60 STOP, DRAWER
4820F014-59 4820F014-59 STRAP, INSULATION
3801P822-45 3801P822-45 SUPPORT, OV BTM
3807P680-45 3807P680-45 SUPPORT, OVEN
W10823720 W10823720 SURFACE ELEMENT
WPW10275049 WPW10275049 SURFACE ELEMENT
WP9762851 WP9762851 SURFACE ELEMENT
W11171119 W11171119 SURFACE ELEMENT
74008715 74008715 SWITCH, LIMITER THERMAL
WP74008718 WP74008718 SWITCH, ROCKER (BLACK)
74008717 74008717 SWITCH, ROCKER (WHT)
WP74010824 WP74010824 SWITCH- EL
9762761 9762761 TIPS, SAFE COOKING (ENGLISH)
W10065852 W10065852 TIPS, SAFE COOKING (FRENCH)
3608F092-70 3608F092-70 TRIM, DOOR BOTTOM (BLACK)
3608F126-70 3608F126-70 TRIM, DOOR SIDE (BLACK)
3608F139-70 3608F139-70 TRIM, DOOR TOP (BLACK)
3608F139-71 3608F139-71 TRIM, DOOR TOP (WHITE)
WP3608F092-71 WP3608F092-71 TRIM-BOTTM
W10168033 W10168033 USE & CARE GUIDE
8026P081-60 8026P081-60 VENT, OVEN
W10281612 W10281612 WIRING DIAGRAM
