Model Image
Manufacturer

Whirlpool

Model Number

KUIA18PNLS0

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
978030 978030 ACCESS VALVE (3/4``)
WP279368 WP279368 ADHESIVE
W11179302 W11179302 AFF ICE MA
WP2185592 WP2185592 ASSEMBLY, SWITCH (ALSO ORDER 4)
W10218024 W10218024 BALLAST-BACK, I.M.
2217205 2217205 BASE, UNIT
2208354 2208354 BIN, DOOR
W10340993 W10340993 BOX, CONTROL
WP2185532 WP2185532 BRACKET
2185585 2185585 BRACKET, CONNECTOR ASSEMBLY
2217466 2217466 BRACKET, DOOR (LEFT SIDE)
2217465 2217465 BRACKET, DOOR (RIGHT SIDE)
2208487 2208487 BRACKET, SPRING
676304 676304 BULB
100000 100000 CABINET & LINER (NOT SERVICED)
WP2185694 WP2185694 CAMERA LENS, LED
WP2185696 WP2185696 CAP, DRAIN FASTENER
2185691 2185691 CHANNEL, WIRING
W11456069 W11456069 CLAMP
W10861184 W10861184 CLAMP
2185825 2185825 CLAMP
WP488366 WP488366 CLAMP
WP489503 WP489503 CLAMP
2185960 2185960 CLAMP, POWER CORD
WP2208367 WP2208367 CLAMP-HALF
31462A 31462A CLEANER, STAINLESS STEEL (12 OZ)
2208535 2208535 CLIP
A201435 A201435 CLIP, MOUNTING
WP759112 WP759112 COIL, SOLENOID
W11735041 W11735041 COMPRESSOR
8201810 8201810 CONDENSER
WP2304016 WP2304016 CONTROL BOARD
2208365 2208365 COVER, GRID
2185677 2185677 COVER, PUMP
2217394 2217394 COVER, WIRING
WP2162358 WP2162358 COVER-TERM
WPW10136200 WPW10136200 COVER-UNIT
4387020 4387020 CUTTR-WIRE
2208530 2208530 DAMPENER, SPRING
W10843121 W10843121 DRIER-TUBE
W11413461 W11413461 ENDCAP, DOOR (BLACK)
2208383B 2208383B ENDCAP, PANEL (BLACK)
WPW10218037 WPW10218037 EVAPORATOR
2217269 2217269 EVAPORATOR
WP2190685 WP2190685 FAN, BLADE
WP2208539 WP2208539 FASTENER
2208361 2208361 GASKET, DOOR
2217296 2217296 GASKET, TOP PANEL
WP2313637 WP2313637 GRID-CUTTR
WP2217206B WP2217206B GRILLE
2185965 2185965 GROMMET (4)
2208596B 2208596B GROMMET, EDGE GUARD(2)
2208595B 2208595B GROMMET, EDGE GUARD(2)
2217310 2217310 GUDE-ICE, GRID
WP2217442S WP2217442S HANDLE
WP2208452B WP2208452B HANDLE
2185681 2185681 HARNESS, GRID
4388494 4388494 HARNS-LGHT
WP2187836 WP2187836 HARNS-PUMP
2208425 2208425 HINGE (LEFT SIDE)
2208426 2208426 HINGE (RIGHT SIDE)
2208449 2208449 HOLDER, SCOOP
WP2313890 WP2313890 HOSE
WP2185626 WP2185626 HOSE
4387491 4387491 INSERT, TUBE
2208384 2208384 INSULATION
2208377 2208377 INSULATION
8193716 8193716 LEVLER-LEG
LIT2217232 LIT2217232 LITERATURE PARTS (SERVICE & WIRING SHEET)
876370 876370 MISCELLANEOUS, INSULATION (2 PIECES, 3`` X 24`` X 48``)
W10822259 W10822259 MOTOR-COND
2217214B 2217214B NAMEPLATE (BLACK)
WP3400909 WP3400909 NUT
WP245183 WP245183 NUT
WP627018 WP627018 NUT, COMPRESSION 1/4``
488660 488660 NUT, SPEED
2208317W 2208317W OVERLAY
WP2217223 WP2217223 OVERLOAD
LIT2217251 LIT2217251 OWNERS MANUAL
2217225 2217225 PAD, FOAM
2217397 2217397 PAD, FOAM (2)
2185675 2185675 PAD-FOAM
8201617 8201617 PAN-WATER
WP2185625 WP2185625 PAN-WATER
2208352B 2208352B PANEL, EXTERIOR (BLACK)
2208353 2208353 PANEL, INTERIOR
2208594S 2208594S PANEL, LOWER
2313817 2313817 PANEL, WRAP
2208382B 2208382B PANEL, WRAP LOWER (BLACK)
2208417 2208417 PIN, HINGE
1901A 1901A PUMP
W11539855 W11539855 PUMP, DRAIN
WP2217220 WP2217220 PUMP, WATER (COMPLETE)
WP2217224 WP2217224 RELAY, START
W11420408 W11420408 SCOOP
WP8281196 WP8281196 SCREW
WP489128 WP489128 SCREW
489472 489472 SCREW
WP489069 WP489069 SCREW
W11693756 W11693756 SCREW
WP489474 WP489474 SCREW
WP90767 WP90767 SCREW
WP999367 WP999367 SCREW
WP250830 WP250830 SCREW
WP3400884 WP3400884 SCREW
WP8281186 WP8281186 SCREW
WP489464 WP489464 SCREW
WP489443 WP489443 SCREW
WP3370389 WP3370389 SCREW 10-32X15/16
WP489442 WP489442 SCREW 8-15 X 5/8
WP3400886 WP3400886 SCREW 8-18 X 1 1/4
8281184 8281184 SCREW 8-18 X 1/2
WP503695 WP503695 SEALER
WP505587 WP505587 SEALER MASTIC (1 QUART)
212643 212643 SEALER, PERMAGUM (4 - 12`` STRIPS)
2185690 2185690 SHIELD, ELECTRICAL
A201441 A201441 SHIM (4)
2208401 2208401 SHIM, HINGE
WP487627 WP487627 SLEEVE
8201791 8201791 SPACER
8201790 8201790 SPACER
836667 836667 SPACER
2185678 2185678 SPACER
WP486692 WP486692 SPEED NUT (1/4-20)
WP2208570 WP2208570 SPRING
2208427 2208427 SUPPORT, BRACKETEVAPORATOR GRID
2217378 2217378 SUPPORT, RESERVOIR BRACKET
WP2149705 WP2149705 SWITCH, LIGHT
WPW10683580 WPW10683580 THERMISTER, ICE CONTROL
WPW10503764 WPW10503764 THERMOSTAT
681534 681534 THUMBSCREW, 10-32 X 3/4
978026 978026 TOP PARTS NOT ILLUSTRATED AND OPTIONAL PARTS (NOT INCLUDED) (VALVE, ACCESS (5/16``))
2929703B 2929703B TOP-CABNET
WP2185657 WP2185657 TRANSFORMER
2208533 2208533 TUBE
W10863947 W10863947 TUBE
2185926 2185926 TUBE, AIR VENT
2313832 2313832 TUBE, DRAIN
2208459 2208459 TUBE, DRAIN
W10528572 W10528572 TUBE, PROCESS
2217322 2217322 TWIST LOC
W10801996 W10801996 VALVE
978027 978027 VALVE, ACCESS ((3/8``) TUBE)
978028 978028 VALVE, ACCESS (1/2``)
WP978025 WP978025 VALVE, ACCESS (1/4``)
978029 978029 VALVE, ACCESS (5/8)
W10724988 W10724988 VALVE, BODY
W10823511 W10823511 WATER TUBE
WP302819 WP302819 WHEEL LEG (2)
851095 851095 WIRE TIE
2185692 2185692 WIRING HARNESS GRID/ LIGHT
2187834 2187834 WIRING HARNESS, COMPLETE UNIT (INCLUDES POWER CORD)
2187835 2187835 WIRING HARNESS, CONDENSER FAN
